Honeywell Friedland HISK1 User manual

1
GlobalGuard Alarm System
HISK1
Hardware Installation and Operating Manual

2
FOREWORD
All devices in this wireless Alarm System are
designed and manufactured to provide long
reliable service. The system is designed for
ease of installation using only conventional
domestic tools. However, it is essential that the
installer reads and fully understands the advice
and procedures contained in this manual and
plans the system before proceeding with the
installation.
IMPORTANT:
LOCAL AUTHORITY REGULATIONS
AND LEGISLATION'
This alarm system should be installed and
operated in accordance with the requirements of
any current local and/or national regulations and
legislation. We recommend that you contact
your authority to obtain details of your area's
requirements local and/or national regulations.
For example in Belgium, the installation and use
of an alarm system including notification by
telephone (Voice Dialler) functionality and the
optional use of an external siren is controlled by
Belgium legislation "KB" of 19/06/2002.
DECLARATION
Novar ED&S hereby declares that this wireless
alarm system is in compliance with the essential
requirements and other relevant provisions of
the Radio and Telecommunications Terminal
Equipment (R&TTE) directive, 1999/5/EC.
Tools and Equipment Required:
No.0 Philips Screwdrivers
Bradawl
No.1 Philips Screwdrivers
Drill
No.2 Philips Screwdrivers
3mm Drill Bit
Small Spirit Level
5 & 6mm Masonry Drill Bits
DEVICE RANGE
The quoted range of the system devices (see
component specification on rear cover) is
measured in ideal conditions. Any solid object
(e.g. walls, ceilings, reinforced PVC doors etc)
placed between the transmitter and Receiver
device will reduce the radio range.
The amount by which the range will be reduced
is dependent upon the nature of the barrier. For
example:
Wall Type Range
Reduction
Dry-lined partition wall: 10-30%
Single layer brick wall: 20-40%
Double layer brick wall: 30-70%
Metal panel/radiator: 90-100%
Note: The effect on the range of multiple walls is
cumulative. i.e. if there are 2 brick walls in the
way, the range will be reduced by up to 40% by
each wall.
SYSTEM SECURITY
This system has been designed to both detect
intruders and act as a strong deterrent to would-
be intruders when installed correctly.
Please remember that given adequate
knowledge and time it is possible to overcome
any alarm system and we therefore recommend
that your Alarm is used in conjunction with good

3
physical protection such as security window and
door locks.
All units in the system are encoded to operate
together using an 20 bit rolling House Code.
The system House Code is automatically
changed each time the system is
armed/disarmed or triggered by a detector.
The system can be operated from one or more
accessory Remote Control Units and/or
Keypads. It can also be operated remotely over
the internet using a PC or mobile
device(Android/Apple IOS device). Care should
be taken to ensure that any of your Remote
Control Units are not lost or the User Access
PIN Code for the Control Panel do not become
known to other people as this will compromise
the security of your system. The User Access
PIN Code should be changed as soon as
possible.
HOME AUTOMATION CONTROL
The system allows you to create Programmes,
Schedules and Events using the GlobalGuard
PC setup software. Home automation allows you
to control wireless ON/OFF switching devices
together with security arming. There are 3
function keys I/II/III located on the side of the
Control Panel which are programmable via the
PC software and each function key can store a
Programme. The activation of a Programme can
be instantly activated simply by pressing one of
the corresponding function keys.
REMOTE ACCESS AND SYSTEM
REQUIREMENTS
This system is supplied pre-linked to an IP
gateway module which allows you to remotely
access and control your system via the internet.
In order to get the full benefits of the system,
please ensure you meet the following
requirements:
•A broadband router with x2 spare LAN ports
(x1 for IP gateway and other for an optional IP
Camera if added in future)
- An unrestricted internet broadband
connection with wired or wireless (Wifi)
connectivity. (For optional wireless
indoor CCTV accessory, Wifi will allow
you connect the camera to the router
wirelessly)
- A PC with;
•Operating System:
Windows XP/Vista/Window7
•Internet Explorer 6.x or higher Internet
Web Browser
•CPU: Pentium 4, 1GHz or above
•VGA Card Resolution: 800x600 or
above
•Video Memory Size: 128Mb or above
•Recommended internet upload speed
512kbp/s for 1 x IP Camera (optional)
or 2Mbp/s for 8 x cameras connected
Optional Android or Apple IOS
Smartphone/mobile device;
•IOS: iPhone1/2/3/4, iPad1/2, iPod
Touch 4 up to IOS V4.3. 4(latest iOS
Version release)
•Android: Android phone V2.X, tablet PC
tested up to V4.0
PROGRAMMING THE SYSTEM
The system can be setup using the instructions
in this manual or alternatively using the
GlobalGuard PC setup software available at
www.GlobalGuard.Friedland.co.uk
Note that home automation Programmes,
Events and Schedules can only programmed
using the PC software. This means that the
function keys I/II/III located on the side of the
Control Panel can only be programmed from the
PC software.
If using a PC to run the setup software then
ensure that it is connected wired or
wirelessly (WIFI) to the same internet
broadband router as that connected to the IP

