Koplus KOLO MIDI User manual

acoustic collection - kolo midi
[left hand open - outlet on right - without furniture]
koplus b.v. | koplus.eu
[email protected]
version 220415
Assembly
Instructions
KOLO
MIDI

Before we start, here are some things to be aware of:
This is the assembly instruction guide for left hand opening
door Kolo Midi without furniture.
A packaged Kolo Midi unit weights 406 kg and will
require 2-3 persons to install. It takes an average of 30 - 45
min to install Kolo Midi.
Please assemble with caution and make sure that the
installation site is protected to prevent any injuries or risks of
damaging the product and surrounding.
Position and assemble Kolo Midi as close to its final
placement as possible. If needed, a fully assembled Kolo
Midi can be repositioned by retracting its four leveling feet
and moved with its bottom rollers. When moving the unit,
DO NOT push the unit against the rollers’ direction! You
may risk tipping Kolo Midi or damaging its rollers.
Make sure you have all the required tools listed (pg. 03).
We recommend leaving at least 30 cm of space between
the wall or between multiple units of Kolo Midi.
Make sure that the Kolo Midi power source can safely
load 10amp. When the ventilation is on, LED light is at its
full lumination, and the power charging station is not in use,
the wattage usage is 14W. The power cord fuse is set at
7amp to prevent overloading.
Kolo Midi comes with 2 AC power outlets and 2 USB
charging outlets. DO NOT plug in any electronic devices
that uses over 5amp.
1.
2.
3.
4.
5.
6.
7.
8.

Required Tools
Drill 90 Degree Drill Adaptor
**Please confirm the adaptor specification
with a Koplus sale ahead of time**
Rubber Mallet
Ratchet Wrench - Metric Socket Phillips Screw Driver Allen Key Set
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 03

Part List
Tool Kit: Screw Pack Tool Kit: Power Cord
Floor Corner
Nº1-1 Nº1-2
Nº2-1
x1
x1
x1
M4x40mmL x2
Dowel Pin
Nº1-3
x8
Exterior Handle
Nº1-4
x1 Mounting Plate
Nº1-5
x2 Rose
Nº1-6
x2
Interior Handle
Nº1-7
x1
Nº1-8
Bottom Socket Cover Tile
Nº6
x1
Screw Cover Double
Nº1-10
x9
Nº1-11
Screw Cover Single
Nº1-9
x2
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 04

Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 05
Frame Corners
Nº10
x8
Horizontal Frame Covers
Nº8-2
x4
Horizontal Frames
Nº8-1
x4
Roof
Nº7
x1
Floor
Nº6
x1Side Wall
Nº5
x1Side Wall + Electric
Nº4
x1
Roof Corner
Nº3-1
x1 Roof Corner + Electric
Nº3-2
x1
Vertical Frame Covers
Nº9-2
x4
Vertical Frames
Nº9-1
x4
Floor Corner + Electric
Nº2-2
x1

Side Floor PET Tiles x2
Nº15
Glass Door
Nº13
x1
Center Floor PET Tile
Nº14
x1
Nº17
Bottom Side Panels x2
Nº16
Top Side Panels x2
Side Glass
Nº11
x2 Back Glass
Nº12
x1
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 06

Tool Kit: Screw Pack List
M8 x 50 M8 x 25 Spring Washer
M4 x 25
A / B C D
E F
x40
M4 x 30 x7
x24
x4
x40
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 07

Step 1.
Nº2-1
Floor Corner
Nº2-2
Floor Corner + Electric
Nº6
Floor
FRONT
Handle with care! Parts are NOT fully assembled
out of the packaging. Please disjoint the parts
before proceeding with the following step.
HEADS UP
M8 x 50
Bx4
Dowel Pin
Nº1-3 x4
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 08

Yellow
Green
Internet
(Yellow)
Montior
(Green)
Yellow Green
Internet
(Yellow)
Montior
(Green)
Nº4
Side Wall + Electric
Nº5
Side Wall
M8 x 50
Ax4
M8 x 50
Ax4
Step 2.
FRONT
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 09

Nº3-1
Roof Corner + Electric
Nº3-2
Roof Corner
Step 3.
FRONT
M8 x 50
Bx4
Dowel Pin
Nº1-3 x4
Nº7
Roof
Handle with care! Parts are NOT fully assembled
out of the packaging. Please disjoint the parts
before proceeding with the following step.
HEADS UP
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 10

FRONT
Step 4.
M8 x 50
Ax4
M8 x 50
Ax4
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 11

Step 5.
Nº8-1
Horizontal Frame
Spring Washer
Dx5
M8 x 25
Cx5
FRONT
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 12

Step 6.
Nº9-1
Vertical Frame
Nº10
Frame Corner
Spring Washer
Dx5
M8 x 25
Cx5
FRONT
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 13

Step 7.
Nº11
Side Glass Nº12
Back Glass
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 14

Step 8.
Nº8-2
Horizontal Frame Cover
Nº9-1
Vertical Frame
Nº10
Frame Corner
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 15

Step 9.
Nº9-1
Vertical Frame
Spring Washer
Dx5
M8 x 25
Cx5
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 16

Step 10.
Nº9-2
Vertical Frame Cover
Nº9-2
Vertical Frame Cover
Nº8-2
Horizontal Frame Cover Nº8-1
Horizontal Frame Nº10
Frame Corner
Nº10
Frame Corner
Nº10
Frame Corner
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 17

Step 11.
Spring Washer
Dx5
M8 x 25
Cx5
Koplus B.V. | Kolo Midi | Left Hand Open Door | Outlet on Right | Without Furniture | Assembly Instructions Page 18
