Honeywell TUXWIFIS Assembly instructions

800-16571V1 7/14 Rev. A
T
Tu ux xe ed do o T To ou uc ch h
™
W Wi i- -F Fi i
®
®
Models TUXWIFIS and TUXWIFIW
Home Automation System
Installation and
Setup Guide

TRADEMARKS
Honeywell is a registered trademark of Honeywell International Inc.
Total Connect is a trademark of Honeywell International Inc.
Windows and Windows Vista are trademarks, or registered trademarks of Microsoft Corporation in the United States and other
countries.
Android™ is a trademark of Google Inc.
BlackBerry®, RIM®, Research In Motion®, and related trademarks, names, and logos are the property of Research In Motion
Limited and are registered and/or used as trademarks in the U.S., Canada, and countries around the world.
QuickTime® is a registered trademark of Apple Inc., registered in the U.S. and other countries.
iPad
®
and iPhone
®
are registered trademarks of Apple Inc.
iTunes®and iTunes Store®are registered trademarks of Apple Inc., registered in the U.S. and other countries.
All other trademarks and service marks are the properties of their respective owners.
Z-Wave devices are identified by the Z-Wave logo and can be purchased from your local
retailer.
Z-Wave
®
is a registered trademark Sigma Designs, Inc. and/or its subsidiaries.

Table of Contents
iii
About the System ............................................................................................................................ 5
Tuxedo Features ............................................................................................................................... 5
Control Panel Compatibility ............................................................................................................ 7
Programming the Control Panel ..................................................................................................... 8
Quick Programming ( IP Mode) ..................................................................................................... 8
Data Entry Keyboard ......................................................................................................................... 9
First Time Setup.............................................................................................................................. 11
First Time Power Up (Keypad Initialization) ..................................................................................... 11
Set ECP Address/RIS Automation Address ..................................................................................... 11
Operating Modes ............................................................................................................................. 12
Time/Date Setup ............................................................................................................................. 14
Power Mode Setup ........................................................................................................................... 15
Remote Access Setup ...................................................................................................................... 15
Setup a LAN Connection .................................................................................................................. 15
Setup a WLAN (Wi-Fi) Connection ................................................................................................... 16
Mounting and Wiring ...................................................................................................................... 17
Mounting .......................................................................................................................................... 17
Wiring ................................................................................................................................................ 18
Setup Menus ................................................................................................................................... 19
Brightness and Volume Control ........................................................................................................ 19
Display & Audio Setup ...................................................................................................................... 19
Language Selection (if applicable) ................................................................................................. 19
Weather Forecast ............................................................................................................................ 19
Temperature Unit ........................................................................................................................... 19
Adjust the Screen Timeouts ........................................................................................................... 20
Clean Screen .................................................................................................................................... 20
Panel Configuration ........................................................................................................................ 20
Multi-Media ...................................................................................................................................... 21
Picture Setup ................................................................................................................................... 21
Camera Setup .................................................................................................................................. 22
iewing Cameras ............................................................................................................................ 24
ideo Setup ...................................................................................................................................... 25
ideo Recording & Event iewing ................................................................................................. 25
Creating a Scene for Camera Recording ......................................................................................... 26
Manual Video Recording .................................................................................................................. 26
Security ............................................................................................................................................ 29
Screen Security ................................................................................................................................ 29
Code Authority ................................................................................................................................ 29
Device Events .................................................................................................................................. 30

