GREAT PLAINS PL5700 User manual

Read the operator manual entirely. When you see
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
!
Table of Contents Index
Original Instructions 411-681Q
Great Plains
PRE-DELIVERY MANUAL
MODEL PL5700 3-Section Planter
PLANTER

© 2020 Great Plains | Printed in the United States of America
All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any
means, including photocopying, recording, or other electronic or mechanical methods, without the prior written
permission of the publisher, except in the case of brief quotations embodied in critical reviews and certain other
noncommercial uses permitted by copyright law.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator
Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land
Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-
Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and product names that appear and are owned by others are trademarks of their respective owners.
For permission requests, write to the publisher at the address below.
Great Plains Mfg.
1525 E. North St.
P.O. Box 5060
Salina, KS 67402
You can also visit our website at www.greatplainsag.com/en/manuals/905/product-manuals for a full catalog of this
and other manuals.
Ordering Information:
Quantity sales. Special discounts are available on quantity purchases by corporations, associations, and others. For
details, contact the publisher at the address above.
Orders for personal, non-commercial use. Please contact our service department by mail or our website
www.greatplainsag.com.

PL5700 Planter Cover Index
Great Plains | 411-681Q | 05/12/2020 iii
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description of Unit . . . . . . . . . . . . . . . . . . . . . . . . 1
Intended Use Statement . . . . . . . . . . . . . . . . . . . 1
Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . 1
Models Covered . . . . . . . . . . . . . . . . . . . . . . . 1
Document Family . . . . . . . . . . . . . . . . . . . . . . . . . 1
Directional Information . . . . . . . . . . . . . . . . . . . . . 1
Product Support . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information . . . . . . . . . . . . . . . . . . . . . . . 3
Before Getting Started . . . . . . . . . . . . . . . . . . . . . 3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Handling and Disposing of Chemicals . . . . . . 4
Operation Noise Hazard. . . . . . . . . . . . . . . . . 4
PTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Tire Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
High Pressure Fluids . . . . . . . . . . . . . . . . . . . 5
Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Chain. . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Lights and Devices . . . . . . . . . . . . . . . 5
Shutdown and Storage. . . . . . . . . . . . . . . . . . . . . 5
Proper Waste Disposal . . . . . . . . . . . . . . . . . . . . 5
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Tools Required. . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Before Beginning . . . . . . . . . . . . . . . . . . . . . . . . . 7
Unloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Hose Holder . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Shipping Zip Ties . . . . . . . . . . . . . . . . . . . . . . 8
Wheels and Tire Hubs . . . . . . . . . . . . . . . . . . . . . 8
Hitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Center Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Main Transport Tires . . . . . . . . . . . . . . . . . . . . . 10
Main Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Center and Main Frames . . . . . . . . . . . . . . . . . . 12
Left-Wing Gauge Wheel Mount . . . . . . . . . . . . . 13
Wheel Swing Arm Mount . . . . . . . . . . . . . . . . . . 13
Wing Gauge Tires . . . . . . . . . . . . . . . . . . . . . . . 14
Fertilizer Tank . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Hose Connections . . . . . . . . . . . . . . . . . . . . . . . 15
Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hydraulic Connections . . . . . . . . . . . . . . . . . 16
Wing Hydraulic Cylinders . . . . . . . . . . . . . . . 17
Cylinder Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Row Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Hose Holder . . . . . . . . . . . . . . . . . . . . . . . . . 18
Openers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Ground Speed Sensor . . . . . . . . . . . . . . . . . . . . 19
Air Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Valve Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Press Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Slow Moving Vehicle Reflector . . . . . . . . . . . . . . 20
AccuShot Precision Fertilizer System. . . . . . . . . 21
Ground Drive Liquid Fertilizer. . . . . . . . . . . . . . . 21
Close-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Hydraulic Hose Connections . . . . . . . . . . . . . . . 23
Fan Hydraulic Connections for Hoppers. . . . 23
Fan Hydraulic Hoses . . . . . . . . . . . . . . . . . . 23
Hydraulic Schematics. . . . . . . . . . . . . . . . . . . . . 25
Lift Hydraulics - 12 Row Planters . . . . . . . . . 25
Lift Hydraulics - 16 Row Planters . . . . . . . . . 26
Fold Hydraulics. . . . . . . . . . . . . . . . . . . . . . . 27
Marker Hydraulics. . . . . . . . . . . . . . . . . . . . . 27
Weight Transfer Hydraulics . . . . . . . . . . . . . 28
Fan Hydraulics . . . . . . . . . . . . . . . . . . . . . . . 29
Fan Hydraulics . . . . . . . . . . . . . . . . . . . . . . . 29
Plumbing Schematics. . . . . . . . . . . . . . . . . . . . . 30
Liquid Fertilizer . . . . . . . . . . . . . . . . . . . . . . . 30
Liquid Fertilizer . . . . . . . . . . . . . . . . . . . . . . . 31
Electrical Connections . . . . . . . . . . . . . . . . . . . . 33
Electrical Harness Schematics . . . . . . . . . . . 33
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Hitches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Hitching with 2-Point Hitch . . . . . . . . . . . . . . 33
Lift and Fold Hydraulics . . . . . . . . . . . . . . . . . . . 33
Planter Leveling . . . . . . . . . . . . . . . . . . . . . . . . . 34
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Chain Lubrication . . . . . . . . . . . . . . . . . . . . . 34
Chain Slack . . . . . . . . . . . . . . . . . . . . . . . . . 34
Chain Clips . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Torque Value Chart . . . . . . . . . . . . . . . . . . . . . . 37
Tire Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Tire Warranty Information. . . . . . . . . . . . . . . . . . 37