4
Gateway otherwise the software will not run
correctly. If using a WIFI connection, ensure
the PC is within operating range of the router.
SECURITY DEVICES BACKWARD
COMPATIBILITY
Please note that earlier versions of the
Response branded 868MHz security PIR
movement detectors, magnetic door/window
contact detectors, remote control and remote
keypad devices are also compatible with this
system.
If you are upgrading an existing Response
868MHz wireless security system you already
purchased in the past, then you can reuse the
existing security devices installed by simply
linking one each to the GlobalGuard system.
SAFETY
Always follow the manufacturer’s advice when
using power tools; steps, ladders etc. and wear
suitable protective equipment (e.g. safety
goggles) when drilling holes etc.
Before drilling holes in walls, check for hidden
electricity cables and water pipes, the use of a
cable/pipe locater maybe advisable if in doubt.
When using ladders, ensure that they are
positioned on a firm stable surface at the correct
angle and suitably secured before use.
The use of ear defenders is advisable when
working in close proximity to the Siren due to the
high sound level produced by this device.

5
CONTENTS
KIT CONTENTS 7
INTRODUCTION AND OVERVIEW 8
Multiple Users 8
User Access PIN Code 8
System Arming 8
Entry/Exit Delay 8
Zones 9
Zone Lockout 9
Quick Set 9
Event Log 9
Chime 10
Tamper Protection 10
Jamming Detection 10
Battery Monitoring 10
Home Automation 10
PLANNING AND EXTENDING 11
YOUR ALARM SYSTEM
EXTERNAL SOLAR SIREN 14
Configuring the Solar Siren 14
Charging the Solar Siren Battery 15
CONTROL PANEL 16
Positioning the Control Panel 16
Control Panel Overview 16
Installing the Control Panel 17
IP GATEWAY 18
Installing the IP Gateway 19
LED Indications 19
Linking An IP Gateway To The
Control Panel(Optional) 19
Deleting The IP Gateway From
The Control Panel(Optional) 20
PASSIVE INFRA-RED (PIR) MOVEMENT
DETECTOR 20
Positioning the PIR Detectors 21
Installing the PIR Movement
Detector 21
Testing the PIR Detector Independently 22
Linking A PIR Detector To The Control
Panel 23
Testing the PIR Detector with the
Control Panel 24
MAGNETIC CONTACT DETECTORS 25
Positioning the Magnetic Contact
Detectors 25
Installing and Configuring the
Magnetic Contact Detectors 25
Testing A Magnetic Contact Detector
Independently 27
Linking A Magnetic Contact Detector
To The Control Panel 27
Testing the Magnetic Contact
Detector with the Control Panel 28
INSTALLING THE SOLAR SIREN AFTER
CHARGING 29
Testing the Siren from the Control
Panel 30
Mounting the Siren on the wall 31
REMOTE CONTROL UNIT (OPTIONAL
ACCESSORY) 31
Configuring the Remote Control 31
Testing the Remote Control 32
Linking a Remote Control or
Remote Keypad to the Control Panel 32
EXTERNAL CONNECTIONS 35
TESTING THE SYSTEM 37

