HiB novum NF02S3DRT30 Series User manual

Fitting Instructions
Thank you for purchasing this HiB Novum product.
Please read through these instructions carefully and refer back to
them during installation to ensure that your product is fitted safely
and that it retains its high quality finish.
GENESIS FITTED FURNITURE - DRAWERS
Top Drawer: Art No. NF02S3DRT30***
Lower Drawer (mid or bottom): Art No. NF02S3DRL30***
MBL - Midnight Blue | DEM - Dark Emerald | CGR - Carbon Grey |
MWH - Matt White | SWO - Sherwood Oak
FI#03 022 R220426 Ver 1.0 June 2022

• Please read the instructions and warnings carefully before
installing the product and ensure this document is kept with the
product for future reference, to ensure product longevity and in
the interest of safety.
• This product is intended for domestic use only.
• Not for use in saunas or steam rooms.
• Do not overload shelves or unit.
• Do not sit or stand on the unit.
• Ensure that excessive standing and surface water is removed
from the product to avoid long term damage and spoiling.
Warnings for Safe Use
Tools Required
Screwdriver
Drawer Installation and Adjustment
1. HiB recommends fixing handles to the drawer box prior to installing the
drawers.
2. Align the drawer onto the runners ensuring the rear hooks are located in the
holes on the rear of the drawer box, see Fig. 1.
3. Ensure that the locator pin on the front of the runner, see Fig. 2, is aligned with
the hole predrilled on the base of the drawer.
4. Push the drawer shut to check the alignment of the drawer. Adjust using the
adjustment wheel on the drawer runner, see Fig. 17.
5. If additional adjustment is required locate the central screw behind the drawer
front in the drawer box. Loosen the screw, adjust the drawer front into position
and then tighten the screw, see Fig. 18.
6. Push the drawer shut to finish.

Figures
Fig. 1 - Drawer Runner Rear Hooks Fig. 2 - Locator Pin & Adjustment Wheel
Fig. 3 - Drawer Front Adjustment
Locator Pin
Adjustment Wheel
1. Loosen screw
2. Adjust drawer front
3. Tighten screw

Care & Maintenance
Aftercare
Replacement components can be purchased from your retailer, quote the
article number found on the Care & Maintenance label located on your furniture
component. See example below:
In the unlikely event that this product should fail please contact the retailer from
which the item was purchased.
To preserve the high quality finish of your HiB product, please ensure you regard
the following care and cleaning recommendations:
• Use only a so damp cloth.
• Wipe off all water spillages as soon as possible.
• Do not use any abrasives or solvents.
• Ensure adequate ventilation is maintained in the bathroom.
CARE & MAINTENANCE
All cut edges must be sealed
Clean with a so, damp cloth
Do not use any abrasives or solvents
Ensure that excessive standing and surface
water is removed from the product to
avoid long term damage and spoiling
Scan for
more
information
Article No.: Batch No.:
NF02TP50CGR
