Husky H46X18MWC9BLK User manual

Husky 46 in. 9-Drawer Mobile Work Bench
USE AND CARE GUIDE
Questions, problems, missing parts?
Before returning to the store, call
Husky Customer Service
8 a.m – 7 p.m., EST, Monday-Friday
9 a.m – 6 p.m., EST, Saturday
THANK YOU
We appreciate the trust and con dence you have placed in Husky through the purchase of this cabinet. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Husky!
1-888-HD-HUSKY
HUSKYTOOLS.COM
Caster hubcap may be different than shown in diagram
Model # / SKU
H46X18MWC9BLK / 1000000000
H46X18MWC9WHT / 1000000000
H46X18MWC9GRY / 1000000000
H46X18MWC9BLU / 1000000000
H46X18MWC9GRN / 1000000000
H46X18MWC9RED / 1000000000
H46X18MWC9ORG / 1000000000

CAUTION: Load unit starting with bottom
drawers. Overloading the top of the unit may
result in the product becoming unstable and
creating a tipping hazard, which may cause
personal injury or product damage.
Table of Contents
Table of Contents..................................................2
Safety Information ...............................................2
Warranty ................................................................3
Specifications ........................................................3
Package Contents..................................................3
Hardware Included........................................................... 3
Assembly ...............................................................5
6............................... ................................ecnanetniaM
Safety Information
1. Do not pull this unit, push it when moving.
2. Use the brakes when this product is not being
moved. This prevents the product from rolling.
3. Secure this product properly before moving it with a
forklift.
4. Do not tow the product with power equipment.
5. Do not alter this product in any manner. For
example, do not weld external lock bars or attach
electrical equipment.
Do not stand on this product. You
may fall which may cause personal injury or
Be careful when opening more than
one drawer. The product may become unstable
and tip, which may cause personal injury or
product damage.
CAUTION: Keep the product on level surfaces.
The product may become unstable and tip if
stored or moved on an unlevel surface, which
may cause personal injury or product damage.
CAUTION:
CAUTION:
CAUTION:
Lock the drawers before moving
this product. The drawers could come open and
make the product unstable and tip, which may
cause personal or product damage.
.............. 3Alternative Tools For Assembly (Not Included)
Replacement Parts ................................................7
product damage.
6. Before locking the cabinet, ensure the drawers are
completely closed in order for the lock bars to work properly.
2
Do not attach or mount this product
to a vehicle or mobile trailers. This may cause
personal injury or product damage. Mounting this
product to any vehicle or mobile trailers in any
warranty.
CAUTION:
manner will void
CAUTION: Do not use the side handle as a
point of leverage to lift the unit off of the
ground. Handle is not intended to withstand
the force of vertical lifting, and is only designed
to aid in the movement of unit around on casters.
Failure to adhere to this warning may cause
handle to break and cause personal injury
and/or product damage.
5...........................................
Optional Attachment
6..............................................................
Operation

3 Please contact 1-888-HD-HUSKY
HUSKYTOOLS.COM
for further assistance.
Specifications
Casters support up to 1500 lbs.
NOTE: Begin product assembly close to t nal
intended location of your cabinet. This product is
heavy and may be di cult to move after assembly.
)rewardtenibac(repthgiewmumixaM 100 lbs.
Package Contents
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description
AA
BB M6 x 16 bolt
M8 x 20 bolt
4
CC Hex key 1
Quantity
BB
AA CC
Warranty
The manufacturer warrants the product to be free from defects in materials and workmanship for a period of three (3) years from date of
purchase. This warranty applies only to the original consumer and only to products used in normal use and service. If this product is found to
be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s
mishandling.
This warranty shall not apply to any product that is found to have been improperly installed, setup, or used in any way not in accordance with
the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse,
negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not apply to
ar purpose,
consequential
or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.
Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.huskytools.com.
ALTERNATIVE TOOLS FOR ASSEMBLY
(Not Included)
*12 mm wrench or socket
16

4
Part Description Quantity
A
B
C
Cabinet 1
Cabinet handle 1
D
2
2
Swivel caster
Fixed caster
Package Contents (continued)
NOTE:
The keys are inside top drawer.
A
B
C
D
NOTE:
Caster hubcap may be different than
shown in diagram.

A
D
AA
Assembly
1
Attaching the cabinet handle
Position the cabinet handle (B) over the holes on the
cabinet (A).
Attach with the bolts (BB) and tighten with supplied
hex key (CC).
NOTE:
The holes in the cabinet are tapped and do not
require nuts.
□
□
CAUTION:
Two people are recommended for assembly.
Attaching the casters
□Be sure the drawers are locked and lay the cabinet (A)
□emasehtno,tinuehtot)D(sretsacleviwsehthcattA
side as the handle, inserting bolts (AA) through the swivel
casters(D) and into the cabinet (A).
□Tighten with supplied hex key (CC) or 12 mm wrench/socket.
□Repeat this process for the xed casters (C) on the
opposite side of the cabinet (A).
□Return the cabinet (A) to its upright position.
CAUTION: Do not over tighten the bolts.
2
NOTE:
Caster hubcap may be different than
shown in diagram.
The workbench has pre-threaded holes on the back
and side of the unit for the installation of optional
pegboard back wall (Model #D6T09001). Refer to
huskytools.com or homedepot.com for more details.
□
Optional Attachment
NOTE:
Caster hubcap may be different than
shown in diagram.
A
BB
B
NOTE:
One handle comes with this cabinet and can be
installed on either the left or right side. If a second
handle is desired, please call 1-888-HD-HUSKY to order.
5HUSKYTOOLS.COM
Please contact 1-888-HD-HUSKY for further assistance.

Operation
1
Removing the drawers 2 Re-inserting the drawers
Fully extend the empty drawer.
□
□
elihwrevelesaelerenoehtpuhsuP pulling
down on the other release lever.
□Pull the drawer outward until it is released from the
drawer slide.
Extend the drawer slides.
□
□
Insert the brackets on each side of the drawer into
the slots in the slides, being careful that they are
properly positioned.
□Once properly inserted, completely close the drawer
to set the slides in their proper positions.
□Periodically clean the drawer fronts, drawer trim, and other surfaces with a mild detergent and water.
□you would on a car.
□
Maintenance
1 Caster maintenance 2 Drawer maintenance
□Grease the casters annually using high-quality
bearing grease.
□Lu
bearing grease.
bricate the slides semi-annually with high-quality
NOTE:
Caster hubcap may be different than
shown in diagram.
6

7HUSKYTOOLS.COM
Please contact 1-888-HD-HUSKY for further assistance.
Replacement Parts
For assistance with replacement parts please call 1-888-HD-HUSKY.
Drawer Liner 9
ACabinet Handle 1
B
2
C 2
DLock 1
F
Badge
1
HDrawer Slide
22
G
Caster Bolt 16I
4J
Key 2 E
Part Description Quantity
Fixed Caster
Swivel Caster
Handle Bolt
K 18Drawer End Cap
NOTE:
Caster hubcap may be different than
shown in diagram.
DE F
BC
I
J
A
K
G
H

Questions, problems, missing parts? Before returning to the store call
Husky Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-888-HD-HUSKY
HUSKYTOOLS.COM
Retain this manual for future use.