6
DEFAULT SETTINGS 39
RESET 41
PROGRAMMING 42
User Setup 42
Learn Remote Control 44
System Setup 46
Internal Siren 47
Alarm Duration 47
Wireless Siren 47
Night Alarm 47
Warning/Error Beep 48
Jamming Detection 48
Alarm Relay 48
Zone Lockout 49
Part-Arm I Setup 49
Part-Arm II Setup 49
Fully Arm Setup 49
Holiday Arm Setup 50
Date and Time Setup 50
Learn Wireless Keypad 50
Link Panel To Friedland
Spectra Receiver (Optional) 52
Lighting Setup For Spectra Receiver 52
Security Detector/Zone Setup 53
Learn Detector Code 53
Chime 55
Part-Arm I Setup For Zone Detector 55
Part-Arm II Setup For Zone Detector 55
Detector Status 56
Detector Remove 56
Siren At Trigger 56
Entry Delay 56
Home Automation Setup 58
Home Automation Control 59
Learning a receiver 59
All Turn ON 59
Device Remote Access Control 59
Home Automation/Remote Sensor 60
Learning a transmitter 60
Communication Device Setup 61
Learning/replacing a communication
device 61
Backup & Restore 62
OPERATING INSTRUCTIONS
Fully Arming The System 62
Holiday Arming The System 63
Part-Arming The System: Part-Arm-I 64
Part-Arming The System: Part-Arm-II 64
Disarming the System 64
Disarming the System with
the Duress Code 64
Spectra Lightening 64
Quick Set 65
Home Automation Function
Keys I/II/III 65
Personal Attack (PA) Alarm 65
Zone Lockout 65
Device Tamper 66
Chime 66
Keyboard Beep Mute 66
Entry/Exit Beeps 66
Event Log 66
Siren Service/Operating Mode 67
Battery Monitoring 68
MAINTENANCE 69
ALARM RECORD 71
USER PIN CODE NOTES 72
TROUBLESHOOTING 73
EXTENDING YOUR ALARM SYSTEM 75
COMPONENT SPECIFICATION 77

7
KIT CONTENTS
The Alarm System should contain the following devices
1 x Solar Siren
1 x LCD Control Panel
1 x IP Gateway
1 x Wireless USB Dongle
1 x PIR Movement Detector
1 x Magnetic Door /Window Detector
Also included:
1 x 12VDC Power Supply Adaptor (For Control Panel
and charging Siren)
1 x 5VDC Power Supply Adaptor
1 x 0.5m Ethernet cable
Siren Mounting Template
Quick Start Guide
Fixings Pack
Batteries
Wireless IP
Gateway
Solar Siren
Control Panel
HEALTH WARNING:
Do not put the coin cell battery in your mouth as this could impair
your health. Keep this cell out of reach from young children as
they could swallow it and choke.
2 x NiMH batteries (6V for Control Panel
and 7.2V for Siren)
3V CR2032
Lithium Coin Cells
(for Door/Window
Detector)
9V PP3 Alkaline
Battery (for PIR
Movement
Detector)
PIR Movement
Detector Door/Window
Contact Detector
Ethernet cable
12V DC Power supply
adaptor
5V DC Power supply adaptor
Please visit www.GlobalGuard.Friedland.co.uk
to view an online installation video. Further
details on setup and operation can be found in
both this and the online software manual

8
INTRODUCTION AND
OVERVIEW
MULTIPLE USERS
The system allows for up to 8 Users, a Master
(Admin) and 7 Users to be configured. This
allows the system Event Log to maintain a
record of which users have armed and disarmed
the system. Each user will have a different User
Access PIN Code.
Only the Admin User has access to the
programming functions and is able to configure
the system.
USER ACCESS PIN CODE
The Control Panel is the brains of the system
and is where the system is programmed and
operated from. A 4 digit PIN code is used to
ensure that only authorized people have access
to the system. This is the User access PIN code
and can be set to a code of your choice that only
you and other authorized system users know.
SYSTEM ARMING
The system has a ‘Fully Arm’, two ‘Part-Arm’
and a ‘Holiday Arm’ modes. Fully Arm and
Holiday Arm will ‘Arm’ all zones while the ‘Part-
Arm’ modes will only arm the zones that are
enabled for the particular Part-Arm mode.
For example:
The system could be configured so that during
night time, ‘Part-Arm-I’ would arm only zones
protecting the lower floor and outbuildings
leaving the upper floor free for movement
without triggering the alarm.
During the day while the property is occupied
‘Part-Arm-II’ could arm only the zones protecting
the outbuildings. However, when the property is
left un-occupied, the ‘Fully Arm’ mode will arm
all zones to protect the entire property, (i.e.
upper and lower floors and outbuildings).
ENTRY/EXIT DELAY
When the system is armed with the Exit-Delay
enabled, no signal from any detector on an
active zone will be able to trigger an alarm until
the Exit-Delay has expired. This enables the
system to be armed from within the property and
allows time for the user to exit the property
without triggering an alarm. If the Exit-Delay is
disabled then detectors on active zones will
immediately be able to trigger an alarm once the
system is armed.
Zones1&2 only have been pre-configured
with an entry/exit delay of 30 seconds
because detectors added on these zones are
Fully & Holiday Arm
Part-Arm-I
Part-Arm-II

