GREAT PLAINS Yield-Pro Air-Pro YP2425A User manual

Table of Contents Index
Read the operator manual entirely. When you
see this symbol, the subsequent instructions
and warnings are serious - follow without
exception. Your life and the lives of others
depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
!
Original Instructions 411-976m
6.13
IntelliAg ISO6 Version
Great Plains
OPERATOR MANUAL
MODELS 2430, 2470, 3620, 4715, and 4825
YP2425A

Machine Identification
Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new
manual.
If you or the dealer have added options not originally ordered with the machine, or removed options that were
originally ordered, the weights and measurements are no longer accurate for your machine. Update the record by
adding the machine weight and measurements with the option(s) weight and measurements.
Dealer Contact Information
Model Number
Serial Number
Machine Height
Machine Length
Machine Width
Machine Weight
Year of Construction
Delivery Date
First Operation
Accessories
Name:
Street:
City/State:
Telephone:
Email:
Dealer’s Customer
No.:
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov

To our customer:
Congratulations on the purchase of your Great Plains product. Great Plains welcomes you to its
growing family of new product owners. Your product has been designed and built by skilled
workers using quality materials.
Your dealer has performed the necessary pre-delivery service to your machine, and will advise
you of the proper maintenance and operating practices that will give you long, satisfactory use of
your machine. Do not hesitate to contact your dealer when you have a question related to your
machine.
Your machine has been designed to run efficiently in most operating conditions, and will perform
relative to the service it receives. If you need customer service or repair parts, contact your dealer
who has trained personnel, repair parts, and equipment specially designed for Great Plains
products.
Read this manual carefully before using the machine. It will familiarize you with safety, operation,
adjustments, and maintenance of your new equipment. This manual must always be kept with
your machine.
Great Plains wants you to be satisfied with your product. If for any reason you do not understand
any part of this manual or are otherwise dissatisfied, please take the following actions first:
1. Discuss the matter with your dealership service manager. Make sure he is aware of
any problems so he can assist you.
2. If you are still unsatisfied, seek out the owner or general manager of the dealership.
If your dealer is unable to resolve the problem or the issue is parts related, please contact:
Great Plains Service Department
1525 E. North St.
P.O. Box 5060
Salina, KS, USA 67402-5060
Printed 07/21/2021 | English
Great Plains reserves the right to revise and improve its products at any time. This publication describes the state of this product at the
time of its publication, and may not reflect the product in the future. The content of this publication may be changed without notice.

© 2021 Great Plains | Printed in the United States of America
All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any
means, including photocopying, recording, or other electronic or mechanical methods, without the prior written
permission of the publisher, except in the case of brief quotations embodied in critical reviews and certain other
noncommercial uses permitted by copyright law.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator
Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains,
Land Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max,
Turbo-Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and product names that appear and are owned by others are trademarks of their respective owners.
For permission requests, write to the publisher at the address below.
Great Plains Mfg.
1525 E. North St.
P.O. Box 5060
Salina, KS 67402
You can also visit our website at www.greatplainsag.com/en/manuals/905/product-manuals for a full catalog of this
and other manuals.
Ordering Information:
Quantity sales. Special discounts are available on quantity purchases by corporations, associations, and others. For
details, contact the publisher at the address above.
Orders for personal, non-commercial use. Please contact our service department by mail or our website
www.greatplainsag.com.

