Owner’s Manual
RAPiD®
VEHICLE SAFE
Item No. 98210
Instructional videos for Hornady Security®
products are available at hornady.com.
With patented RFID technology.

1
READ THIS FIRST
Warning: NEVER store a loaded firearm in the Hornady Security®RAPiD®
Vehicle Safe under any circumstances. The risks associated with storage of
a loaded firearm include, but are not limited to, unintentional discharge upon
insertion or removal of the firearm. Unintentional discharge may result in
bullet and safe fragments dispersing in multiple directions, which may cause
serious injury or death. Hornady Security®is not liable for any misuse of the
RAPiD®Safe.
Warning: No safe is entirely secure. The RAPiD®Safe is only as secure as
your maintenance of the keys, code and RFID tags. You are solely responsible
for maintaining your keys, code, and RFID tags. Keep your keys and RFID
tags in a secure location at all times. Store your RAPiD®Safe in a secure
location away from your keys and RFID tags. Hornady Security®is not liable
for unauthorized access, including damage to, or loss of property, or personal
injury. Again, NEVER store a loaded firearm in your Hornady®RAPiD®Safe, as
this may result in unauthorized access to the loaded firearm.
Warning: Except as expressly provided in the RAPiD®Safe Limited Warranty,
Hornady Security®is not liable for any expense or damage associated with
your inability to open the RAPiD®Safe. Electronic systems may fail. Verify that
the keys furnished operate the lock. Keep your keys in a secure location at all
times. For your security, Hornady Security®WILL NOT send replacement keys.
Warning: Hornady Security®is not liable for any loss, theft, or damage to
personal property. The RAPiD®Safe is not intended to protect the contents
from fire, water, humidity, or other environmental conditions. Do not, under
any circumstances, return the RAPiD®Safe to Hornady Security®with any
personal property inside.
Important Information
• RFID Tag refers to the chip in any of the RFID “keys” included with the
RAPiD®Safe (wristband, key fob or decals). You may also purchase
additional RFID tags.
• For trouble-free operation of your RAPiD®Safe, please read and understand
all instructions before use.
• Questions? Call our tech line at 800-338-3220.
• Never store loaded firearms in the RAPiD®Safe. Follow local laws for
firearm storage.

2
Not Pictured:
• Owner’s Manual
• Warranty Card
Table of Contents Page
Warnings and Important Information............................................................. 1
Items Included............................................................................................................. 2
Setup and Operation................................................................................................ 3
Installation.................................................................................................................... 7
Warranty......................................................................................................................... 9
Product Registration and Service................................................................... 10
Frequently Asked Questions.............................................................................. 10
Items included with your RAPiD®Safe
1. RAPiD®Vehicle Safe
2. One (1) RFID Adjustable Wristband (No. 98166)
3. Two (2) RFID Adhesive Decals (No. 98168)
4. One (1) RFID Key Fob Tag (No. 98167)
5. Two (2) Circular Barrel Keys
6. Security Cable
7. 12V Car Adapter Power Supply
(not pictured)
RAPiD®Vehicle Safe
Item No. 98210
Exterior: 12.0" x 6.4" x 2.2"
Interior: 7.5" x 5.6" x 1.7"
Power: 12 V 1.0A or four (4) AAA
batteries (not included)
U.S. Patent No. 9530266
1
2
4
5
6
3

3
Batteries
For backup or mobile use, your safe
requires four AAA batteries (not
included).
To install batteries, press the release
tab on the side of the safe while lifting
off the battery cover. Install four AAA
batteries according to the diagram
inside the battery compartment.
Replace the battery cover by inserting
the end opposite the release tab
and then snapping it into place. Only
use new high-quality AAA batteries.
Replace all batteries at the same time.
AC Power
The RAPiD®Vehicle Safe is designed
to be powered by either the 12V Car
Adapter or four AAA batteries.
To connect the 12V Car Adapter, plug
one end of the cable into your car’s 12V
accessory socket. Then, carefully run
the cable behind the safe and through
the channel in the back of the safe and
plug the cable into the power jack.
RAPiD®Safe Setup and Operation
Congratulations on purchasing the technologically advanced RAPiD®Safe. You have
taken a significant step in securing the safety of your handgun.
To achieve the best experience with your RAPiD®Safe, please read all instructions
carefully, and understand its operation.
After the RAPiD®Safe has been taken out of the box, make sure both circular barrel
keys fit and unlock your RAPiD®Safe. Contact Hornady®at 800-338-3220 if the keys do
not work. Store keys in a secure location outside the safe.
Release Tab
Power Jack

