IBM Netfinity 5100 8658 21Y User manual

Netfinity 5100 Type 8658 Models
11Y, 21Y, 31Y, 41Y, 51Y, 1RY,
2RY, 3RY, 4RY, 5RY
S10K-2615-00


Note: Before using this information and the product it
supports, be sure to read the general information
under “Notices” on page 233.
First Edition (June 2000) (updated July 2002)
The following paragraph does not apply to the United
Kingdom or any country where such provisions are
inconsistent with local law:
INTERNATIONAL BUSINESS MACHINES CORPORATION
PROVIDES THIS PUBLICATION ″AS IS″WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. Some states
do not allow disclaimer of express or implied warranties in
certain transactions, therefore, this statement may not
apply to you.
This publication could include technical inaccuracies or
typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in
new editions of the publication. IBM may make
improvements and/or changes in the product(s) and/or the
program(s) described in this publication at any time.
This publication was developed for products and services
offered in the United States of America. IBM may not offer
the products, services, or features discussed in this
document in other countries, and the information is subject
to change without notice.
Consult your local IBM representative for information on
the products, services, and features available in your area.
Requests for technical information about IBM products
should be made to your IBM reseller or IBM marketing
representative.
© Copyright International Business Machines
Corporation 2000. All rights reserved.
US Government Users Restricted Rights – Use, duplication
or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

About this manual
This manual contains diagnostic information, a
Symptom-to-FRU index, service information, error codes,
error messages, and configuration information for the
Netfinity 5100 server.
Important: This manual is intended for trained servicers
who are familiar with IBM PC Server products.
Important safety information
Be sure to read all caution and danger statements in this
book before performing any of the instructions.
Leia todas as instruções de cuidado e perigo antes de
executar qualquer operação.
Prenez connaissance de toutes les consignes de type
Attention et
Danger avant de procéder aux opérations décrites par les
instructions.
Lesen Sie alle Sicherheitshinweise, bevor Sie eine
Anweisung ausführen.
© Copyright IBM Corp. 2000 iii

Accertarsi di leggere tutti gli avvisi di attenzione e di
pericolo prima di effettuare qualsiasi operazione.
Lea atentamente todas las declaraciones de precaución y
peligro ante de llevar a cabo cualquier operación.
Online Support
Use the World Wide Web (WWW) to download Diagnostic,
BIOS Flash, and Device Driver files.
File download address is:
http://www.us.pc.ibm.com/files.html
IBM Online Addresses
The HMM manuals online address is:
http://www.us.pc.ibm.com/cdt/hmm.html
The IBM PC Company Support Page is:
http://www.us.pc.ibm.com/support/index.html
The IBM PC Company Home Page is:
http://www.pc.ibm.com
iv : Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

Contents
About this manual ...........iii
Importantsafetyinformation.........iii
Online Support .............iv
IBM Online Addresses..........iv
General checkout ............1
General information ...........3
Features and specifications .........3
What your IBM Netfinity 5100 offers .......5
Reliability, availability, and serviceability features . . . 7
Servercontrolsandindicators........8
Starting the server ..........11
Operator Information panel .........14
Diagnostics .............17
Diagnostic tools overview .........17
POST ...............17
Event/errorlogs...........18
Small computer system interface messages ....18
Identifying problems using status LEDs .....18
Light path diagnostics .........18
Power supply LEDs .........19
Diagnostics panel ..........19
Light path diagnostics table .......19
Diagnostic programs and error messages.....20
Text messages ...........20
Starting the diagnostic programs ......21
Viewingthetestlog..........22
Diagnostic error message tables ......23
Recovering BIOS ............23
Troubleshooting the Ethernet controller .....24
Network connection problems .......24
Ethernet controller troubleshooting chart ....25
Ethernet controller messages ........27
Novell NetWare or IntraNetWare server ODI driver
messages ............27
Network driver interface specification 2.01 (OS/2)
driver messages ..........30
NDIS 4.0 (Windows NT) driver messages....32
UNIX messages ...........33
Power checkout ............36
Replacing the battery...........36
Temperature checkout ..........38
Configuringtheserver..........41
Using the Configuration/Setup Utility program . . . 41
Starting the Configuration/Setup Utility program 42
Choices available from the Configuration/Setup
main menu ............42
© Copyright IBM Corp. 2000 v