YP2425A Cover Index
Great Plains | 411-976m | 07/21/2021 v
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description of Unit . . . . . . . . . . . . . . . . . . . . . . . . 1
Intended Usage . . . . . . . . . . . . . . . . . . . . . . . 1
Models Covered . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Document Family . . . . . . . . . . . . . . . . . . . . . . 1
Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . 1
Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Owner Assistance . . . . . . . . . . . . . . . . . . . . . . . . 2
Further Assistance . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Information . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Symbols and Signal Words. . . . . . . . . . . . 3
Observe Safety and Informational Symbols. . 3
Be Aware of Signal Words . . . . . . . . . . . . . . . 3
Before Getting Started . . . . . . . . . . . . . . . . . . . . . 3
Read Machine Information . . . . . . . . . . . . . . . 3
Wear Appropriate Clothing and Equipment . . 3
Inspect Machine Before Use . . . . . . . . . . . . . 3
Machine Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operate Responsibly . . . . . . . . . . . . . . . . . . . 4
Handle Hydraulics with Care . . . . . . . . . . . . . 4
Avoid Potential Collision Damage . . . . . . . . . 4
Chemicals and Waste . . . . . . . . . . . . . . . . . . . . . 4
Dispose of Waste Properly. . . . . . . . . . . . . . . 4
Machine Maintenance . . . . . . . . . . . . . . . . . . . . . 5
Follow Tire Recommendations. . . . . . . . . . . . 5
Prepare for Performing Maintenance . . . . . . . 5
PTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Machine Transport . . . . . . . . . . . . . . . . . . . . . . . . 5
Use Safety Lights and Devices . . . . . . . . . . . . . . 5
Shutdown and Storage. . . . . . . . . . . . . . . . . . . . . 5
Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Machine Decals . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Slow Moving Vehicle Reflector. . . . . . . . . . . . 6
Red Reflectors . . . . . . . . . . . . . . . . . . . . . . . . 6
Daytime Reflectors. . . . . . . . . . . . . . . . . . . . . 6
Amber Reflectors . . . . . . . . . . . . . . . . . . . . . . 7
Danger: Crushing Hazard. . . . . . . . . . . . . . . . 7
Danger: Read Manual . . . . . . . . . . . . . . . . . . 7
Danger: Electrocution Hazard . . . . . . . . . . . . 7
Danger: Rotating Driveline . . . . . . . . . . . . . . . 8
Warning: Speed . . . . . . . . . . . . . . . . . . . . . . . 8
Warning: High Pressure Fluid Hazard . . . . . . 8
Warning: Markers: Pinch/Crush . . . . . . . . . . . 8
Warning: Hot Fluid . . . . . . . . . . . . . . . . . . . . . 9
Caution: 1000 rpm PTO . . . . . . . . . . . . . . . . . 9
Caution: Read Operator Manual . . . . . . . . . . 9
Caution: Transport Locks . . . . . . . . . . . . . . . . 9
Caution: Tires Not A Step. . . . . . . . . . . . . . . 10
Caution: Pressure and Torque . . . . . . . . . . . 10
Caution: Pressure and Torque . . . . . . . . . . . 10
Warning: Pinch/Crush. . . . . . . . . . . . . . . . . . 10
Preparation and Setup . . . . . . . . . . . . . . . . . . . 11
Post-Delivery/Seasonal Setup . . . . . . . . . . . . . . 11
Pre-Planting Setup . . . . . . . . . . . . . . . . . . . . . . . 11
Hitching Tractor to Planter . . . . . . . . . . . . . . . . . 11
Hydraulic Hose Hookup . . . . . . . . . . . . . . . . 11
If Weight Transfer is Installed . . . . . . . . . . . . 11
Color Coded Hydraulic Hoses . . . . . . . . . . . 12
Current Style Color Coded Hose Handles . . 12
Older Style Hoses with Color Ties . . . . . . . . 12
Protecting Fan Hydraulic Motor Seals . . . . . 12
Electrical Hookup . . . . . . . . . . . . . . . . . . . . . 13
Hitching with 3-Point. . . . . . . . . . . . . . . . . . . 13
Hitching with Hydraulic Tongue (Option) . . . 14
Local Float on Hydraulic Tongue . . . . . . . . . 14
Store Main Parking Stand. . . . . . . . . . . . . . . 14
Raising/Lowering Tongue. . . . . . . . . . . . . . . 15
Tank Cart Hitching . . . . . . . . . . . . . . . . . . . . . . . 15
Heights and Leveling . . . . . . . . . . . . . . . . . . . . . 16
Set Tongue Height . . . . . . . . . . . . . . . . . . . . 16
Checking Planter Leveling Side to Side . . . . 16
Center Section Level Check . . . . . . . . . . . . . 17
Wing Leveling. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Wing Leveling, Inboard End . . . . . . . . . . . . . 17
Wing Leveling, Outboard End. . . . . . . . . . . . 17
Lock Up Fertilizer Drive . . . . . . . . . . . . . . . . . . . 18
YP2425A serial number B1029G+ . . . . . . . . 18
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Pre-Start Checklist . . . . . . . . . . . . . . . . . . . . . . . 19
Fold/Unfold Lock Overview. . . . . . . . . . . . . . . . . 19
Raising/Lowering Machine . . . . . . . . . . . . . . . . . 20
Raising . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Lowering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Unfolding Machine . . . . . . . . . . . . . . . . . . . . . . . 20
Folding Machine . . . . . . . . . . . . . . . . . . . . . . . . . 21
Transporting the Planter. . . . . . . . . . . . . . . . . . . 22
Transport Checklist. . . . . . . . . . . . . . . . . . . . 23
Loading Materials . . . . . . . . . . . . . . . . . . . . . . . . 23
82 Bushel Hopper Operation . . . . . . . . . . . . 23
Adding Seed to 82 bu. Hopper . . . . . . . . . . . 23
Changing the Seed Box or 82 bu. Hopper . . 24
Auxiliary Hydraulics . . . . . . . . . . . . . . . . . . . . . . 26
Connecting Auxiliary Hydraulics . . . . . . . . . . 26
Marker Operation . . . . . . . . . . . . . . . . . . . . . . . . 27

