GREAT PLAINS MC5109 Max-Chisel User manual

Manufacturing, Inc.
www.greatplainsmfg.com
© Copyright 2019 Printed 2019-07-18 566-242Q
EN
Table of Contents Index
Table of Contents Index
ORIGINAL INSTRUCTIONS
Pre-Delivery Manual
MC5109 , 5111, 5313 & 5315
Max-Chisel
Read the operator’s manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
43667

Table of Contents Index
Table of Contents Index

MC5109-5315 Cover Index iii
2019-07-18 Cover Index 566-242Q
© Copyright 2015, 2016, 2017, 2018, 2019 All rights Reserved
Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been
taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed
for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products
as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, Max-Chisel, Row-Pro,
Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered Trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone,
Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Till, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and Product Names that appear and are owned by others are trademarks of their respective owners.
Printed in the United States of America
Table of Contents
Important Safety Information.................................................1
Introduction.............................................................................4
Description of Unit .............................................................4
Models Covered ................................................................4
Document Family...............................................................4
Tools Required ..................................................................4
Pre-assembly Checklist .....................................................4
Using This Manual.............................................................5
Definitions...................................................................5
Shipping.............................................................................6
Unloading ..........................................................................7
Unload Smaller Items First .........................................7
Unload Max-Chisel .....................................................7
Unpacking Boxes .......................................................7
Further Assistance .....................................................7
Assembly.................................................................................8
Gang Frames.....................................................................8
Trusses & Brace Bars........................................................9
Lift Straps ........................................................................10
Hitch & Level Bar Assembly ............................................11
Hydraulic Hose Assembly................................................12
Hydraulic Valve Bracket ..................................................12
Install Depth Control Valve and O-Ring Fittings.......13
Attach Hose Clamps and Hose Wraps.....................14
Hydraulic Hose Hookup............................................14
Hose Handles...........................................................15
Purging Hydraulic System ........................................16
Depth Gauge............................................................17
569-190S & 596-293S Shanks.................................17
569-195S Shank.......................................................18
5113-5115 Wings .....................................................18
Chopper/ML Roller ...................................................19
Light Brackets ..........................................................20
Completing Setup.....................................................20
Appendix - Reference Information......................................21
Tire Inflation Chart...........................................................22
Hydraulic Connectors and Torque...................................22
MC5109-MC5315 Hydraulic Lift Layout ..........................23
MC5313-MC5315 Hydraulic Fold Layout ........................24
MC5109-5111 Hydraulic Gang Layout ............................25
MC5313-MC5315 Hydraulic Gang Layout ......................26
MC5109 Machine Layout ................................................27
MC5111 Machine Layout ................................................28
MC5313 Machine Layout ................................................29
MC5315 Machine Layout ................................................30
Twisted Shovel Layout ....................................................31
Blade Layout ...................................................................32
MC5109 Chopper Reel Layout........................................33
MC5111 Chopper Reel Layout........................................34
MC5313 Chopper Reel Layout........................................35
MC5315 Chopper Reel Layout........................................36
MC5109 & MC5111 Chopper/ML Roller Hydraulic Layout..
37
MC5313 & MC5315 Chopper/ML Roller Hydraulic Layout..
38
MC5109 Chopper/ML Roller Layout................................39
MC5111 Chopper/ML Roller Layout................................40
MC5313 Chopper/ML Roller Layout................................41
MC5315 Chopper/ML Roller Layout................................42

2019-07-18 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index iv

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index 1
Important Safety Information
Look for Safety Symbol
The SAFETY ALERT SYMBOL indicates there is a
potential hazard to personal safety involved and extra
safety precaution must be taken. When you see this
symbol, be alert and carefully read the message that
follows it. In addition to design and configuration of
equipment, hazard control and accident prevention are
dependent upon the awareness, concern, prudence and
proper training of personnel involved in the operation,
transport, maintenance and storage of equipment.
Be Aware of Signal Words
Signal words designate a degree or level of hazard
seriousness.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
This signal word is limited to the most extreme situations,
typically for machine components that, for functional
purposes, cannot be guarded.
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury, and includes hazards that are exposed when
guards are removed. It may also be used to alert against
unsafe practices.
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury. It may also be used to alert against unsafe
practices.
Use Adequate Lifting Means
The frame sections and gangs of this machine are
extremely heavy. If using multiple lifters, make sure each
is rated for at least its share of the load.
Prepare for Emergencies
Be prepared if a fire starts
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctor, ambulance, hospital
and fire department near phone.
> 14,000
POUNDS

