Top View
Vista Superior
opening in the countertop
abertura en la cubierta
countertop
cubierta
Side View of the Installed Product
Vista Lateral del Producto
Instalado
⅛"
scissors
tijeras
* “W” for White or “B” for Bone finish.
* "W" para blanco ó "B" para acabado Marfil.
Undermount Bathroom Sink
Lavabo de Bajo Cubierta
LAV MARCUS BC
S11700232E21
ing
tape measure jig saw
Recommended Tools and Materials /
Herramienta y Materiales Recomendados
Items Included in the Product /
Artículos Incluidos en el Producto
porcelain ceramic
Note: To drill the surface it is recommended to use the included
template.
incluida.
Technical Specifications / Especificaciones Técnicas
inserts, screws,
lag screw and anchors
insertos, tornillos, pijas y anclas
Measurements for Installation / Dimensiones para la Instalación
This Installation Guide Applies to the Product in any Finishing.
Esta Guía de Instalación Aplica al Producto en Cualquier Acabado.
The methylene blue substance is used in the quality assurance process of the product in order to ensure that the
product does not show any cracks or leaks. Isopropyl alcohol is used to clean methylene blue. These substances
are not harmful to human health.
La sustancia azul de metileno se utiliza en el proceso del aseguramiento de la calidad del producto con el objetivo
de asegurar que el producto no presente alguna grieta o fuga. El alcohol isopropílico se utiliza para limpiar el azul
de metileno. Estas sustancias no representan ningún daño para la salud del ser humano.
Thank you for choosing HELVEX products.
We are confident that the product reliably will exceed your highest expectations. This product's functionality,
aesthetics, durability, quality and support will grant you full satisfaction for years, thus reflecting Helvex's
commitment to quality, innovation and the environment.
Agradecemos su elección por los productos HELVEX.
Estamos seguros de que su confiabilidad por el producto excederá sus más altas expectativas, cuya
funcionalidad, estética, durabilidad, respaldo integral y alta calidad le otorgarán plena satisfacción por años,
reflejando el compromiso con la calidad, innovación y el medio ambiente que forman parte de Helvex.
To reduce the risk of injury or property damage, please read all instructions before installing the product.
Wear safety glasses. For any construction, installation, alteration, extension or repair, comply with your
local building codes. The product's illustration may vary in appearance to the actual product as result of
the continuous improvement process it is subject to.
Para disminuir el riesgo de lesiones o daños a la propiedad, lea todas las intrucciones antes de instalar el
producto. Utilice gafas de seguridad. En obras de construcción, instalación, modificación, ampliación y
reparación deben cumplir con el reglamento de construcción y obras de su localidad. El producto ilustrado
puede sufrir cambios de aspecto como resultado de la mejora continua a la que está sujeto.
WARNING / ADVERTENCIA
CAUTION: THIS PRODUCT IS FRAGILE.
TO AVOID BREAKAGE AND POSSIBLE
INJURY, HANDLE WITH CARE!.
PRECAUCIÓN: ESTE PRODUCTO ES
FRÁGIL. PARA EVITAR ROTURAS Y
POSIBLES LESIONES,¡MANÉJESE CON
CUIDADO!.
Note: According to your installation requirements,
select the Guide Line or the Maximum Limit Guide
Line for the cutout
Nota: Seleccione la Línea Guía para Recorte o la
Línea Guía para Recorte Límite Máximo, de acuerdo
con sus requerimientos ideales de instalación.
Mark the outline on the surface and cut
along the traced line to form the
opening. / Marque el contorno recortado
en la cubierta y realice el corte,
siguiendo la línea trazada, para formar
la abertura.
On the lower side of the plate or base,
mark the centers for the lag screws
or brass inserts. / Por la parte inferior
de la placa o base, marque los centros
para las pijas o insertos de latón.
brass insert
inserto de latón
On the lower side of the plate or base,
drill with 3/8” drill bit up to ½" deep and
insert the brass insert adding
epoxy adhesive (not included) at the
bottom of the hole. / Por la parte inferior
de la placa o base perfore con broca de
3/8” hasta ½” de profundidad e
introduzca el inserto de latón colocando
adhesivo epóxico (no incluido) al fondo
de la perforación.
adhesive sealant
Cut the guide line on the template and
place it over the surface to install the
sink. / Recorte la línea guía de la
plantilla y colóquela sobre la superficie
a instalar del lavabo.
Place the anchors on the marks, and
screw the lag screws (included) to fix
the sink. / Coloque las anclas a la
distancia de las marcas y enrosque las
pijas (incluidas) para fijar el lavabo.
Note: Place the sink with the overflow hole opposite to the
faucet location.
Note: Coloque el lavabo con el rebosadero al lado opuesto
de la mezcladora o monomando.
Apply adhesive sealant to the sink’s rim,
then place the sink with the anchors and
tighten the screws (included) to fix the
sink in place. / Aplique sellador adhesivo
a la ceja del lavabo, después coloque el
lavabo en posición con las anclas y
enrosque los tornillos (incluidos) para
fijarlo.
A drain stopper without overflow was installed. stopper
Liquids stay stagnant
It is very important to follow the instructions below to preserve HELVEX products
finishings, shiny and in perfect conditions:
1. Use only water and a clean cloth.
2. Do not use fibers, powders, abrasives, or chemicals.
3. Do not use sharp objects to clean the finishings.
4. It is recommended to clean your device daily
Visit our website www.helvexusa.com
Es muy importante seguir las siguientes instrucciones para conservar los
acabados de los productos HELVEX, con brillo y en perfecto estado:
1. Utilice únicamente agua y un paño limpio.
2. No utilice fibras, polvos, abrasivos, ni productos químicos.
3. No utilice objetos punzo-cortantes para limpiar los acabados.
4. Se recomienda realizar la limpieza de su producto diariamente.
Visite nuestra página www.helvexusa.com
Cleaning Recommendations / Recomendaciones de Limpieza