Cover Index

PL5700 Planter Table of Contents Index Introduction
Great Plains | 411-681Q | 05/12/2020 1
Introduction
Great Plains wants you to be satisfied with any new
planter delivered. To ease assembly and produce a
properly working machine, read this entire manual
before beginning assembly.
All information in this manual is current as of
publication. Information contained within is subject to
change to ensure top performance.
Illustrations in this manual were not done during an
actual assembly. For clarity, some illustrations may or
may not include parts, assemblies, and other
components at the same point in an actual assembly.
Description of Unit
The Great Plains PL5700 Planter is a pull-type
implement with optional mounted fertilizer capability.
The planter is front-fold for transport.
The PL5700 planter includes 5000 Series openers
with Air-Pro® meters. Optional unit-mounted coulters
are available for light to moderate no-till conditions.
The seed metering system is ground drive, hydraulic
drive, or electric drive.
Intended Use Statement
Use this planter to seed and fertilize production-agriculture
crops only. It is suitable for conventional till, min-till,
and moderate no-till conditions.
Using This Manual
This manual was written to help you assemble and
prepare the new PL5700 Planter for the customer. The
manual includes instructions for assembly and setup.
Read this manual and follow the recommendations for
safe, efficient, and proper assembly and setup.
An operator manual and parts manual are also
included with the new planter. Read and understand
Safety Information, Preparation and Setup, and
Operation sections in the operator manual before
assembling the planter. As a reference, it is a good
idea to keep the operator and part manuals on hand
during assembly.
Models Covered
PL5700 models with 12 rows and 16 rows on 30-inch
row spacing, and 12 rows and 16 rows on 70-cm row
spacing.
Document Family
Directional Information
All directional information in this manual, such as left,
right, front, rear, forward, or backward, is determined
by facing the direction of forward travel of the planter.
Product Support
If you do not understand any part of this manual, or
have other assembly or setup questions, assistance
is available. Contact our service department at:
Great Plains Manufacturing, Inc
Service Department
P. O. Box 5060
Salina, Kansas 67402-5060
Or call us at [phone] to speak with a service
representative by phone.
Additional copies of the pre-delivery, operator, and/or
parts manuals, are available by mail or online.
Please visit www.greatplainsag.com and follow the
product links for your PL5700 planter. If writing,
please include the serial number in all correspondence.
411-681M Operator Manual
411-681P Parts Manual
411-681B Material Rate Manual

Great Plains | 411-681Q | 05/12/2020 2
PL5700 Planter Table of Contents Index Introduction