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index Important Safety Information 2
Be Familiar with Safety Decals
Read and understand the “Safety Decals” section of the
Operators Manual.
Read all instructions noted on the decals.
Keep decals clean. Replace damaged, faded and illegible
decals.
Wear Protective Equipment
Wear protective clothing and equipment.
Wear clothing and equipment appropriate for the job.
Avoid loose-fitting clothing.
Because prolonged exposure to loud noise can cause
hearing impairment or hearing loss, wear suitable
hearing protection such as earmuffs or earplugs.
Because operating equipment safely requires your full
attention, avoid wearing entertainment headphones while
operating machinery.
Avoid High Pressure Fluids
Escaping fluid under pressure can penetrate the skin,
causing serious injury.
Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
Use a piece of paper or cardboard, NOT BODY PARTS, to
check for suspected leaks.
Wear protective gloves and safety glasses or goggles when
working with hydraulic systems.
If an accident occurs, seek immediate medical assistance
from a physician familiar with this type of injury.
Use Safety Lights and Devices
Slow-moving tractors and towed implements can create
a hazard when driven on public roads. They are difficult
to see, especially at night.
Use flashing warning lights and turn signals whenever
driving on public roads.
Use lights and devices provided with implement
Keep Riders Off Machinery
Riders obstruct the operator’s view. Riders could be
struck by foreign objects or thrown from the machine.
Never allow children to operate equipment.
Keep all bystanders away from machine during operation.
Shutdown and Storage
Lower implement, put tractor in park, turn off engine, and
remove the key.
Secure Max-Chisel using blocks and supports provided.
Detach and store Max-Chisel in an area where children
normally do not play.

MC5109-5315 Table of Contents Index Important Safety Information 3
07/18/2019 Table of Contents Index 566-242Q
Tire Safety
Tire changing can be dangerous and should be
performed by trained personnel using correct tools and
equipment.
When inflating tires, use a clip-on chuck and extension
hose long enough for you to stand to one side–not in front
of or over tire assembly. Use a safety cage if available.
When removing and installing wheels, use wheel-handling
equipment adequate for weight involved.
Safety At All Times
Thoroughly read and understand the instructions in this
manual before operation. Read all instructions noted on
the safety decals.
Be familiar with all machine functions.
Operate machinery from the driver’s seat only.
Do not leave machine unattended with tractor engine
running.
Do not stand between the tractor and machine during
hitching.
Keep hands, feet and clothing away from power-driven
parts.
Wear snug-fitting clothing to avoid entanglement with
moving parts.
Watch out for wires, trees, etc., when folding and raising
machine. Make sure all persons are clear of working area.

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index 4
Introduction
The Max-Chisel has been designed with care and built
by skilled workers using quality materials. Proper setup,
maintenance, and safe operating practices will help the
customer get years of satisfactory use from the machine.
Description of Unit
The MC5109-5315 Max-Chisel is a one or three-section
“vertical” tillage tool. Working width ranges from 11’ 6” to
19. The implement is designed to cut, size and bury
residue. It can work up to 11” deep, the blades will
dislodge rootballs while mixing and incorporating residue
in the top 4-5” of soil chopping in to accelerate the
decaying process, leaving the field smooth enough for
“one pass” finishing in Spring. For optimum leveling of
your machine, it should be equipped with either a
Chopper Reel or Buster Bar attachment.
Models Covered
Document Family
Tools Required
•Basic Hand Tools
•Torque Wrench
•Fork Truck, Overhead Hoist or Loader
Pre-assembly Checklist
Before assembling, read and understand “Important
Safety Information” in front part of this manual.
Have at least two people on hand while assembling.
Make sure area is level and free of obstructions
(preferably an open concrete area).
Have all major components
Have all fasteners and pins shipped with machine.
MC5109 11-Foot 1-section
MC5111 14-Foot 1-section
MC5313 16-Foot 3-section
MC5315 19-Foot 3-section
566-242Q-ENG Assembly Manual
566-242Q Pre-Delivery Manual (this document)
566-242M Operator Manual
566-242P Parts Manual
Figure 1
Max Chisel
43667