Table of Contents (cont’d)
iv
User Codes ....................................................................................................................................... 30
Add a User ........................................................................................................................................ 31
NIGHT Setup Function ..................................................................................................................... 31
Output Setup Function ................................................................................................................... 32
Z-Wave Setup .................................................................................................................................. 33
Adding Z-Wave Devices .................................................................................................................. 33
Abort a Z-Wave Action ..................................................................................................................... 34
Z-Wave Factory Default .................................................................................................................. 34
Z-Wave Device List ......................................................................................................................... 34
Z-Wave Network Update ................................................................................................................ 35
Creating Scenes ............................................................................................................................... 35
Room Setup ...................................................................................................................................... 37
Group Setup ..................................................................................................................................... 37
Setting a Secondary Tuxedo Controller ......................................................................................... 38
Tuxedo Synchronization ................................................................................................................. 38
Removing a Secondary Tuxedo ....................................................................................................... 39
Remote Access ............................................................................................................................... 41
Remote Access Log In Setup (Account Setup) ............................................................................... 42
Remote Services ............................................................................................................................. 43
Using Total Connect with Tuxedo (Remote Services) ................................................................... 43
Controlling Automation (Z-Wave) Devices Remotely ................................................................... 43
Creating Scenes in Total Connect .................................................................................................. 43
iewing and Controlling Total Connect Scenes from Tuxedo ...................................................... 44
Enabling Devices for Total Connect ............................................................................................... 44
Total Connect Server Screen for Troubleshooting ........................................................................ 44
Software Updates ........................................................................................................................... 45
System Information ........................................................................................................................ 45
Keypad Diagnostics and Calibration Tests ................................................................................. 47
Calibration ......................................................................................................................................... 48
Z-Wave Test ..................................................................................................................................... 48
Keypad Reset ................................................................................................................................... 49
Factory Default ................................................................................................................................. 49
Notes and Compatible Devices ..................................................................................................... 51
Supported Camera List ..................................................................................................................... 53
Z-Wave Compatible Devices ........................................................................................................... 54
Panel Fault Displays ......................................................................................................................... 55
Specifications ................................................................................................................................... 55
Navigation Icons ............................................................................................................................... 56

5
About the System
This guide provides information to install and set-up Honeywell’s Tuxedo Touch™ Wi-Fi
®
Home
Automation and Security System (herein referred to as Tuxedo). Tuxedo is an Advanced User Interface
(AUI) device, which combines wireless home automation and security. Tuxedo connects to a ISTA
®
series control panel via the keypad (ECP) terminals.
Tuxedo Features
Feature Description
Local Wi-Fi
Access
The keypad contains a built-in web server which allows local Wi-Fi access to the
system via any web enabled device within the local Wi-Fi network.
Remote
Services
(Total
Connect
If used with a ista control panel, Tuxedo supports Remote Services for controlling
Z-Wave devices and scenes remotely from an associated Total Connect™ account
(contact an AlarmNet representative to open an account if necessary).
Remote
Access
Tuxedo’s remote access option allows the user to access Tuxedo’s menus directly via
the Internet when away from home. Up to five user logins can be created.
Z-Wave
Devices
Tuxedo supports various Z-Wave devices, including lamp modules, dimmer modules,
door locks, thermostats and shade openers.
Automation
Scenes
Define system actions to automatically start when certain conditions occur. Supports
up to 30 scenes.
Cameras iew up to four cameras at the same time. Supports up to 32 cameras.
Video iew videos from the Home screen. A video converter is required. See ideo Setup
section for details.
Security
System
Control the security system via Tuxedo menus. Offers burglary protection and may
provide fire, carbon monoxide and emergency protection.
Weather
Forecast
The *Weather forecast (if enabled) is displayed on the “Home” screen by pressing the
“Weather” feature to enter your location and temperature unit.
*Enable the weather option at: Setup > System setup > CS Setup > Options.
Software
Upgrades
To ensure you have the latest software version, tuxedo allows automatic software
upgrades (see the Software Upgrades section for details).
Switchable
Themes
Switch from normal view to mobile view depending on the type of device used with
the Tuxedo.
Output
Setup
Function
Tuxedo can activate/deactivate up to 18 pre-defined control panel output functions
(if programmed in the control panel). These output functions are typically used to
turn on lights or active relay devices.
Safe Mode In the rare event that the keypad cannot successfully communicate in its graphic
mode with the control panel, the Safe Mode is a backup mode that ensures that you
can communicate with the system. In this mode, the keypad operates much like a
standard non-graphic keypad so that you can control the system until the problem is
corrected.