YP2425A Cover Index
Great Plains | 411-976m | 07/21/2021 vi
Row Marker Operation . . . . . . . . . . . . . . . . . 27
Unfolding and Folding Markers . . . . . . . . . . 27
Air System Operation . . . . . . . . . . . . . . . . . . . . . 28
Air System Overview . . . . . . . . . . . . . . . . . . 29
Fan Circuit Operation . . . . . . . . . . . . . . . . . . 29
Fan General Operating Information . . . . . . . 30
Y-Tubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Weight Transfer Operation (Option). . . . . . . . . . 31
Fertilizer Systems Overview. . . . . . . . . . . . . . . . 32
SML Cart Pump System Diagram . . . . . . . . 33
Trailer Operations . . . . . . . . . . . . . . . . . . . . . . . 35
AccuShot System (Option). . . . . . . . . . . . . . . . . 35
Field Set-Up Checklist . . . . . . . . . . . . . . . . . . . . 36
Field Operation. . . . . . . . . . . . . . . . . . . . . . . . . . 37
Short-Term Parking . . . . . . . . . . . . . . . . . . . . . . 38
3 Point Hitch Parking . . . . . . . . . . . . . . . . . . 38
Hydraulic Tongue Hitch Parking. . . . . . . . . . 38
Either Hitch Parking . . . . . . . . . . . . . . . . . . . 39
Long-Term Storage . . . . . . . . . . . . . . . . . . . . . . 39
Storage: Fertilizer Option . . . . . . . . . . . . . . . 40
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Planting Rate for Hydraulic Drive . . . . . . . . . . . . 42
Planting Rate with IRC . . . . . . . . . . . . . . . . . . . . 42
Hydraulic Pump Fertilizer Rate. . . . . . . . . . . 42
Ground Drive Pump Fertilizer Rate . . . . . . . 42
Gauge/Transport Wheel Adjustments . . . . . . . . 42
Marker Adjustments . . . . . . . . . . . . . . . . . . . . . . 43
Marker Disk Adjustment . . . . . . . . . . . . . . . . 43
Marker Extension . . . . . . . . . . . . . . . . . . . . . 43
Marker Gauge Wheel Adjustment . . . . . . . . 44
Marker Chain Length Adjustment. . . . . . . . . 44
Height Switch Adjustment . . . . . . . . . . . . . . . . . 45
(S/N B1030G+). . . . . . . . . . . . . . . . . . . . . . . 45
Height Switch Adjustment . . . . . . . . . . . . . . . . . 45
(S/N B1029G-) . . . . . . . . . . . . . . . . . . . . . . . 45
Fan / Meter Pressurization Adjustment . . . . . . . 46
Fans on PTO . . . . . . . . . . . . . . . . . . . . . . . . 46
Fans on Hydraulic Remotes. . . . . . . . . . . . . 46
Fine-Tuning Meter Pressurization . . . . . . . . 47
Seed Delivery Fan Adjustments. . . . . . . . . . 48
Frame-Mounted Row Accessories . . . . . . . . . . . 48
Terra-Tine™ Adjustments . . . . . . . . . . . . . . 48
Frame-Mounted Coulter Adjustments . . . . . 49
Vantage I Fertilizer Adjustments . . . . . . . . . 50
25 Series Row Unit Adjustments . . . . . . . . . . . . 50
Row Unit Down Pressure . . . . . . . . . . . . . . . 51
Coulter Adjustments. . . . . . . . . . . . . . . . . . . 54
Row-Unit Opener Disk Adjustments. . . . . . . 55
Side Gauge Wheel Adjustment . . . . . . . . . . 56
Seed Meter Setup and Adjustment. . . . . . . . 58
Air-Pro® Meter Disk Installation . . . . . . . . . . 61
Removing a Seed Disk . . . . . . . . . . . . . . . . . 62
Row Unit Shut-Off. . . . . . . . . . . . . . . . . . . . . 62
Seed Firmer Adjustments . . . . . . . . . . . . . . . 64
Seed-Lok® Seed Firmer Lock-Up. . . . . . . . . 65
Seed-Lok® Seed Firmer Lock-Up (older style) . .
65
Press Wheel Adjustment . . . . . . . . . . . . . . . 66
Press Wheel Down Pressure . . . . . . . . . . . . 66
Press Wheel Stagger . . . . . . . . . . . . . . . . . . 66
Press Wheel Centering. . . . . . . . . . . . . . . . . 67
Maintenance and Lubrication . . . . . . . . . . . . . 68
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Material Clean-Out . . . . . . . . . . . . . . . . . . . . . . . 68
Air Box Clean-Out. . . . . . . . . . . . . . . . . . . . . 68
Air System Clean-Out. . . . . . . . . . . . . . . . . . 69
Meter Clean-Out. . . . . . . . . . . . . . . . . . . . . . 70
Seed Tube Clean-Out. . . . . . . . . . . . . . . . . . 71
Meter Brush Maintenance . . . . . . . . . . . . . . . . . 71
Meter Brush Replacement . . . . . . . . . . . . . . . . . 72
Tufted Brush Replacement. . . . . . . . . . . . . . 72
Strip Brush Replacement . . . . . . . . . . . . . . . 72
Seed Drop Brush Replacement . . . . . . . . . . 73
Seed Disk Maintenance . . . . . . . . . . . . . . . . . . . 73
Air Box Residue Clean-Out . . . . . . . . . . . . . . . . 74
Hydraulic Maintenance. . . . . . . . . . . . . . . . . . . . 75
Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Hydraulic Drive Maintenance . . . . . . . . . . . . 75
To change the element: . . . . . . . . . . . . . . . . 75
Marker Maintenance. . . . . . . . . . . . . . . . . . . . . . 76
Marker Shear Bolt Replacement . . . . . . . . . 76
Marker Grease Seal Cap . . . . . . . . . . . . . . . 76
Wing Alignment . . . . . . . . . . . . . . . . . . . . . . . . . 77
Chain Maintenance . . . . . . . . . . . . . . . . . . . . . . 77
Chain Slack . . . . . . . . . . . . . . . . . . . . . . . . . 78
Chain Clips . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Meter Drive Chain . . . . . . . . . . . . . . . . . . . . . . . 78
Disc Spreaders and Scrapers. . . . . . . . . . . . . . . 79
25 Series Row-Unit Side Wheels . . . . . . . . . 79
Fertilizer System Maintenance . . . . . . . . . . . . . . 80
Liquid Fertilizer Strainer . . . . . . . . . . . . . . . . 80
In Season Filter Cleaning . . . . . . . . . . . . . . . 80
End of Season Filter Cleaning . . . . . . . . . . . 80
Seed Flap Replacement (S/N B1002E+) . . . . . . 81
Seed Flap Replacement (S/N B1001E-). . . . . . . 81
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Wing Casters: Parallel Arms. . . . . . . . . . . . . 82
Wing Casters: Lift Cylinder Ends . . . . . . . . . 82