Usingpasswords...........47
Power-on password .........47
Administrator password ........49
Bypassing an unknown power-on password ....49
Using the SCSISelect utility program ......50
Starting the SCSISelect utility program ....50
Choices available from the SCSISelect menu . . 50
Installing options ...........53
Exploded view of the Netfinity 5100 server ....53
System board layout ...........54
System board options connectors ......54
System board internal cable connectors ....56
System board external port connectors ....56
System board switches and jumpers .....57
System board LED locations .......59
Before you begin ............61
System reliability considerations ......62
Working inside a server with power on ....62
Handling static sensitive devices ......63
Removing the cover, door, and bezel ......63
Removing the left-side cover (tower model) . . . 64
Removing the cover (rack model) ......65
Removing the server door (tower model) ....66
Removing the bezel (rack or tower) .....67
Working with adapters ..........67
Adapter considerations .........68
Installing an adapter ..........69
Installing internal drives ..........71
Internal drive bays ..........71
Hot-swap drives ...........73
Non-hot-swap drives ..........74
Preinstallationsteps(allbays).......74
Installing a hot-swap drive ........75
Replacing a drive in a hot-swap bay ....76
Installing a non-hot-swap drive .......78
Installing memory modules .........80
Installing a microprocessor .........82
Installing or removing a power supply ......85
Adding a power supply .........87
Removing a hot-swap power supply .....88
Removing the only power supply ......89
Replacing a fan assembly .........90
Installing the cover ...........92
Installing the cover (tower) ........92
Installing the bezel and front door .....93
Installing the cover (rack) ........94
Installing the bezel .........95
Connecting external options .........95
Installation procedure..........95
I/O connector locations ..........96
Input/Outputports............97
Parallelport............97
vi : Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

Viewing or changing the parallel-port
assignments ..........97
Parallel port connector ........98
Serialports.............98
Viewing or changing the serial-port assignments 99
Serial-port connectors ........99
UniversalSerialBusports........100
USB cables and hubs ........100
USB-port connectors ........100
Keyboard port ...........100
Auxiliary-device (pointing device) port ....101
Videoport.............101
SCSI ports ............102
SCSI cabling requirements.......103
Setting SCSI IDs..........103
SCSI connector pin-number assignments 103
Ethernetport............104
ConfiguringtheEthernetcontroller....105
Failover for redundant Ethernet .....105
Ethernet port connector........110
Advanced System Management ports ....110
Cablingtheserver...........111
Netfinity Manager ...........113
Managing your IBM Netfinity server with Netfinity
Manager .............113
Netfinity Manager documentation .......114
Netfinity Manager system requirements .....114
Netfinity Manager for OS/2 system requirements 114
Netfinity Manager for Windows 95 and Windows
98 system requirements ........115
Netfinity Manager for Windows NT system
requirements ...........116
Starting the Netfinity Manager installation program 117
Netfinity Manager database support ......125
DB2 database support .........126
System requirements ........126
Installing and configuring the database . . . 126
Activating the database........127
Granting and revoking database privileges 128
Deleting the database ........130
Lotus Notes database support.......131
System requirements ........131
Installing the database ........131
Browsing the Netfinity Manager Lotus Notes
database ...........133
ODBC database support ........133
System requirements ........133
ODBC database configuration ......134
Creating the Netfinity Manager tables . . . 135
Supported and certified databases ....137
Starting Netfinity Manager .........139
Netfinity Manager Service Manager .....140
Contents vii

