Instruction Manual
HI145-00 • HI145-01
HI145-20 • HI145-30
Rugged Thermometers
with T-shaped Handle
and Cal-Check®
www.hannainst.com
HI145-00 / HI145-20
Range -50.0 to 220 °C
Resolution 0.1 °C (-50.0 to 199.9 °C)
1 °C (200 to 220 °C)
Accuracy ±0.3 °C ±1 digit (-20.0 to 90.0 °C);
±0.4% f.s. ±1digit (outside)
HI145-01 / HI145-30
Range -58.0 to 428 °F
Resolution 0.1 °F (-58.8 to 199.9 °F);
1 °F (200 to 428 °F)
Accuracy ±0.6 °F ±1 digit (-4.0 to 194.0 °F);
±0.4% f.s. ±1 digit (outside)
Common specifications
Probe
Stainless steel
HI145-00/HI145-01 125 mm x dia 5 mm
HI145-20/HI145-30 300 mm x dia 5 mm
Calibration
Check Automatic, at start-up
Battery Type
/ Life
2 x 1.5 V AAA
/ 14.000 hours of continuous use
Auto-off after 8 minutes of non-use
Environment -10 to 50 °C (14 to 122 °F); RH max 95%
Dimensions/
Weight
HI145-00/
HI145-01
92 x 165 x 38 mm / 76 g
3.6 x 6.5 x 1.5” / 2.9 oz
HI145-20/
HI145-30
92 x 340 x 38 mm / 91 g
3.6 x 13.4 x 1.5” / 3.2 oz
SPECIFICATIONS
IST145N 09/18
WARRANTY
HI145-00 , HI145-01, HI145-20 and HI145-30 are guaranteed
for two year against defects in workmanship and materials when
used for their intended purpose and maintained according to
instructions. This warranty is limited to repair or replacement
free of charge. Damage due to accidents, misuse, tampering or
lack of prescribed maintenance is not covered.
If service is required, contact your local Hanna Instruments
Office. If under warranty, report the model number, date of
purchase, serial number and the nature of the problem. If the
repair is not covered by the warranty, you will be notified of
the charges incurred. If the meter is to be returned to Hanna
Instruments, first obtain a Returned Goods Authorization number
from the Technical Service department and then send it with
shipping costs prepaid. When shipping any instrument, make
sure it is properly packed for complete protection.
All rights are reserved. Reproduction in whole or in part is prohibited
without the written consent of the copyright owner.

CALIBRATION CHECK®
Turn the meter ON by pressing ON/OFF button. The “CAL”
message on the display indicates that the meter is performing an
automatic calibration check. If the test is successful the display
will show “0”. If the calibration check fails and the meter requires
recalibration, the display will show “Err”. Contact your local Hanna
Instruments Office for recalibration. It is recommended to recalibrate
the thermometer once a year.
After performing the calibration check, the instrument will
automatically enter the normal measurement mode.
GENERAL DESCRIPTION
The HI145 thermometer series are the ideal solution for
temperature monitoring of semi-solids, such as frozen foods,
as well as applications in food preparation and during cooking.
The HI145 series is equipped with the exclusive CAL Check®
feature. When the instrument is turned on, it performs a self
check of its calibration status and display it on the LCD.
HI145-00 (°C) and HI145-01 (°F) are supplied with a 125 mm
(5”) long AISI 316 stainless steel probe. It has a conic sharp
tip which provides fast response and improved accuracy over
the entire range.
HI145-20 (°C) and HI145-30 (°F) are supplied with a 300 mm
(12”) long AISI 316 stainless steel probe and are ideal for
monitoring hot liquids in cooking applications, such as deep
frying and soup preparation.
Thank You
Thank you for choosing a Hanna Instruments product. Please
read this instruction manual carefully before using this
instrument.
For technical support, contact your local Hanna Instruments
Office or email us at [e-mail].
To find your local Hanna Instruments Office or for
additional information on Hanna Instruments products,
visit www.hannainst.com
PRELIMINARY EXAMINATION
Remove the meter from the packing material and examine it to
make sure that no damage has occurred during shipping. If there
is any damage, contact your local Hanna Instruments Office.
Each meter is supplied with batteries and instructions.
Note: Save all packing material until you are sure that the
meter functions correctly. Any defective item must
be returned in the original packing with the supplied
accessories.
TAKING MEASUREMENTS
•Insert the probe into the sample to be measured. Thanks to
the special probe shape, the insertion even into semi-solid
samples is very easy.
•Wait for a few seconds for the display to stabilize.
• To freeze the display, press the HOLD button. A blinking M
appears on the right side of the LCD to indicate that reading has
been memorized. Press any button to return to the normal mode.
• After use, switch the instrument off, or the meter automatically
turns off after 8 minutes of non-use.
Hanna Instruments reserves the right to modify the design,
construction or appearance of its products without advance notice.
CERTIFICATION
All Hanna Instruments conform to the CE European Directives.
Disposal of Electrical & Electronic Equipment. The product
should not be treated as household waste. Instead hand it over
to the appropriate collection point for the recycling of electrical
and electronic equipment which will conserve natural resources.
Disposal of waste batteries. This product contains batteries, do
not dispose of them with other household waste. Hand them over
to the appropriate collection point for recycling.
Ensuring proper product and battery disposal prevents potential
negative consequences for the environment and human health.
For more information, contact your city, your local household waste
disposal service, the place of purchase or go to www.hannainst.com.
RECOMMENDATIONS FOR USERS
Before using Hanna Instruments products, make sure that they
are entirely suitable for your specific application and for the
environment in which they are used. Any variation introduced
by the user to the supplied equipment may degrade the meter’s
performance. For yours and the instrument safety do not use or
store the instrument in hazardous environments.
PROTECTIVE CAP
The thermometers are supplied with a
protective cap, which can also be used to hold
the thermometer on the side of a vessel.
BATTERY REPLACEMENT
When the HI145 cannot be turned ON
or message “Err” appear on the display
after power ON the meter, unscrew
the two screws to access the battery
compartment and replace the two 1.5V
AAA batteries, while paying attention to
heir polarity. Batteries should be replaced
only in a safe area and using the battery type specified in this
instruction sheet.