PL5700 Planter Table of Contents Index Safety Information
Great Plains | 411-681Q | 05/12/2020 3
Safety Information
The safety symbol indicates a potential safety
hazard to persons operating or near the
machine and advises on how to avoid it.
The notice symbol indicates a potential for
machine or property damage from operator
error and advises on how to avoid misuse.
The information symbol indicates useful - but
not crucial - information for machine operation,
assembly, or adjustment.
Before Getting Started
1. Read the operator manual in its entirety before
attempting to start and operate the machine.
2. Only use operators that are thoroughly trained by
the owner or trained by someone with the
owner’s consent. The operator must be familiar
with all functions of the tractor and attachments,
and be able to handle emergencies quickly.
3. Maintain attention on operation at all times. Do
not operate if using a smart phone, tablet, or
similar electronic device, and never operate
machine while impaired by alcohol, medication,
any controlled substance, or while fatigued.
4. Do not ever allow passengers to ride the machine
at any time, for any reason.
5. Before operation, make sure that all tractor cab
levers are in their neutral positions and that the
parking brake is engaged.
6. Check brakes, link pins, and other mechanical
parts for wear before using machine.
7. Never wear loose or bulky clothing around
machine. Use additional safety equipment, such
as hard hats, eye and ear protection, safety
boots, etc., as needed.
8. Do not modify the machine. Unauthorized
modification can result in unsafe conditions that
lead to machine damage or personal injury.
Operation
1. Always stop the tractor, put in Park, set the parking
brake, and turn off engine before leaving the cab.
Dismounting from a moving tractor can cause
serious injury or death.
2. Consider turning radius of tractor and implement
in the field. Turning tractor too tight can cause
hitched implement to ride up on wheels which can
result in injury or equipment damage.
3. Pull machine only from the hitch at the end of the
tongue. Never pull from jack stand, safety chain,
or any point other than the hitch.
4. Never leave the tractor cab unattended while the
implement is running. Set parking brake, turn off
tractor, and remove key before exiting the tractor
cab.
5. Watch your surroundings at all times. Do not
operate with bystanders nearby, and avoid
contacting overhead obstructions.
6. Check that all guards and shields are
undamaged, installed, and secure before
operating implement.
7. Keep children out of the work area. Do not
operate or turn on machine while children are in
the area.
8. Do not operate near ditches, holes, steep slopes,
embankments, or other surfaces which may
collapse under the machine’s weight or tip the
machine over.
9. Never stand between tractor and implement
unless parking brake is applied. Use care as
being crushed between tractor and planter can
cause serious injury or death.
!
!
i

Great Plains | 411-681Q | 05/12/2020 4
PL5700 Planter Table of Contents Index Safety Information
Handling and Disposing of Chemicals
Agricultural chemicals can be dangerous. Improper
use can seriously injure persons, animals, plants, soil,
and property.
1. Read chemical manufacturer’s instructions
carefully, and then take appropriate precautions
before use.
2. Wear protective clothing.
3. Wash hands and face before eating after working
with chemicals. Shower as soon as application is
completed for the day.
4. Apply only with acceptable wind conditions. Make
sure wind drift of chemicals will not affect any
surrounding land, people, or animals.
5. Dispose of unused chemicals and chemical waste
as specified by the manufacturer. Observe all the
local ordinances and regulations in your area.
Operation Noise Hazard
1. Use proper ear protection like earmuffs or earplugs
while working.
PTO
1. Wait until all moving components have completely
stopped before adjusting, cleaning, or servicing
any PTO driven equipment.
2. Before installing or using PTO driven equipment,
read the tractor manual and review the safety
labels attached to the equipment.
3. When operating stationary PTO driven equipment,
always apply the parking brake and place chocks
behind wheels.
4. Stay clear of and never step over any rotating
parts.
Maintenance
1. Understand procedure before doing work. Use
proper tools and equipment.
2. Work in a clean, dry area.
3. Lower the implement. Put tractor in Park, set
parking brake, and turn off engine. To prevent
unauthorized starting, remove key before
performing maintenance or service work.
4. Make sure all moving parts have stopped and all
system pressure is relieved.
5. Relieve hydraulic pressure before disconnecting
hydraulic lines or performing any work on the
system.
6. Do not work underneath any hydraulically supported
components. Hydraulics can settle, leak, or be
accidentally lowered. If working underneath
hydraulically supported components is necessary,
secure implement with stands or suitable blocking
beforehand.
7. Disconnect electronic console and lighting
harness from the tractor before servicing or
adjusting electrical systems.
8. Before welding, disconnect electronic console,
and lighting harness from the tractor. Protect
hydraulic lines. Avoid fumes from heated paint.
9. Remove buildup of grease, oil, or debris.
10. Check and replace worn brake lines as needed.
11. Remove all tools and unused parts from
implement before operation.
Tire Safety
1. Check tires for cuts, bulges, and correct
pressure. Replace worn or damaged tires.
2. Tire changing can be hazardous and must be
performed by trained personnel using correct
tools and equipment.
3. Tire explosion and/or serious injury can result from
over inflation. Do not exceed tire inflation
pressures.
4. When removing and installing wheels, use wheel-
handling equipment adequate for weight involved.
5. Tighten wheel bolts only to the specified torque.