YP2425A Cover Index
Great Plains | 411-976m | 07/21/2021 vii
Wing Casters: Pointing Cylinders. . . . . . . . . 82
Marker Joints . . . . . . . . . . . . . . . . . . . . . . . . 83
Wing Frames . . . . . . . . . . . . . . . . . . . . . . . . 83
Rockshaft to Frame . . . . . . . . . . . . . . . . . . . 83
Rockshaft to Link Arm . . . . . . . . . . . . . . . . . 83
Lift Cylinders: Rod End . . . . . . . . . . . . . . . . 84
Center Links: Aft End . . . . . . . . . . . . . . . . . . 84
Caster Pivots . . . . . . . . . . . . . . . . . . . . . . . . 84
25 Series Side Wheel Bushing. . . . . . . . . . . 84
Ground Drive Fertilizer Pump (option) . . . . . 85
Hydraulic Drive Chains. . . . . . . . . . . . . . . . . 85
Meter Drive Chains. . . . . . . . . . . . . . . . . . . . 86
Frame-Mounted Coulter (optional) Hub . . . . 86
Frame-Mounted Coulter (option) Pivot. . . . . 86
Wing Casters: Pivot . . . . . . . . . . . . . . . . . . . 86
Hitch Parallel Arms. . . . . . . . . . . . . . . . . . . . 87
Tongue Latch . . . . . . . . . . . . . . . . . . . . . . . . 87
Tongue Slide Roller . . . . . . . . . . . . . . . . . . . 87
Wing Transfer Drive Shafts . . . . . . . . . . . . . 87
Wing Fold Cylinders: Rod End . . . . . . . . . . . 88
Row Cleaner Bearings . . . . . . . . . . . . . . . . . 88
Wing Casters: Wheel Hubs . . . . . . . . . . . . . 88
Markers: Disk Hub . . . . . . . . . . . . . . . . . . . . 88
Transport Wheels: Wheel Hubs . . . . . . . . . . 89
Gauge Wheel Bearings . . . . . . . . . . . . . . . . 89
Seed Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 90
Ezee Glide Plus Talc+Graphite Mix . . . . . . . 90
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
82 Bushel Seed Hoppers . . . . . . . . . . . . . . . . . . 91
Seed Lubricant . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Hydraulic Tongue . . . . . . . . . . . . . . . . . . . . . . . . 91
Weight Transfer System. . . . . . . . . . . . . . . . . . . 92
PTO Pump Kits . . . . . . . . . . . . . . . . . . . . . . . . . 92
Low Speed Kit . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Trailer Hitch Weldment. . . . . . . . . . . . . . . . . . . . 93
Fertilizer Carts . . . . . . . . . . . . . . . . . . . . . . . 93
Hydraulic Drive Fertilizer Pump . . . . . . . . . . 94
Ground Drive Fertilizer Pump. . . . . . . . . . . . 94
Fertilizer Manifolds . . . . . . . . . . . . . . . . . . . . 94
VeriFlow Nozzles . . . . . . . . . . . . . . . . . . . . . 95
High-Rate Dribblers . . . . . . . . . . . . . . . . . . . 96
Frame-Mounted Row Options . . . . . . . . . . . . . . 96
Terra-Tines. . . . . . . . . . . . . . . . . . . . . . . . . . 96
Frame-Mounted (Zone) Coulters . . . . . . . . . 97
Smart Box Mounting Kit . . . . . . . . . . . . . . . . . . . 97
Unit-Mounted Row Options . . . . . . . . . . . . . . . . 98
Row-Pro™ . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Swath Command™ . . . . . . . . . . . . . . . . . . . 98
Unit-Mounted Disk Coulters . . . . . . . . . . . . . 99
Coulter Blades . . . . . . . . . . . . . . . . . . . . . . . 99
Row Cleaners . . . . . . . . . . . . . . . . . . . . . . . 100
Gauge Wheel Scrapers . . . . . . . . . . . . . . . 100
Seed Meter Disks . . . . . . . . . . . . . . . . . . . . 101
Clean-Out Container. . . . . . . . . . . . . . . . . . 101
Seed Tube Brush . . . . . . . . . . . . . . . . . . . . 101
Seed Firmers . . . . . . . . . . . . . . . . . . . . . . . 102
Row Unit Press Wheels . . . . . . . . . . . . . . . 102
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 103
Planting Rate Problems . . . . . . . . . . . . . . . . . . 103
Seed Pool Troubleshooting . . . . . . . . . . . . . . . 104
Seed Pool Recovery. . . . . . . . . . . . . . . . . . 105
Population Troubleshooting Charts . . . . . . . . . 106
Appendix A - Reference Information . . . . . . 113
Specifications and Capacities . . . . . . . . . . . . . 113
Specifications/Capacities, North America. . 113
Specifications/Capacities, Metric Model . . . 114
Tire Inflation Chart . . . . . . . . . . . . . . . . . . . . . . 114
Hydraulic Diagrams . . . . . . . . . . . . . . . . . . . . . 115
Auxiliary Hydraulics (standard). . . . . . . . . . 115
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Hydraulic Drive . . . . . . . . . . . . . . . . . . . . . . 117
Hydraulic Tongue (Optional). . . . . . . . . . . . 118
Lift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Markers. . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Wing Fold, Markers and Auxiliary. . . . . . . . 121
Chain Routing. . . . . . . . . . . . . . . . . . . . . . . . . . 122
25AP Final Meter Drive . . . . . . . . . . . . . . . 122
Hydraulic Drive Chain Routing . . . . . . . . . . 123
Fertilizer Pump Ground Drive Chain Routing . . .
124
Seed Hose Routing . . . . . . . . . . . . . . . . . . . . . 125
YP2425A Machine Left Side
Seed Hose Routing . . . . . . . . . . . . . . . . . . 126
YP2425A Machine Right Side
Seed Hose Routing . . . . . . . . . . . . . . . . . . 127
Torque Values Chart . . . . . . . . . . . . . . . . . . . . 128
Radar Calibration . . . . . . . . . . . . . . . . . . . . . . . 129
Weight Transfer Shipping Links . . . . . . . . . 129
122-278S Scraper Installation . . . . . . . . . . . . . 130
402-520A Low Speed Kit Installation . . . . . . . . 131
Preparation and Setup . . . . . . . . . . . . . . . . . . . 132
Row-Pro™ Setup (Option) . . . . . . . . . . . . . 132
Operating Instructions . . . . . . . . . . . . . . . . . . . 132
Row-Pro™ Components. . . . . . . . . . . . . . . . . . 133
Load Cell, DPLCM and Valves . . . . . . . . . . 133
Row-Pro™ Air Compressor System . . . . . . 134
Row-Pro™ Air Tank . . . . . . . . . . . . . . . . . . 134

YP2425A Cover Index
Great Plains | 411-976m | 07/21/2021 viii
Row-Pro™ Air Tank Lines . . . . . . . . . . . . . 135
Row-Pro™ Air Pressure Gauge . . . . . . . . . 135
Check for Air Leaks . . . . . . . . . . . . . . . . . . 135
Row-Pro™ Troubleshooting. . . . . . . . . . . . . . . 136
Row-Pro™ Maintenance . . . . . . . . . . . . . . . . . 136
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

