Home Styles 88 5412 09 User manual

Hardware List
Part List
Tool(s) required for assembly: Phillips screwdriver, Level
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
88 5412 09
Entertainment Center
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
M.
Shelf
1 pc.
A.
Top
1 pc.
B.
Shelf
1 pc.
C.
Bottom
1 pc.
D.
Side Panel
1 pc.
E.
Side Panel
1 pc.
F.
Front Rail
1 pc.
G.
Middle Panel
1 pc.
H.
Back Rail
1 pc.
N.
Back Panel
1 pc.
J.
Door
1 pc.
K.
Door
1 pc.
L.
Shelf
1 pc.
I.
Back Panel
1 pc.
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
M6x35
Head Cap Bolt
8 pcs. (+1 extra)
Adjustable Pin
8 pcs. (+1 extra)
M4x25
Machine Screw
4 pcs.
Knob
2 pcs.
M3x16
Wood Screw
4 pcs. (+1 extra)
Magnet
2 pcs.
Flat Washer
8 pcs. (+1 extra)
Spring Washer
8 pcs. (+1 extra)

Assembly Instructions 2/5
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench in a safe place as the bolts may need to be tightened up in the future.
STEP 1
Attach Magnets to Shelf (B) with
Wood Screws. (See Figure 1)
Magnet
Figure 1
Wood Screw
B
Figure 2
STEP 2
Attach Bottom (C) and Shelf (B) to
Middle Panel (G), then flip the locks.
(See Figures 2 and 3)
G
C
B
Lock
Figure 3

Assembly Instructions 3/5
STEP 4
Attach Front Rail (F) and Back Rail (H)
to unit s., then flip the lock
Slide Back Panels (I) and (N) into place.
Attach Side Panel (D) to unit
with Flat Washers, Spring Washers
and Head Cap Bolts, then flip the locks.
Figure 4
STEP 3
Attach Side Panel (E) to unit with
Flat Washers, Spring Washers and
Head Cap Bolts, then flip the locks.
(See Figure 4)
Lock
Spring Washer
Head Cap Bolt
Flat Washer
E
N
F
I
H
Spring Washer
Head Cap Bolt
Flat Washer
Lock
D

Assembly Instructions 4/5
STEP 5
Attach Top (A) to unit .with Flat Washers, Spring Washers and Head Cap Bolts, then flip the lock
Attach Knobs to Doors (J) and (K) with Machine Screws. (See Figure 5)
Attach Doors (J) and (K) to unit by sliding the door lift hinges into the side panel lift hinges.
(See Figure 6)
Insert Adjustable Pins into middle panel and side panels at the desired level. (See Figure 7)
Place Shelves (L) and (M) into position.
Level the unit by adjusting the adjustable levelers on the bottom of legs. (See Figure 8)
Note: Unit must be level to work properly.
Figure 6 Figure 8
Figure 5
L
M
J
K
A
Adjustable Pin
Flat Washer
Head Cap Bolt
Spring Washer
Figure 7

Assembly Instructions 5/5
Drill 3/8” hole in wall
Top of unit
Hardware List
STEP 6
Drill a 3/8” hole in wall in-line with
the pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Wood Screw.
Move unit back into place.
Slide Tipover Restraint through
Bracket on wall and Bracket on unit.
(See Figure 9)
Put tie end of Tipover Restraint into lock
end of Tipover Restraint and pull until tight.
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tipover Restraint
1 pc. (+1 extra)
M3.5x40
Wall Screw
1 pc. (+1 extra)
M3.5x16
Wood Screw
1 pc. (+1 extra)
Figure 9
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Pre-drilled hole
at top of unit
Tie end
Lock end
Bracket at
top of unit
Tipover
Restraint
IMPORTANT
To help reduce the risk of the unit tipping over, the Tipover Restraint must be installed following these instructions exactly.

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