4
Battery Power Mode
When the RAPiD®Safe is unplugged and is
operating on battery power, you must press
any button on the keypad on the top panel
to activate the RFID reader.
Pressing any button on the keypad causes
the system to go from battery-saving mode
to ready status.
For example: To open your safe with an
RFID tag while the system is running on
battery power, first press any button on the
keypad to bring it to ready status. Place
your RFID tag within 1" of the center of the
RFID reader to open the safe.
Keypad Tones On/Off
Press and hold the “H” button on the keypad
for 5 seconds until the light turns off to toggle
sound on and off.
To check battery level:
1. Disconnect from the 12V Car Adapter.
2. Press any button on the keypad.
3. The LED light near the center of the
keypad will flash.
a. Flashing Green – Good battery
b. Flashing Yellow – Low battery
c. Flashing Red – Weak battery
NOTE: Replace batteries every 12 months
or if they become low or weak.
"H" Button
Keypad
RFID Reader
Battery & Latch
Status Light

5
to program an RFID tag fail, please contact
Hornady at 800-338-3220.a
6. One to five RFID tags can be programmed
into the safe.
WARNING: After programming, confirm all
RFID tags are either programmed or not. All
programmed RFID tags must be kept in a safe
place to prevent use from unauthorized users.
How to Program Your
RFID Tags
Your RAPiD®Safe includes three (3) styles
of RFID tags, including:
• 1 Adjustable Wristband
• 1 Key Fob
• 2 Decals
*Additional RFID tags can be purchased
separately.
The RAPiD®Safe can store up to 5 tags.
To program these tags:
1. Open the RAPiD Safe with either the
key, an RFID tag previously programmed
by the user or the key code. (The safe
does not ship with pre-programmed
RFID tags. An RFID tag must be
programmed by the user to work with
this safe.)
2. Locate the red program button. Press
and release the button to begin
programming an RFID tag. The first
available program location will begin to
blink.
3. Hold the RFID tag no more than 1-inch
from the illuminated RFID reader in
the center of the top panel. If the
programming was successful, the safe
should beep two times and the available
slot should go from blinking to solid red
for approximately 10 seconds.
NOTE: If the user attempts to program
an RFID tag that is already stored
into the safe, the safe will beep three
times and the RFID tag will not be
programmed into the duplicate slot. The
RFID tag can only be programmed into
one location.
4. Verify the RFID tag is programmed by
holding the tag over the RFID reader
with the safe open. The motor should
cycle after each scan.
5. If the RFID tag does not program into the
safe, the program function will time out
after 10 seconds and the safe will return
to normal operation. If multiple attempts
NOTE: The RFID chip is located in the bulge of the
wristband near the clasp. It is designed to be worn on
the bottom of the wrist for maximum read distance.
RFID Chip
RFID Reader

6
How to Program Your
Key Code
A single user-defined 4 to 6 digit code can
be programmed into the RAPiD®Safe.
1. Open the RAPiD Safe with either the key
or a previously programmed RFID tag or
key code. The safe ships with a default
code and should be reprogrammed
before first use.
2. Locate the red program button to begin
programming your key code. The first
available tag location will begin to blink
to indicate program mode.
3. With the safe open, enter a 4- to 6-digit
code into the keypad. Press the “H”
after entering your code. Verify your
code is correct by re-entering your
code and pressing “H.” The motor
should cycle.
Program Button
How to Remove All RFID Tags From Safe
1. Open the RAPiD®Safe with either
the key or a previously programmed
RFID tag or key code. Locate the red
program button. Press and hold the
button for five seconds to erase all
tags from the safe. All five red LEDs
will begin to blink in sequence. (The
safe does not allow individual tags to
be removed. They must all be erased at
one time. The intended RFID tags can
then be reprogrammed back into the
safe with the instructions above.)
NOTE: To abort the erase procedure,
press the “H” button on the keypad, or
do not touch anything, and the erase
procedure will automatically abort
after 10 seconds and return to normal
operation. Test RFID tags and the key
code to confirm they are operational.
2. To confirm erasing procedure, press
and release the program button again.
All five LED lights will blink three times
to visually confirm all RFID tags have
been removed. All RFID tags will no
longer work until they are programmed
back into the safe with the instructions
in the “How to Program Your RFID
Tags” section.
Closing the Safe
The safe has a latch closure sensor that will illuminate the LED in the keypad when
the lid is closed.
Green – Latch has fully closed.
Blinking Red – Latch has NOT fully closed.
Press lid to close or re-open and check for interference.
4. Your key code can now be used to open
the safe.
NOTE: Only one key code can be
programmed into the safe. If you attempt
to program a second code, the previous
code will be overwritten. A total of
5 RFID tags and 1 key code can be
programmed into the safe.