PL5700 Planter Table of Contents Index Safety Information
Great Plains | 411-681Q | 05/12/2020 5
High Pressure Fluids
1. Escaping fluid from holes in hydraulic lines is
difficult to spot. Do not use your hands or bare
skin to search for suspected leaks; instead, use a
piece of cardboard or wood. If injured by
escaping hydraulic fluid, see a medical
professional immediately. Exposure can result in
gangrene or severe allergic reaction.
2. Check that hydraulic fittings are tight and all
hydraulic hoses and lines are in good condition
before applying pressure to the system.
3. Wear protective gloves and safety glasses or
goggles when working with hydraulic systems.
Transporting
1. As with transporting any piece of heavy
machinery, comply with all local laws and
regulations before and during transport process.
2. Transport only at recommended transport speed
for implement. Some rough terrains require a
slower speed. Sudden braking can cause a
towed load to swerve and upset.
3. Know transport height and width of implement.
4. Do not tow an implement that, when fully loaded,
weighs more than 1.5 times the weight of towing
vehicle.
5. Keep clear of overhead power lines and other
obstructions when transporting.
6. Do not fold or unfold the implement while the
tractor is moving.
7. Reduce speed when turning, and make as wide a
turn as possible. Turning tractor too tight can
cause implement to tip over.
8. When towing on a trailer, secure implement with
tie downs and chains.
9. When towing on a trailer, sudden braking can
cause a trailer to swerve and upset. Reduce
speed if trailer is not equipped with brakes.
Safety Chain
1. Use a chain with a strength rating equal to or
greater than the gross weight of towed machinery.
2. Replace chain if any links or end fittings are
broken, stretched, or damaged.
3. Do not use safety chain for towing.
Safety Lights and Devices
1. Always use safety lighting. Slow-moving tractors
and towed machinery can create a hazard when
driven on public roads. They are difficult to see,
especially at night.
2. If equipped, use flashing warning lights and turn
signals whenever driving on public roads.
3. Use safety devices provided with implement.
4. Keep safety lights and signs clean and visible from
front and rear of machine.
5. Keep lights in operating condition.
Shutdown and Storage
1. Park the tractor and implement on a solid, level
surface where children normally do not play.
2. Lock up toolbars, fold wings, and engage transport
hook.
3. Put tractor in park, set the parking brake, turn off
engine, and remove switch key to prevent
unauthorized starting.
4. Wait for all components to come to a complete
stop before leaving the operator’s seat.
5. Detach the tractor. Secure the implement using
chocks.
Proper Waste Disposal
1. Dispose of waste properly to avoid threatening
the environment and ecology. Potential harmful
waste includes oil, fuel, filters, and batteries.
2. Use a leak-proof container for draining fluids. Do
not use a food or beverage container that may be
mistaken for a consumable product.
3. Do not drain or pour waste onto the ground,
down a drain, or into any water source.
4. Contact your local environmental or recycling center
for the proper way to recycle or dispose of waste.

Great Plains | 411-681Q | 05/12/2020 6
PL5700 Planter Table of Contents Index Safety Information

