Home Styles 20 05420 94Q1 User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver, Level
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Kitchen Island
20 05420 94Q1
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Cam Lock Screw
23 pcs. (+4 extra)
Cam Lock
23 pcs. (+6 extra)
M6x38
Head Cap Bolt
6 pcs. (+1 extra)
Adjustable Pin
16 pcs. (+1 extra)
M4x32
Machine Screw
5 pcs.
Knob
5 pcs.
M3x25
Wood Screw (long)
24 pcs. (+1 extra)
M3x16
Wood Screw (short)
28 pcs. (+1 extra)
M3.5x19
Wood Screw
9 pcs. (+1 extra)
Magnet
2 pcs.
Patent 8,584,600 B2
Carton 20 05420 94Q2 and 94Q3 are also needed for assembly.
A.
Top
1 pc.
B.
Leaf Top
1 pc.

Assembly Instructions 2/8
I
Figure 2
H
STEP 1
Place Top (A), Base (C), Front Rail (E),
Back Rail (F) and Side Panels (H), (I)
on a soft cloth.
Insert Cam Lock Screws into
pre-drilled holes in Top (A),
Front Rail (E), Back Rail (F) and
Side Panels (H), (I), then tighten.
(See Figure 1)
Attach Magnets to Front Rail (E)
by inserting Wood Screws (short)
into pre-drilled holes, then tighten.
(See Figure 2)
A
C
Cam Lock Screw
E
F
Figure 1 Cam Lock Screw
Magnet
Wood Screw (short)
Cam Lock Screw
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Make sure unit is level before tightening these screws.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in the future.

Assembly Instructions 3/8
Figure 4
STEP 3
Attach unit to Side Panel (H) with
Cam Locks and Head Cap Bolts.
(See Figure 4)
STEP 2
Attach Middle Panel (J) to Front Rail (E)
and Back Rail (F) with Cam Locks.
(See Figure 3)
Attach Base (C) to unit with Cam Locks.
Figure 3
Cam Lock
E
F
J
C
H
Cam Lock
Head Cap Bolt

Assembly Instructions 4/8
STEP 4
Attach Back Rail (G) to unit with Cam Lock.
Slide Back Panel (L) into position.
Slide Upright (M) into position.
Slide Back Panel (L) into position.
M
L
G
Cam Lock
STEP 5
Attach Side Panel (I) to unit
with Cam Locks and Head Cap Bolts.
Insert Supports (N) into
pre-drilled holes in unit, then tighten.
I
Head Cap Bolt
N
N
Cam Lock
L

Assembly Instructions 5/8
Cam Lock Figure 6
Wood Screw (short)
STEP 7
Turn unit from Step 5
to its’ upright position.
Attach Dividers (K) to unit
with Cam Locks.
Attach top unit to unit
with Cam Locks.
Level unit by adjusting the
adjustable levelers on bottom
of unit. (See Figure 6)
Note: Unit must be level to proceed.
Insert Wood Screws (short) into
pre-drilled holes in unit, then tighten.
Note: Unit must be level before
tightening these screws.
K
K
STEP 6
Place Top (A) and Leaf Top (B)
upside down on a soft cloth.
Attach Leaf Top (B) to Top (A)
with Wood Screws.
(See Figure 5)
B
Wood Screw
A
Figure 5

Assembly Instructions 6/8
Q1.
Drawer Front
3 pcs.
Q2.
Drawer Back
3 pcs.
Q3.
Drawer Side
3 pcs.
Q4.
Drawer Side
3 pcs.
Q5.
Drawer Bottom
3 pcs.
Drawer (Q)
STEP 8
Attach Drawer Front (Q1) and Drawer
Back (Q2) to Drawer Side (Q3)
with Wood Screws (long).
Attach Drawer Side (Q4) to unit
with Wood Screws (long).
Q1
Q2
Q3
Q4
Bottom
Wood Screw (long)
STEP 9
Slide Drawer Bottom (Q5) into groove.
Attach Drawer Bottom (Q5) to
unit with Wood Screws (short).
Q5
Roller at back
Wood Screw (short)
Part List
STEP 10
Attach Knob with Machine Screw.
Machine Screw
Knob

Assembly Instructions 7/8
STEP 12
Slide Drawers (Q) into position.
QQQ
Figure 7 Figure 8
STEP 11
Insert Adjustable Pins into
side panels and middle panel
at desired level.
Place Shelves (D)
into position.
Attach Doors (O) and
(P) to unit by sliding
door hinges into
side panel hinges.
(See Figure 7)
Attach Knobs to
Doors (O) and (P)
with Machine Screws.
(See Figure 8)
D
D
D
D
Adjustable Pin
Machine Screw
Knob
O
P

Assembly Instructions 8/8
Top Extension Instructions
STEP 13
Lift up leaf top.
STEP 14
Holding leaf top up, pull out
a back post from unit; then
pull out other back post.
Note: Unit must be level
to work properly.

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