YP2425A Table of Contents Index Introduction
Great Plains | 411-976m | 07/21/2021 1
Introduction
Great Plains welcomes you to its growing family of
new product owners. The 60 Foot Yield-Pro® Planter
with Air-Pro® Meters (YP2425A) has been designed
with care and built by skilled workers using quality
materials. Proper setup, maintenance, and safe
operating practices will help you get years of
satisfactory use from the machine.
Description of Unit
The YP2425A Planter is a pull-type implement for
use in conventional till, minimum-till, or light no-till
conditions. The YP2425A Planter accepts optional
unit mounted and frame-mounted row accessories.
Coulters make it suitable for light to moderate no-till
conditions only. The YP2425A Planter is outfitted
with 25 Series, side-depth-control row-units and
Air-Pro® seed meters. The YP2425A Planter folds
for transport.
Intended Usage
Use the YP2425A Planter to seed
production-agriculture crops only. Do not modify the
planter for use with attachments other than Great
Plains options and accessories specified for use with
the YP2425A Planter.
Models Covered
Document Family
Using This Manual
This manual will familiarize you with safety,
assembly, operation, adjustments, troubleshooting,
and maintenance. Read this manual and follow the
recommendations to help ensure safe and efficient
operation.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this
manual.
Right-hand and left-hand as used in
this manual are determined by
facing the direction the machine will
travel while in use unless otherwise
stated. An orientation rose in some
line art illustrations shows the
directions of: Up, Back, Left, Down,
Front, Right.
Notice Symbol
A crucial point of information related to the
current topic. Read and follow the directions
to remain safe, avoid serious damage to
equipment and ensure desired field results.
Useful information related to the preceding
topic.
YP2425A-2430 24 Row, 30 Inch Spacing
YP2425A-2470 24 Row, 70 cm Spacing
YP2425A-3620 36 Row, 20 Inch Spacing
YP2425A-4715 47 Row, 15 Inch Spacing
YP2425A-48TR 48 Row (24 Twin), 30 Inch Spacing
YP2425AIR-4715 47 Row, 15 Inch Spacing
U
D
F
B
L
R
L
R
411-976m Owner’s Manual (this document)
401-626b Seed Rate Charts
401-626P Parts Manual
411-015M PTO Operate/Install manual
DICKEY-john® IntelliAg® Manuals:
11001-1662 Planter/Drill Control, User Level 1
11001-1501A Planter/Drill Control, User Level 2&3
110011518 YP2425A-48TR Quick-Start Guide
110011519 YP2425A-4715 Quick-Start Guide
110011520 YP2425A-2430 Quick-Start Guide
110011521 YP2425A-3620 Quick-Start Guide
110011522 YP2425A-2470 QSG
U
D
F
B
L
R
!
i

Great Plains | 411-976m | 07/21/2021 2
YP2425A Table of Contents Index Introduction
Owner Assistance
If you need customer service or repair parts, contact
a Great Plains dealer. They have trained personnel,
repair parts and equipment specially designed for
Great Plains products.
Refer to Figure 1
Your machine’s parts were specially designed and
should only be replaced with Great Plains parts.
Always use the serial and model number when
ordering parts from your Great Plains dealer. The
serial-number plate is located on the left end of the
seed cart tool bar, as shown.
Record your YP2425A Planter model and serial
number here for quick reference:
Model Number:__________________________
Serial Number: __________________________
Further Assistance
Great Plains Manufacturing, Inc. and your Great
Plains dealer want you to be satisfied with your new
planter. If for any reason you do not understand any
part of this manual or are otherwise dissatisfied,
please take the following actions first:
1. Discuss the matter with your dealership service
manager. Make sure they are aware of any
problems so they can assist you.
1. If you are still unsatisfied, seek out the owner or
general manager of the dealership.
If your dealer is unable to resolve the problem or the
issue is parts related, please contact:
Great Plains Service Department
1525 E. North St.
P.O. Box 5060
Salina, KS 67402-5060
Or go to www.greatplainsag.com and follow the
contact information at the bottom of your screen for
our service department.
Figure 1
Serial Number Plate
26032

YP2425A Table of Contents Index Safety Information
Great Plains | 411-976m | 07/21/2021 3
Safety Information
Safety Symbols and Signal Words
Observe Safety and Informational Symbols
Throughout this manual you will see the following
safety and informational symbols. They indicate
safety hazards, machine hazards, or information to
improve operation. Read the instructions carefully
whenever you see any of these symbols:
The safety symbol indicates a potential safety
hazard to persons operating or near the
machine and advises on how to avoid it.
The notice symbol indicates a potential for
machine or property damage from operator
error and advises on how to avoid misuse.
The information symbol indicates useful - but
not crucial - information for machine operation,
assembly, or adjustment.
Be Aware of Signal Words
Some decals are accompanied by a signal word.
Signal words indicate the seriousness of a potential
hazard. These signal words are:
DANGER indicates an imminent hazard which, if not
avoided, will result in death or serious injury. This
signal word is limited to the most serious situations,
typically for unguarded machine components.
WARNING indicates a potential hazard which, if not
avoided, could result in death or serious injury
including hazards that are exposed when guards are
removed. It also alerts against unsafe practices.
CAUTION indicates a potential hazard, which if not
avoided, may result in minor or moderate injury. It
also alerts against unsafe practices.
Before Getting Started
Read Machine Information
Read this manual in its entirety before attempting to start
and operate the machine. Do not let anyone operate
machine without proper instruction.
Non-Great Plains components on this machine may
contain additional safety information not found in this
manual. Consult the manufacturer’s safety
information and product decals to safely use products
from third-parties.
Wear Appropriate Clothing and Equipment
Never wear loose clothing around machine. Always
wear appropriate clothing and equipment such as hard
hats, gloves, face masks, eye protection, and work or
steel-toed boots as needed.
Prolonged exposure to machine noise during
operation can cause hearing impairment or loss. Use
proper hearing protection like earmuffs or earplugs
while working.
Inspect Machine Before Use
Inspect brakes, link pins, and other mechanical parts
for wear and dirt buildup, and check that all guards
and shields are undamaged, installed, and secure
before operating machine.
Check that hydraulic fittings are tight and all hydraulic
hoses and lines are in good working condition before
applying pressure to the system.
Do not modify the machine. Unauthorized
modification can result in unsafe conditions that lead
to machine damage or personal injury.
!
!
i