Netfinity Manager service descriptions ....140
Advanced System Management .....141
Alert Manager ..........141
AlertonLANconfiguration.......142
Capacity Management ........142
Cluster Manager ..........142
Critical File Monitor .........142
DMIBrowser...........142
ECC Memory Setup.........142
Event Scheduler ..........143
FileTransfer...........143
Power-On Error Detect ........143
Predictive Failure Analysis .......143
Process Manager .........143
RAID Manager ..........143
Remote Session ..........143
Remote System Manager .......144
Remote Workstation Control ......144
ScreenView...........144
Security Manager .........144
Serial Connection Control .......144
Service Configuration Manager .....144
SoftwareInventory.........145
System Diagnostics Manager ......145
SystemInformationTool.......145
SystemMonitor..........145
System Partition Access .......145
System Profile ..........146
Update Connector Manager ......146
Web Manager Configuration ......146
Delaying Netfinity Manager startup on OS/2
systems............146
Getting more information about Netfinity Manager 147
Installationoptions...........148
Automated installation .........148
Customizedinstallation.........150
FRUinformation(serviceonly).......153
Removing the external LED card .......153
Removing the power reset card .......154
Removing the rear cable bracket .......155
Removing the DASD backplane assembly ....156
Removing the power supply backplane .....157
Removing the system board ........158
Symptom-to-FRU index .........159
Beep Symptoms ............159
No Beep symptoms ...........162
Information panel system error LED ......162
Diagnostic error codes ..........165
Errorsymptoms............169
Power supply LED errors .........170
POST error codes ...........171
viii : Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

SCSI error codes ...........178
Temperature error messages ........178
Fan error messages...........179
Power error messages ..........180
System shutdown ...........181
Voltage related system shutdown ......181
Temperature related system shutdown ....182
DASD checkout ............183
Host Built-In Self Test (BIST) ........183
Bus fault messages ...........183
Undetermined Problems .........183
Parts listing (Type 8658) .........185
Keyboards .............189
Power cords .............189
Relatedserviceinformation........191
Safetyinformation...........192
General safety ...........192
Electrical safety ...........193
Safety inspection guide .........195
Handling electrostatic discharge-sensitive devices 196
Grounding requirements ........197
Safety notices (multi-lingual translations)....197
Send us your comments! .........232
Problemdeterminationtips.........232
Notices ..............233
Trademarks .............234
Contents ix

x: Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

General checkout
The server diagnostic programs are stored in upgradable
read-only memory (ROM) on the system board. These
programs are the primary method of testing the major
components of the server: the system board, Ethernet
controller, video controller, RAM, keyboard, mouse
(pointing device), diskette drive, serial ports, hard drives,
and parallel port. You can also use them to test some
external devices. See “Diagnostic tools overview” on
page 17.
Also, if you cannot determine whether a problem is caused
by the hardware or by the software, you can run the
diagnostic programs to confirm that the hardware is
working properly.
When you run the diagnostic programs, a single problem
might cause several error messages. When this occurs,
work to correct the cause of the first error message. After
the cause of the first error message is corrected, the other
error messages might not occur the next time you run the
test.
A failed system might be part of a shared DASD cluster
(two or more systems sharing the same external storage
device(s)). Prior to running diagnostics, verify that the
failing system is not part of a shared DASD cluster.
A system might be part of a cluster if:
vThe customer identifies the system as part of a cluster.
vOne or more external storage units are attached to the
system and at least one of the attached storage units is
additionally attached to another system or unidentifiable
source.
vOne or more systems are located near the failing
system.
If the failing system is suspected to be part of a shared
DASD cluster, all diagnostic tests can be run except
diagnostic tests which test the storage unit (DASD residing
in the storage unit) or the storage adapter attached to the
storage unit.
Notes:
1. For systems that are part of a shared DASD cluster,
run one test at a time in looped mode. Do not run all
tests in looped mode, as this could enable the DASD
diagnostic tests.
2. If multiple error codes are displayed, diagnose the first
error code displayed.
© Copyright IBM Corp. 2000 1

