HPRT MPT-II User manual

-1-
-2- -3- -4-
2inch Mobile Thermal Printer
MPT-II
User Manual
1.Precauons
1.1 Safety Precauons
1）Be sure to use the specified baery and power source provided by our
company. Connecon to an improper power source may cause fire, explosion
or damage to the printer.
2）Don’t put the baery into the fire or water, don’t disassemble or
modify the baery, don’t be short circuit, otherwise may result in injury or fire
even explosion.
3）If the printer would not be used for a long me, be sure to take off the
baery, otherwise the baery may leak liquid which is corrosive, if improper
operaon causes baery leak, and the liquid is spaered on the skin or
clothes, please wash it with water, if spaered in the eyes, please rinse them
with water thoroughly and see a doctor.
4）Please do not open the paper case cover when it is prinng or just when
prinng is over, do not touch the print head with hand or body, overheat
may cause scald.
1.2 Operaon Precauons
1）Water or other liquid should not spill into the printer, also the printer should
not be appeared in the rain, or else may cause printer damage.
2）Please do not open the paper case cover when it is prinng, otherwise the
printer may work improperly.
3）If print with serial interface, should not unplug the interface cable in the
course of prinng, or else some prinng data may be lost.
4）When print in Ir or IrDA mode, be sure the Ir window of the host equipment face
rightly the Ir window of the printer, the distance should be within the range
of 50cm, and the angle should be within the range of 30°.
5）When print with Bluetooth interface, the communicaon distance
should be within 10 meters, otherwise the printer doesn’t print or prints
rubbish codes.
6）Too high（50℃）or too low（-5℃）temperature and too high (80％) or too
low (25％) relave humidity both effect the print quality.
7）The print paper in poor quality or stored for too long me also may reduce
the print quality even damage the printer.
8）In the black mark detecng mode, the printer requires that the preprinted black
mark is accordant with the black mark specificaons (details please refer to 5.2),
otherwise the black mark can not be detected correctly.
9）Be sure to use up the power of the baery before charge it, as it can ensure
the using life of the baery.
1.3 Storage Precauons
1) The printer should be placed in such an environment that the temperature is
between -40℃ and +60℃, and the relave humidity is
≤93%RH(40°C) .
2) If the printer will be stored for a long me, please be sure to take out the
baery, otherwise may damage the baery and printer.
3) Normal thermal paper can’t be kept too long, if you need to keep the receipt
for a long period, please choose long term effecve thermal paper.
4) The print paper should be keep away from high temperature environment and
point-blank sunshine.
1.4 Baery Safety Precauons
Be sure to carefully read the user manual before using the product.
Ignore the following instrucons may cause baery overheang, fire,
explosion, damage and/or performance, and reduced product life.
1) Do not allow water, sea water from entering or leaking into the
baery inside. If the baeries internal safety device burn, when charging it, it
may produce any abnormal current and/or voltage, and cause any abnormal
chemical reacon, then may cause the baery overheang, fire and/or
explosion.
2) Do not use or place the baery nearby the stove or other high temperature places.
Excessive heat maybe damage the resin shell and/or the insulaon materials,
thereby cause short-circuit inside the baery, then the baery may be caused
overheang, burning and/or explosion.
3) When charging, use a specified charger. Other condions (high
temperature, high pressure/high current, using the modified baery
charger, etc.) excluded here may result in over-charging the baery and
abnormal current and/or voltage, cause abnormal chemical reacon, and may
cause the baery overheat, light and/or explosion.
4) Baery clearly marks with posive and negave. When connect the baery
with the charger and/or printer, be sure to verify the correct baery orientaon.
Reverse inseron will cause the reverse charging andmay cause abnormal
chemical reacon, and then may cause the baery overheat, ignite, and/or
explosion.
5) Do not make the baery contact with the power outlet and/or car cigaree
lighter socket. This may cause high pressure and excessive current, and lead to
the baery overheat, burning and/or explosion.
6) Do not heat the baery or put the baery into fire. This may melt
insulaon material and/or damage safety devices or safety equipment,then
ignite electrolyc soluon, and cause the baery overheat, burning and/or
explosion.
7) Do not use the baery with contrary (+) and (-) Locaon. In the charging
process ,this will cause the reverse charging and may cause abnormal chemical
reacon. During use, may appear unpredictable current excepon, and cause the
baery overheat, ignite, and/or explosion.
8) Do not make the baery (+) and (-) contact with any metal. Also, do not
carry along or store baeries with metal objects, such as necklaces, hair clips
and so on. Baery internal short circuit may cause excessive current, and lead
to the baery overheat, ignite, and/or explosion and the adjacent metal
objects (necklaces, hairpins, etc.) may be overheang.