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 05/12/2020 7
Assembly
High Pressure Fluid Hazard
Escaping fluid under pressure can have sufficient
pressure to penetrate the skin. Check all hydraulic
lines and fittings before applying pressure. Use
paper or cardboard, not body parts, and wear heavy
gloves to check for suspected leaks. If injured, seek
immediate medical attention from a physician familiar
with this type of injury.
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
This section will provide step-by-step instructions for
assembling the PL5700 Planter. Read and understand
this manual before beginning work. Ensure you have all
the necessary tools and equipment before beginning.
Follow each set of instructions in order to make the
job as timely and safe as possible and to assemble a
properly working planter.
It is the dealer’s responsibility to unload the PL5700
planter. Unload all equipment before beginning
assembly. Do not attempt any work with the PL5700
on the truck.
Tools Required
Three forklifts.
General hand tools.
Jack stands or blocks and safety chains.
Hoist straps with proper load rating.
At least three people to assist.
Before Beginning
Read and understand “Safety Information” before
beginning to assemble the planter.
Have at least three people on hand while assembling.
Ensure the assembly location is level and free of
obstructions and debris. Great Plains recommends an
open, concrete area.
Have all major components and required tools. Test to
ensure they are properly working.
Have all loose components, fasteners, and pins
shipped with the PL5700 Planter.
Use a tractor of sufficient size and horsepower
with at least three remote hydraulic circuits. Refer
to Specifications in the operator manual for
tractor requirements.
Ensure safety decals and reflectors are located
correctly and legible. Replace if improperly located or
damaged. Refer to Safety Decals in operator manual.
Have a copy of the parts manual on hand. If unsure of
proper placement or use of any part or fastener, refer
to the parts manual.
Ensure all moving parts are moving freely, bolts are
tighten to torque, and cotter pins are spread.
Unloading
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
Tire Weight
Tires are extremely heavy. It may take more than one
or two people to safely move each tire. Use extreme
caution to prevent injury.
1. Remove all loose components from the truck. Set
aside.
2. Remove all tires. Some may be bolted to the
shipping rack and shipping plates. Loosen the
bolts, washers, and nuts to remove from rack and
shipping plates. Set aside shipping plates, bolts,
washers, and nuts.
Hose Holder
Machine Damage Risk
You must remove the hose holder and set aside
before removing any more parts from the rack or
machine damage will occur.
!
!
!
!
!
!

Great Plains | 411-681Q | 05/12/2020 8
PL5700 Planter Table of Contents Index Assembly
It is essential for the hose holder to be removed from
row unit number 4 on the rack before moving any
more parts. Row units are marked with a tag.
Row unit number 4 can be located in the general
area as indicated below. Verify the row unit with the
tag.
To remove hose holder:
1. Locate the hose holder (1) attached to row unit
number 4. It is located at the row unit mount and
near the u-bolt assembly securing the row unit to
the rack.
2. Loosen the nut and washer holding the hose
holder.
3. Remove the hose holder, nut, and washer. Set
aside.
Shipping Zip Ties
For shipping purposes hydraulic hoses, air hoses,
wires, and lines may have been tied back and bundled
with zip ties. Shipping zip ties have not been trimmed.
Zip ties that have been trimmed should remain intact to
help keep parts in place or bundled together while
operating the planter. Carefully clip shipping zip ties while
assembling planter.
Wheels and Tire Hubs
Weight and Crushing Hazards
Tires are extremely heavy and can crush body parts
between the tire and another surface. It may take
more than one or two people to move each tire, even
when aided by a hoist. Use extreme caution when
unloading or moving the tires. Thoroughly secure
tires in safe place after unloading to prevent a
falling or loose tire.
1. Remove wheel lugs from tire hub assembly.
2. Using at least two people, thread the studs on
the tire hub assembly to mount to the wheel.
3. Secure with the wheel lugs. Ensure the wheel
lugs secure the tire hub assembly on the same
side as the tire valve stem. Tighten to torque. See
“Torque Value Chart” on page 37.
4. Set assembled wheels aside for future use.
5. Repeat steps for all eight wheels.
Hitch
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
TP-71848
TP-71846
TP-71847
1
TP-71881
Trimmed
TP-71882
Untrimmed
!
!

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 05/12/2020 9
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
Hydraulic Hose Damage Risk
Use care when assembling parts near hydraulic
hoses. Pinching or crushing hydraulic lines can
cause hose damage and will leak hydraulic fluid.
1. Prepare to unload the hitch from the rack using a
hoist by placing a strap (1). Make sure the strap
is placed in a way that does not pinch, bend, or
damage any parts.
2. Remove the parking stands (2) from each side of
the hitch by removing the pin assembly on each
parking stand. Set aside.
The parking stands have been inverted for
shipping purposes and will need to be
positioned for operation.
3. Remove the hitch bolts, washers, and nuts (3)
securing the hitch to the rack. Set aside.
4. Using care, guide the hitch near the tongue. The
tongue/main frame is still secured on the
shipping rack.
5. With the hitch suspended at a comfortable
working height, and with enough clearance from
the ground, install both parking stands onto the
hitch. Do not place parking stands back into the
inverted shipping position.
6. Join hitch to tongue and secure with hitch bolts,
washers, and nuts at the top and bottom mounting
holes. Tighten to torque. See “Torque Value
Chart” on page 37.
!
!
TP-71853
1
3
3
2
2
i
TP-71855
TP-71856
TP-71857