3. If the computer hangs with a POST error, go to the
“POST error codes” on page 171.
4. If the computer hangs and no error is displayed, go to
“Undetermined Problems” on page 183.
5. Power supply problems, see “Power supply LED
errors” on page 170.
6. Safety information, see “Safety information” on
page 192.
7. For intermittent problems, check the error log; see
“POST error codes” on page 171.
1. IS THE SYSTEM PART OF A CLUSTER?
YES. Schedule maintenance with the customer. Shut down
all systems related to the cluster. Run storage test.
NO. Go to step 2.
2. IS THE SYSTEM IS NOT PART OF A CLUSTER?
vPower-off the computer and all external devices.
vCheck all cables and power cords.
vSet all display controls to the middle position.
vPower-on all external devices.
vPower-on the computer.
vRecord any POST error messages displayed on the
screen. If an error is displayed, look up the first error
in the “POST error codes” on page 171.
vCheck the information LED panel System Error LED;
if on, see “Information panel system error LED” on
page 162.
vCheck the System Error Log. If an error was
recorded by the system, see “Symptom-to-FRU
index” on page 159.
vStart the Diagnostic Programs. See “Starting the
diagnostic programs” on page 21.
vCheck for the following responses:
a. One beep.
b. Readable instructions or the Main Menu.
3. DID YOU RECEIVE BOTH OF THE CORRECT
RESPONSES?
NO. Find the failure symptom in “Symptom-to-FRU index”
on page 159.
YES. Run the Diagnostic Programs. If necessary, refer to
“Starting the diagnostic programs” on page 21.
If you receive an error, go to “Symptom-to-FRU index” on
page 159.
If the diagnostics completed successfully and you still
suspect a problem, see “Undetermined Problems” on
page 183.
2: Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

General information
Your IBM
®
Netfinity
®
5100 server is a high-performance,
symmetric multiprocessing (SMP) server. It is ideally suited
for networking environments that require superior
microprocessor performance, efficient memory
management, flexibility, and large amounts of reliable data
storage.
Your IBM Netfinity 5100 server comes with a three-year
limited warranty and IBM Netfinity/PC Server 90-Day Start
Up Support. If you have access to the World Wide Web,
you can obtain up-to-date information about your Netfinity
5100 model and other IBM server products at the following
World Wide Web address:
http://www.ibm.com/pc/us/netfinity/
Your server serial number and model number are located
on labels on the rear of the server and on the front under
the trim bezel. You will need these numbers when you
register your server with IBM. To register your server, go to
the following World Wide Web address:
http://www.ibm.com/pc/register
To find the meanings of various computer-related terms,
you can access the IBM Netfinity 5100 at the following
World Wide Web address:
http://www.networking.ibm.com/nsg/nsgmain.htm
Features and specifications
The following table provides a summary of the features
and specifications for your Netfinity 5100 server.
Microprocessor:
vIntel
®
Pentium III microprocessor with MMX technology
and SIMD extensions
v256 KB Level-2 cache (min.)
vSupports up to two microprocessors
Memory:
vStandard: 128 MB
vMaximum: 4GB
vType: 133 MHz, ECC, SDRAM, Registered DIMMs
vSockets: 4 dual inline sockets
Drives standard:
vDiskette: 1.44 MB
vCD-ROM: 40X IDE
Expansion bays:
vHot-swap: 6 slim high or 3 half high
© Copyright IBM Corp. 2000 3

vNon-hot-swap: Three 5.25-inch (one used by CD-ROM
drive)
PCI expansion slots:
vThree 33 MHz/ 64-bit slots
vTwo 33 MHz/ 32-bit slots
Power supplies: 250 W (115-230 Vac)
vStandard: One, non-hot-swappable
vMaximum: Three, only with optional power backplane
that enables multiple power supplies and
hot-swappability
Video:
vS3 Savage 4 video controller (integrated on system
board)
vCompatible with SVGA and VGA
v4 MB video memory
Size (Rack Model)
vHeight: 220 mm (8.7 in.)
vDepth: 630 mm (24.8 in.)
vWidth: 440 mm (17.3 in.)
vWeight: approximately 27.22 Kg (60 lb.) when fully
configured
Size (Tower Model)
vHeight: 440 mm (17.3 in.)
vDepth: 660 mm (26.0 in.)
vWidth: 220 mm (8.7 in.)
vWeight: approximately 27.22 Kg (60 lb.) when fully
configured
Integrated functions:
vNetfinity Advanced System Management processor
vDual channel Ultra2 SCSI controller (both channels
internal)
vOne 10BASE-T/!00BASE-TX AMD Ethernet controller
vOne S3 Savage 4 video controller
vTwo serial ports
vOne parallel port
vTwo Universal Serial Bus (USB) ports
vKeyboard port
vMouse port
vVideo port
Acoustical noise emissions:
vSound power, idling: 6.0 bel maximum
vSound power, operating: 6.0 bel maximum
vSound pressure, operating: 45 dBa maximum
Environment:
4: Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

