Design Studio™
Wand Control Ripplefold
Drapery Hardware
Installation • Operation • Care

CONTENTS
Questions?
Call the Hunter Douglas Consumer Support Center at 1-888-501-8364.
© 2019 Hunter Douglas. All rights reserved. All trademarks used herein are the property of Hunter Douglas or
their respective owners.
GETTING STARTED
Product View................................................................................................3
Tools and Fasteners Needed .......................................................................4
INSTALLATION
Wall Mount..................................................................................................5
Flush Ceiling Mount.....................................................................................6
Install the Track............................................................................................7
Install the Drapery .......................................................................................8
OPERATION
Operate the Track.......................................................................................10
Troubleshooting ........................................................................................10
CARE
Remove Drapery (If Necessary) .................................................................11
Remove Drapery Track (If Necessary)........................................................11
Cleaning Procedures .................................................................................12
WARRANTY.................................................................................Back Cover

3
GETTING STARTED
Product View
Wall Mount
Bracket
Drapery
Track
Lead
Carrier
Carriers

4
GETTING STARTED
Thank you for purchasing Hunter Douglas Design Studio™Wand Control Ripplefold Drapery
Hardware. With proper installation, operation and care, your new drapery will provide years of
beauty and performance.
Please thoroughly review this instruction booklet and enclosed packing list before beginning
the installation.
Tools and Fasteners Needed
■ Phillips screwdriver
■ Level (laser level is recommended)
■ Measuring tape and pencil
■ Power drill,
1
∕ 8 " drill bit, and a Phillips driver
In addition, you will need fasteners designed to work with your specific mounting surface(s).
■ Three #8 1
3
∕ 4” Phillips pan head screws.
Refer to the appropriate page below based on your order:
➤ “Wall Mount” on page 5.
➤ “Flush Ceiling Mount” on page 6.

5
INSTALLATION
Wall Mount
■ Measure the width of the drapery track and use this measurement to determine where the
ends of the track will be located. Use a pencil to lightly mark where its ends are located.
■ Use the figure below to mark the locations on the wall for each of the brackets. These
marks will be the outside top hole position of the wall bracket. Keep in mind the following:
➤ A minimum of 1
1
⁄ 2 " flat vertical surface is required to mount the installation brackets.
➤ Mark the top hole of the brackets 1" above where you want the top of the drapery
header to be positioned.
➤ Mount the end installation brackets 4" in from end marks.
➤ If more than two installation brackets came with your order, space additional bracket(s)
evenly between the two end brackets and mark their location. Mount into wood
whenever possible.
IMPORTANT: The front edges of the installation brackets must be level and aligned
after mounting.
■ Place the outside top hole of each wall bracket on previously made marks and mark the
top two and bottom hole.
■ Drill the screw holes using a
1
∕ 8 ” drill bit.
■ Attach the installation brackets using the three screws
provided.
➤ Check that the mounting surface is level and the brackets
are aligned. If mounting to a heavily textured surface, shim
the brackets, if needed.
WARNING: Product is heavy. Mount into wood/metal studs or into concrete
with concrete anchors. Drywall anchors can be used when studs are not present.
Choose the appropriate anchors to safely secure the track.
■ Loosen the projection adjustment screws
then fully extend the brackets.
■ Lock the brackets into position by
tightening the projection adjustment
screws.
Proceed to “Install theTrack” on page 7.
4"
End of Track Marks
Evenly Spaced Evenly Spaced Evenly Spaced
4"
Projection
Adjustment
Screw

6
INSTALLATION
Flush Ceiling Mount
■ Measure the width of the drapery track and use this measurement to determine where the
ends of the track will be located. Use a pencil to lightly mark where its ends are located.
■ Use the figure below to mark the locations on the ceiling for each of the brackets. These
marks will be the screw hole position of the ceiling bracket. Keep in mind the following:
➤ Make marks exactly 3
3
∕ 8 " away from wall.
➤ Mount the end ceiling brackets 4" in from end marks.
➤ If more than two ceiling brackets came with your order, space additional bracket(s)
evenly between the two end brackets and mark their location. Mount into wood
whenever possible.
IMPORTANT: The front edges of the installation brackets must be level and aligned
after mounting.
■ Drill the screw holes using a
1
∕ 8 " drill bit.
■ Snap each ceiling bracket onto the track.
➤ The ceiling brackets can slide along the track to position
each bracket the same measurements as the previously
made marks.
■ Hold the track with brackets attached up to the
ceiling and position the bracket screw holes
on pre-drilled holes and secure with screws
provided.
➤ Check that the mounting surface is level
and the brackets are aligned. If mounting
to a heavily textured surface, shim the
brackets, if needed.
WARNING: Product is heavy. Mount into wood/metal studs or into concrete
with concrete anchors. Drywall anchors can be used when studs are not present.
Choose the appropriate anchors to safely secure the track.
Proceed to “Install the Drapery” on page 8.
4"
End of Track Marks
Evenly Spaced Evenly Spaced Evenly Spaced
4"
Wall
Track
Bracket
Snap Bracket
onto Track