Great Plains | 411-681Q | 05/12/2020 10
PL5700 Planter Table of Contents Index Assembly
Center Frame
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
1. Prepare to unload the center frame from the rack
using a hoist by placing two straps (2). Make
sure the straps are placed in a way that does not
pinch or damage any parts.
2. Loosen and remove the u-bolt assemblies (3) to
release the center frame from the rack.
3. Using a hoist, and at least two assistants to guide
and balance the center frame, move the center
frame into an area with enough clearance to
assemble to the planter.
4. Temporarily stabilize the suspended center frame
with jack stands, blocking, hoist, forklift, etc. to
prepare to install the main transport tires. The
center frame will remain in the hoist.
Main Transport Tires
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
None of the main transport tires have a speed
wheel mounted on the tire hub assembly.
1. With the center frame blocked or supported by
jack stands, move the tire into place on the wheel
mount (1) to be able to secure the wheel
assembly into the center hole (2) in the wheel
mount with a bolt and locking washer on each
side.
2. Secure the wheel assembly on each side with the
bolt and locking washer. Tighten to torque. See
“Torque Value Chart” on page 37.
3. Repeat for each of the four main transport tires
on the center frame.
!
!
TP-71846
3
3
2
2
!
!
i
TP-71849
1
TP-71850
2

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 05/12/2020 11
Main Frame
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
Hoist Chains and/or Lift Straps Placement
To prevent uneven load or flailing parts, ensure
hoist chains and/or lift straps are placed on the
main frame and not on either or both wings.
1. Prepare to unload the main frame from the rack
using a hoist by placing two straps (1). Do not
secure the strap to any section of either or both
wings. Make sure the straps are placed in a way
that does not pinch or damage any parts.
2. Loosen and remove the shipping plate, bolts,
washers, and nuts from the main frame and rack.
3. Loosen and remove the u-bolts, washers, and
nuts from the main frame located below the fan
on the rack.
4. Move the main frame off of the rack so that the
rear of the main frame is near the center frame.
!
!
!
TP-71858
TP-71862
TP-71860
Top
TP-71861
Below
TP-71863

Great Plains | 411-681Q | 05/12/2020 12
PL5700 Planter Table of Contents Index Assembly
Center and Main Frames
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
Planter Damage Risk
Use care when assembling parts near electrical
wiring, lines, and hydraulic hoses. Pinching or
crushing hydraulic lines can cause hose damage
and will leak hydraulic fluid. Pinching or crushing
hoses, wiring, or lines can cause damage.
1. Using a hoist, move the center frame to join at
the mount plate to the main frame.
2. Bring the center and main frames together until
the mount plates are flush with one another.
3. Secure the center and main frames with bolts,
washers, and nuts. There are ten mounting holes
around the mount plates. Tighten to torque. See
“Torque Value Chart” on page 37.
4. Install two 3/4-10 x 8 1/32 x 14 u-bolts with
washers and nuts on the rear of the mount on the
!
!
!
TP-71864
TP-71865
TP-71866

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 05/12/2020 13
center frame. Tighten to torque. See “Torque
Value Chart” on page 37.
Left-Wing Gauge Wheel Mount
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
For shipping purposes the outer left-wing gauge
wheel mount was moved and will need to be
repositioned in the proper location.
1. Loosen the u-bolts (1), washers (2), and nuts (2).
2. Slide the entire gauge wheel mount forward on
the wing towards the wing end stopping when
centered on shipping mark (3) on wing.
If the mark is not present, the mark is
measured 30.5 in (77.5 cm) from the end of
the wing.
3. Tighten the u-bolts, washers, and nuts once in
position. Tighten to torque. See “Torque Value
Chart” on page 37.
Wheel Swing Arm Mount
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
1. Remove wing gauge wheel swing arm mount
from rack using a hoist strap.
2. Align wheel swing arm mount into the gauge
wheel mount on the wing. Secure with pin roll, pin
(1), washer, and snap ring (2).
3. Repeat for all four wheel swing arm mounts.
TP-71867
!
!
TP-71868
2
1
3
i
!
!
TP-71869
TP-71870
2
1

