Huck BOBTAIL User manual

November 12, 2014
HK1151
INSTRUCTION MANUAL
BOBTAIL®INSTALLATION SYSTEM
SFBTT15
SFBTT15

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
2

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
3
EC DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . .2
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
PRINCIPLE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PREPARATION FOR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
TOOL TO POWERIG SET-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
WRENCHING-UP OF PIPE THREADS . . . . . . . . . . . . . . . . . . . . . . . .9
HYDRAULIC COUPLINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
DISASSEMBLY AND ASSEMBLY PREPARATION . . . . . . . . . . . . . . . . .11
TOOL ASSEMBLY DRAWINGS WITH PART NUMBERS . . . . . . . . .12-13
OPTIONAL EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
C
CONTENTS
ONTENTS

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
4
I. GENERAL SAFETY RULES:
1. A half hour long hands-on training session with qualified per-
sonnel is recommended before using Huck equipment.
2. Huck equipment must be maintained in a safe working con-
dition at all times. Tools and hoses should be inspected at the
beginning of each shift/day for damage or wear. Any repair
should be done by a qualified repairman trained on Huck pro-
cedures.
3. For multiple hazards, read and understand the safety instruc-
tions before installing, operating, repairing, maintaining,
changing accessories on, or working near the assembly
power tool. Failure to do so can result in serious bodily
injury.
4. Only qualified and trained operators should install, adjust or
use the assembly power tool.
5. Do not modify this assembly power tool. This can reduce
effectiveness of safety measures and increase operator risk.
6. Do not discard safety instructions; give them to the operator.
7. Do not use assembly power tool if it has been damaged.
8. Tools shall be inspected periodically to verify all ratings and
markings required, and listed in the manual, are legibly
marked on the tool. The employer/operator shall contact the
manufacturer to obtain replacement marking labels when
necessary. Refer to assembly drawing and parts list for
replacement.
9. Tool is only to be used as stated in this manual. Any other use
is prohibited.
10. Read MSDS Specifications before servicing the tool. MSDS
specifications are available from the product manufacturer or
your Huck representative.
11. Only genuine Huck parts shall be used for replacements or
spares. Use of any other parts can result in tooling damage or
personal injury.
12. Never remove any safety guards or pintail deflectors.
13. Never install a fastener in free air. Personal injury from fas-
tener ejecting may occur.
14. Where applicable, always clear spent pintail out of nose
assembly before installing the next fastener.
15. Check clearance between trigger and work piece to ensure
there is no pinch point when tool is activated. Remote trig-
gers are available for hydraulic tooling if pinch point is
unavoidable.
16. Do not abuse tool by dropping or using it as a hammer. Never
use hydraulic or air lines as a handle or to bend or pry the
tool. Reasonable care of installation tools by operators is an
important factor in maintaining tool efficiency, eliminating
downtime, and preventing an accident which may cause
severe personal injury.
17. Never place hands between nose assembly and work piece.
Keep hands clear from front of tool.
18. Tools with ejector rods should never be cycled with out nose
assembly installed.
19. When two piece lock bolts are being used always make sure
the collar orientation is correct. See fastener data sheet for
correct positioning.
II. PROJECTILE HAZARDS:
1. Risk of whipping compressed air hose if tool is pneudraulic
or pneumatic.
2. Disconnect the assembly power tool from energy source
when changing inserted tools or accessories.
3. Be aware that failure of the workpiece, accessories, or the
inserted tool itself can generate high velocity projectiles.
4. Always wear impact resistant eye protection during tool
operation. The grade of protection required should be
assessed for each use.
5. The risk of others should also be assessed at this time.
6. Ensure that the workpiece is securely fixed.
7. Check that the means of protection from ejection of fastener
or pintail is in place and operative.
8. There is possibility of forcible ejection of pintails or spent
mandrels from front of tool.
III. OPERATING HAZARDS:
1. Use of tool can expose the operator’s hands to hazards
including: crushing, impacts, cuts, abrasions and heat. Wear
suitable gloves to protect hands.
2. Operators and maintenance personnel shall be physically able
to handle the bulk, weight and power of the tool.
3. Hold the tool correctly and be ready to counteract normal or
sudden movements with both hands available.
4. Maintain a balanced body position and secure footing.
5. Release trigger or stop start device in case of interruption of
energy supply.
6. Use only fluids and lubricants recommended by the manu-
facturer.
7. Avoid unsuitable postures, as it is likely for these not to allow
counteracting of normal or unexpected tool movement.
8. If the assembly power tool is fixed to a suspension device,
make sure that fixation is secure.
9. Beware of the risk of crushing or pinching if nose equipment
is not fitted.
Continued on next page ...
GLOSSARY OF TERMS AND SYMBOLS:
- Product complies with requirements set forth by the rele-
vant European directives.
-READ MANUAL prior to using this equipment.
-EYE PROTECTION IS REQUIRED while using this equip-
ment.
-HEARING PROTECTION IS REQUIRED while using this
equipment.
Notes: are reminders of required procedures.
Bold, Italic type and underlining: emphasizes a specific instruction.
S
SAFETY AFETY I INSTRUCTIONS NSTRUCTIONS
CAUTIONS: show conditions that will
damage equipment and or structure.
WARNINGS: Must be understood to avoid
severe personal injury.

