Read this guide carefully and follow all instructions to safely install the RoomPresence system.
General
When installing the RoomPresence, obey local safety laws and regulations. The safety
precautions of this guide are supplementary to local safety regulations.
Adhere to the safety instructions in this guide during device installation. Only trained and
qualified personnel should install or maintain the device.
Prevent device damage during storage, transportation, and operation.
Wear safety gloves when moving and lifting the RoomPresence components to prevent
from being cut by hard angles.
Do not attempt to dismantle the device by yourself. In case of a problem, contact the
official maintenance center for assistance or repair.
Electricity
The installation of the AC power supply must adhere to local safety regulations. Only
qualified personnel should install AC power supplies.
Do not wear any metal items with high conductivity, such as watches or jewelry,
during installation.
Disconnect the power supply before installing or removing power cables.
Use the labels to match cables with their corresponding connections.
Use the appropriate tools to perform high voltage AC operations.
ESD
Before beginning, wear an Electrostatic Discharge (ESD) wrist strap or gloves. Check
that the strap's other end is properly grounded to prevent ESD from damaging sensitive
components.
Safety Precautions
01

2
Tools provided with the RoomPresence:
NOTE
M6 hex socket wrench
Tools prepared by the installer:
Diagonal pliers Electric screwdriver
ESD gloves
Spirit level
Phillips screwdriver Measuring tape
Actual tools may differ.
Installation Tools
02

Item
Power supply Two or more wall-mounted power outlets (220 V/10 A or 110 V/10 A)
Two or more standard RJ45 network ports
Illuminance on the participants' faces of at least 250 lux
Color temperature approximately 4,000 K
Color rendering index (CRI) 82 R or greater
Background noise in a meeting room (with all devices turned off) 38 dB or lower
Noise after the ventilation is turned on 40 dB or lower
Distance between the microphone and the display at least 2 m
Acoustic insulation for places with noise pollution (such as doors or windows)
Network
Lighting
Noise
Requirement
Installation Environment
03
Unpacking and Check
Checking the Included Items
04
1
Before installing the RoomPresence, check that you have all of the listed components. If any
component is missing or damaged, contact your local supplier.
ComponentBox Remarks
Floor stand
Floor stand box Large box, including two small
boxes (RoomPresence 65S)/three
small boxes (RoomPresence 75S)
Small box
Small box
-
-
-
-
-
-
-
Front decorative strip box
Display mount bracket box
Cable box
Display box
Front decorative strips
Display mount brackets
Camera 200Camera 200 box
Power box container
Loudspeaker box
Box 600 & Touch box
Mic 500 box Mic 500
Box 600 & Touch
Loudspeaker
Power box
Cables & PDU
Display
3

Unpacking and Check
Checking the Included Items
04
1
Cut the straps with the diagonal pliers.
Remove the box lid.
Here, unpacking the floor stand box of the RoomPresence 75S is used as an example.
NOTE
Unpack the RoomPresence only when:
1. You are at the actual installation site.
2. Each box is intact and undamaged.
If the installation site is wrong or the boxes are damaged, contact your local supplier.
Columns, bottom bar, cable covers, screws,
and socket wrench
Columns, bottom bar, cable covers, screws, and
socket wrench
-
Camera mount bar, tray, attachment plates, display mount
bar, power adapter hangers, and rear cover plates
Camera mount bar, tray, attachment plates, display
mount bar, power adapter hangers, and support levers
Rear cover plates
RoomPresence 65S RoomPresence 75S
01
Box No.
02
03
What's in the floor stand box:
2
Unpacking
2
1
2
4

Remove the outer covering.
Unpacking and Check
Unpacking
04
2
Powering On Components
Before installing the RoomPresence, power on the listed components to check whether they
work properly.
3
Component Operation Expected Result Troubleshooting
Display Connect the power cable and
switch it on. The startup animation appears.
The indicator blinks green
before turning steady green.
The camera rotates for several seconds
before facing front. The indicator blinks
red before turning steady green after
initialization is complete.
Contact your local
supplier.
Connect the power cable
and switch it on.
Connect the power cable
and switch it on.
Box 600
Camera 200
CAUTION
1. Lift the display by both sides of its edges to avoid applying direct force on the screen.
2. After powering on the display, set the display parameters by referring to the "Configuring the HD Display" section in the
Configuration Guide.
3
5

Attaching Cable Labels
Cable Labels
05
Cable List
Distinguish cables based on their labels.
Before installing the RoomPresence, attach the correct labels for cable connection and maintenance.
1
2
Cable
2.5-meter USB
conversion cable
HDMI-HDMI
HDMI-HDMI
HDMI-HDMI
HDMI-HDMI
HD-AI-HD-AI
3.5 mm audio jack-RCA x 2
RCA x 2-RCA x 2
10-meter round network cable
10-meter flat network cable
RJ45 to VISCA
Wall outlet power cable
PDU power cable
Box 600 power cable
Video display power cable
Video display power cable
Loudspeaker power cable
Camera 200 power adapter
Camera 200 power cable
Length
2.5 m
-
3 m
10 m
3 m
10 m
10 m
10 m
2 m
10 m
10 m
2 m
3 m
1.5 m
1.5 m
1.5 m
1.5 m
1.5 m
1.5 m
1.5 m
–
1
1
1
1
1
1
1
1
1
Quantity
1
1
1
1
1
1
1
1
1
1
1
Attach Labels Onsite
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Remarks
Delivered with the Camera 200
–
Delivered with the Box 600
–
Delivered with the Mic 500
–
Delivered with the loudspeaker
–
Delivered with the Box 600
–
–
Differs depending on your country
Differs depending on your country
Differs depending on your country
Differs depending on your country
Differs depending on your country
Differs depending on your country
–
[V01]
[V02]
[V03]
[V04]
No.
[A01]
[A02]
[A04]
[P01]
[P02]
[P03]
[P04]
[P05]
[P06]
[P07]
[P08]
[P09]
[N01]
[N02]
[N03]
[U01]
External power cable of the
entire system
For RoomPresence 75S only
Differs depending on your country
For RoomPresence 65S only
Differs depending on your country
6