vAir temperature:
– Server on: 10║to 35║C (50.0║to 95.0║F). Altitude:
0 to 914 m (2998.7 ft.)
– Server on: 10║to 32║C (50.0║to 89.6║F). Altitude:
914 m (2998.7 ft.) to 2133 m (6998.0 ft.)
– Server off: 10║to 43║C (50.0║to 109.4║F).
Maximum altitude: 2133 m (6998.0 ft.)
vHumidity:
– Server on: 8% to 80%
– Server off: 8% to 80%
Heat output: Approximate heat output in British Thermal
Units (BTU) per hour:
vMinimum configuration: 683 BTU (200 watts)
vMaximum configuration: 2048 BTU (600 watts)
Electrical input:
vSine-wave input (50-60 Hz) required
vInput voltage low range:
– Minimum: 90 V ac
– Maximum: 137 V ac
vInput voltage high range:
– Minimum: 180 V ac
– Maximum: 265 V ac
vInput kilovolt-amperes (kVA) approximately:
– Minimum: 0.08 kVA
– Maximum: 0.42 kVA
What your IBM Netfinity 5100 offers
The unique design of your server takes advantage of
advancements in symmetric multiprocessing (SMP), data
storage, Your server combines:
vImpressive performance using an innovative approach to
SMP
Your server supports up to two Pentium III
microprocessors. Your server comes with one
microprocessor installed; you can install an additional
microprocessor to enhance performance and provide
SMP capability.
vLarge data-storage and hot-swap capabilities
All models of the server support up to six hot-swap hard
disk drives. This hot-swap feature enables you to
remove and replace hard disk drives without turning off
the server.
vRedundant power capabilities
The standard 250-watt power supply in your server can
handle a load of up to 250 watts. By replacing the
power backplane with the optional backplane that
provides hot-swap capability to the power supplies, you
can install a second, optional power supply. This
General information 5

provides a full 500 watts of power. If the average load
on your server is less than 250 watts and a problem
occurs with one of the power supplies, the other power
supply can handle the load (redundant power). If the
average load on your server is greater than 250 watts,
and you have installed a second power supply, you can
install a third, optional power supply to provide
redundancy.
The OVERCURRENT light emitting diode (LED) on the
system board is lit when the power load is 250 watts or
greater with two power supplies, or when the power load
is 500 watts or greater with three power supplies.
vLarge system memory
The memory bus in your server supports up to 4 GB of
system memory. The memory controller provides error
correcting code (ECC) support for up to four industry
standard PC133, 3.3 V, 168-pin, 8-byte, registered,
synchronous-dynamic-random access memory (SDRAM)
DIMMs (Intel PC-Registered SDIMM Specifications,
Revision 1.0 or later), synchronous, dual inline memory
modules.
vSystem-management capabilities
Your server comes with a Netfinity Advanced System
Management Processor on the system board. This
processor, in conjunction with the Netfinity Manager
™
provided on your ServerGuide CDs, allows you to
manage the functions of the server locally and remotely.
The Netfinity Advanced System Management Processor
also provides system monitoring, event recording, and
dial-out alert capability.
Note: The Netfinity Advanced System Management
Processor is sometimes referred to as the service
processor.
Refer to the Advanced System Management section for
more information.
vIntegrated network environment support
Your server comes with an Ethernet controller on the
system board. This Ethernet controller has an interface
for connecting to 10-Mbps or 100-Mbps networks. The
server automatically selects between 10BASE-T and
100BASE-TX. The controller provides full-duplex (FDX)
capability, which allows simultaneous transmission and
reception of data on the Ethernet local area network
(LAN).
vRedundant network-interface card
The addition of an optional, redundant network interface
card (NIC) provides a failover capability to a redundant
Ethernet connection. If a problem occurs with the
primary Ethernet connection, all Ethernet traffic
6: Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