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
5
IV. REPETITIVE MOTION HAZARDS:
1. When using assembly power tool, the operator can experi-
ence discomfort in the hands, arms, shoulders, neck or
other parts of the body.
2. When using tool, the operator should adopt a comfortable
posture while maintaining a secure footing and avoid awk-
ward or off balanced postures.
3. The operator should change posture during extended tasks
to help avoid discomfort and fatigue.
4. If the operator experiences symptoms such as persistent or
recurring discomfort, pain, throbbing, aching, tingling,
numbness, burning sensations or stiffness, these warnings
should not be ignored. The operator should tell the
employer and consult a qualified health professional.
V. ACCESSORIES HAZARDS:
1. Disconnect tool from energy supply before changing
inserted tool or accessory.
2. Use only sizes and types of accessories and consumables
that are recommended. Do not use other types or sizes of
accessories or consumables.
VI. WORKPLACE HAZARDS:
1. Be aware of slippery surfaces caused by use of the tool
and of trip hazards caused by the air line or hydraulic
hose.
2. Proceed with caution while in unfamiliar surroundings;
there could be hidden hazards such as electricity or other
utility lines.
3. The assembly power tool is not intended for use in poten-
tially explosive environments.
4. Tool is not insulated against contact with electrical power.
5. Ensure there are no electrical cables, gas pipes, etc., which
can cause a hazard if damaged by use of the tool.
VII. NOISE HAZARDS:
1. Exposure to high noise levels can cause permanent, dis-
abling hearing loss and other problems such as tinnitus,
therefore risk assessment and the implementation of prop-
er controls is essential.
2. Appropriate controls to reduce the risk may include
actions such as damping materials to prevent workpiece
from ‘ringing’.
3. Use hearing protection in accordance with employer’s
instructions and as required by occupational health and
safety regulations.
4. Operate and maintain tool as recommended in the instruc-
tion handbook to prevent an unnecessary increase in the
noise level.
5. Select, maintain and replace the consumable / inserted tool
as recommended to prevent an unnecessary increase in
noise.
6. If the power tool has a silencer, always ensure that it is in
place and in good working order when the tool is being
operated.
VIII. VIBRATION HAZARDS:
1. Exposure to vibration can cause disabling damage to the
nerves and blood supply to the hands and arms.
2. Wear warm clothing when working in cold conditions and
keep hands warm and dry.
3. If numbness, tingling, pain or whitening of the skin in the
fingers or hands, stop using the tool, tell your employer
and consult a physician.
4. Support the weight of the tool in a stand, tensioner or bal-
ancer in order to have a lighter grip on the tool.
X. HYDRAULIC TOOL SAFETY INSTRUCTIONS:
1. Carry out a daily check for damaged or worn hoses or
hydraulic connections and replace if necessary.
2. Wipe all couplers clean before connecting. Failure to do so
can result in damage to the quick couplers and cause over-
heating.
3. Ensure that couplings are clean and correctly engaged
before operation.
4. Use only clean oil and filling equipment.
5. Power units require a free flow of air for cooling purposes
and should therefore be positioned in a well ventilated
area free from hazardous fumes.
6. Do not inspect or clean the tool while the hydraulic power
source is connected. Accidental engagement of the tool
can cause serious injury.
7. Be sure all hose connections are tight.
8. Wipe all couplers clean before connecting. Failure to do so
can result in damage to the quick couplers and cause over-
heating.
WARNING: Do not exceed maximum pull or
return settings on tool.
S
SAFETY AFETY I INSTRUCTIONS NSTRUCTIONS ( (CONTINUED CONTINUED) )