9) Do not throw or heavy aack the baery . If internal safety device of the
baeries burn, the baery charging may cause any abnormal current
and/or voltage, and abnormal chemical reacon, and lead to the baery
overheat, ignite, and/or explosion.
2. Brief Introducon
2.1 Appearance
2.2 Accessories
2.2.1 Standard Accessories
Li-ion Baery Paper Roll USB Cable
Leather Case
CONTENTS
1. Precauons·············································································································1
1.1 Safety Precauons··························································································1
1.2 Operaon Precauons····················································································1
1.3 Storage Precauons························································································2
1.4 Baery Safety Precauons·············································································2
2. Brief Introducon ···································································································4
2.1 Appearance ····································································································4
2.2 Accessories ····································································································4
2.1.1 Standard Accessories···········································································4
3. Specificaons..........................................................................................................5
4. Operaon Methods································································································6
4.1 Preparaon Before Using ··············································································6
4.1.1 Li-polymer Baery Installaon ····························································6
4.1.2 Paper Loading ·······················································································6
4.2 Basic Funcon································································································7
4.2.1 Printer On ·····························································································7
4.2.2 Printer Off ·····························································································7
4.2.3 Self-test ·································································································7
4.2.4 Paper Feeding ·······················································································7
4.2.5 Baery Charging ···················································································7
4.3 Interface and Prinng ···················································································8
4.3.1 Serial Interfaces ···················································································8
4.3.2 Bluetooth ·····························································································8
4.4 LED Indicator and Buzzer Definion ····························································9
4.5 Soware Tools of MPT-II ············································································10
5. Other Informaon ······························································································10
5.1 Printer Technical Manual ··········································································10
5.2 Preprinted Black Mark Specificaon·························································10
1.Power Indicator
2.Status Indicator
3.Infrared Ray (IR) Interface
4.USB Interface
5.Power Input
6.FEED Buon
7.Power On/Off
8.Top Cover
9.RS232 Interface
10.Li-ion Baery
10
9
4
5
6
2
3
8
7
1
ADD: Room 305A, Angye Building, Pioneering Park,
Torch High-tech Zone, Xiamen, China 361009
TEL: [phone]
FAX: [phone]
WEB：www.hprt.com
Xiamen Hanin Electronic Technology Co.,Ltd.

-5- -6- -7-
-10--9--8-
4. Operaon Methods
4.1 Preparaon Before Using
4.1.1 Li-polymer Baery Installaon
1) Refer to the picture, put the baery in the baery slot, please pay aenon
to the correct insert, (+) and (-).
2) Close the baery case.
4.1.2 Paper Loading
Operaon methods:
1) Use two fingers to press the place showed in the picture and open the
upper cover.
2) Put the paper into the paper case, pay aenon to the direcon of the
paper. If loaded reversely, it won’t print.
3) Pull paper out of paper case.
4) Make sure paper in the center then close upper cover.
4.2 Basic Funcon
4.2.1 Printer On
The printer is powered on by pressing the power buon; the power indicator is on
with red color whenever the printer is on.
Note: when the baer is almost exhausted, the power indicator blinks with
blue color, in this case, you must charge the baery by using the adaptor. The
method of charging the baery, please refer to 4.2.5.
4.2.2 Printer Off
The printer is off aer hold down the power buon for 2 seconds. All the
indicators are off whenever the printer is off.
4.2.3 Self-test
The self-test checks the printer’s current sengs, status and whether the printer
has any problems. Hold down the [FEED] buon while press [Power] buon about 3
seconds, the self-test begins.
The printer is ready to receive data as soon as it completes the self-test.
4.2.4 Paper Feeding
When printer works under non-blackmark mode, user could use [FEED] buon to
feed paper manually. Printer will stop feeding when reaching max feeding distance.
Max feeding distance could be set by the PC soware “MPTTools”, please refer to
your distributor for more technical informaon of “MPTTools”.
4.2.5 Baery Charging
When li-polymer baery runs out of power, blue LED indicator will flash and
buzzer will beep twice. It will power off automacally when connues prinng. If
you want to go on, please charge it.
Charging method：
The printer is connected to a computer via USB, which provides power and
collects the data.
1) Power-off charging : LED light will always indicate blue color and goes off when
fully charged.
2) Power-on charging: LED light will keep blinking in blue color, and depends on
the current state of the printer when fully changed.
Printer could be in use when charging.
Notes: Please use the manufacturers supplied baery and USB cable,
otherwise cause to printer damage and baery leakage, light and/or
explosion.
