1 General Information
1.1 Information about the Operating Instructions
These operating instructions provide important information about the operation and handling of the
multifunctional counter. To ensure safe operation it is vital that the safety information and instructions be
strictly observed.
For Counters with interfaces Tico 773 and Tico 774 please see the amendment 2 772 069
The multifunction counter has been designed for industrial use and for installation in machinery or industrial
plants.
The party responsible for the end use/application has the ultimate responsibility to ensure that the
multifunction counter is installed and set-up in accordance withe operating guidelines set forth in this
manual.
The manufacturer’s safety rules shall be applicable.

Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
2
06.07.2010 10:31:38
All local regulations applicable to safety and accident prevention must be adhered to for the installation and
operation of this multifunction counter.
Before starting any work on the machine/plant, the operating instructions and in particular, the Safety
chapter and the respective safety information must be fully read.
These operating instructions are an integral part of the product and must be maintained in the direct vicinity
of the machine/plant and in a place that is readily accessible for the operating staff.
7
General Information
These operating instructions contain important information concerning the installation, connection and
programming of the multifunction counter.
Description of the programming sequence:
-Programming of the basic functions
-Programming of the function codes

General
Information
Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
3
06.07.2010 10:31:38
-Programming of the user times
-Programming of the prescaler
-Programming of the presets
Before commissioning the multifunction counter, consider locking-out functions not required for regular operation.
8

Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
4
06.07.2010 10:31:38
1.2 Explanation of symbols
The warnings in these operating instructions are designated by symbols. Signal words at the beginning of the
warnings indicate the severity of a safety hazard.
These notes have to be observed by all means, and all actions have to be taken with utmost care so as to
prevent any accidents or damage or personal injury.
Danger!
This warning indicates a direct safety hazard, which may lead to serious injuries
or even death if preventative action is not taken.
Warning!
This warning indicates a possible safety hazard, which may lead to serious
injuries or even death if preventative action is not taken.
Caution!
This warning indicates a possible safety hazard, which may lead to minor damage
or injuries if preventative action is not taken.
9

General
Information
Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
5
06.07.2010 10:31:38
General Information
Note!
This symbol indicates a potentially hazardous situation, which may lead to
damage to property or to the environment if preventative action is not taken.
Tips and recommendations
This symbol is used to point out to useful tips, recommendations and information
for optimal operation.
1.3 Limitation of Liability
The information and notes contained in these operating instructions were gathered in accordance with
applicable standards and regulations, the state-of-the-art, as well our long-standing experience and know-
how.
The manufacturer shall not assume any liability for damage caused by:
-Non-adherence to the operating instructions

Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
6
06.07.2010 10:31:38
-Improper use
-Employment of unskilled or untrained personnel
-Modifications or changes to the multifunction counter
-Opening of the multifunction counter
We reserve the right to make changes or modifications to the design, specifications or options without notice.
The
10
actual product may not appear exactly as illustrated in this manual.
1.4 Copyright protection
The operating instructions must be treated confidentially and used exclusively by the personnel responsible
for the setup, maintenance, repair and operation of the machine/plant. Disclosure of these operating
instructions to any third parties is not permissible without the prior written consent of the manufacturer.
The data and information stated here, including text, drawings, images and
other illustrations, are protected by copyright laws and subject to industrial
property rights.Any misuse of such information will be subject to prosecution.

General
Information
Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
7
06.07.2010 10:31:38
1.5 Guarantee conditions
Our guarantee conditions are available for download from our homepage at www.hengstler.com –
DOWNLOAD –General Terms & Delivery Terms.
1.6 Customer Service
Our customer service is available to provide technical information and assistance for our customers. Detailed
information on your responsible contact partner is given on our homepage (www.hengstler.com) under
Contact and How to find us.
11

Safety
Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
8
06.07.2010 10:31:38
2 Safety
This section provides an overview of important consideration to ensure the safe and trouble-free operation
of your counter. Non-adherence to these instructions may result in serious injury or death.
2.1 Intended Use
The multifunctional counter is exclusively designed and constructed for the intended use and purposes
described herein.
The multifunctional counter serves together with a corresponding sensor for the counting of pieces,
lengths, flow rates, velocities and times, as well as for the controlling and monitoring of machinery and
equipment by sending control signals.
Warning!
Safety hazards due to improper use!
Using the multifunction counter for any purposes other than those described may
cause hazardous situations.

Betriebsanweisungen_772_080909 engl_überarbeitet.indd
1
9
06.07.2010 10:31:38
Claims for damages resulting from any kind of misuse shall be expressly excluded.
12
Safety 2.2 Assembly, connection, programming
The multifunction counter is built and tested in accordance with IEC/EN 61010-1, Protection Class II –Safety
Measures for Electronic Measuring Equipment. They have left the factory in a condition that is in compliance
with all safety-relevant requirements. In order to maintain this condition and ensure operational safety, the
User is required to observe the safety notes and warnings in these operating instructions.
Danger!
Risk of safety hazards due to incorrect/faulty assembly and connection.
•The max. operating voltages must not be exceeded!
•12 –24VDC and 24VAC multifunction counters must be operated at safety extra-low voltages (SELV) and
under potential-compensated conditions in order to prevent hazardous shock.
•An external fuse must be provided to protect the multifunction counter (see Chapter 10, Technical Data).

Safety
Betriebsanweisungen_772_080909 engl_überarbeitet.indd
2
0
06.07.2010 10:31:38
•Installation and assembly shall be carried out by skilled and trained electricians only.
•Do not connect or disconnect a multifunction counter while it is in contact with a live current. Always dis-
connect the main power supply before connecting or disconnecting the multifunction counter.
•Make sure that live terminals are properly protected against inadvertent contact.
13
•To ensure proper protection of terminals against hand contact, make sure that the live conductors are
properly connected to the terminals.
•The rules and regulations set forth by the local electricity providers have to be observed.
•Do not establish any connections with non-allocated (NC) terminals.
•Multifunction counters may only be operated when properly installed.