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
6
3.74
(9.5)
3.27
(8.3)
.47
(1.2)
2.16
(5.5)
2.63
(6.7)
The nose assembly is placed over the end of the fastener
until the tool's puller bottoms on the fastener. When the
trigger is pressed, a solenoid‐operated valve in the powerig
directs pressurized hydraulic fluid through the PULL hose to
the rear side of the piston and allows fluid on the RETURN
side to flow back to the tank. The piston moves forward to
start the swaging process.
After the fastener is fully swaged, the trigger must be
released, at which point the solenoid is de‐energized and the
valve directs pressurized hydraulic fluid to the front side of
the piston and allows fluid on the PULL side to flow back to
the tank. This causes the piston to move back while pushing
the anvil off of the swaged collar, releasing the tool from the
fastener.
P
PRINCIPLE
RINCIPLE
OF
OF O
OPERATION
PERATION
S
SPECIFICATIONS PECIFICATIONS
Power Source: Huck POWERIG Hydraulic Unit
Hose Kits: Use only genuine HUCK Hose Kits rated @
10,000 psi working pressure.
Hydraulic Fluid: Hydraulic fluid shall meet DEXRON III,
DEXRON VI, MERCON, Allison C‐4 or equivalent ATF
specifications. Fire resistant fluid may be used if it is an
ester based fluid such as Quintolubric HFD or equivalent.
Water based fluid shall NOT be used as serious damage
to equipment will occur.
Max Operating Temp: 125 ° F ( 51.7 ° C)
Max Flow Rate: 2 gpm ( 7.6 l/m)
Max Inlet Pull Pressure: 6,000 psi, ( 414 bar)
Max Inlet Return Pressure: 5,000 psi, ( 345 bar)
Pull Capacity: 13,960 lbf ( 62 KN)
Return Capacity: 8,940 lbf ( 40 KN)
Stroke: 1.450 inches ( 3.7 cm)
Weight: 6.0 lbs (2.72 kg)
Inches
(cm)
FIGURE 2
RETURN
PULL
Piston Piston
SECTION A-A SECTION B-B
AB
AB
FIGURE 1

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
7
1. Attach proper Nose Components to Tool as applicable.
2. Use Huck POWERIG Hydraulic Unit, or equivalent, that
has been prepared for operation per instruction manu-
al. Check both PULL and RETURN pressures and, if
required, adjust to pressures given in P PRESSURE
RESSURE
S
SETTINGS ETTINGS section of this manual.
3. First, turn hydraulic unit to OFF. Then disconnect power
supply from hydraulic unit. Disconnect trigger control
system from hydraulic unit.
4. Connect PULL pressure hose, with coupler nipple, into
port “P” of tool. Use only with HUCK supplied hoses
rated at 10,000 psi or greater. Check trigger assembly
for apparent damage or wear. If required, adjust posi-
tion of trigger assembly on hose. Connect trigger con-
trol system to hydraulic unit.
5. Connect hydraulic unit to power supply (air or electric).
Turn hydraulic unit to ON. Depress trigger a few times
to cycle tool and to circulate hydraulic fluid. Observe
action of Tool and check for leaks.
P
PREPARATION
REPARATION
FOR
FOR U
USE
SE
WARNINGS:
Read full manual before using tool.
A half-hour training session with qualified
personnel is recommended before using
Huck equipment.
When operating Huck installation equip-
ment, always wear approved eye protec-
tion.
Be sure there is adequate clearance for
the operator’s hands before proceeding.
CAUTION: Do not use TEFLON®* tape on
pipe threads. Pipe threads may cause tape to
shred resulting in tool malfunction.
(Threadmate™ is available from Huck in a
4oz. tube as part number 508517.)
WARNING: Correct PULL and RETURN
pressures are required for operator’s
safety and for Installation TooI’s function.
Gauge T-124833CE is available for check-
ing pressures. See P PRESSURE
RESSURE S SETTINGS ETTINGS
and Gauge Instruction Manual. Failure to
verify pressures may result in severe per-
sonal injury.
WARNING: Be sure to connect Tool’s
hydraulic hoses to POWERIG Hydraulic
Unit before connecting Tool’s switch con-
trol cord to unit. If not connected in this
order, severe personal Injury may occur.
WARNING: Huck recommends that only
Huck Powerig Hydraulic Units be used as
a power source for Huck installation
equipment. Hydraulic power units that
deliver high pressure for both PULL and
RETURN, AND ARE NOT EQUIPPED
WITH RELIEF VALVES ARE SPECIFICAL-
LY NOT RECOMMENDED AND MAY BE
DANGEROUS.
Threadmate is a registered trademark of Parker Intangibles LLC.
TEFLON is a registered trademark of E. I. du Pont de Nemours and Company
CAUTION: Do not let disconnected hoses
and couplers contact a dirty floor. Keep
harmful material out of hydraulic fluid. Dirt in
hydraulic fluid causes valve failure In Tool
and In POWERIG Hydraulic Unit.
CAUTION: Hose couplers must be completely
joined together to insure that ball checks in
both nipple and body are completely open.
Improperly assembled couplers will cause
overheating and malfunctions in both tool
and Powerig. Hand tighten couplers. Do NOT
use a pipe wrench.