MC5109-5315 Table of Contents Index Introduction 5
07/18/2019 Table of Contents Index 566-242Q
Using This Manual
This manual was written to help you assemble and pre-
pare the new machine for the customer. The manual
includes instructions for assembly and setup. Read this
manual and follow the recommendations for safe, effi-
cient and proper assembly and setup.
An operator’s and parts manual is also provided with the
new machine. Read and understand “Important Safety
Information” and “Operating Instructions” in the oper-
ator’s manual before assembling the machine. Refer to
the parts manual for proper part’s identification. As a ref-
erence, keep the operator’s and part’s manual on hand
while assembling.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
A crucial point of information related to the preceding topic.
Read and follow the directions to remain safe, avoid serious
damage to equipment and ensure desired field results.
Useful information related to the preceding topic.
Right-hand and left-hand as used in
this manual are determined by facing
the direction the machine will travel
while in use unless otherwise stated.
An orientation rose in some line art
illustrations shows the directions of: Up,
Back, Left, Down, Front, Right.
L
R
U
D
F
B
L
R
Figure 2
Right / Left
43667
U
D
F
B
L
R

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index Introduction 6
Shipping
The Max-Chisel will be shipped pre-assembled as
shown.
Refer to Figure 3
•The Max-Chisel will be shipped with shipping stands
and u-bolts that will not need to be returned to Great
Plains.
•Wings (if equipped) will be stacked and will need to
be attached to the center frame after unloading.
•Finishing attachments (if equipped), will be pre-
assembled, shipped stacked with the center frames,
and, or banded to pallet
•Some shank mount assemblies will be attached to
frames in proper locations, others will need to be
installed.
•Shank assemblies will be shipped in a box on a
pallet, and tips may need to be installed.
•Refer to Figure 4.
•Gang frames will be pre-assembled and stacked
together on shipping stands.
•Some shank mount assemblies will be attached to
frames in proper locations, others will need to be
installed.
•Shank assemblies will be shipped in a box on a
pallet, and may need tips installed.
•Chopper/ML Roller Attachments will be shipped
partially assembled. They will be banded to palates
or in crates.
Figure 3
Shipping Stands Center Frames
43734
Figure 4
Shipping Gang Frames
43736

MC5109-5315 Table of Contents Index Introduction 7
07/18/2019 Table of Contents Index 566-242Q
Unloading
Be sure the truck is on level ground, preferably concrete.
Centering components:
The Max Chisel is very heavy, be sure to use 2, 8000# forks
trucks to unload machine. Be sure to center fork truck or chains
(overhead hoist) on components so they won’t slide and cause
injury.
Unload Smaller Items First
Unloading the Max-Chisel is a potentially dangerous
operation.
Reduce risk and complications by first unloading
1. the gang frames and finishing attachments
2. the misc. boxes
3. the Max-Chisel (described in the next section)
Unload Max-Chisel
4. Place smaller components well out of the
maneuvering area needed for unloading the Max-
Chisel.
5. Double-check that all chains and tie-down straps
have been released and stowed.
6. Set parking brake on trailer tractor.
7. Slowly lift the Max-Chisel off trailer bed using two
fork lifts.
8. Stop lifting about 12” above the bed.
9. Have the truck driver slowly pull the trailer straight
out from under the Max-Chisel.
10. Making sure to keep level from front to back and side
to side, slowly lower the Max-Chisel.
11. Lower the Max-Chisel to the ground, DO NOT
remove the shipping stands.
12. Unstack the Chopper attachment, hitch, level bar,
and center frame.
Unpacking Boxes
Position boxes in area that you can maneuver
components up to machine to assembly.
13. Carefully remove banding from boxes.
14. Carefully remove any banding from attachments or
where items are secured on frame components.
15. Locate and identify all components before
assembling.
Further Assistance
Great Plains Manufacturing, Inc. wants you to be
satisfied with your new Max-Chisel. If for any reason you
do not understand any part of this manual or are
otherwise dissatisfies with the product please contact:
Great Plains Service Department
1525 E. North St.
PO Box 5060
Salina, KS 67402-5060
Or go to www.greatplainsag.com and follow the contact
information at the bottom of your screen for our service
department.