4.3 Interface and Prinng
4.3.1 Serial Interfaces
This model of printer uses DB-9 serial interface cable (one end is D model standard
serial interface socket, connected to host computer, the other end is PS/2
socket,connected to printer)
4.3.2 Bluetooth
PDA with Bluetooth interface, laptop and other informaon terminals can drive
the mobile thermal printer MPT-II instrucons as follows:
1. Power on printer.
2. Main device search for outer Bluetooth devices.
3. If there are some outer Bluetooth devices, choose “MPT-II ”.
4. Enter password “0000”.
5. Finish matching.
In pairing,mobile thermal printer MPT-II must be turned on.
Note: when pairing, do not set many printers on, otherwise it can’t figure out
which one succeeds in pairing.
Having finished pairing, other main devices (main devices) sll can pair with
mobile thermal printer. The max main devices of each printer are 8. If more
than 8, the earliest ones will be deleted from printer pairing list
automacally. If these earliest main devices want to drive printer to print and
need pairing again.
Aer pairing, main devices with virtual Bluetooth interface (smart phone , pocket
PC, palm, notebook ) can drive mobile printer MPT-II to print through such
virtual Bluetooth interface.
Status indicator
(Blue)
Power indicator
(Red)
Status
Flash OFF Power-on charging
ON OFF Power-offcharging
Flash OFF Baery low
Depends on the current state of the printer Power-on charging ,
baery full
OFF OFF Power-offcharging,
baery full
OFF ON Power on
Flash Flash Paper end
OFF Flash Standby
5. Other Informaon
5.1 Printer Technical Manual
Please refer to MPT-II technical manual.
5.2 Preprinted Black Mark Specificaon
If user wants to locate receipt by detecng preprinted black mark, shall accord to
the following specificaon for the black mark. Otherwise it may cause printer can’t
recognize the black mark.
Prinng posion: black mark shall preprint at the le side of receipt.
Width rang：≥7mm
Height：4mm≤height≤6mm
Reflecon rate to IR：<10%（reflecon rate to the black mark on paper > 65% ）
Hps：Hps indicates the distance from down edge of detecng mark from
beginning line.（0mm≤Hps≤1mm）
width
height
Hps
4.4 LED Indicator and Buzzer Definion
There are one buzzer and two LED indicators to indicate the printer status.
LED indicators indicate current status and buzzer indicates the changes of
status.
Item Parameter
Prinng
Prinng method
Resoluon
Prinng speed
Valid prinng width
Power saving
Character set
Barcode
symbologies
Graphics
Detecon
LED indicator
Power supply
Paper
Interface
Sleep mode
Font
1D
Sensors
Power indicator
Status indicator
Baery
Paper type
Paper width
Paper thickness
Paper roller diameter
Paper loading
Power supply
Thermal line prinng
203dpi, 8dots/mm
Oponal
（Bluetooth, RS232, USB）
ASCII: 12×24
GBK: 24×24
UPC-A, U PC-E, EAN8, EAN13,
CODE39, ITF,CODEBAR,CODE128,
CODE93
Support bitmap prinngwith different
densityand user defined bitmap
prinng(Max. 40K for per bitmap,
and Max. 64K for total)
Paper out detecon
2000mAh/3.7V
rechargeable Li-polymer baery
Easy loading mechanism
30~50mm/s
48mm
YES
Red
Blue
USB charging
Thermal paper
58mm
≤0.12mm
≤40mm
Physical
characteriscs
Working condion
Storage condion
-5°C~50°C , 25%~80%RH
-40°C~60°C, ≤93%RH(40°C)
Dimension
Weight
102.5×75×45mm
269g (without paper roll)
Reliability
Soware
TPH
Emulaon
Driver
50km(not more than 12.5% prinng
density)/100 million pulses
Windows XP/Vista/Win 7/ 8/ 10
ESC/POS
Oponal kits Serial interface cable, leather case
Upper cover
Platen
Use two fingers to press
this place and open the
upper cover.
3. Specificaons
There is soware which called MPTTools. It’s soware to set the printer
parameters, it used to set the baud rate of serial port, Infrared mode, Raw-IR,
VIR, SW40 Compable and IrComm, it also support seng the printer
Bluetooth device name and password, Standby Time, Sleep Time,Max Feed
Length and so on. The instrucons pls refer to MPTTools Guide.
4.5 Soware Tools of MPT-II
Buzzer Status
Once Power on
Twice Power off
Once Press [FEED] buon
Three mes Power-on charging ,Baery full
Three mes Enter to the parameter sengmode
Four mes Download the Font library
2D(oponal) QR CODE