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
8
SFBTT15
HUCK 918 Powerig® Shown
To primary power source
Hose Assembly
(See O OPTIONAL PTIONAL E EQUIPMENT QUIPMENT
section of this manual
for part numbers.)
TOOL 1
TOOL 1
CAUTION
CAUTION
ON
OFF
POWERIG HYDR ULIC UNIT
C UTIO N
TOOL 2 1 VAC
24 VAC
TOOL 2
C UTIO N
C UTIO N
C UTIO N
C UTIO N
C UTIO N
T
TOOL
OOL
TO
TO P
POWERIG
OWERIG S
SETUP
ETUP
NOTE: To decrease Relief Valve pressure, turn
the Relief Valve handle gradually counterclock-
wise; turn clockwise to increase pressure.
1. With the Nose Assembly in place on the
Installation Tool, begin setup. First connect the
Hydraulic Hoses to the Powerig.
2. Connect the other end of the Hose Assembly to
the installation tool.
3. Connect the Power Cord from the Tool to the
Hose Assembly.
4. Connect the Power Cord from the Hose Assembly
to the Powerig.
5. Set Pull and Return pressures on Powerig and
Relief Valve using Huck Gage P/N: T-124833CE
and Table 1.
6. Once the system is set up, install test fastener.
Check to be sure that the fastener is installed
correctly. This can be checked by inspecting the
dimples on the collar flange. At least one dimple
should be marked by the anvil.
Fastener Size Fastener
Grade
Powerig PULL
Pressure Setting
Powerig RETURN
Pressure Setting
1/2” (‐16) 53900 psi (269 bar) 1700 psi (117 bar)
1/2” (‐16) 85600 psi (386 bar) 2400 (165 bar)
Table 1 - Pressure Settings
Table 1 - Pressure Settings
WARNING: To prevent tripping hazard, sus-
pend tools and route hoses off of floors.
WARNING: Only use compatible equipment
with this tool.
FIGURE 3

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
9
W
WRENCHING RENCHING- -UP UP OF OF P PIPE IPE T THREADS HREADS
The following table pertains to 1/8, 1/4, and 3/8 NPTF joints in this product. All turn counts listed are beyond
hand-tight. Teflon stick or equivalent (NOT tape) must be used without exception.
Pipe Thread Size Number of Turns
1/8 NPTF 2 - 2 1⁄4
1/4 NPTF 1 1⁄2 - 1 3⁄4
3/8 NPTF 1 1⁄2 - 1 3⁄4
Table 2
H
HYDRAULIC YDRAULIC C COUPLINGS OUPLINGS
GENERAL
■ Operators should receive training from qualified
personnel.
■ Do not bend tool to free if stuck.
■ Tool should only be used to install fasteners.
■ NEVER use as a jack/spreader or hammer.
TO INSTALL A BOBTAIL FASTENER:
1. Check work and remove excessive gap. (Gap is the
space between sheets. Gap is excessive if not
enough pintail sticks through the collar for the nose
assembly puller to grab onto).
2. Put BOBTAIL pin in hole.
3. Slide BOBTAIL collar over pin. (The flanged end of the
collar must be towards the pieces being fastened.)
4. Push nose assembly onto the pin until the nose
assembly puller stops against the pin. Tool and nose
assembly must be held at right angles (90 degrees) to
the work.
5. Depress tool trigger to start installation cycle.
6. When forward motion of nose assembly anvil stops,
release trigger. Tool will go into its return stroke and
push off the installed fastener.
7. The tool and nose assembly are ready for the
next installation cycle.
O
OPERATING PERATING I INSTRUCTIONS NSTRUCTIONS
For safe operation. Please read completely
WARNING: To avoid severe personal injury,
wear approved eye and ear protection. Ensure
adequate clearance for Operator’s hands
before proceeding with fastener installation.
WARNING: Do not pull on a pin without plac-
ing fastener/collar in a workpiece. This can
cause pin to eject with great velocity and
force if pintail breaks off or teeth or grooves
strip. This may cause severe personal injury.
CAUTION: Remove excess gap from between
the sheets. This permits enough pintail to
emerge from collar for ALL puller teeth to
engage with pintail. If ALL teeth do not engage
properly, jaws will be damaged.
WARNING: To avoid pinch point, never
place hand between nose assembly and
work piece.
WARNING: Only use compatible equip-
ment with this tool.
FIGURE 4

