Home Styles Storage Island 20 08000 0912 User manual

Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/16” Drill Bit, 3/8” Drill Bit
Carton 20 08000 0911 is also needed for assembly.
20 08000 0912
IMPORTANT
Storage Island
Part List
Hardware List
Cam Lock (small)
18 pcs. (+2 extra)
Plastic Cap
2 pcs. (+1 extra)
Cam Lock Screw
48 pcs. (+2 extra)
Adjustable Pin
12 pcs. (+1 extra)
Dowel
20 pcs. (+1 extra)
M3 x.5 38
Wood Screw for
Bottom
6 pcs. (+1 extra)
M3 x.5 64
Wood Screw (long)
14 pcs. (+1 extra)
Cam Lock
30 pcs. (+6 extra)
E.
Middle Panel
1 pc.
J.
Drawer
1 pc.
F.
Front Rail
2 pcs.
G.
Plinth
2 pcs.
H.
Plinth
2 pcs.
I.
Shelf
3 pcs.
M3 x.5 25
Wood Screw
15 pcs. (+1 extra)
Refer to later page(s) of these
instructions for drawer assembly.
K.
Drawer
2 pcs.

Assembly Instructions 2/8
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in the future.
STEP 1
Insert Cam Lock Screws into pre-drilled holes
in Top (A), Bottom (B), Side Panels (C), (D) and
Plinths (G), then tighten. (See Figure 1)
G
D
Cam Lock Screw
Cam Lock
AB
C
G
STEP 2
PlinthAttach s (G) to Plinths (H) with
Cam Locks. (See Figure 2)
Figure 1 Figure 2
Cam Lock Screw
G
H
GH
Cam Lock Screw

Assembly Instructions 3/8
STEP 3
Attach Side Panels (C) and (D) to Middle Panel (E)
and Front Rails (F) with Dowels and Cam Locks.
STEP 4
Attach Bottom (B) to unit with
Dowels, Cam Locks and
Wood Screws for Bottom.
F
B
D
E
F
C
Dowel
Wood Screw for Bottom
Dowel
Cam Lock
Cam Lock

Assembly Instructions 4/8
STEP 5
Attach unit from Step 2 to unit from Step 4
with Dowels and Wood Screws (long)
into pre-drilled holes.
STEP 6
Turn unit over to it’s upright position.
Attach Top (A) to unit with
Dowels and Cam Locks.
Cover Cam Locks with Plastic Caps.
(See Figure 3)
Cam Lock
Wood Screw (long)
Plastic Cap
Dowel
Figure 3
A
Dowel

Part List
Assembly Instructions 5/8
Drawer (J)
STEP 8
Slide Drawer Bottom (J5) into groove in unit.
Attach Support (J6) to unit with
Wood Screw.
J1.
Drawer Front
1 pc.
J2.
Drawer Back
1 pc.
J3.
Drawer Side
1 pc.
J4.
Drawer Side
1 pc.
J6.
Support
1 pc.
STEP 9
Insert Cam Lock Screws
into pre-drilled holes in
Drawer Front (J1),
then tighten.
Attach Drawer Front (J1) to
unit with Cam Locks (small).
STEP 7
Attach Drawer Sides (J3) and
(J4) to Drawer Back (J2) with
Wood Screws.
Cam Lock Screw
Cam Lock (small)
Wood Screw
Wood Screw
J4
J3
J1
J5.
Drawer Bottom
1 pc.
J6 J5
J2

Part List
Assembly Instructions 6/8
Drawer (K)
STEP 11
Slide Drawer Bottom (K5) into groove in unit.
Attach Support (J6) to unit with
Wood Screw.
J1.
Drawer Front
2 pcs.
J2.
Drawer Back
2 pcs.
J3.
Drawer Side
2 pcs.
J4.
Drawer Side
2 pcs.
J6.
Support
2 pcs.
STEP 12
Insert Cam Lock Screws
into pre-drilled holes in
Drawer Front (J1),
then tighten.
Attach Drawer Front (J1) to
unit with Cam Locks (small).
STEP 10
Attach Drawer Sides (J3) and
(J4) to Drawer Back (J2) with
Wood Screws.
Cam Lock Screw
Cam Lock (small)
Wood Screw
Wood Screw
J4
J3
J1
K5.
Drawer Bottom
2 pcs.
J6 K5
J2

Assembly Instructions 7/8
STEP 14
Insert Adjustable Pins into side panels
at desired level. (See Figure 5)
Place Shelves (I) into position.
STEP 13
Level unit by adjusting the adjustable levelers
on bottom of unit. (See Figure 4)
Note: Unit must be level to work properly.
Slide Drawers (J) and (K) into position.
Figure 5
K
I
K
J
I
I
Adjustable Pin
Figure 4

Assembly Instructions 8/8
Hardware List
Anchor
1 pc. (+1 extra)
Tipover Restraint
1 pc. (+1 extra)
M3.5x38
Wall Screw
1 pc. (+1 extra)
M3x16
Wood Screw
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
STEP 15
Drill a 3/16” hole 1/2” deep 1” below top
of unit in middle of side panel that is
against a wall.
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
3/16” hole drilled in side panel.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at drilled hole in
side panel of unit with Wood Screw.
Move unit back into place.
Slide Tip-over Restraint through
Bracket on wall and Bracket on unit.
(See Figure 6)
Put tie end of Tip-over Restraint into lock
end of Tip-over Restraint and pull until tight.
Drill 3/8” hole in wall
Side Panel of unit
Per regulatory requirements, a Tip-over Restraint is included. Follow Step 15 to install it.
Figure 6
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
3/16” hole in
side panel of unit
Tie end
Lock end
Bracket
on side panel
of unit
Tip-over
Restraint

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
