HunterDouglas PowerView M25T User manual

Safety instructions
The motor may only be operated after reading these safety instructions, failing to do so might cause serious harm.
• Do not operate a blind which in any way is damaged
• Charging of battery operated blinds, only with suitable chargers
• only operate the blind within the prescribed environmental situation
• the motor may only be used in combination with the recommended and suitable power source, originally supplied
with the blind.
• A remote control is considered NOT to be a children's toy
• window decoration motors should be replaced when the rated cycle limitation is reached
Never drop the
motor!
Never drill into
the motor!
Do not immerse
into liquid!
Avoid
collisions!
MANUAL
Page 1 of 30 version: 1.2

PowerView® Twist® Roller Blind 18VDC
The PowerView® M25T tubular motor is suited to be used with Twist® Roller Blinds from HunterDouglas.
1. Delivery condition
As standard, no remote control or hub is connected to the motor. No limits are set. Motor is default set to
Roller blind
motor type. If the motor condition is unknown, perform the following steps.
1.1. Check motor type
The motor can be programmed as a
•Roller blind (default)
•Roller blind, slow scene speed disabled
•Twist® Roller Blind
•Twist® Roller Blind, slow scene speed disabled
By reading out the LED sequence after power up, the motor type can be seen.
Twist® Roller Blind
IMPORTANT
The motor type (default set to
Roller blind
), has to be changed to
Twist® Roller Blind
type. Use the
PowerView®
Programmer
software tool or
PowerView® remote
to change.

MANUAL
Page 2 of 30 version: 1.2

1.2. End limits reset (factory default)
This procedure will erase all limits stored in the volatile motor memory. It will not clear the Network ID and Group
assignments.
1.1.1 Power up the motor by connecting the power cable to
the battery wand or power supply.
1.1.2 Immediately Check the motor button LED sequence
after start up.
1.1.3 LED sequence of motor set to Roller blind
type:
LED sequence of motor set to Roller
blind, slow scene speed disabled type:
NOT OK!
LED sequence of motor set to Twist®
Roller Blind type:
LED sequence of motor set to Twist®
Roller Blind, slow scene speed
disabled type:
ALL GOOD!
MANUAL
Page 3 of 30 version: 1.2

Note
This procedure can be skipped for a fresh out of the box motor.
The motor will jog 2x when receiving any PowerView® command (e.g. Pressing the manual control button on the motor),
to conrm no limits are set.

1.2.1 Remove power from the motor by disconnecting the
power cable from the battery wand or power supply
and wait for 20 seconds.
1.2.2 Press and hold the manual control button on the
motor.
1.2.3 Reconnect power to the motor while press and hold
the manual control button .
MANUAL
Page 4 of 30 version: 1.2

1.3. Network reset
This procedure will erase all network data stored in the motor, including Network ID and Group assignments. It will not
clear the end limits. Completing a Network reset will prevent a PowerView® remote or App from operating the window
covering until it is reprogrammed.
1.2.4 Press and hold the manual control button until the
motor jogs 1x.
The motor LED ashes red-orange after the motor jogs
1x.
1.2.5 Release the manual control button .
The end limits have been cleared.
1.3.1 Press and hold the manual control button on the
motor for 12 seconds .
The blind will jog 1x at 6 seconds and a second time at
12 seconds.
MANUAL
Page 5 of 30 version: 1.2

2. Pairing a remote
A PowerView® remote can control up to 6 individual groups of blinds (buttons 1 to 6 at the top of the remote). The
instructions below assign a blind to group 1.
1.3.2 Release the manual control button after the
second jog.
The Network ID and Group assignments have
been cleared.
2.1 Locate the manual control button on your blind.
2.2 Press and hold the stop button for 6 seconds.
Keep pressing until the remote lights start blinking.
MANUAL
Page 6 of 30 version: 1.2

2.3 Press the group1 button.
IMPORTANT
Watch out to perform steps 2.4 and 2.5 within 3 seconds!

2.4 Press and hold the manual control button .
2.5 Press the open button.
The blind will jog 1x.
MANUAL
Page 7 of 30 version: 1.2

3. Checking motor direction
3.1. Put motor in program mode
2.6 Release the manual control button .
2.7 Press and hold the stop button for 6 seconds.
Keep pressing until the remote lights stop blinking.
The remote will exit programming mode
automatically after 20 seconds.
IMPORTANT
Reversing motor direction is only possible with a fresh out of the box motor (no limits set) or when the end limits are
reset.
Before any limits are programmed, the motor direction has to be checked and reversed if needed. If the top or bottom
Limit is already set, and the motor direction has to be reversed, perform a
reset
before continuing.

IMPORTANT
Watch out to perform steps 3.1.1 and 3.1.2 within 3 seconds!