Great Plains | 411-976m | 07/21/2021 4
YP2425A Table of Contents Index Safety Information
Machine Use
Operate Responsibly
Maintain attention on operation at all times to avoid
injury to yourself or others.
Do not operate machine while distracted by a smart
phone, tablet, or similar electronic device, or while
impaired by alcohol, medication, any controlled
substance, or while fatigued.
Do not ever allow passengers to ride on any part of
the machine at any time, for any reason.
Handle Hydraulics with Care
Keep clear of machine while hydraulics are in use.
Any failure in the hydraulic system can cause
machine parts to move or fall rapidly with a great deal
of force. Anyone struck, caught between, or crushed
beneath these parts can suffer serious injury or even
death.
A raised planter without cylinder locks installed or
without active hydraulic pressure will slowly lower
over time. Use tractor hydraulics to raise planter only
for brief periods, such as field turns and cylinder lock
installation.
Relieve hydraulic pressure and wait for all parts to
come to a complete stop before disconnecting any
hydraulic lines or performing any work on the
hydraulic system.
Do not have skin exposed when searching for leaks in
hydraulic lines. Use a piece of cardboard or wood to
locate leaks. If injured by escaping hydraulic fluid, seek
immediate medical attention.
Wear protective gloves and eye protection when
working on the machine’s hydraulic system.
Avoid Potential Collision Damage
Watch your surroundings at all times. Do not operate
with nearby bystanders or while anyone makes
adjustments or fills the machine.
Avoid contacting overhead obstructions such as low
bridges, overpasses, and power lines.
Do not operate near ditches, holes, steep slopes,
embankments, or other surfaces which may collapse
under the machine’s weight or tip the machine over.
Chemicals and Waste
Agricultural chemicals can be dangerous. Improper
use can seriously injure persons, animals, plants, soil
and property.
Read chemical manufacturer’s instructions carefully,
and then take appropriate precautions before use. In
the absence of manufacturer instructions, chemical
labels will inform you of any potential hazards and
their severity.
Wear protective clothing and as well as any other
personal protective equipment.
Wash hands and face before eating after working
with chemicals. Shower as soon as application is
completed for the day.
Apply only with acceptable wind conditions.
Make sure wind drift of chemicals will not affect
any surrounding land, people or animals.
Dispose of unused chemicals and chemical waste as
specified by the manufacturer. Observe all the local
ordinances and regulations in your area.
Dispose of Waste Properly
Dispose of waste properly to avoid threatening the
environment and ecology. Potential harmful waste
includes oil, fuel, filters, and batteries.
Use a leak-proof container for draining fluids. Do not
use a food or beverage container that may be
mistaken for a consumable product.
Do not drain or pour waste onto the ground, down a
drain, or into any water source.
Contact your local environmental or recycling center
for the proper way to recycle or dispose of waste.

YP2425A Table of Contents Index Safety Information
Great Plains | 411-976m | 07/21/2021 5
Machine Maintenance
Follow Tire Recommendations
Consult the tire manufacturer’s recommendations for
maintenance and replacement of your machine’s
tires. Only use prescribed tire sizes with correct
ratings and tire pressure.
Replacing tires is potentially hazardous. Have a
trained professional change the machine’s tires with
the proper tools and equipment.
Avoid over inflation of tires and over torquing wheel
bolts. Review the machine specifications and tire
information in this manual first before doing any work
on the tires of your machine.
Prepare for Performing Maintenance
Understand procedure before performing any
work. Always use proper tools and equipment.
Only work on or around the machine if frame is
lowered, or raised with the cylinder locks in place.
Lower the implement. Put tractor in Park, turn off
engine. To prevent unauthorized starting, remove key
before performing maintenance or service work.
If work must be performed with wings raised, set
the wing tilt locks to the road position.
Disconnect electronic monitor and lighting
harness from the tractor before servicing or
adjusting electrical systems.
Check and replace worn brake lines as needed.
Remove all tools and unused parts from
implement before operation.
PTO
Wait until all moving components have completely
stopped before adjusting, cleaning, or servicing any
PTO driven equipment.
When operating stationary PTO driven equipment,
always apply the parking brake and place chocks
behind wheels.
Stay clear of and never step over any rotating parts.
Machine Transport
This machine does not meet all local, regional, or
national regulations for transport on a public road.
Know and comply with your local laws and regulations
before transporting your machine.
Transport only at recommended transport speed.
Further reduce speed when turning.
Before towing implement on roads, empty out all
material from hoppers or boxes. Implement should
never weigh more than 1.5 times the weight of towing
vehicle.
Know transport height and width of implement to
avoid collision.
Do not engage any hydraulic functions while machine
is in transport.
Use Safety Lights and Devices
Inspect safety chain and chain load rating before use
with machine. Never use the safety chain for towing.
Replace chain if any links or end fittings are broken,
stretched, or otherwise damaged.
Always use safety lights and devices when
transporting and operating the machine. If equipped,
use flashing warning lights and turn signals whenever
driving on public roads.
Regularly inspect safety lights, signs, and devices to
ensure that they are clean and visible from either end
of the machine.
Shutdown and Storage
Park the tractor and implement on a solid, level
surface devoid of bystanders.
Fold and tilt wings up.
Put tractor in park or set the parking brake. Turn
off engine and remove key from ignition.
Turn lockout valve and wing lock levers to locked
position to prevent the wings from lowering.
Detach the tractor. Secure the implement using
blocks.

Great Plains | 411-976m | 07/21/2021 6
YP2425A Table of Contents Index Safety Decals
Safety Decals
Your implement comes equipped with safety
reflectors and decals in place.
Read and follow decal directions. Keep all safety
decals clean and legible. Replace all damaged,
faded, or missing decals.
Order new decals from your Great Plains dealer.
Refer to this section for proper decal placement.
When ordering new parts or components, also
request corresponding safety decals.
To install new decals:
Clean the area on which the decal is to be placed.
Peel backing from decal. Press firmly on surface,
being careful not to cause air bubbles under decal.
Machine Decals
Slow Moving Vehicle Reflector
818-055C
On the back of the walkboard platform;
1 total
Red Reflectors
838-266C
On the back of seed box support structure each end
(above wheels, outside Daytime reflectors);
two total
Daytime Reflectors
838-267C
On the back of seed box support structure each end
(above wheels, inside of red reflectors);
two total
25211
29710
29710

YP2425A Table of Contents Index Safety Decals
Great Plains | 411-976m | 07/21/2021 7
Amber Reflectors
838-265C
On the front of the center section front lower tool
bars,
on the rear of the wing tool bars, and
on the sides of the seed box frame;
six total.
Danger: Crushing Hazard
818-590C
Top center of 3-point hitch; one total
(not present with hydraulic tongue option)
Danger: Read Manual
848-512C
On tongue at hitch;
1 total
Danger: Electrocution Hazard
838-599C
One each side or marker upright arm, each side;
four total
29710
29710
29710
848-512C
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
29710

