Grange ELITE SQUARE PLANTER - LARGE User manual

Grange Code: ESLP
GRANGE FENCING LIMITED
Halesfield 21, Telford TF7 4PA
Tel:[phone] Fax:[phone]
Email:[email protected] Web:www.grangefen.co.uk
OUT OF HOURS MESSAGE SERVICE: 01952 588088
MARCH 2014 - ISSUE 1
0.5m
0.352m
0.5m
0.5m SIDE ELEVATIONS
TOP ELEVATION
ELITE
SQUARE
PLANTER
[LARGE]
ELITE SQUARE PLANTER - LARGE (ESLP)
PLAN
Elite Planter [ESPL] label (A5) 7/3/14 11:06 Page 1

ASSEMBLY INSTRUCTIONS
ELITE SQUARE PLANTER [LARGE]
TOOLS REQUIRED:
RUBBER MALLET
SCREWDRIVER
SPANNER
B
A
PARTS LIST
HARDWARE
Screws x 4
Base Section x 1
Side Sections x 4
B
A
y
Top Nut x 4
v
Long Bolt x 4
xBase Nut x 4
Washers x 8
w
z
With the interlocking corners in
position it may be advisable to
use a rubber mallet to ‘gently’
drive the long bolts (y) through
the aligned holes.
Use your Spanner to tighten the
top and bottom nuts (v/x)
Insert the Base
Section (B) into
the bottom of the
assembled planter
and secure in
position with the
four screws (z)
ASSEMBLY TIP:
The top edges of
Side Sections (A)
are smooth while the
undersides have
nail holes visible.
A A
A A
B
B
z
z
v
w
w
x
y
v
w
y
w
x
A