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
10
M
MAINTENANCE AINTENANCE
See S SPECIFICATIONS PECIFICATIONS for fluid type. Dispose of fluid in
accordance with local environmental regulations.
Recycle steel, aluminum, and plastic parts in accor-
dance with local lawful and safe practices.
PREVENTIVE MAINTENANCE
NOTE: For supplementary information refer to
T
TROUBLESHOOTING ROUBLESHOOTING, Parts Lists, and D DISASSEMBLY ISASSEMBLY
AND
AND A ASSEMBLY SSEMBLY procedures in this manual.
SYSTEM INSPECTION
Operating efficiency of the installation tool is directly
related to performance of the complete system,
including the tool with nose assembly, hydraulic
hoses, trigger and control cord, and POWERIG.
Therefore, an effective preventive maintenance pro-
gram includes scheduled inspections of the system to
detect and correct minor troubles.
1. Inspect tool and nose for external damage.
2. Verify that hydraulic hose fittings and couplings
and electrical connections are secure.
3. Inspect hydraulic hose for signs of damage or
aging. Replace hoses if damaged.
.4. Inspect tool, hose, and POWERIG during operation
to detect abnormal heating, leaks, or vibration.
POWERIG MAINTENANCE
Maintenance instructions and repair procedures are in
the appropriate POWERIG Instruction Manual.
TOOL MAINTENANCE
At regular intervals, depending on use, replace all O-
rings and back-up rings in the tool. Spare Parts Kit
SFBTT15KIT should be kept on hand. Inspect cylin-
der bore, piston and piston rod and unloading valve
for scored surfaces, excessive wear or damage, and
replace as necessary.
NOSE ASSEMBLY MAINTENANCE
Daily cleaning of the nose assembly is recommended.
This can usually he accomplished by dipping nose
assembly in mineral spirits, or other suitable solvent,
to clean jaws and wash away metal chips and dirt. If
more thorough cleaning or maintenance is necessary,
disassemble the nose assembly. Use a sharp pointed
“pick” to remove imbedded particles from the pull
grooves of the jaws.
CAUTIONS:
- Consult MSDS before servicing tool.
- Keep dirt and other material out of
hydraulic system.
- Separated parts most be kept away
from dirty work surfaces.
- Dirt/debris in hydraulic fluid causes
Dump Valve failure in Tool and in POW-
ERIG® Hydraulic Unit’s valves.
- Always check tool assembly drawing
for the proper direction of the flats on
the Dump Valve.
CAUTION: Always replace seals, wipers,
and back-up rings when tool is disassem-
bled for any reason.
CAUTION: Do not use TEFLON®tape on
pipe threads. Pipe threads may cause tape
to shred resulting in tool malfunction.
Threadmate™ is available from Huck in a
4oz. tube as part number 508517.
* Threadmate is a registered trademark of Parker Intangibles LLC
* TEFLON is a registered trademark of DuPont Corp.

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
11
GENERAL PRECAUTIONS
During disassembly and assembly, take the following
precautions to avoid damaging tool or components:
(a) Always work on a clean surface.
(b) Use relatively soft materials, such as brass,
aluminum or wood, to protect tool when applying
pressure.
(c) Apply a continuous strong pressure, rather than
sharp blows, to disassemble or assemble a com-
ponent. An arbor press provides steady pressure
to press a component in or out.
(d) Never continue to force a component if it “hangs
up” due to misalignment. Reverse the procedure
to correct misalignment and start over.
(e) Smear LubriplateTM 13OAA or equivalent on O-
rings and mating surfaces to aid assembly and
prevent damage to O-rings. (A handy tube of
Lubriplate 13OAA is available from Huck as part
number 502723).
(f) Coat pipe plug threads, hose fitting threads, and
quick connect fittings with Threadmate™, which
is available from Huck in a 4oz. tube as part
number 508517. DO NOT use Teflon tape on
hose fitting threads.
DISASSEMBLY AND ASSEMBLY TOOLS
Standard hand tools such as wrenches, drifts, copper
or lead hammers, screwdrivers, socket screw hexa-
gon keys, long forceps (tweezers), etc. which can be
purchased at most local supply firms are required. If
possible, an arbor press and vise with soft jaws
should be available.
SPARE PARTS AND SPARE PARTS KITS
The quantity of spare parts that should be kept on
hand varies with the application and number of tools
in service. However, spare parts kits containing per-
ishable parts such as O-rings, back-up rings, etc.,
should be kept on hand at all times.
POWERIG MAINTENANCE
Maintenance instructions and repair procedures are in
the appropriate POWERIG Instruction Manual.
TOOL MAINTENANCE
At regular intervals, depending on use, replace all O-
rings and back-up rings in the tool. Spare Parts Kit
SFBTT15KIT should be kept on hand. Inspect cylin-
der bore, piston and end cap for scored surfaces,
excessive wear or damage, and replace as neces-
sary.
NOSE ASSEMBLY MAINTENANCE
Daily cleaning of the nose assembly is recommended.
This can usually he accomplished by dipping nose
assembly in mineral spirits, or other suitable solvent,
to clean jaws and wash away metal chips and dirt. If
more thorough cleaning or maintenance is necessary,
disassemble the nose assembly. Use a sharp pointed
“pick” to remove imbedded particles from the pull
grooves of the jaws. Apply anti-seize lubricant, part
number 505565, to outside of puller and inside of
anvil.
D
DISASSEMBLY ISASSEMBLY AND AND A ASSEMBLY SSEMBLY P PREPARATION REPARATION
WARNING: Be sure to disconnect Tool’s
electrical control trigger system from
POWERIG® Hydraulic Unit BEFORE dis-
connecting Tool’s hydraulic hoses from
unit. If not disconnected in this order
before any maintenance or cleaning is
done, severe personal injury may occur.
* Threadmate is a registered trademark of Parker Intangibles LLC
* TEFLON is a registered trademark of DuPont Corp.
* LUBRIPLATE is a registered trademark of Fiske Brothers Refining Co.