Great Plains | 411-976m | 07/21/2021 8
YP2425A Table of Contents Index Safety Decals
Danger: Rotating Driveline
858-030C (Option)
On front face of hydraulic reservoir;
one total
Warning: Speed
818-188C
On front of center section, one total
Warning: High Pressure Fluid Hazard
818-339C
On side of tongue; one total
Warning: Markers: Pinch/Crush
818-682C
One each side or marker upright arm, each side;
four total
858-030C
Alldriveline guards, tractor
andequipment shieldsin place
PTOpump assembly securely
attachedwithtorque arm and clamp
boltsproperly torqued
ROTATING DRIVELINE -
CONTACTCAN CAUSE DEATH
KEEP AWAY!
DO NOT OPERATEWITHOUT-
DANG ER
858-029C
CAPACITY= 13.5 U.S. GALS
USEANY HIGH QUALITY MINERAL BASED
HYDRAULICFLUID WITH A VISCOSITY RATING
OF10W-30. OIL MUST BE CLEAN AND FREE
FROMDIRT OR CONTAMINANT PARTICLESTO
PREVENTDAMAGE TO PUMP AND MOTOR.
REPLACEFILTER ELEMENT AFTER EVERY
150OPERATING HOURS OR 2 YEARSSERVICE.
LEVELTOOLBAR BEFORE CHEKINGOIL LEVEL
OIL FILL LINE
858-004C
ReadOwner’sM anual BEFORE operatingmachine.
Keeptractorat IDLING SPEED and slowly engage PTO
toprevent damage to Hydraulic Motor
KeepRadiatorclean and free of foreign matter to
preventoverheating.
DoNOT operate with hydraulicoil at or above 180°F.
HOT FLUID HAZARD
WARNING
818-240CRev.A
To avoidInjur y or
Machine Damage:
·Operate only with
1000 rpm PTO
CAUTION
34843
29710
818-188C Rev. C
Do Not exceed 20 mph maximum transport
speed. Loss of vehicle control and/or machine
can result.
To Prevent Serious Injury or Death:
EXCESSIVE SPEED HAZARD
WARNING
29710
29710

YP2425A Table of Contents Index Safety Decals
Great Plains | 411-976m | 07/21/2021 9
Warning: Hot Fluid
858-004C (Option)
On front face of hydraulic reservoir;
one total
Caution: 1000 rpm PTO
818-240C (Option)
On front face of hydraulic reservoir;
one total
Caution: Read Operator Manual
818-587C
On center tool bar; one total
Caution: Transport Locks
818-351C
Hitch tongue,
Rock shaft face, forward center transport wheels,
front of wing casters;
five total
858-030C
Alldriveline guards, tractor
andequipment shields in place
PTOpump assembly securely
attachedwith torque arm and clamp
boltsproperly torqued
ROTATING DRIVELINE -
CONTACTCAN CAUSE DEATH
KEEP AWAY!
DO NOT OPERATEWITHOUT-
DANG ER
858-029C
CAPACITY= 13.5 U.S. GALS
USEANY HIGH QUALITY MINERAL BASED
HYDRAULICFLUID WITH A VISCOSITY RATING
OF10W-30. OIL MUST BE CLEAN AND FREE
FROMDIRT OR CONTAMINANT PARTICLESTO
PREVENTDAMAGE TO PUMP AND MOTOR.
REPLACEF ILTER ELEMENT AFTER EVERY
150OPERATING HOURS OR 2 YEARS SERVICE.
LEVELTOOLBAR BEFORE CHEKING OIL LEVEL
OIL FILL LINE
858-004C
ReadOwner’s Manual BEFORE operating machine.
Keeptractorat IDLING SPEED and slowly engage PTO
toprevent damage to Hydraulic Motor
KeepRadiatorclean and free of foreign matterto
prevent overheating.
DoNOT operate with hydraulic oil at or above 180°F.
HOT FLUID HAZARD
WARNING
818-240CRev.A
To avoidInjur y or
Machine Damage:
·Operate only with
1000 rpm PTO
CAUTION
34843
858-004C
Read Owner’s Manual BEFORE operating machine.
Keep tractor at IDLING SPEED and slowly engage PTO
to prevent damage to Hydraulic Motor
Keep Radiator clean and free of foreign matter to
prevent overheating.
Do NOT operate with hydraulic oil at or above 180°F.
HOT FLUID HAZARD
WARNING
858-030C
Alldriveline guards, tractor
andequipment shields in place
PTOpump assembly securely
attachedwith torque arm and clamp
boltsproperly torqued
ROTATING DRIVELINE -
CONTACTCAN CAUSE DEATH
KEEP AWAY!
DO NOT OPERATEWITHOUT-
DANG ER
858-029C
CAPACITY= 13.5 U.S. GALS
USEANY HIGH QUALITY MINERAL BASED
HYDRAULICFLUID WITH A VISCOSITY RATING
OF10W-30. OIL MUST BE CLEAN AND FREE
FROMDIRT OR CONTAMINANT PARTICLESTO
PREVENTDAMAGE TO PUMP AND MOTOR.
REPLACEFILTER ELEMENT AFTER EVERY
150OPERATING HOURS OR 2 YEARS SERVICE.
LEVELTOOLBAR BEFORE CHEKING OIL LEVEL
OIL FILL LINE
858-004C
ReadOwner’s Manual BEFORE operating machine.
Keeptractor at IDLING SPEED and slowly engage PTO
toprevent damage to Hydraulic Motor
KeepRadiator clean and free of foreign matter to
preventoverheating.
DoNOT operate with hydraulic oil at or above 180°F.
HOT FLUID HAZARD
WARNING
818-240CRev.A
To avoidInjur y or
Machine Damage:
·Operate only with
1000 rpm PTO
CAUTION
34843
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Read Owner’s Manual before using machine.
Stand clear when folding and unfolding markers.
Stand clear when raising and lowering machine.
Keep all safety shields and devices in place.
Keep hands, feet, and clothing away from
Never ride on machine.
Always lower or properly support machine
Escaping hydraulic fluid can cause serious
Review safety instructions with all operators
moving chains and sprockets.
BEFORE servicing.
818-587C Rev.B
injury.
annually.
CAUTION
29710
29796