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index 8
Assembly
Gang Frames
Refer to Figure 5
16. Carefully move the gang frames , & into place in front of the center section.
17. Bolt the gang frames together using, 58 x 212 Gr. 5 hex bolt , lock washers and hex nuts.
18. Locate the 5109/11 Center Cylinder Lift Bracket , and install it onto the front of the gang frames using 114 x 634
hardened pin ,12 x 258 Gr. 8 special thread bolt , and top lock.
19. Install both rear sub frame lift brackets onto the rear of the gang frames using 114 x 634 hardened pins ,
12 x 258 Gr. 8 special thread bolts , and top locks.
20. Attach hydraulic cylinders , to the 5109/11 Center Cylinder Lift Bracket , with clevis pin, washer, and cotter
pin.
 Be sure to connect hydraulic cylinders to 5109/11 Center Cylinder Lift Bracket, before installing lift straps.
21. Bolt may be tightened to specs, See “Torque Values Chart” on page 21.
10
11
12
13
14
16
17
15
Figure 5
Gang Frames
43729
10
11
12
13
14
15
16
14
15
17
13

MC5109-5315 Table of Contents Index Assembly 9
07/18/2019 Table of Contents Index 566-242Q
Trusses & Brace Bars
Refer to Figure 6
22. With the gang frames in place and the rear section of the center frame, shipping stands still attached, setting on
the ground attach the left and right frame trusses , using 114 x 812 Gr. 8 Special Thread Bolt , lock washers
and hex nuts, to the rear section of the frame.
23. Bolt the truss cross braces , to the inside of the center trusses , using 58 x 2 Gr. 5 bolts , lock washers and
hex nuts.
24. Using 58 x 2 Gr. 5 bolts , lock washers and hex nuts, install the left and right brace bars to the center
trusses.
25. Secure the 5109/11 Center Cylinder Lift Bracket , and the rear sub frame lift brackets to the left and right
center frame brace bars & using 114 x 634 hardened pins ,12 x 258 Gr. 8 special thread bolts , and top
locks.
26. Bolts may be tightened to specs, See “Torque Values Chart” on page 21.
18
19
20
23
21
26
21
27
25
22
24
21
20
Figure 6
Trusses & Brace Bars
43731
18
19
20
18
20
21
22
23
24
25
22
23
26
27

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index Assembly 10
Lift Straps
Refer to Figure 7
Be sure to connect hydraulic cylinders to the 5109/11 Center Cylinder Lift Bracket, before installing lift straps.
27. Attach the left gang frame lift strap , & strap , to the rear sub frame lift brackets and the 5109/11 Center
Cylinder Lift Bracket using 1 x 734 Gr. 8 Special Thread Bolt and top lock nuts. Repeat this for the right side.
28. Now the hydraulic cylinders may be attached to the left and right center frame brace bars using clevis pin,
washer, and cotter pin.
29. Bolts may be tightened to specs, See “Torque Values Chart” on page 21.
1
7
6
2
3
5
4
U
D
F
B
L
R
5
Figure 7
Lift Straps
43730
1
2
3
4
5
6
7