MANUAL
Page 8 of 30 version: 1.2

3.2. Check and conrm
3.1.1 Press and hold the manual control button .
3.1.2 Press the open button.
The blind will jog 1x.
Make sure group1 on the remote is selected.
3.1.3 Release the manual control button .
The motor LED turns red to acknowledge the motor is
in program mode.
IMPORTANT
Watch out to perform steps 3.2.1 and 3.2.2 immediately after each other to avoid mechanical damage!
Carefully read them rst before executing!

MANUAL
Page 9 of 30 version: 1.2

3.2.1 Press the arrow down button to check motor
direction.
3.2.2.AIf the blind moves upwards, immediately
Press the stop button.
Motor direction NOT OK!
3.2.2.BIf the blind moves downwards, Press the 
stop button and continue with step 4.1.4
Motor direction OK!
3.2.3 Press and hold the manual control button for 1
second to reverse motor direction.
The blind will jog 1x to acknowledge the direction is
reversed.
3.2.4 Continue with step 4.1.4
MANUAL
Page 10 of 30 version: 1.2

4. Setting end limits
It doesn’t matter if you start with setting the open or the close limit rst. In this description we start with the open (top)
limit.
4.1. Open limit (top)
Note
It is important to have the fabric of the blind tight around the tube.

4.1.1 Press and hold the manual control button .
4.1.2 Press the open button.
The blind will jog 1x.
Make sure group1 on the remote is selected.
MANUAL
Page 11 of 30 version: 1.2

4.1.3 Release the manual control button .
The motor LED turns red to acknowledge the motor is
in program mode.
4.1.4 Use the open , stop and close buttons to
move the blind to the desired top position.
Use the  arrow up and  arrow down buttons to
ne tune the desired position.
4.1.5
Press and hold the stop button for 6
seconds. DO NOT select a group on the remote!
Keep pressing until the remote lights start blinking.
MANUAL
Page 12 of 30 version: 1.2

IMPORTANT
Watch out to perform steps 4.1.6 and 4.1.7 within 3 seconds!

4.1.6 Press and hold the manual control button .
4.1.7 Press the open button.
The blind will jog 1x to acknowledge the limit is set.
4.1.8 Release the manual control button .
The motor LED turns off.
MANUAL
Page 13 of 30 version: 1.2

4.1.9 Press and hold the stop button for 6 seconds.
Keep pressing until the remote lights stop blinking.
The remote will exit programming mode
automatically after 20 seconds.
4.1.10 The top limit is set!
Note
To re-position the top limit of the blind, repeat step
4.1 Open limit (top)

MANUAL
Page 14 of 30 version: 1.2

4.2. Close limit (bottom)
4.2.1 Press and hold the manual control button .
4.2.2 Press the close button.
The blind will jog 1x.
Make sure group1 on the remote is selected.
4.2.3 Release the manual control button .
The motor LED turns red to acknowledge the motor is
in program mode.
MANUAL
Page 15 of 30 version: 1.2

4.2.4 Use the open , stop and close buttons to
move the blind to the desired bottom position.
Use the  arrow up and  arrow down buttons to
ne tune the desired position.
4.2.5 Press and hold the stop button for 6 seconds.
Keep pressing until the remote lights start blinking.
DO NOT select a group on the remote!
IMPORTANT
Watch out to perform steps 4.2.6 and 4.2.7 within 3 seconds!

4.2.6 Press and hold the manual control button .
MANUAL
Page 16 of 30 version: 1.2

4.2.7 Press the close button.
The blind will move to the top limit to acknowledge the
bottom limit is set.
4.2.8 Release the manual control button .
The motor LED turns off.
4.2.9 Press and hold the stop button for 6 seconds.
Keep pressing until the remote lights stop blinking.
The remote will exit programming mode
automatically after 20 seconds.
MANUAL
Page 17 of 30 version: 1.2

5. fabric open position
When the end limits of a Twist® Roller Blind have been programmed correctly, setting the fabric open position allows the
Twist® Roller Blind to tilt open and close at the bottom position.
4.2.10 The bottom limit is set!
Note
To re-position the bottom limit of the blind, repeat step
4.2. Close limit (bottom)

IMPORTANT
It is important to correctly set the end limits rst! When a top or bottom limit is repositioned, the fabric open position has
to
cleared
and repositioned accordingly!

MANUAL
Page 18 of 30 version: 1.2

5.1. Set fabric open position
5.1.1 Locate the manual control button on your blind.
5.1.2 Press the group1 button.
5.1.3 Press the close button to move the blind to the
bottom position.
MANUAL
Page 19 of 30 version: 1.2

5.1.4 Determine the fabric open position using the 
arrow up , arrow down and stop buttons.
5.1.5 Press and hold the stop button for 6 seconds.
Keep pressing until the remote lights start blinking.
DO NOT select a group on the remote!
IMPORTANT
Watch out to perform steps 5.1.6 and 5.1.7 within 3 seconds!

5.1.6 Press and hold the manual control button .
MANUAL
Page 20 of 30 version: 1.2
