GSi 30' BINS User manual

®
Grain Bin Eave Towers
Models:
30' - 48' BINS
Installation Manual
PNEG-2328
Version 1.0
Date: 06-03-21
PNEG-2328

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines........................................................................................................................5
Cautionary Symbol Definitions......................................................................................................6
Safety Cautions...........................................................................................................................7
Safety Sign-off Sheet.................................................................................................................10
Chapter 2 General Information ................................................................................................................11
Important Notes on Use of Grain Bin Eave Towers ....................................................................... 11
Chapter 3 Assembling the Tower.............................................................................................................13
Assembling the Diagonal Bracings .............................................................................................13
Assembling the Main Tower .......................................................................................................14
Assembling the Tower Knee Braces............................................................................................18
Connecting the Tower Knee Braces to the Main Tower .................................................................22
Chapter 4 Installing the Tower .................................................................................................................23
Installing the Main Tower to the Bin (FC Stiffened Bins) ................................................................23
Installing the Main Tower to the Bin (CTS Stiffened Bins)..............................................................25
Chapter 5 Parts List.................................................................................................................................27
30' Main Tower Parts .................................................................................................................28
33' Main Tower Parts .................................................................................................................30
36' Main Tower Parts .................................................................................................................32
36' (44.5" Center Collar) Main Tower Parts ..................................................................................34
42' Main Tower Parts .................................................................................................................36
42' (44.5" Center Collar) Main Tower Parts ..................................................................................38
48' Main Tower Parts .................................................................................................................40
48' (44.5" Center Collar) Main Tower Parts ..................................................................................42
30' Knee Brace Tower Parts .......................................................................................................44
33' Knee Brace Tower Parts .......................................................................................................46
36' Knee Brace Tower Parts .......................................................................................................48
42' Knee Brace Tower Parts .......................................................................................................50
42' (44.5" Center Collar) Knee Brace Tower Parts ........................................................................52
48' Knee Brace Tower Parts .......................................................................................................54
48' (44.5" Center Collar) Knee Brace Tower Parts ........................................................................56
Limited Warranty — N.A. Grain Products ................................................................................59
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 3

NOTES
4PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Cautionary Symbol Definitions
▪ Safety Cautions
▪ Safety Sign-off Sheet
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is
written to help you understand safe operating procedures and problems that can be encountered by the
operator and other personnel when using this equipment. Read and save these instructions.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all
times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable regula-
tions, which must be carefully followed in all cases. Authorities having jurisdiction must be consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
ST-0001–4
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 5

Chapter 1: Safety Precautions
Cautionary Symbol Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
Table 1-1 Description of the different cautionary symbols
Symbol Description
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to personal
injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005–2
6PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

Chapter 1: Safety Precautions
Safety Cautions
Use Personal Protective Equipment
• Use appropriate personal protective equipment:
Eye
Protection
Respiratory
Protection
Foot
Protection
Hearing
Protection
Head
Protection
Fall
Protection
Hand
Protection
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004–1
Follow Safety Instructions
• Carefully read all safety messages in this manual and safety
signs on your machine. Keep signs in good condition.
Replace missing or damaged safety signs. Be sure new
equipment components and repair parts include the current
safety signs. Replacement safety signs are available from
the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
ST-0002–1
Lifting Hazard
• Single person lift can cause injury.
• Use a mechanical lifting device to lift or move the equipment
during installation.
ST-0021–2
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 7

Chapter 1: Safety Precautions
Maintain Equipment and Work Area
• Understand service procedures before doing work. Keep
area clean and dry.
• Never service equipment while it is operating. Keep hands,
feet, and clothing away from moving parts.
• Keep your equipment in proper working condition. Replace
worn or broken parts immediately.
ST-0003–1
Sharp Edge Hazard
• This product has sharp edges, which can cause serious
injury.
• To avoid injury, handle sharp edges with caution and always
use proper protective clothing and equipment.
ST-0036–2
Fall Hazard
• Ladders, stairways and platforms are for use by competent
and trained personnel only. Do not allow children or other
unauthorized persons to have access to the equipment.
• Access to the equipment must be restricted by the use of
security fencing and lockable gates.
• Lower sections of ladders must be fitted with a lockable
safety gate to prevent unauthorized access.
• Make sure that hot surfaces have had adequate time to cool
before working on or in the equipment.
• Lock out and tag out power supplies and fuel supplies to all
equipment.
• Do not attach lifting equipment to ladders or platforms.
• Do not go outside of the safety rails provided on elevated
platforms.
• Do not work at heights during high winds, rain, snow, or ice
storms.
ST-0056–1
8PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

