Hornady SnapSafe 75402 User manual

Owner’s Manual
Under Bed Safe
Item No. 75402
Customer Service: PO Box 1848, Grand Island, NE 68802-1848
1-877-214-4470 | Email: [e-mail]
586006 / REV 1 19SNAP0036 | 09/2019
Ext. Dimensions: 26.0" x 5.0" x 20.0"
Int. Dimensions: 23.5" x 3.5" x 14.3"
LOW BATTERY WARNING
If the batteries become weak, the keypad will remain red during operation.
Replace batteries immediately to ensure proper operation of the safe.
SECURITY CABLE INSTALLATION
There are holes located on both
sides of the safe for installing the
security cable.
1. Loop the cable around a secure
object and then insert the
threaded end of the cable through
the loop of the cable.
2. Remove the plastic plug on the
side of the safe.
3. Open the drawer just far enough
that the hole in the side of the
drawer aligns with the hole in the
side of the housing.
4. Insert the threaded stud into the
side of the safe and install the
nut. NOTE: The nut only needs
to be tightened until the nylon
thread lock engages.
NOTE: The drawer can be removed
to make installing the security cable
easier or to permanently bolt down
the safe.
To remove the drawer, fully extend
the drawer and then locate the
small lever inside each drawer
slide. Press up on the right lever
and down on the left lever. With the
levers pressed, carefully pull out the
drawer for removal.
To reinstall the drawer, carefully
align the slides on each side and
then press the drawer in.The levers
should click into place.
Weight: 55 Lbs
Power: 4 AA batteries (not included)
Threaded
Stud
Drawer Lever
Threaded Stud
Inserted in Housing

POWER
1. Remove key override cover by
pressing on either end of the cover.
2. Open the safe with the mechanical
override key.
3. Remove the battery cover inside
the door.
4. Insert 4 AA batteries and replace
the battery cover.
5. Do not close the door before
testing digital lock.
Note: Do not store keys in safe.
PROGRAMMING/RESET
COMBINATION CODE
Note: The safe is pre-programmed
with default code 1-2-3-4-ENTER.
You must change this code before
storing valuables to ensure the
security of the product.
1. Open the safe with either the
mechanical override key or
default code.
2. Press and hold the red program
button inside the door.The safe
will beep twice and the keypad
will blink.
3. Enter the new code (4 to 6
digits) then press and release
the program button.The keypad
should beep and blink two times.
4. Re-enter the same new code
(4 to 6 digits) then press and
release the program button.The
keypad should beep and blink
three times.
Note: If a mismatched code is
entered during programming, the
keypad will blink red and beep three
times. Return to step 2 to enter a
new code.
5. With the safe open, enter the new code followed by ENTER to confirm the
safe is working properly.The motor should cycle after each correct entry.
Note: Become comfortable with the operation of your safe before storing
anything of value inside.
OPEN SAFE BY COMBINATION CODE
Note: To save batteries, the keypad lights turn off after approximately 10
seconds of inactivity.To enter a code, the keypad must first be turned on by
pressing any of the buttons in the center of the front panel.
• With the keypad on, enter the programmed code followed by ENTER.
• When a correct code is entered, the keypad will beep and blink
blue one time.
• When an incorrect code is entered, the keypad will beep and blink red
two times. After five incorrect entries, the safe will beep and lock out
for 3 minutes.
• The safe drawer should open a few inches automatically under
spring tension.
• If five incorrect codes are entered, the safe will beep and the keypad will
deactivate for 5 minutes.The safe can only be opened with the manual key
during this time.
Note: If the safe does not open automatically, make sure the drawer front
is not blocked by an object (i.e. carpet, bedding, clothes, etc.) and check
to make sure the internal contents are not interfering with the top inside
of the safe.
TO CLOSETHE SAFE
• Push the center of the drawer until you hear the locking lugs on both sides
of the drawer lock into place.
Note: The drawer is placed under spring tension, so the last few inches
can be a little more difficult to close. Press firmly on the drawer front, but
excessive force should not be used as it may damage the drawer slides or
spring mechanism.
KEYPAD TONES ON/OFF
Press and hold the “1” button for three seconds to toggle sound ON
and OFF.
Note: Toggling the sound off will turn the keypad, program, and alarm
beeps off.Toggling the sound on will turn the keypad, program, and
alarm beeps on.
Key Override
Cover
Press here or here
to remove cover
Override Keys
Program
Button