130211 Cylinder Assy
501149
Back-up Ring
50462
O-Ring
506066
Wiper Seal
130196 Aft Cover
500100 Screws (4)
Apply Loctite 243,
HUCK p/n 5 8567
to threads per
manufacturers
instructions.
122764 Locking Disc
120361 Trigger
Switch Asy
130200 Machined
Handle
130210 Clamp Guide
505344 Strain Relief
502472 Screws (3)
Apply Loctite 243,
HUCK p/n 5 8567
to threads per
manufacturers
instructions.
Apply Threadmate,
HUCK p/n 5 8517
to these threaded joints
per manufacturers
instructions.
A
A
130197 Hydraulic
Plug Cover
5024 9 Screws (2)
Apply Loctite 243,
HUCK p/n 5 8567
to these threads
per manufacturers
instructions.
SECTION A-A
See next page for
Hose and Fitting
part numbers.
503 4 O-Ring
1
13019 Piston & Seal Assy
contains Piston and
components marked 1
5024 3 Screws ( )
Apply Loctite 243,
HUCK p/n 5 8567
to these threads
per manufacturers
instructions.
590517 HUCK
Trademark &
590512-11 WARNING
& CE Stickers
NOTE: These stickers must
remain in place and
readable at all times.
501152 Back-up Ring
1
501152 Back-up Ring
1
503 41 O-Ring
501145
Back-up Ring
1
1
2
130199 End Cap & Seal Assy
contains End Cap and
components marked 2
2
503 4 O-Ring
501152 Back-up Ring
SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
12
A
ASSEMBLY SSEMBLY D DRAWING RAWING - H - HEAD EAD AND AND H HANDLE ANDLE
B
D
A
C
F
E
G
FIGURE 5
ORDER OF DISASSEMBLY:
Remove 7 Screws “A” & “B”
Remove Aft and Plug Covers “C” & “D”
Remove Locking Disc “E”
Unscrew/remove End Cap then Piston “F” & “G”

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
13
See previous page for
Tool Head and Handle
part numbers.
Apply Loctite 242,
HUCK p/n 5 5 16,
to these threaded joints
per manufacturers
instructions.
Apply Loctite 242,
HUCK p/n 5 5 16,
to these threaded joints
per manufacturers
instructions.
11043 Male
Hydraulic Coupler
110439 Female
Hydraulic Coupler
12 93 Cord Assy
503431
Reducing Bushing
503431
Reducing Bushing
124 1-6
2-Foot Hydraulic Hose
Assy with Guard
Apply Loctite 242,
HUCK p/n 5 5 16,
to these threaded joints
per manufacturers
instructions.
Apply Loctite 242,
HUCK p/n 5 5 16,
to these threaded joints
per manufacturers
instructions.
A
ASSEMBLY SSEMBLY D DRAWING RAWING - H - HOSES OSES, C , CORD ORD, , AND AND F FIRINGS IRINGS
FIGURE 6