Chapter 1: Safety Precautions
Stay Clear of Hoisted Equipment
• Always use proper lifting or hoisting equipment when assem-
bling or disassembling equipment
• Do not walk or stand under hoisted equipment.
• Always use sturdy and stable supports when needed for
installation. Not following these safety precautions creates
the risk of falling equipment, which can crush personnel and
cause serious injury or death.
ST-0047–1
Confined Space Hazards and Entry Procedures
• Note that the interior of this equipment is considered a con-
fined space. Maintenance of this equipment can require
access to the confined space.
• Access doors must be shut and locked except when access
is required.
• Doors giving access to dangerous equipment must be safety
interlocked.
• The following entry procedures must be followed:
— Be aware of all possible hazards present inside the con-
fined space and wear personal protective equipment
(PPE) as needed.
— Complete a permit to work and follow all permit required
confined space entry procedures defined by the site
manager.
— Make sure that the area has been purged of any hazard-
ous products or gases. Check the atmosphere for harm-
ful gases or vapors with a suitable gas analyzer and
make sure levels are safe before entering.
— Do not smoke or use naked flames.
— Lock out and tag out power supplies and fuel supplies to
all equipment.
— Do not work alone. Work in teams of at least three so
that help is immediately available in the event of an
emergency.
— Confirm that all personnel have safely exited the equip-
ment and tools have been recovered once work is
complete.
ST-0055–1
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 9

Chapter 1: Safety Precautions
Safety Sign-off Sheet
Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007
10 PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

2General Information
Topics Covered in this Chapter
▪ Important Notes on Use of Grain Bin Eave Towers
Important Notes on Use of Grain Bin Eave Towers
1. Grain bin eave towers should be mounted only on specific special gauge stiffener columns. It is
necessary to obtain the specific gauge sheet from GSI/AGCO Grain for the bin to which the eave
tower is installed. Use the gauge sheet to confirm the locations and placement of the special
columns. The grain bin eave towers should be installed only on those stiffener columns.
2. The owner or project manager or other responsible party must properly coordinate the construction
of the special bin stiffener columns and grain bin eave towers. Proper orientation must be
determined by the system planner for the site layout and provide instructions based on the required
orientation for the site construction documents.
3. The maximum axial load on the grain bin eave tower for the 20K versions is 40000 lbs. with each
column supporting up to a maximum of 20000 lbs. The maximum axial load for the 10K versions is
20000 lbs. with each column supporting up to a maximum of 10000 lbs. The system planner or other
parties are responsible for determining and making sure that the maximum load is not exceeded.
4. The grain bin eave towers are intended to support only vertical loads and the lateral loads are
negligible.
5. The system planner must incorporate the adequate allowance for the movement in the overall
system such as bin settlements, shrinkage and expansion after filling the bin or other related
movements so that the improper loads are not applied to the grain bin and grain bin eave towers.
6. Additional stiffener anchor provisions may be required depending on the uplift load induced by the
towers being attached. Confirm with the bin manufacturer if the uplift loads to the bin are acceptable.
7. The system planner or other responsible parties must plan for any additional loads applied on the
foundation by the addition of eave towers and provide the information of such loads to the foundation
design engineer.
8. The owner or system planner or other responsible parties must ensure the grain bin eave tower
installed is designed to accept the applied loading and compatible with the system attached to the
bin.
9. Make sure adequate measures for stability during construction and lifting of the bin as planned.
10.Additional tieback members are required for tower configurations with a single knee brace. The
tieback members will need to be checked by a qualified structural engineer to ensure they have
sufficient strength and stiffness to prevent excessive deflection of the eave tower.
11.It is required that the applied load onto the eave tower is split evenly to both catwalk diagonal
members at the support locations.
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 11

