Grange ERP User manual

Grange Code: ERP
GRANGE FENCING LIMITED
Halesfield 21, Telford TF7 4PA
Tel:[phone] Fax:[phone]
Email:[email protected] Web:www.grangefen.co.uk
OUT OF HOURS MESSAGE SERVICE: 01952 588088
MARCH 2014 - ISSUE 1
1.2m
0.310m
0.4m
0.4m
ELITE RECTANGLE PLANTER (ERP)
PLAN
SIDE ELEVATIONS
TOP ELEVATION
ELITE
RECTANGLE
PLANTER
Elite Planter [ERP] label (A5) 6/3/14 11:36 Page 1

ASSEMBLY INSTRUCTIONS
ELITE RECTANGLE PLANTER
PARTS LIST
HARDWARE
Screws x 4
Short Side x 2
Long Side x 2
TOOLS REQUIRED:
RUBBER MALLET / SCREWDRIVER / SPANNER
Base Section x 1
C
B
A
y
Top Nut x 4
v
Long Bolt x 4
xBase Nut x 4
Washers x 8
w
z
B
C
A
Insert the Base
Section (C) into the
bottom of the
assembled planter
and secure in
position with the
four screws (z)
ASSEMBLY TIP:
The top edges of Side Sections (A) and (B)
are smooth while the
undersides have
nail holes visible.
B
B
C
C
A
A
x
z
z
v
w
y
w
v
w
y
x
w
With the interlocking corners
in position it may be advisable
to use a rubber mallet to
‘gently’ drive the long bolt (y)
through the aligned holes.
Use your Spanner to tighten
the top and bottom nuts (v
and x)
A B
