Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined
action, you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the
screws should be tightened to the torque specified. This guarantees, that the product is mounted without tension.
Observe the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle
zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das
entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut
ist. Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
120618/180121
1
2x Zylinderschraube ISK M8x45
2x Zylinderschraube ISK M8x20
2x Sechskantschraube M8x16
4x Senkkopfschraube M6x20
4x U-Scheiben ø6,4
8x U-Scheiben ø8,4
2x selbstsichernde Muttern M8
4x Selbstsichernde Mutter M6
4x Senkscheibe M6
1x Logo H&B Ø30mm
2x allen screw M8x45
2x allen screw M8x20
2x hexagon screw M8x16
4x countersunk screw M6x20
4x washer ø6,4
8x washer ø8,4
2x self lock nut M8
4x self lock nut M6
4x countersunk washer M6
1x emblem H&B Ø30mm
Ratsche/Ratchet
Verlängerung/extension
Set
DUCATI Scrambler 1100 / Sport / Spezial
(2018-2020)
Artikel Nr.: / Item-no.:
8007566 00 01 Schwarz/black
Verbreiterung / Enlargement
1x 610053 00 01 Verbreiterungsplatte schwarz
1x 700010099 Rohradapter links
1x 700010100 Rohradapter rechts
1x 700010097 Adapterbügel hinten
1x 700010102 Schraubensatz
1x 610053 00 01 enlargement plate black
1x 700010099 tube adapter left
1x 700010100 tube adapter right
1x 700010097 rear adapter bow
1x 700010102 screw kit
INHALT
CONTENTS
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
Fastening of the rear adapter bow:
At the now free threads under the rear fender
with allen screws M8x45 and washers Ø8,4.
Fastening of the tube adapter front right/left:
At the now free threads under the seat with
hexagon screws M8x16 and washers Ø8,4.
Fastening of the tube adapter rear right/left:
At the already mounted rear adapter bow
with allen screws M8x20, washers Ø8,4 and
self lock nuts M8.
2
VORBEREITUNG
PREPARING
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2x
1
2x
2
3
2x
2x
4x
2x 2x
DUCATI Scrambler 1100 / Sport / Spezial
(2018-2020)
Artikel Nr.: / Item-no.:
8007566 00 01 Schwarz/black
Verbreiterung / Enlargement
Die beiden hinteren Schrauben im Heck (Adapter Auspuffhalterung) sowie die beiden Kunststoffstopfen zwischen Sitzbank
und Fender entfernen, diese entfallen.
Dismantle the rear original screws of the exhaust holder under the fender - screws are obsolete.
Dismantle the two original plastic plugs left and right under the seat in the fairing - they are obsolete.
Montage Adapterbügel hinten:
Die Montage erfolgt an den nun freien
Gewindebohrungen im Heckbereich mit
den Zylinderschrauben M8x45 und
U-Scheiben Ø8,4.
Montage Rohradapter vorne rechts/links:
Die Montage erfolgt in den nun freien
Gewindebohrungen mit den Sechskant-
schrauben M8x16 und U- Scheiben ø8,4.
Montage Rohradapter hinten rechts/links:
Die Montage erfolgt am bereits montierten
Adapter mit den Zylinderschrauben
M8x20, U-Scheiben ø8,4 sowie
selbstsichernden Muttern M8.
Bei gemeinsamer Montage mit dem C- Bow
werden die Zylinderschrauben M8x25 aus
dessen Schraubensatz verwendet.
When mounted together with the C-Bow, use
the allen screws M8x25 from its screw set.
Logo hier einkleben
3
Als weiteres Zubehör lieferbar:/ Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
4
4x
4x
4x4x
DUCATI Scrambler 1100 / Sport / Spezial
(2018-2020)
Artikel Nr.: / Item-no.:
8007566 00 01 Schwarz/black
Verbreiterung / Enlargement
5017566 00 01 Motorschutzbügel / Engine guard
6307566 00 01 C-Bow Halter / C-Bow holder
7007566 00 01 Lampengitter / Headlight grilles
42117566 00 91 Seitenständerplatte / Side stand enlargement
Montage der Verbreiterung:
Die Verbreiterung wird mit den
Senkkopfschrauben M6x20 und den
Senkscheiben M6 von oben auf die
montierten Rohradapter aufgesetzt.
Von unten mit den U-Scheiben Ø6,4
und den selbstsichernden Muttern M6
verschrauben.
Fastening of the enlargement:
with countersunk screws M6x20 and
countersunk washers M6 on top of the
tube adapters.
Underneath secure with washers Ø6,4
and self lock nuts M6.