The vehicle mounting system includes a large mounting plate that can be wedged between
the seat and center console or between two seats in the vehicle. The inflatable air bladder
allows the mounting plate to adjust to nearly any seat gap and provide a firm mounting
location for the Vehicle Safe without modifying the vehicle.
Installing the Vehicle Safe to the Mounting System
Determine if the Vehicle Safe will be placed on the driver or passenger side of the vehicle.
Then loop the security cable around a solid anchor system near the desired mounting
location. The seat frame is typically the most accessible anchor point.
The Vehicle Safe attaches to the mounting plate
using two clamping rings. The safe ships with
one ring already attached to the back of the safe.
To attach the security cable, remove the one bolt
and nut on the clamp ring near the mounting post
with a gap. Place eye of cable ferrule between
the safe and clamp ring and replace bolt and nut.
The mounting plate is designed to wedge between
the seat and center console. The inflatable
bladder is meant to take up the space between
the seat and mounting plate so the mounting
plate is held firmly against the center console.
7

Air Bladder
Air Bladder
PASSENGER
SEAT
DRIVER
SEAT
console
console
8
Install the safe onto the mounting plate by
aligning the two clamp rings with the pins on the
mounting plate and tighten the four screws.
NOTE: The safe can be tilted forward or
back by adjusting the clamp rings BEFORE
installing the screws.
Once the safe is mounted, slide the mounting
plate between the seat and center console.
Make sure the door of the safe can open
without interfering with the seat.
Inflate the air bladder by turning the
control valve clockwise and then
squeezing the inflater bulb
until the mounting
system is firmly
in place.
• Verify the air bladder is positioned onto the
mounting plate so it will inflate against the seat.
It may need to be rotated around the mounting
plate depending on if the safe will go on the
driver or passenger side of the vehicle.
• To rotate the air bladder, release all air in
the bladder by turning the control valve
counterclockwise.
• Slide the fabric cover back to expose the air
bladder on the mounting plate. Rotate the air
bladder around the mounting plate until the
inflatable air bladder is on the correct side.
• Slide fabric cover back over the air bladder.
• Begin by verifying the inflatable bladder is on
the seat side of the mounting plate by closing
the valve on the hand pump and gently inflating
the air bladder.
WARNING:
a. Do not overinflate
the air bladder.
b. The air bladder should
be inflated just enough
to hold the mounting
system in place.
c. Make sure the mounting system does not move even during hard braking by testing in a
controlled environment.
Verify system works as expected before storing a firearm or other valuables inside the safe.