About the System (cont’d)
6
Feature Description
IMPORTANT
• DO NOT perform panel programming while in the Safe Mode. Performing panel
programming while in Safe Mode may cause the panel and keypad to become out of sync.
• DO NOT use more than several hardwired motion detectors in high traffic locations. The
high quantity of signals received by the panel may cause the keypad to enter the Safe Mode.
The actual number of installed detectors depends on the amount of traffic and the number of
detectors being used. High traffic can cause Safe Mode with as few as three detectors.
Screen
Blackout
The Screen Blackout (EN50131) feature prevents unauthorized users from viewing
the status of the Security System by returning to the Home screen and turning off
the Armed and Ready status LEDs.
When the EN50131 Display is turned ON:
•Tuxedo returns to the "Home" screen after 30 seconds; "Armed" and "Ready"
LEDs turn OFF.
•The "To Homepage After" time setting changes to 30 seconds and the time is
non-selectable.
•The “Auto Slideshow After” is preset to “1” minute and cannot be changed.
•The Security, Message and Lighting screen does not display system status
until an authorized user code is entered.
•The "Setup" menu does not display system status until an authorized user code
is entered.
• ideos cannot be played.
Night Setup The NIGHT function can beset to arm the system in one of five arming modes. Refer
to the “Night Setup” section for details.
UL
•
Web server hosting is not Listed for use in UL installations.
• Remote Arming/Disarming/Programming is not to be used in UL Listed installations.
•
Wi-Fi has not been evaluated by UL.

About the System (cont’d)
7
Control Panel Compatibility
The table below lists compatible control panels and their software revision levels.
NOTE: For SIA installations used with a ISTA-128BPTSIA Control, see the SIA CP-01 Quick
Reference Chart, Document # 800-09699 located at:
http://www.security.honeywell.com/hsc/resources/MyWebTech
* Not evaluated by UL.
NOTE: Tuxedo may only be used in the following UL/cUL installations: UL 365, UL609, UL 985,
UL1023, UL 1610, CAN/ULC-S303, CAN/ULC-S304, ULC-S545, ULC/ORD-C1023, and
ANSI/SIA CP-01-2010.
To obtain the software revision level on commercial panels:
•From program mode, enter #92 on the keypad (this can be done from the Console Mode).
The second line of the keypad displays the software revision level (w/out the decimal point).
To obtain the software revision level on residential panels:
•From the Home Screen press Setup/System setup /Central Station Setup/ enter installer
code/ press the panel configuration icon; the software revision level is displayed.
•The keypad sound suppression feature available in some commercial panels is not
compatible with the Tuxedo keypad.
•The ‘Voice Chime’ feature is a residential control feature only.
NOTE: If using the maximum number of keypads, an additional auxiliary power supply may be needed.
Refer to the “Wiring” and “Specifications” section for more information.
Maximum Number of Keypads
Minimum Software
Revision Level
Alarm System
ISTA-15P, ISTA-20P, FA148CP,
FA168CPS 2 3.0
ISTA-20P, FA168CPS 4 5.0
* ISTA-21IP 4 1.0
ISTA-128BP, ISTA-250BP 3 4.4
ISTA-128BPEN 3 7.0
ISTA-128FBP, ISTA-250FBP,
FA1670C 3 4.1
ISTA-128FBPN 3 5.1
ISTA-128BPT, ISTA-250BPT, ISTA-
128BPTSIA, FA1660CT 6 10.1
FA1660C, FA1700C 3 3.0