Here, the RoomPresence 75S is used as an example.
Start
Point
G-03
1
2
2
4
4
5
5
7
8
7
8
3
3
RL
R-75S
L-75S
26
25
28
27
27
25
10
12
11
9
14
14
15
17
18
18
19
20
21
21
22
22
23
23
24
* Note: Labels
Installation steps
X
* Note: Labels
* Note: Labels
X
Install the front decorative strips.
Install the display support levers onto the display mount bar.
Install components.
Install the cable covers on the bottom bar of the floor stand and its two columns.
Secure the rear covers to the top bar.
Secure the rear covers to the floor stand.
9
1413
12
24
15 20
21
26
27 28
25
Assemble the bottom bar.
Fasten the left and right columns to the bottom bar.
Connect the display mount bar to the left and right columns.
Install the display mount brackets.
Mount the display onto the display mount bar.
Connect the bottom tray to the left and right columns.
Insert the arc attachment plates into the top of the left and right columns.
Install the camera mount bar to the floor stand.
1
2
3
4
5
6
7
8
7 8
Installation Overview
06
-
-
-
-
-
-
6
6
16
13
13

9
Installing the Floor Stand
07
4 x M6 x 16
Assemble the bottom bar with screws.
8 x M6 x 16
Insert the left and right columns into the bottom bar, and ensure
that there is no gap at the joints. Then tighten the screws.
500 mm
500 mm
NOTE
1. Install the floor stand components in the sequence numbered on boxes. For example,
install the bottom bar and columns in box 01, then display mount bar in box 02.
2. The screws must be pre-installed and then tightened. (Torque: 28 ±10% kgf.cm)
Left column
Right column
1
2
CAUTION
A heavy device cannot be moved easily after installation.
Therefore, determine the installation position in advance. It
is recommended that the column be 500 mm away from the
wall or any object protruding from it.

10
10 x M6 x 16
Raise the display mount bar and mount it onto the attachment plates on the columns
back-to-front. Then tighten the screws.
Installing the Floor Stand
07
3
RoomPresence 65S
RoomPresence 75S
A
Install the display
mount bar
A
Install the display
mount bar
B
Install the power
adapter hanger

11
Use the screws that come with the display to secure the display mount brackets to the back
of the display through the four VESA holes.
RoomPresence 65S
RoomPresence 75S
1. To prevent scratches to the screen, clear the installation site and ensure that no obstacles or sharp objects are around
the HD display.
2. Do not apply direct force on the screen when installing the display mount brackets.
3. When mounting the display, do not use its own handles.
Installing the Display
08
CAUTION
B
1
Loosen the adjustment
screws and remove them.
Mount the brackets
onto the display back.
A
C
Install the adjustment screws
onto the brackets.

12
Two people working together are required to mount the display to its mount bar. Insert the
locating block between the column and the display. Then, adjust the position of the display
to align it closely with the locating block. After the display is installed, connect it to the
power supply.
Installing the Display
08
Front view
Rear view
2

13
Installing the Tray
09
Lift the tray and place it on the attachment plates on the columns back-to-front. Tighten
by screw type in the sequence A > B.
1
BA
R
L
4 x M6 x 16

14
Installing the Camera Mount Bar
10
8 x M6 x 16
Insert the two arc attachment plates into the top of the left and right columns respectively,
make sure all the joints are well fit, and secure them using screws.
1

15
4 x M6 x 12
Lift the camera mount bar and install it on the floor stand. Then secure the camera mount
bar using flat head screws.
Installing the Camera Mount Bar
10
CAUTION
1. Prepare a ladder or chair for tightening the screws.
2. Two people working together are required to lift the camera mount bar and place it into the floor stand.
3. Keep the support rods of the camera mount bar away from the screen to avoid damage.
2
Two people working together are
required to lift the camera mount
bar and place it into the floor stand.

Attach the left and right front decorative strips using the embedded magnet, Use the clamps
to align the upper and lower strips.
Adjust the display again to ensure that the front decorative strips are closely aligned with the
display frames.
2
3
3
4
1
2
16
Adjust the horizontal and vertical screws on the display support to ensure that the display is
framed in the floor stand.
Adjusting the Display
11
1
Push it under
the clamp.
Push it above
the clamp.

17
4
Adjusting the Display
11
Adjust the display support levers to secure the display. Then tighten the screws.
4 x M6 x 16
B
A
C
D

18
Screw in the mounting ears that come with the Box 600.
Install the Box 600 in the middle of the tray. (You only need to install the two screws on the
diagonal.)
2 x M6 x 16
Installing Components
Installing the Box 600
12
1
Rubber feet facing forward
1
2

19
Place the Camera 200 in the middle of the top bar and align it with the locating pins.
Tighten the clamps.
Installing Components
Installing the Camera 200
12
2
Place the Mic 500 microphone array and Touch on the conference table, and connect their cables by following the
instructions in Connecting Cables.
NOTE
1
2

20
4 x M4 x 3
Insert the USB connector on the tray. Then tighten the screw.
Place the two loudspeakers (L, R) on both sides of the tray.
Installing Components
Installing the USB Connector
12
3
Installing the Loudspeakers
4
1 x M4 x 20
1
1
R
L
L
R
L