MC5109-5315 Table of Contents Index Assembly 11
07/18/2019 Table of Contents Index 566-242Q
Hitch & Level Bar Assembly
Refer to Figure 8
The hitch assembly will come pre-assembled from the factory. The hose loop will need to be installed.
30. Attach hitch assembly to front of trusses with 114x 8 Gr. 8 hex bolts , 114 flat washers and 114 lock
nuts. Be sure to insert the two 114 flat washers (one on each side of hitch uni-ball) to ensure tight fit. Bolts
need to be tightened securely, but do not torque as the hitch needs to pivot.
31. Slide the level bar assembly into place. On folding models slide the level bar assembly under fold cylinders
(as this will be attached to the leveling h-bracket as shown).
32. The leveling h-bracket will be installed on the center frame. Use 1 x 4 Gr. 8 special thread hex bolts , top
lock, and nuts to secure the level bar assembly to the leveling h-bracket .
33. Attach the level bar spring rod , to the level bar assembly with 34 x 112 Gr. 8 hex bolts , lock washers and
hex nuts.
34. With the level bar spring rod in place, remove the 112 jam nut , 112 hex nut , spring guide and front half
of compression spring . Slide the h-bracket onto the level bar spring rod , and reinstall spring , spring
guide , hex nut and jam nut .
35. Install the h-bracket , to the rear of the hitch using 1 x 7 Gr 8 hex bolt , and top lock nut, do not torque as this
needs to pivot. Connect the hitch turnbuckle (with the turnbuckle lock in place) to the h-bracket with
114x8
12Gr. 8 Special Thread bolt , and top lock. Use a 1 x 3.63 clevis pin , washer and cotter pin to
connect the turnbuckle to the hitch.
36. The Level Bar Spring nuts should be tightened so that the dimension from the spring guide to the back of the level
bar is 2814” (see illustration inset.)
Tongue jack may be adjusted up or down to get holes to align up to install pin through the turnbuckle.
37. Tighten all bolts securely but do not torque as the level bar assembly needs to pivot.
10
11
12
13
15
14
16
17
25
24
23
21
22
20
19
18
27
26
Figure 8
Hitch & Level Bar
43732
43749
10
10
11
12
13
13
14
14
15
16
15
17
14
18
19
20
21
22
23
17
22
21
20
19
23
24
25
26
27

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index Assembly 12
Hydraulic Hose Assembly
See hydraulic layout section in Appendix for complete
hose layout and follow the steps to connect hoses.
Once the trusses and hitch are installed, the
hydraulics may be hooked up. All models will be
shipped with hoses attached to hitch. The hoses will
be capped off and will need to be hooked up to fittings.
The hose ends and fittings will be marked with color
ties and will need to be hooked up with matching
colors. Be sure to get the hoses hooked correctly or
hydraulics will not work correctly, Refer to hydraulics
in parts manual for hydraulic layouts.
Hydraulic Valve Bracket
Refer to Figure 9
The hydraulic valve bracket will be installed in place
on the front of the center frame, but will need to be
reoriented so it hangs down.
38. Remove the hydraulic valve bracket , & reorient it
so that it hangs down from the center frame
mounting plate , reinstall the 34 x 2 Gr. 5 hex bolt
, lock washer and hex nut. The double hydraulic
tee block , and the lock valve , will already be
installed on the bracket.
39. The hydraulic lift and gang frame hoses that are
routed from the hitch will need to be hooked to the
correct valves.
40. See “MC5109-MC5315 Hydraulic Lift Layout” on
page 23 for hose routing and hook up.
3
1
2
5
4
U
D
F
B
L
R
Figure 9
Hydraulic Valve Bracket
43668
1
2
3
4
5

MC5109-5315 Table of Contents Index Assembly 13
07/18/2019 Table of Contents Index 566-242Q
Install Depth Control Valve and O-Ring
Fittings
Refer to Figure 10
Some hydraulic hoses will already be routed and
installed. The following procedure is for any hoses
that have not been connected, or have needed repair.
41. Inspect all components for damage or contamination
during shipping.
42. Lubricate o-ring and threads on fitting.
43. Thread straight (non-adjustable stud) fittings into
ports finger tight.
44. Thread elbow (adjustable stud) fitting into side
port of depth stop valve . Thread straight (non-
adjustable stud) fittings into front port of depth
control valve .
Do not over tighten as this could cause damage to
valves. Tighten as shown, See “Hydraulic
Connectors and Torque” on page 22 or proper
torque value.
45. Route hoses as shown in layout section in Appendix.
46. When the JIC hoses are routed, follow the following
procedure for hooking up and tightening.
a. Inspect for possible contamination or damage from
shipping or handling. Sealing surface should be
smooth. Annular tool marks of (100uin) concentric
with thread permissible.
b. Lubricate the threads and the entire surface of the
cone with hydraulic fluid or a light lubricant.
c. Align mating components for hand connection and
turn flare nut until sealing surfaces make full contact.
d. Torque nut to the values shown in “Torque Value
Chart” page 23. If a wrench pad is provided next to
nut, place a second wrench on pad to prevent flare
from rotating while being torqued.
e. When torquing nut onto a straight flared fitting, it may
be necessary to also place a wrench on the flared fit-
ting wrench pad to prevent it from turning during
assembly.
47. Alternate Assembly Method for JIC.
a. If torqued method not possible, then proceed to
steps b-e.
b. Lightly wrench tighten the nut until there is firm resis-
tance.
c. Place a wrench on wrench pad next to nut as near
the 6 0’clock position as possible.
d. Place second wrench on nut as near the 3 o’clock
position as possible.
e. Turn nut clockwise to no less than the 4 o’clock posi-
tion and no more than the 6 o’clock position.
Required rotation generally decreases as size
increases.
3
2
1
U
D
F
B
L
R
Figure 10
Depth Control Valve Fittings
41671
3
1
2
1

