Growatt Shine3G Instruction sheet

Growatt Shine3G
Quick Installation Guideline
Search “Shine Phone” in google play or app store, or scan
the picture below, download and install the app.
Register and Add device
For more info, please download from http://server.growatt.com
NOTE: 1.Please install the latest version;
2.For more details, please refer to the content on
server.growatt.com.
【Android& 】iOS
[phone] [phone]
[e-mail]
Growatt ShineGPRS
SIM card installation procedure
Note: 1. If there is SIM card in the data logger, ignore this step.
2. Don’t touch other parts on the PCB board.
Remove the waterproof gasket, unscrew the screws, then open the shell
and take out the PCB board, install the SIM card, put the PCB board into
its shell, tighten the screws and put on the waterproof gasket.
Step2.
A If there is a DIP switch next to the RS232 port, please set
DIP 1 to . Then plug in the Shine3G/ShineGPRS and
lock screws.
B If there is no DIP switch, poke the small rubber plug from the
screw hole adjacent to the RS232 port. Plug into the RS232
port and lock screws.
“ON”
Electrical Connection
Step3. 1.Connect your mobile phone to the WiFi of the router.
3.Then enter the SN and check code of the Shine3G/
ShineGPRS or just scan the QR code on it in the following
page to add Shine3G/ShineGPRS into this account.
4.The successful registration, login account go to "My power
plants, click" + “on to view the acquisition whether
online access;
top right
5. Then click the “Device” tab at the bottom line to move to
“Device” page, All detailed information of the PV system
can be viewed here.
Remark:The connection status of the
can be checked by the status of the blue LED light
beside the Key button in the
1. Blue LED status indicator:
Steady:Device Initialization
Off:No device found on RS232 port
Flash (0.2s cycle changes): Found device on RS232 port
Slow flash (1s cycle changes): The network communication
normal
2. Press KEY button of the Shine3G/ShineGPRS more than 6s
to restore the factory settings, short press the KEY button to
restart it.
Shine3G/ShineGPRS
Shine3G/ShineGPRS
2.Run the ShinePhone, register users, fill in the user information;

快速安装指导
扫描以下二维码,或在谷歌商店或苹果商店搜索“ShinePhone”,
下载并安装软件。
A 当逆变器RS-232接口的旁边有一个DIP开关时，先将逆变器
RS-232接口旁的拨码开关1置于”ON”位置，然后将
Shine3G/ShineGPRS的RS-232接口与逆变器的RS-232接口对接 ，
并用螺丝将Shine3G/ShineGPRS固定在逆变器上。
注册添加设备 1. 首先将手机连接到有无线网络的路由器
4. 注册成功，登录帐号进入“我的电站，点击右上角“+”查看采集
器是否已接入在线 ;
5. 在“我的电站”点击所监控设备，查看光伏设备信息； 备注: 可以通过Shine3G/ShineGPRS上蓝色LED灯的闪烁情况来判断
Shine3G/ShineGPRS的连接状态 :
1.蓝色LED灯状态指示：
常亮：设备初始化
常灭：RS232端口没找到设备
快闪(周期0.2秒 变化)：RS232 端口找到设备
慢闪(周期1秒 变化)：网络通信正常
2.长按采集器主体KEY键6 秒以上恢复出厂设置，短按重启。
SIM 卡安装步骤
详细信息及最新用户手册，请到http://server.growatt.com下载
[phone] [phone]
[e-mail]
注意事项：1. 如是含SIM卡产品则无需此步操作
2. 尽量避免触碰其它器件。
取出防水垫片，拧出螺丝，拆开上盖，取出PCB ,安装SIM卡，装入PCB,
入上盖，拧紧螺丝，装上防水垫片。
3. 进入添加采集器页面，手动输入或扫描采集器序列号及验证码
完成添加;
戳在这里
备注：1. 确保安装的是最新版本的软件；
2. 详情请参考server .growatt.com上的内容 。 -cn
【安卓&苹果】
Growatt Shine3G
Growatt ShineGPRS
电气连接
Step2.
B 当逆变器RS-232接口的旁边没有DIP开关时，先将防水垫片上的
橡胶塞用螺丝刀戳开，然后将Shine3G/ShineGPRS的RS-232接口
与逆变器的RS-232接口对接，并用螺丝将Shine3G/ShineGPRS
固定在逆变器上.
Step3.
用螺丝刀将逆变器RS-232接口上的防水金属片卸下:
2. 运行ShinePhone , 注册用户并登录；