Great Plains | 411-976m | 07/21/2021 10
YP2425A Table of Contents Index Safety Decals
Caution: Tires Not A Step
818-398C
One front face each wing gauge wheel,
One each side front center axle;
6 total
Caution: Pressure and Torque
838-426C (S/N B1113G-)
On outside rim each transport tire;
10 total
Caution: Pressure and Torque
858-773C (S/N B1114G+)
On outside rim each transport tire;
10 total
Warning: Pinch/Crush
818-045C
On forward transport wheel arms, each side
On rear axle by seed hopper, each side;
five total
29710
29710
29710
858-773C
Torque wheel bolts to 170 lb-ft.
Maximum inflation pressure of tires is 73 psi.
To Avoid Injury or Machine Damage from Improper Tire
Inflation or Torquing of Wheel Bolts:
CAUTION
29710

YP2425A Table of Contents Index Preparation and Setup
Great Plains | 411-976m | 07/21/2021 11
Preparation and Setup
This section helps you prepare your tractor and
YP2425A Planter for use, and covers tasks that need
to be done seasonally, or when the tractor/planter
configuration changes.
Before using the YP2425A Planter in the field, you
must hitch the planter to a suitable tractor, inspect
systems, level the planter. Before using the planter
for the first time, and periodically thereafter, certain
adjustments and calibrations are required.
Post-Delivery/Seasonal Setup
On initial delivery, use with a new tractor, and
seasonally, check and as necessary, complete these
items before continuing to the routine setup items:
Install seed monitor console in tractor (page 129).
Bleed hydraulic system (page 75).
Wing leveling and alignment (page 77).
Marker setup (page 43)
Radar calibration (page 129).
De-grease exposed cylinder rods if so protected at
last storage.
Pre-Planting Setup
Complete this checklist before routine setup:
Read and understand “Important Safety
Information” on page 1.
Check that all working parts are moving freely, bolts
are tight, and cotter pins are spread.
Check that all zerks are in place and lubricated. See
“Lubrication” on page 82.
Check that all safety decals and reflectors are
correctly located and legible. Replace if damaged.
See “Safety Decals” on page 6.
Inflate tires to pressure recommended and tighten
wheel bolts as specified. See “Specifications and
Capacities” on page 113.
Hitching Tractor to Planter
Crushing Hazard:
Do not stand or place any part of your body
between planter and moving tractor. You
may be severely injured or killed by being
crushed between the tractor and planter.
Stop tractor engine and set park brake
before attaching cables and hoses.
Hydraulic Hose Hookup
High Pressure Fluid Hazard:
Relieve pressure before disconnecting
hydraulic lines. Escaping fluid under
pressure can have sufficient pressure to
penetrate the skin causing serious injury.
Use a piece of paper or cardboard, NOT
BODY PARTS, to check for leaks. Wear
protective gloves and safety glasses or
goggles when working with hydraulic
systems. If an accident occurs, seek
immediate medical attention from a
physician familiar with this type of injury.
If Weight Transfer is Installed
If the optional weight transfer system is not installed,
or a PTO pump is installed, continue at “Color
Coded Hydraulic Hoses” on page 12.
!
!
Figure 1
Weight Transfer System
36421
858-295C
DO NOT MOVE PLANTER FOLDED
OR UNFOLDED WITHOUT CONNECTING
FAN CASE DRAIN AND LOW PRESSURE
RETURN TO THE TRACTOR OR
INSTALLING WEIGHT TRANSFER
SHIPPING LINKS. FAILURE TO DO
SO CAN RESULT IN DAMAGE TO
WEIGHT TRANSFER CIRCUIT.
NOTICE

Great Plains | 411-976m | 07/21/2021 12
YP2425A Table of Contents Index Preparation and Setup
The weight transfer cylinders must be free to flex
during all planter movements where the system is
not in active use.
To allow cylinder flex:
connect at least the fan case drain and fan return lines
to suitable receptacles (see page 12), or
install the shipping links (see page 129).
Machine Damage Risk:
Do not move the planter with a hydraulically
locked weight transfer system. Relieve the
system or install shipping links. If the
cylinders are not free to flex, oil loss will
result from even minor movement flexing.
Color Coded Hydraulic Hoses
Great Plains hydraulic hoses have color coded
handle grips to help you hookup hoses to your tractor
outlets. Hoses that go to the same remote valve are
marked with the same color.
For hydraulic fan and drive motors, connect the hose
under the retracted cylinder symbol to the pressure
side of the motor. Connect the hose under the
extended cylinder symbol to the return side of the
motor.
The fan motor further requires hookup of a third line,
which returns hydraulic fluid from the fan motor case.
If the PTO pump option is installed, there are no
hoses at the hitch for fan, hydraulic meter drive, or
optional hydraulic fertilizer pump.
Current Style Color Coded Hose Handles
To distinguish hoses on the same hydraulic circuit,
refer to the symbol molded into the handle grip.
Hoses with an extended-cylinder symbol feed
cylinder base ends. Hoses with a retracted-cylinder
symbol feed cylinder rod ends.
Older Style Hoses with Color Ties
To distinguish hoses on the same hydraulic circuit,
refer to hose label. The hose under an
extended-cylinder symbol feeds a cylinder base end.
The hose under a retracted-cylinder symbol feeds a
cylinder rod end.
Protecting Fan Hydraulic Motor Seals
Motor Seal Damage Risk:
Case Drain Hose must be attached first,
prior to inlet and return hoses being
connected.
Case Drain Hose must be detached last,
to prevent damage to the fan motor.
Hydraulic Motor Performance Risk:
DO NOT hook case drain line to a
“power-beyond port”
Low Pressure (Case) Drain Connection
1. Attach case drain hose to low pressure drain
connection.
!
Figure 2
Color Coded Hose Handles
31733
Color Hydraulic Function
Gray Wing Fold / Marker Fold / Auxiliary
Blue Lift / (and Hitch if hydraulic tongue)
Black Fan
Yellow Hydraulic Drive
Figure 3
Older Style Hoses w/Label
27270
Color Hydraulic Function
White Wing Fold / Marker Fold / Auxiliary
Blue Lift / (and Hitch if hydraulic tongue)
Orange Fan
Yellow Hydraulic Drive
!
!