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
14
O
OPTIONAL PTIONAL E EQUIPMENT QUIPMENT
Loctite®243 -508567
Never-Seez®NS-160 - 505565
(anti-seize and lubricating compound)
LUBRIPLATE®130-AA - 502723
Threadmate™ (4oz. tube) - 508517
Hose Cable Extension Assy - 118309-6 (6 ft)
(Contains 2 hoses with - 118309-12 (12 ft)
quick connect fittings - 118309-26 (26 ft)
and trigger control cord) - 118309-38 (38 ft)
- 118309-52 (52 ft)
Swage Gage - HG-S-BT16 (1/2 in.)
HG-S-MBT12 (12 mm)
HG-S-MBT14 (14 mm)
Pressure Gage - T-124833CE
Service Kit - SFBTT15KIT
DEXRON is a registered trademark of General Motors Corp.
Quintolubric is a registered trademark of Quaker Chemical Corp.
Threadmate is a registered trademark of Parker Intangibles LLC..
TEFLON is a registered trademark of DuPont Corp.
LUBRIPLATE is a registered trademark of Fiske Brothers Refining Co.
Never‐Seez is a registered trademark of Bostick, Inc.
To maintain CE conformity, only CE compatible equipment should be used with these tools. Installation tools
and nose assemblies are the only CE components unless otherwise noted. Controls and other hardware shown
in the manual are for domestic use only.

SFBTT15 BOBTAIL® Hydraulic Tool (HK1151) Alcoa Fastening Systems
15
L
LIMITED
IMITED W
WARRANTIES
ARRANTIES
TOOLING WARRANTY:
Huck warrants that tooling and other items (excluding
fasteners, and hereinafter referred as "other items")
manufactured by Huck shall be free from defects in
workmanship and materials for a period of ninety (90)
days from the date of original purchase.
WARRANTY ON "NON STANDARD OR CUSTOM
MANUFACTURED PRODUCTS":
With regard to non-standard products or custom man-
ufactured products to customer's specifications, Huck
warrants for a period of ninety (90) days from the date
of purchase that such products shall meet Buyer's
specifications, be free of defects in workmanship and
materials. Such warranty shall not be effective with
respect to non-standard or custom products manufac-
tured using buyer-supplied molds, material, tooling
and fixtures that are not in good condition or repair
and suitable for their intended purpose.
THERE ARE NO WARRANTIES WHICH EXTEND
BEYOND THE DESCRIPTION ON THE FACE
HEREOF. HUCK MAKES NO OTHER WAR-
RANTIES AND EXPRESSLY DISCLAIMS ANY
OTHER WARRANTIES, INCLUDING IMPLIED
WARRANTIES AS TO MERCHANTABILITY OR AS
TO THE FITNESS OF THE TOOLING, OTHER
ITEMS, NONSTANDARD OR CUSTOM MANUFAC-
TURED PRODUCTS FOR ANY PARTICULAR PUR-
POSE AND HUCK SHALL NOT BE LIABLE FOR
ANY LOSS OR DAMAGE, DIRECTLY OR INDI-
RECTLY, ARISING FROM THE USE OF SUCH
TOOLING, OTHER ITEMS, NONSTANDARD OR
CUSTOM MANUFACTURED PRODUCTS OR
BREACH OF WARRANTY OR FOR ANY CLAIM
FOR INCIDENTAL OR CONSEQUENTIAL DAM-
AGES.
Huck's sole liability and Buyer's exclusive remedy for
any breach of warranty shall be limited, at Huck's
option, to replacement or repair, at FOB Huck's plant,
of Huck manufactured tooling, other items, nonstan-
dard or custom products found to be defective in
specifications, workmanship and materials not other-
wise the direct or indirect cause of Buyer supplied
molds, material, tooling or fixtures. Buyer shall give
Huck written notice of claims for defects within the
ninety (90) day warranty period for tooling, other
items, nonstandard or custom products described
above and Huck shall inspect products for which such
claim is made.
TOOLING, PART(S) AND OTHER ITEMS NOT MANU-
FACTURED BY HUCK:
HUCK MAKES NO WARRANTY WITH RESPECT
TO THE TOOLING, PART(S) OR OTHER ITEMS
MANUFACTURED BY THIRD PARTIES. HUCK
EXPRESSLY DISCLAIMS ANY WARRANTY
EXPRESSED OR IMPLIED, AS TO THE CONDI-
TION, DESIGN, OPERATION, MERCHANTABILITY
OR FITNESS FOR USE OF ANY TOOL, PART(S),
OR OTHER ITEMS THEREOF NOT MANUFAC-
TURED BY HUCK. HUCK SHALL NOT BE LIABLE
FOR ANY LOSS OR DAMAGE, DIRECTLY OR INDI-
RECTLY, ARISING FROM THE USE OF SUCH
TOOLING, PART(S) OR OTHER ITEMS OR
BREACH OF WARRANTY OR FOR ANY CLAIM
FOR INCIDENTAL OR CONSEQUENTIAL DAM-
AGES.
The only warranties made with respect to such tool,
part(s) or other items thereof are those made by the
manufacturer thereof and Huck agrees to cooperate
with Buyer in enforcing such warranties when such
action is necessary.
Huck shall not be liable for any loss or damage result-
ing from delays or nonfulfillment of orders owing to
strikes, fires, accidents, transportation companies or
for any reason or reasons beyond the control of the
Huck or its suppliers.
HUCK INSTALLATION EQUIPMENT:
Huck International, Inc. reserves the right to make
changes in specifications and design and to discontin-
ue models without notice.
Huck Installation Equipment should be serviced by
trained service technicians only.
Always give the Serial Number of the equipment
when corresponding or ordering service parts.
Complete repair facilities are maintained by Huck
International, Inc. Please contact one of the offices
listed below.
Eastern
One Corporate Drive Kingston, New York 12401-0250
Telephone [phone] FAX [phone]
Outside USA and Canada
Contact your nearest Huck International Office, see
back cover.
In addition to the above repair facilities, there are
Authorized Tool Service Centers (ATSC's) located
throughout the United States. These service centers
offer repair services, spare parts, Service Parts Kits,
Service Tools Kits and Nose Assemblies. Please con-
tact your Huck Representative or the nearest Huck
office listed on the back cover for the ATSC in your
area.