9
typically installed at entry/exit points of your
property.
The system Exit-Delay may be configured for
between 10 to 250 seconds or disabled
completely.
If a detector on a zone with its Entry-Delay
enabled is triggered, then an alarm will not
sound until the Entry-Delay period has expired.
This allows time for the user to re-enter the
property and disarm the system before an alarm
occurs. Generally only the zones on the main
entry route to the property will be configured with
an Entry-Delay. The remaining zones would be
configured with their Entry-Delay disabled
allowing them to immediately initiate an alarm
the instant a detector on the zone is triggered.
The Entry-Delay for each zone may be
configured for between 10 to 250 seconds or
disabled completely.
Note: To conserve power and maximize battery
life the PIR movement Detector will only detect
movement if there has been no movement
detected within the previous 2 minutes.
Consequently the PIR Detector will not become
active until the protected area has been free
from movement for more than 3 minutes.
ZONES
The system incorporates 32 wireless alarm
zones for the connection of a PIR movement or
door/window contact detector per zone used to
independently monitor different areas of the
property. In addition to standard intruder
protection, each zone can also be configured to
operate in alternative modes.
For example:
– ‘Intruder’ mode provides standard intruder
monitoring.
– ‘24-hour Intruder’ mode provides 24 hour
intruder protection for areas where continuous
monitoring is required, (e.g. gun lockers).
– ‘Fire’ mode provides 24 hour monitoring of any
Smoke detectors incorporated into the system.
– ‘Test’ mode allows a zone to be monitored
while the system is armed. If a detector on a
zone is triggered an entry will be recorded in the
Event Log but an alarm will not occur.
In addition there is the facility to connect up to 4
hard wired zones to the Control Panel, each of
which is configurable with most of the features of
the wireless zones.
ZONE LOCKOUT
If a detector on an active zone is triggered while
the system is armed an alarm will sound. After
the programmed alarm duration has expired the
alarm will stop and the system will automatically
reset.
Subsequent detectors triggered will again trigger
an alarm. If a single zone triggers an alarm more
than 3 times then that zone will be ‘Locked Out’
and any further alarm signals from that zone will
be ignored until the system is disarmed.
Note: The ‘Zone Lockout’ feature can be
disabled if required.
QUICK SET
The system may be fully armed in 10 seconds
using the quick set facility, overriding the
programmed exit-delay. This is useful for setting
the system at night when the Exit-Delay warning
beep will be silenced after just a few seconds.
EVENT LOG
The Control Panel incorporates a memory
capable of storing the last 99 system events.

10
This enables the user to see which user has
Armed/Disarmed the system and if and when
any alarms occurred. The time, date and details
of the event type will be recorded for each
system event.
CHIME
Chime is a low security facility for use when the
system is in Standby mode. If the Chime feature
is ON, and a detector on a zone that has its
Chime function enabled is triggered, the internal
sounder will produce a low volume warning tone.
A typical use of the Chime function would be to
warn that a door or particular area has been
entered.
TAMPER PROTECTION
All security related system devices (except any
Remote Control Units) incorporate Tamper
protection features to protect against
unauthorized attempts to interfere with the
device.
Any attempt to remove the battery cover from
any device (except a Remote Control) or to
remove the Solar Siren or Control Panel from
the wall will trigger the alarm even if the system
is Disarmed (unless the system is in Test or
Program modes).
JAMMING DETECTION
In order to detect any attempts to illegally jam
the radio channel used by your alarm system, a
special jamming detection function is
incorporated into the Control Panel. If this
feature is enabled, an alarm will be triggered if
the radio channel is jammed continuously for
more than 30 seconds or if the system is
jammed for more than 3 periods of 10 seconds
in a 5 minute period. At full alarm it will beep for
3 seconds and will alarm after 10 seconds. At
Part Arm it will beep for 3 seconds.
The jamming detection circuit will constantly
scan for jamming signals. However, it will also
detect and could in extreme cases be triggered
by radio signals from other radio equipment
within range operating on the same frequency
which would not interfere with the normal
operation of your alarm.
If you are planning to operate the Jamming
Detection feature we recommend that you wait
at least 30 days before activating this feature to
allow time for you to become familiar with the
operation of your system.
When activating jamming detection the system
should be monitored carefully for false jamming
alarms for at least 2 weeks before leaving the
Jamming Detection function permanently
enabled.
BATTERY MONITORING
All security devices powered by non-
rechargeable batteries incorporate a battery
level monitoring feature which will warn of a low
battery status.
In addition the Control Panel will also indicate a
low battery status on any PIR (Passive Infra-
Red) movement or Magnetic Door /Window
Detector on the system.
The batteries on any device indicating a low
battery status should be replaced immediately.
HOME AUTOMATION
This system can also accommodate up to 32
wireless receiver home automation devices.
Devices include an ON/OFF Plugin Controller or
Bayonet Lampholder.
These devices are used to simulate the
presence of occupants whilst you are away from
the home.