99
RAPiD®Safe Limited Warranty
Hornady Security®warrants the RAPiD®Safe will, in normal use and service,
be free from defects in workmanship or materials for one (1) year from date
of purchase.
This Limited Warranty does not cover any of the following:
(a) Damage, deterioration, or malfunction resulting from accident,
negligence, misuse, improper installation, or lack of maintenance;
(b) Any defects not discovered and reported to Hornady Security®during
the one (1) year warranty period;
(c) Usual and customary deterioration or wear resulting from normal use.
This Limited Warranty is not transferable and is enforceable by the original
owner only. In the event that Hornady Security®receives notice from the original
purchase of a warranty claim in conformity herewith, Hornady Security®will
promptly undertake an investigation of such claim. If the warranty claim is
covered by the Limited Warranty, Hornady Security,
®
will, in its sole discretion,
repair the defect(s) or replace RAPiD®Safe at the expense of Hornady Security.
®
Disclaimer of Implied Warranties. EXCEPT AS IS OTHERWISE EXPRESSLY
SET FORTH IN THE ABOVE LIMITED WARRANTY, HORNADY SECURITY®
MAKES NO OTHER REPRESENTATIONS OR WARRANTIES OF ANY KIND,
WHETHER EXPRESSED OR IMPLIED, BY OPERATION OF LAW OR OTHERWISE
WITH RESPECT TO THE RAPiD®SAFE OR ANY COMPONENT PART THEREOF,
INCLUDING WITHOUT LIMITATION ANY REPRESENTATION OR WARRANTY
WITH RESPECT TO MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR
PURPOSE OR USE.
Limitation on Liability. THE OBLIGATION OF HORNADY SECURITY®TO REPAIR
OR REPLACE AS PROVIDED ABOVE SHALL BE THE SOLE AND ONLY REMEDY
RESPECTING ANY DEFECT IN THE RAPiD®SAFE, OR ANY COMPONENT
PART THEREOF. IN THE EVENT THAT THE FOREGOING REMEDY FAILS OF ITS
ESSENTIAL PURPOSE, THE LIABILITY OF HORNADY SECURITY®TO PURCHASER
SHALL NOT, IN ANY EVENT, EXCEED THE ACTUAL PURCHASE PRICE OF THE
NON-CONFORMING GOODS; AND
Limitation on the Nature of Damages. HORNADY SECURITY®SHALL NOT,
UNDER ANY CIRCUMSTANCES, BE LIABLE TO THE PURCHASER OR ANY
THIRD PARTY FOR ANY SPECIAL, INDIRECT, INCIDENTAL, CONSEQUENTIAL,
LIQUIDATED OR PUNITIVE DAMAGES OF ANY NAME, NATURE OR
DESCRIPTION. HORNADY SECURITY®IS NOT RESPONSIBLE FOR DAMAGE TO
OR THEFT OF THE RAPiD®SAFE, OR ITS CONTENTS.

10
Product Registration and Service
You must register your RAPiD®Safe in order to obtain Warranty Service. Simply
complete and return the enclosed product registration card or submit through our
website by going to hornady.com/warranties.
To Receive Warranty Service
In order to report a warranty claim, call Hornady Security®at 800-338-3220 to request
a return authorization number. Returns will not be accepted without prior return
authorization by Hornady Security.®When a return authorization number has been
obtained, be sure all contents have been removed from the RAPiD®Safe before
sending it for service. Hornady Security®is not liable for any loss, theft, or damage to
personal property.
Post-Warranty Service Information
For issues concerning service after the Limited Warranty expires, contact Hornady
Security®at 800-338-3220.
Frequently Asked Questions
I’ve lost my keys. Can I get a replacement?
For security reasons, Hornady®WILL NOT provide replacement barrel keys for the
RAPiD®Safe. Consult a locksmith if needed.
Where can I find the serial number?
The serial number is located on the back of the safe. Prior to mounting the safe, record
the serial number for future reference.
How long should the batteries last?
Quality batteries should last approximately 12 months, depending on use.
How do I return my RAPiD® Safe for warranty work?
Call Hornady®at 800-338-3220 and one of our technicians will assist you.
Why isn’t my RFID wristband, key fob, or decals opening the safe?
• Be sure the RFID tag is programmed to your safe. The RAPiD®Safe allows five (5) RFID
tags to be programmed for use.
• Check the power source. If the unit is plugged into an electrical outlet, the green LED
light should be on. If the unit is on battery power, press the button on the top of the
safe to bring the system to ready before placing the RFID tag on the reader.

12/2017
P.O. Box 1848, Grand Island, Nebraska 68802-1848
308-382-1390 • 800-338-3220 • Fax: [phone]
www.hornady.com • Hornady.com/contact_us
17HMC0345
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This is a California-approved rearms safety device that meets
the requirements of California Penal Code Section 12088 and
the regulations issued thereunder.
This product has been tested and certied to conform to ASTM F2456, Youth Resistant
Firearms Container.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