associated with this primary connection is automatically
switched to the redundant NIC. This switching occurs
without data loss and without user intervention.
vIBM ServerGuide CDs
The ServerGuide CDs included with IBM Netfinity
servers provide programs to help you set up your server
and install the network operating system (NOS). The
ServerGuide program detects the hardware options
installed, and provides the correct configuration program
and device drivers. In addition, the ServerGuide CDs
include a variety of application programs such as IBM
Update Connector to help keep your server BIOS and
microcode updated, and IBM Netfinity Manager for
systems management.
For more information about the ServerGuide CDs, see
the ServerGuide and Netfinity Manager Information
section.
Your server is designed to be cost-effective, powerful, and
flexible. It uses peripheral component interconnect (PCI)
bus architecture to provide compatibility with a wide range
of existing hardware devices and software applications.
As always, your IBM server meets stringent worldwide
certifications for power, electromagnetic compatibility
(EMC), and safety. Refer to the ‘Safety Information’
section. for additional information.
Reliability, availability, and serviceability
features
Three of the most important features in server design are
reliability, availability, and serviceability (RAS). These
factors help to ensure the integrity of the data stored on
your server; that your server is available when you want to
use it; and that should a failure occur, you can easily
diagnose and repair the failure with minimal inconvenience.
The following is an abbreviated list of the RAS features
that your server supports. Many of these features are
explained in later chapters or sections.
vMenu-driven setup, system configuration, RAID
configuration, and diagnostic programs
vPower-on self-test (POST)
vIntegrated Netfinity Advanced System Management
Processor
vPredictive failure alerts
vSystem auto-configuring from configuration menu
vRemote system problem-determination support
vPower and temperature monitoring
vFault-resilient startup
vHot-swap hard drive bays
General information 7

vError codes and messages
vSystem error logging
vUpgradable BIOS, diagnostics, and Netfinity Advanced
System Management Processor code
vAutomatic restart after a power failure
vParity checking on the SCSI and PCI buses
vError checking and correcting (ECC) memory
vRedundant hot-swap power supply option
vRedundant hot-swap cooling
vRedundant Ethernet capabilities (with optional adapter)
vVital Product Data (VPD) on processor complex, system
board, power backplane, SCSI backplane, and each
power supply.
vOperator information panel
vDiagnostic LEDs on the system board
vRemote Connect
Server controls and indicators
1 Operator information panel
2 Hard disk drive activity light
3 Hard disk drive status light
4 Serial number
8: Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY

5 Cover release latch
6 Reset button
7 Power control button
8 Power control button shield (if installed)
General information 9

Rack model
1 Cover release latch
2 Serial number
3 Hard disk drive activity light
4 Hard disk drive status light
5 Reset button
6 Power control button
7 Power control button shield (if installed)
8 Operator information panel
Reset Button: Press this button to reset the server and run
the power-on self-test (POST).
Operator Information Panel: The lights on this panel give
status information for your server. See “Operator
Information panel” on page 14 for more information.
Hard Disk Status Light: Each of the hot-swap drives has a
Hard Disk Status light. When this amber light is on
continuously, the drive has failed. When the light flashes
slowly (one flash per second), the drive is being rebuilt.
When the light flashes rapidly (three flashes per second),
the controller is identifying the drive.
Hard Disk Activity Light: Each of the hot-swap drives has a
Hard Disk Activity light. When this green light is flashing,
the controller is accessing the drive.
10 : Netfinity 5100 Type 8658 Models 11Y, 21Y, 31Y,
41Y,51Y,1RY,2RY,3RY,4RY,5RY
