Grange Bow Top Arch User manual

BTA - 250cm [H] x 160cm [W] x 72cm [D]
BOW TOP ARCH
Self-Assembly required Home Delivery available
www.grangefen.co.uk
All products and related emblems featured
are trademarks of Grange Fencing Ltd.
©2016 Grange Fencing Ltd
All rights reserved.
In line with the Company’s policy of
continuous product development, the
right is reserved to change and improve
product design without prior notice.
CODE: BTA
160cm
45cm
72cm
90cm - 140cm
250cm
250cm
72cm
PLAN
BTA [A5 labels-Oct'16]] 16/1/18 11:32 Page 1

ASSEMBLY INSTRUCTIONS
BOW TOP ARCH PRESSURE TREATED GREEN
PARTS LIST
HARDWARE PACK
Side Panels x 2
Posts x 2
Roof Beams x 2
Roof Rafters x 5
Posts x 2
4x50 csk x10
[w]
4x40 csk x 8
[x]
3x16 x32
[y]
Metal Brackets x 8
[z]
Tools Required: Posidrive Screwdriver / Electric Drill
BEFORE YOU START
•Check the pack/s and make sure that you have all of the parts listed
above. If not, contact your retailer who will be able to help you.
•When you are ready to start, make sure you have the right
tools to hand, plenty of space and a clean, dry area for assembly.
It is advisable for two people to carry out the work
SITE PREPARATION
Excavate a 30cm square hole (approx)
for each post to a depth of at least
30cm. (see Fig.A right)
This will give your structure adequate
stability.
1. Begin with the roof assembly.
2. Mark off five points along the length of each of the curved
beams where the rafters will be fitted (see Fig.1). It is
recommended that the centre is marked first (1) and theother
points measured from it.
3. Fix the rafters to the curved
beams using screws (w)
from the topside of the
rafters into the curved beams.
4. Use the Trellis Sections (C)
to mark where the Metal
Brackets (z)need to be
fitted to the posts. The
metal brackets should be
positioned so that they fit
into the corners of the trellis.
The top brackets should
be 100mm below the
shoulder at the top of
the post (see Fig.2).
Fig A.
30cm
5. Fit the trellis to the
metal brackets
using screws (y).
NB.Check the posts
are the correct way
around so that they fit
inside the roof curved
beams (see Fig.3).
6. Fit the roof assembly onto the
posts of the side assemblies and
fix at the desired position with
screws (x).
Make sure the overhang at each
end is the same.
=
=
=
= = =
=
Fig 1.
Fig 3.
Fig 4.
Fig 2.
w
z
1
10cm
x
x
To ensure longevity of your
structureit is recommended
that it is treated with a wood
preservative on a yearly basis.
AFTERCARE
A B C
D
E
C
B
A
D
E
C
B
A
D
D
E
D
E
D
