CARPET LINER CARE AND USE INSTRUCTIONS
Your new 3D®carpet liners are custom molded to fit your vehicle. The liners are made to take the place of
your factory floor mats. For the correct fit, it is necessary to remove the factory floor mats before installing your
new carpet liners. However, do not remove the factory-installed carpeting.
Your liners are made from a unique combination of a lightweight thermoplastic foam and a high quality
automotive grade carpet that is extremely tough and durable. To clean your carpet liners, vacuum first to
remove loose debris and then use a damp sponge to spot clean. If you wish to use a commercial cleaner,
cleaners such as Resolve®, Woolite®, Capture® or similar products are suggested. Read and follow the care
and use instructions provided with these products. Spot removal is most effective when the soiled area is treated
promptly. Do not use solvent-based cleaners or cleaners containing bleach as these may discolor your carpet.
Your 3D® carpet liners come with a lifetime warranty against tearing and cracking. For warranty
information or to see other products we have available for your vehicle, please see our web site,
http://www.huskyliners.com.
ALIGNMENT VIEW SHOWING PLACEMENT OF YOUR REAR SEAT 3D
CARPET FLOOR LINER IN A LINCOLN NAVIGATOR EQUIPPED WITH
SECOND ROW BUCKET SEATING
FRONT OF VEHICLE
PART NUMBER MOLDED ON BACK SIDE OF LINER

9178_Insert X 2.doc
02/11/03
CARPET LINER INSTALLATION INSTRUCTIONS
Your new 3D® Carpet Liners are designed to be held firmly in place with a Velcro® anchoring system. You
will find that your second seat liner comes with two Velcro® “hook” patches applied to the underneath surface
of the liner. In the hardware bag included in the shipping container you will find 2 anchor screws with the
“loop” portion of the Velcro® applied. The anchor screws will need to be installed in your factory carpet
directly beneath the Velcro® hook patches to hold the liners in place. The anchor screws will not damage your
carpet and can easily be removed if necessary.
To align the anchors with the patches on the liner, first place your liner in the vehicle, adjusting it to the
proper fit. Then, pull up a corner of your liner as shown in the photo below and attach the anchor screw to the
Velcro® pad on the liner. Lower the raised edge and note the position where the anchor screw touches the
vehicle carpet. There are many ways to mark this location; here are a couple of suggestions:
•Apply a 1” strip of masking tape directly to the carpet underneath the anchor screw. When the anchor screw
is lowered, it will pierce the tape and mark the location.
•Insert a straight pin (needle) next to the point where the anchor screw contacts the carpet to mark the screw
location.
With screw secured in carpet, align Velcro®
halves to secure liner in place.
Anchor screw will pierce masking
tape, marking screw location.
Anchor screw shown attached to
Velcro® Dot on back of liner.
Velcro® Dot on back of liner.