About the System (cont’d)
8
Programming the Control Panel
The keypad is not fully operational unless its address in the control panel has been enabled (set as an
alpha console) AUI type device, and assigned to a partition (where applicable). For a list of compatible
alarm systems, refer to the “Compatibility Table” in Section 1 of this document for the quantity of
keypads that may be used and the required control panel software revision level.
We recommend that you use either a standard alpha keypad or the keypad in Console Emulation Mode
when programming the control panel. When in the Console Mode, the keypad emulates an alpha
keypad and the programming of the panel is performed following the procedures provided in your
panel’s Installation and Setup Guide.
NOTE: When programming your control panel, if you change the zone types for your emergency zones
you may disable the emergency buttons in the keypad. The emergency buttons in the keypad are active
for zone types 06 (Silent Panic Button), and 07 (Panic Button), 08 (Medical Button), and 09 (Fire
Button). Additionally, the Medical button is also compatible with a zone type 15 (24-Hour Medical) for
panels that contain this zone type.
On residential control panels (VISTA-20P or equivalent :
Up to four keypads may be used (addresses 1, 2, 5 and 6). Addresses 1 and 2 (in field *189) are enabled
by default. If the defaults have been changed, enable these addresses (in field *189) using an alpha-
keypad and the Data Field Programming procedures located in the panel Installation and Setup Guide.
On commercial control panels (VISTA-128BP, VISTA-128FBP, or equivalent :
Addresses 1-2, and 3-30 may be used for older controls under Rev. 10 supporting 3 AUI’s, see Important
Note below. Addresses 1-30 may be used for commercial Turbo controls Rev. 10 and higher supporting 6
AUI’s. These addresses in the control panel are normally not defaulted for AUI type devices. To enable
the addresses you are using for keypads, use an alpha-keypad and follow the procedures for “Device
Programming” in your control panel “Programming Guide.”
Important Note: If multiple keypads are being used, they must be set to addresses 1, 2, and X (where
X equals any address from 3 through 30). Only one AUI type device may be assigned to an address from
3 through 30 on commercial control panels.
The Keypad should not be assigned as a Master Console. If the keypad is assigned as a Master Console,
partitions must be controlled from the Partition screen or using the Console Emulation Mode.
Quick Programming (VIP Mode)
Tuxedo supports Quick Programming IP ( ista
®
Intelligent Programming) mode when used with a
control panel that supports this feature. Check the control’s manual to check if it supports this function
and for further instructions.
To access Quick Programming mode, while in Normal Mode, press the Setup > System icons.
Select the Quick Programming button: the screen displays a ”Confirmation” message: “Not every
security panel supports quick programming. Check the panels documentation to make sure it supports quick
programming. Choose Abort if the panel does not support it or Continue to enter quick programming. Choosing
Continue on unsupported panels may result in this device resetting. Continue or Abort.
Select Continue, and then enter an authorized code. An “Information” message is displayed: “Panel is
entering programming mode, please wait…“
Follow the prompts to program the control panel.

About the System (cont’d)
9
Front Panel LEDs
The Tuxedo keypad has three LEDs as follows:
6280-001-V0
FLASHING – The system contains new
message(s) for the User.
OFF – No new messages.
RESET BUTTON
Press to reset keypad
ON – System is armed.
OFF – System is not armed.
ARMED (RED) LED
READY (GREEN) LED
ON – System is disarmed and ready to arm.
OFF – System is armed or disarmed but not
ready. If disarmed, faults or troubles are present.
MESSAGE (YELLOW) LED
SD/SDHC CARD Slot
If using Occupancy mode the LEDs are as follows:
LEDs FUNCTION
COLOR STATUS Automation (Occupancy) Mode
RED ON Residential mode = system is set to AWA or NIGHT.
Commercial mode = system is set to CLOSE or NIGHT.
GREEN ON Residential mode = system is set to HOME.
Commercial mode = system is set to OPEN.
Data Entry Keyboard
Throughout this document, the user is required to enter information on the Tuxedo Keypad (i.e.,
password, device names etc.) Use the Data Entry Keyboard to enter all required information.
•Press the “up arrow” to switch to upper case characters.
• Press the Space key to add a space between characters.
•Press the x key to delete/backspace.
•Press the ABC/123 key to switch between numerals and symbols/characters.
•Press GO to return to the previous screen.

About the System (cont’d)
10