NOTES
12 PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

3Assembling the Tower
Topics Covered in this Chapter
▪ Assembling the Diagonal Bracings
▪ Assembling the Main Tower
▪ Assembling the Tower Knee Braces
▪ Connecting the Tower Knee Braces to the Main Tower
Assembling the Diagonal Bracings
Attach the diagonal bracing top clip (10) and diagonal bracing bottom clip (11) to the ends of the diagonal
bracing (13) using 7/16" x 1-1/4" HHCS bolts (1), 7/16" flat washers (5) and 7/16" flange nuts (6).
NOTE: Install nuts (6) to the inside of the bracing (13) flanges.
Figure 3-1 Assembling the diagonal bracing clips to the diagonal bracings
17/16" x 1-1/4" HHCS bolt (S-3886) 10 Diagonal bracing top clip
57/16" flat washer (S-7548) 11 Diagonal bracing bottom clip
67/16" flange nut (S-9073) 13 Diagonal bracing
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 13

Chapter 3: Assembling the Tower
Assembling the Main Tower
1. Slide the main tower leg inserts (17) into the main tower legs (15 and 16) from the top, until the top
edges are flush.
Figure 3-2 Sliding the leg insert into the main tower leg
15 Main tower left leg 17 Main tower leg insert
16 Main tower right leg
2. Assemble the horizontal bracing clips (12) to the main tower left leg (15) using 7/16" x 1-1/4" HHCS
bolts (1), 7/16" flat washers (5) and 7/16" flange nuts (6).
NOTE: Install nuts (6) to the inside of the leg (15) flanges.
Figure 3-3 Assembling the horizontal bracing clips to the main tower left leg
17/16" x 1-1/4" HHCS bolt (S-3886) 12 Horizontal bracing clip
57/16" flat washer (S-7548) 15 Main tower left leg
67/16" flange nut (S-9073)
14 PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

Chapter 3: Assembling the Tower
3. Assemble the horizontal bracing clips (12) to the main tower right leg (16) using 7/16" x 1-1/4"
HHCS bolts (1), 7/16" flat washers (5) and 7/16" flange nuts (6).
NOTE: Install nuts (6) to the inside of the leg (16) flanges.
Figure 3-4 Assembling the horizontal bracing clips to the main tower right leg
17/16" x 1-1/4" HHCS bolt (S-3886) 12 Horizontal bracing clip
57/16" flat washer (S-7548) 16 Main tower right leg
67/16" flange nut (S-9073)
4. Connect the main tower left and right legs by installing the horizontal bracings (14) to the horizontal
bracing clips (12) using 7/16" x 1-1/4" HHCS bolts (1), 7/16" flat washers (5) and 7/16" flange nuts
(6).
NOTE: Install nuts (6) to the inside of the bracing (14) flanges.
Figure 3-5 Connecting the main tower legs with horizontal bracings
17/16" x 1-1/4" HHCS bolt (S-3886) 12 Horizontal bracing clip
57/16" flat washer (S-7548) 14 Horizontal bracing
67/16" flange nut (S-9073)
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 15

Chapter 3: Assembling the Tower
5. Install the diagonal bracing clips (10 and 11) to the main tower left and right legs (15 and 16) using
7/16" x 1-1/4" HHCS bolts (1), 7/16" flat washers (5) and 7/16" flange nuts (6).
NOTE: Install nuts (6) to the inside of the leg (15 or 16) flanges.
Figure 3-6 Installing the diagonal bracing clips to the main tower legs (Detail views are shown from bottom)
17/16" x 1-1/4" HHCS bolt (S-3886) 11 Diagonal bracing bottom clip
57/16" flat washer (S-7548) 15 Main tower left leg
67/16" flange nut (S-9073) 16 Main tower right leg
10 Diagonal bracing top clip
16 PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