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index Assembly 14
Attach Hose Clamps and Hose Wraps
Refer to Figure 11
48. When all the hoses are hooked up and tightened
properly, put hose clamps on hoses as shown.
49. Install hose wraps on hoses as needed.
Be sure and get hoses and light wiring harness
fastened properly so they do not drag. Check to be
sure there is enough slack in hinge area when folding
machine the first time.
Hydraulic Hose Hookup
50. Great Plains hydraulic hoses are color coded to help
you hookup hoses to your tractor outlets. Hoses that
go to the same remote valve are marked with the
same color.
Color Hydraulic Function
Black Lift (2 hoses)
Red Gang (2 hoses)
Green Fold (2 hoses) 3-Section Models
Figure 11
Hose Clamps & Wraps
41583
High Pressure Fluid Hazard:
Relieve pressure before disconnecting hydraulic lines. Use
paper or cardboard, NOT BODY PARTS, to check for leaks.
Wear protective gloves and safety glasses or goggles when
working with hydraulic systems. Escaping fluid under pressure
can have sufficient pressure to penetrate the skin causing
serious injury. If an accident occurs, seek immediate medical
assistance from a physician familiar with this type of injury.
Only trained personnel should work on system hydraulics.

MC5109-5315 Table of Contents Index Assembly 15
07/18/2019 Table of Contents Index 566-242Q
Hose Handles
Refer to Figure 12
51. To distinguish hoses on the same hydraulic circuit,
refer to hose handles. The hose under an extended-
cylinder symbol feeds a cylinder base end. The hose
under a retracted-cylinder symbol feeds a cylinder
rod end.
52. Once all hoses are tightened, hook hoses to tractor
Figure 12
Hose Handles
41552

07/18/2019 Table of Contents Index 566-242Q
MC5109-5315 Table of Contents Index Assembly 16
Purging Hydraulic System
Refer to Figure 13
53. Charge the lift system first. Extend the lift cylinders (black handles) until the center section is fully raised.
Remove the cylinder transport locks and install in storage position. Raise and lower the lift system several times
to purge air from system. Watch for leaks and re-tighten fittings if necessary.
54. The gang frame system (red handles), will need purged. If your machine is a 3 section model the wing gangs
will not start to rise until the center cylinders are fully extended and the master cylinders begin to bypass oil
through the rephasing ports, to the wing cylinders. Continue to pump oil to the gang system until the wing gang
cylinders are also fully extended. At this point, reverse the flow and raise the gangs, retracting all cylinders.
Repeat this procedure several times until all the air is purged out of the system.
55. If your machine is a 3 section model you may now charge the fold system. Before charging the fold cylinders
make sure the rod end of the cylinders are un-pinned and block is under cylinder as shown, so that when the rod
is extended, it will clear the wing fold brackets. Extend the fold cylinders (green ends) completely and then close
them. Extend and retract the cylinders several times to purge air from the system. Now the cylinders may be
extended far enough to be connected to the wing fold brackets. Remove wood block and install the 1 x 338 clevis
pin, 1.5 x 1.0 x.075 machine washer and 316 x 2 cotter pin.
1
2
3
4
4
1
3
2
4
Figure 13
Hydraulic Purging
43733