Great Plains | 411-681Q | 05/12/2020 14
PL5700 Planter Table of Contents Index Assembly
Wing Gauge Tires
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
Two of the tire hub assemblies will have a
speed wheel (3) included on the hub. These
two speed wheels will be mounted on each
outer wing gauge wheel.
1. Move the tire into place on the wheel mount (4) to
be able to secure the wheel assembly into the
center hole (5) in the wheel mount with a bolt and
locking washer on each side.
2. Secure the wheel assembly on each side with the
bolt and locking washer. Tighten to torque. See
“Torque Value Chart” on page 37.
3. Repeat for each of the four wing gauge tires on
the wings.
Fertilizer Tank
Crushing and Pinching Hazards
A falling section or part can cause severe injury or
death by crushing. Always keep body and body
parts out from under any parts or components of the
planter. Ensure all equipment is properly rated for
the load before attempting to unload or move parts,
or assemble the planter. Ensure equipment operates
with smooth movements.
Secure Load
Obey all safety instructions from hoist and/or lifting
equipment manufacturer. Be sure hoist chains and
lift straps are properly rated for load and securely
attached to planter part before moving or unloading
parts.
1. Prepare to unload the fertilizer tank from the rack
using a hoist by placing a strap (1). Make sure
the strap is placed in a way that does not pinch,
bend, or damage any parts.
!
!
TP-71872
3
i
TP-71871
4
TP-71850
5
!
!
TP-71869

PL5700 Planter Table of Contents Index Assembly
Great Plains | 411-681Q | 05/12/2020 15
2. Remove the bolts, washers, and nuts securing
the fertilizer tank to the rack. Set aside.
3. Guide the fertilizer tank to the main frame and
secure with u-bolts, bolts, washers, and nuts on
the fertilizer tank mounting plates.
4. On the front fertilizer tank mount (1), secure the
fertilizer tank with spacer plate (2), u-bolts (3),
washers (4), and nuts (5). Do not pinch or crush
hoses, lines, or wires.
5. On the rear fertilizer tank mount (6), secure the
fertilizer tanks with bolts (7), washers (8), and
nuts (9). Do not pinch or crush hoses, lines, or
wires.
Hose Connections
This section will provide instructions for some, but not
all, of the hoses on the planter. If unsure of proper
placement or use of any part or fastener, refer to the
parts manual. For more information about the parts,
and their placement, for the AccuShot Precision
Fertilizer System refer to the accompanying
manufacturer’s manuals.
1. On the right-side of the center frame, flip the
hose (1) from the shipping position. Insert o-ring
and make connection later.
2. Underneath the fertilizer tank, at the valve, install
one o-ring in each hose ends and tightly secure
each of the two hoses with clamps.
For shipping, hoses may have been tied back
with zip ties. These shipping zip ties have
been left untrimmed and will need to removed
to be able to position hoses for use.
TP-71873
TP-71874
3
4
5
1
2
TP-71875
7
8
6
9
TP-71894
1
TP-71876
i

Great Plains | 411-681Q | 05/12/2020 16
PL5700 Planter Table of Contents Index Assembly
3. Near the fan assembly, secure the rear pump
mount bracket (2) with a u-bolt (3), washers, and
nuts.
4. Secure the front pump mount bracket (2) with a
bolt plate (4) with bolts, washers, and nuts.
5. Secure the AccuShot pump rear mount plate (5)
to the mount plate on the fan with a bolt, washer,
and nut.
6. On the pump assembly install one o-ring in each
hose ends and tightly secure each of the three
hoses with clamps.
Refer to the parts manual if unsure of proper
placement or use of any part or fastener.
Hydraulics
High Pressure Fluid Hazard
Escaping fluid under pressure can have sufficient
pressure to penetrate the skin. Check all hydraulic
lines and fittings before applying pressure. Use
paper or cardboard, not body parts, and wear heavy
gloves to check for suspected leaks. If injured, seek
immediate medical attention from a physician
familiar with this type of injury.
1. Release the hydraulic hoses, hoses, wires, and
lines that have been bundled together with zip
ties near the rear for shipping.
2. Starting from the left side, remove the hydraulic
caps (1) and connect the hydraulic hoses (2) to
each corresponding hydraulic cylinder port (3).
For ease, the hydraulic ports are marked with
colored zip ties and the hoses have been
temporarily marked with colored tape. Set aside
caps.
Hydraulic Connections
Hydraulic hose connection information is provided
from left-to-right for the hydraulic cylinders (4) on the
TP-71877
4
3
2
5
TP-71878
5
i
!
TP-71880
TP-71879
3
3
1
1
2
4