7
INSTALLATION
Install the Track
Wall Mount Installation
■ Loosen the track set screw to allow the track
retainer to flex. Place the track into each
bracket applying pressure until the track clicks
into the bracket.
■ Tighten the bracket set screws to secure
the track.
Set
Screw

8
INSTALLATION
Install the Drapery
■ Attach the pendants to the drapery snaps except the first
2 of leading edge and the last snap on return end.
■ Snap the first 2 snaps on the leading edge of the drapery
to the lead carrier.
■ Insert the pendants into the slots on the carriers hanging
from the inside of the track.
■ Insert the last snap into the stationary carrier in the
end cap.
■ Create ‘S’-like folds throughout the drapery.
➤ Start at the lead carrier and begin by pushing the fabric that follows it toward the back
of the track. This should be the first two carriers that follow after the lead carrier.
➤ Bring the fabric between the next two carriers toward the front of the track.
➤ Repeat to create a ‘S’-like folds for the entire drapery. Front to back, the ‘S’ takes up
approximately 4".
Pendant
Snap
Pendant
Carrier
Stationary
Carrier
Snap

9
INSTALLATION
Return to the Wall
■ Screw the brass eyelets (provided) into the wall on each
end to anchor the returns at the same height as the
drapery.
■ Place the end drapery pins into the eyelets.

10
OPERATION
Operate the Track
■ Hook the wand onto the lead carrier.
■ Pull/push the wand to move the drapery to the
desired position.
Troubleshooting
Problem
The unit does not traverse at all, does not traverse fully, or does not
traverse correctly.
Solution Check that the mounting brackets are level, that their front edges are aligned,
and that there are no obstructions to the movement of the panels.

11
CARE
Remove Drapery (If Necessary)
■ Unhook the returns from the eyelets on the wall.
■ Start at the outside ends of the drapery panel(s) and gently remove the pendants from
carriers.
■ Place the drapery on a flat clean surface to avoid wrinkling and soiling the fabric.
Remove Drapery Track (If Necessary)
Wall Mount
■ Loosen the set screws and rotate the track out
of the brackets.
Flush Ceiling Mount
■ Starting at each end, remove the screws from
the ceiling brackets.

12
CARE
Cleaning Procedures
Dress Your Drapery
■ Most wrinkles and folds will hang out on their own. You may also use a
garment/commercial steamer to help eliminate wrinkles. Please keep in mind linens will
characteristically have wrinkles regardless of steaming or pressing.
Dusting
■ Regular light dusting with a feather duster is all the cleaning needed in most
circumstances.
Vacuuming
■ Use hand-held vacuum with upholstery attachment on low suction, for more thorough dust
removal.

Notes

Notes

8/191010776
The Hunter Douglas®Lifetime Guarantee is an expression of our desire to provide a thoroughly satisfying
experience when selecting, purchasing and living with your window fashion products. If you are not
thoroughly satisfied, simply contact Hunter Douglas at [phone] or visit hunterdouglas.com. In support
of this policy of consumer satisfaction, we offer our Lifetime Limited Warranty as described below.
Hunter Douglas (or its licensed fabricator/distributor) will repair or replace the
window fashion product or components found to be defective.
COVERED
BY A LIFETIME LIMITED WARRANTY
TO OBTAIN WARRANTY SERVICE
NOT COVERED
BY A LIFETIME LIMITED WARRANTY
• Hunter Douglas window fashion products are
covered for defects in materials, workmanship or
failure to operate for as long as the original retail
purchaser owns the product (unless shorter
periods are provided below).
• All internal mechanisms.
• Components and brackets.
• Fabric delamination.
• Operational cords for a full 7 years from the date
of purchase.
• Repairs and/or replacements will be made with
like or similar parts or products.
• Hunter Douglas motorization components are
covered for 5 years from the date of purchase.
1. Contact your original dealer (place of purchase) for warranty assistance.
2. Visit hunterdouglas.com for additional warranty information, frequently asked questions and access to
service locations.
3. Contact Hunter Douglas at [phone] for technical support, certain parts free of charge, for
assistance in obtaining warranty service or for further explanation of our warranty.
NOTE: In no event shall Hunter Douglas or its licensed fabricators/distributors be liable or responsible for
incidental or consequential damages or for any other indirect damage, loss, cost or expense. Some states
do not allow the exclusion or limitation of incidental or consequential damages, so the above exclusion or
limitation may not apply to you. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Different warranty periods and terms apply for commercial products and applications.
• Any conditions caused by normal wear and tear.
• Abuse, accidents, misuse or alterations to the
product.
• Exposure to the elements (sun damage, wind,
water/moisture) and discoloration or fading over
time.
• Failure to follow our instructions with respect to
measurement, proper installation, cleaning or
maintenance.
• Shipping charges, cost of removal and
reinstallation.