Chapter 3: Assembling the Tower
6. Assemble a catwalk diagonal (20) along with a catwalk lamination (21) to each side of the main
tower left and right legs (15 and 16) using 1/2" x 1-1/4" flange bolts (2) and 1/2" flange nuts (7).
NOTE:
a. Make sure to position the top flange (facing the tower legs) of the catwalk diagonal (20)
under the top flange of the catwalk lamination (21).
b. The catwalk lamination (21) is applicable only for 20K towers and not for 10K towers.
c. Install nuts (7) to the inside of the leg (15 or 16) flanges.
7. Also assemble a catwalk support brace (22) between the catwalk diagonals (20) as shown using
1/2" x 1-1/4" flange bolts (2) and 1/2" flange nuts (7).
Figure 3-7 Installing the catwalk diagonals to the main tower legs
21/2" x 1-1/4" flange bolt (S-9062) 20 Catwalk diagonal
71/2" flange nut (S-8506) 21 Catwalk lamination
15 Main tower left leg 22 Catwalk support brace
16 Main tower right leg
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 17

Chapter 3: Assembling the Tower
Assembling the Tower Knee Braces
1. Assemble the horizontal bracing clips (12) to the knee brace left leg (18) using 7/16" x 1-1/4" HHCS
bolts (1), 7/16" flat washers (5) and 7/16" flange nuts (6).
NOTE: Install nuts (6) to the inside of the leg (18) flanges.
Figure 3-8 Assembling the horizontal bracing clips to the knee brace left leg
17/16" x 1-1/4" HHCS bolt (S-3886) 12 Horizontal bracing clip
57/16" flat washer (S-7548) 18 Knee brace left leg
67/16" flange nut (S-9073)
2. Assemble the horizontal bracing clips (12) to the knee brace right leg (19) using 7/16" x 1-1/4"
HHCS bolts (1), 7/16" flat washers (5) and 7/16" flange nuts (6).
NOTE: Install nuts (6) to the inside of the leg (19) flanges.
Figure 3-9 Assembling the horizontal bracing clips to the knee brace right leg
17/16" x 1-1/4" HHCS bolt (S-3886) 12 Horizontal bracing clip
57/16" flat washer (S-7548) 19 Knee brace right leg
67/16" flange nut (S-9073)
18 PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)

Chapter 3: Assembling the Tower
3. Connect the knee brace left and right legs by installing the horizontal bracings (14) to the horizontal
bracing clips (12) using 7/16" x 1-1/4" HHCS bolts (1), 7/16" flat washers (5) and 7/16" flange nuts
(6).
NOTE: Install nuts (6) to the inside of the bracing (14) flanges.
Figure 3-10 Connecting the knee brace legs with horizontal bracings
17/16" x 1-1/4" HHCS bolt (S-3886) 12 Horizontal bracing clip
57/16" flat washer (S-7548) 14 Horizontal bracing
67/16" flange nut (S-9073)
4. Install the diagonal bracing clips (10 and 11) to the knee brace left and right legs (18 and 19) using
7/16" x 1-1/4" HHCS bolts (1), 7/16" flat washers (5) and 7/16" flange nuts (6).
NOTE: Install nuts (6) to the inside of the leg (18 or 19) flanges.
Figure 3-11 Installing the diagonal bracing clips to the knee brace legs (Detail views are shown from bottom)
17/16" x 1-1/4" HHCS bolt (S-3886) 11 Diagonal bracing bottom clip
57/16" flat washer (S-7548) 18 Knee brace left leg
67/16" flange nut (S-9073) 19 Knee brace right leg
10 Diagonal bracing top clip
PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins) 19

Chapter 3: Assembling the Tower
5. Install one catwalk support bracket (23) to the inner side of each of the knee brace legs (18 and 19)
using 1/2" x 1-1/4" flange bolts (2) and 1/2" flange nuts (7).
NOTE: Install nuts (7) to the inside of the leg (18 or 19) flanges.
Figure 3-12 Installing the catwalk support braces to the knee brace legs
21/2" x 1-1/4" flange bolt (S-9062) 19 Knee brace right leg
71/2" flange nut (S-8506) 23 Catwalk support bracket
18 Knee brace left leg
20 PNEG-2328 Grain Bin Eave Towers (30' - 48' Bins)