Americas
Alcoa Fastening Systems
Aerospace Products
Tucson Operations
3724 East Columbia
Tucson, AZ 85714
800‐234‐4825
520‐747‐9898
FAX: 520‐748‐2142
Alcoa Fastening Systems
Aerospace Products
Carson Operations
PO Box 5268
900 Watson Center Rd.
Carson, CA 90749
800‐421‐1459
310‐830‐8200
FAX: 310‐830‐1436
Alcoa Fastening Systems
Industrial Products
Waco Operations
PO Box 8117
8001 Imperial Drive
Waco, TX 76714‐8117
800‐388‐4825
254‐776‐2000
FAX: 254‐751‐5259
Alcoa Fastening Systems
Industrial Products
Kingston Operations
1 Corporate Drive
Kingston, NY 12401
800‐278‐4825
845‐331‐7300
FAX: 845‐334‐7333
Alcoa Fastening Systems
Industrial Products
Latin America Operations
Avenida Parque Lira. 79‐402
Tacubaya Mexico, D.F.
C.P. 11850
FAX: 525‐515‐1776
TELEX: 1173530 LUKSME
Far East
Alcoa Fastening Systems
Industrial Products
Australia Operations
14 Viewtech Place
Rowville, Victoria
Australia 3178
03‐764‐5500
Toll Free: 008‐335‐030
FAX: 03‐764‐5510
Europe
Alcoa Fastening Systems
Industrial Products
United Kingdom Operations
Unit C, Stafford Park 7
Telford, Shropshire
England TF3 3BQ
01952‐290011
FAX: 0952‐290459
Alcoa Fastening Systems
Aerospace Products
France Operations
Clos D’Asseville
BP4
95450 Us Par Vigny
France
33‐1‐30‐27‐9500
FAX: 33‐1‐34‐66‐0600
A Global Organization
Alcoa Fastening Systems (AFS) maintains
company offices throughout the United States
and Canada, with subsidiary offices in many
other countries. Authorized AFS distributors
are also located in many of the world’s
Industrial and Aerospace centers, where they
provide a ready source of AFS fasteners,
installation tools, tool parts, and application
assistance.
For The Long Haul, The Future of Fastening
Technology, The Future of Assembly Technology,
The Future of Tooling Technology, and Tools of
Productivity are service marks of Huck
International. Huck provides technical assistance
regarding the use and application of Huck fasten‐
ers and tooling.
NOTICE: The information contained in this publi‐
cation is only for general guidance with regard to
properties of the products shown and/or the
means for selecting such products, and is not
intended to create any warranty, express,
implied, or statutory; all warranties are contained
only in Huck’s written quotations, acknowledge‐
ments, and/or purchase orders. It is recommend‐
ed that the user secure specific, up‐to‐date data
and information regarding each application
and/or use of such products.
HWB898 1003‐5M
© 2003 Alcoa Fastening Systems
1 Corporate Drive, Kingston, NY 12401 • Tel: 800‐431‐3091 • Fax: 845‐334‐7333 • www.alcoafasteningsystems.com
Certified to
ISO 14001:2004
Industrial
Products
Certified to
ISO 9001:2008
Industrial
Products
One Great ConnectionSM
Alcoa Fastening Systems world-wide locations:
For the Long Haul™
®
