IDEAL 61-340 User manual

#61-340
#61-342
Digital Multimeter
Instruction Manual

Register your product and access more information at
www.idealindustries.com
Read First: Safety Information
Understand and follow operating instructions carefully.
Use the meter, test leads and all accessories only as
specified in this manual; otherwise, the protection
provided by the meter can be impaired.
WARNING
To avoid possible electric shock, personal injury or
death, follow these guidelines:
• Do not use if meter appears damaged. Visually inspect
the meter to ensure case and jaws are not cracked.
• Inspect and replace test leads if insulation is damaged,
metal is exposed, or probes are cracked. Pay particular
attention to the insulation surrounding the connectors.
• Always ensure the meter, test leads and all accessories
meet or exceed the measurement category required
in the working environment. (i.e. CAT rating)
• Note that the measurement category and voltage
rating of combinations of the meter, the test leads,
and the accessories is the lowest of the individual
components.
• Do not use meter if it operates abnormally as
protection maybe impaired.
• Do not use during electrical storms or in wet weather.
• Do not use around explosive gas, dust, vapor,
amperage or in damp or wet environments.
• Do not apply more than the rated voltage to the meter.
• Remove the test leads from the input jacks before
measuring current.
• Replace battery as soon as battery indicator
appears to avoid false readings.
• Remove the test leads from the meter prior to
removing battery cover.
• Do not use without the battery and battery cover
properly installed.
• Do not attempt to repair this unit as it has no user-
serviceable parts.
• Use the proper terminals, functions and range for
your measurements.
• Never ground yourself when taking electrical
measurements.
• Connect the black common lead to ground or neutral
before applying the red test lead to potential voltage.
Disconnect the red test lead from the voltage first.
• Keep fingers behind the guard rings of the probe tips.
• Voltages exceeding 30VAC or 60VDC pose a shock
hazard so use caution.

CAUTION
To protect yourself, think “Safety First”:
• Comply with local and national safety codes.
• Use appropriate personal protective equipment such
as face shields, insulating gloves, insulating boots,
and/or insulating mats.
• Before each use:
- Perform a continuity test by touching the test leads
together to verify the functionality of the battery
and test leads.
- Use the 3 Point Safety Method. (1) Verify meter
operation by measuring a known voltage. (2) Apply
meter to circuit under test. (3) Return to the known
live voltage again to ensure proper operation.
• Always work with a partner.
Test Leads
Symbols on the Unit
Risk of Danger. Important Information. See
Manual.
Hazardous voltage. Risk of electrical shock.
Application around and removal from Hazard-
ous Live conductors is permitted.
AC (Alternating Current)
DC (Direct Current)
Earth Ground
CAT II
Measurement Category II applies to test and
measuring circuits connected directly to utiliza-
tion points (socket outlets and similar points)
of the low-voltage MAINS installation
CAT III Measurement Category III applies to measuring
circuits connected to the distribution part of the
building’s low-voltage MAINS installation
CAT IV Measurement Category IV applies to test and
measuring circuits connected at the source of
the building’s low-voltage MAINS installation
~
...
Guard ring
CAT IV 600V
CAT III 1000V CAT II 1000V

AC Converter: 61-340 model is averaging sensing, rms calibrated; 61-342 model is true rms sensing.
Accuracy: Accuracy is specified as +/-(a percentage of the reading + a fixed amount) at 23°C±5°C (73.4°F ± 9°F), less than 75% relative humidity.
Temperature Coefficient: 0.1 times the applicable accuracy specification from 32°F to 64°F and 82°F to 122°F (0°C to 18°C ; 28°C to 50°C).
Ranges & Accuracies
Function Range & Resolution Accuracy Overload Protection
DC Voltage 400.0m/4.000/40.00/400.0 V ±(0.5%+5)
600.0V ±(1.0%+3)
AC Voltage 400.0m/4.000/40.00/400.0/600 V ±(1.5%+5)
(40~400Hz)
DC Current 400.0/4000 µA ; 40.00/400.0 mA ±(0.5%+5) 500mA/600V Fast Fuse
4.000/10.00 A ±(1.5%+5) 10A/1000V Fast Fuse
AC Current 400.0/4000 µA ±(1.5%+5) 500mA/600V Fast Fuse
(40~400Hz) 40.00/400.0 mA ±(2.0%+5)
4.000/10.00 A ±(2.5%+5) 10A/1000V Fast Fuse
400.0Ω±(1.2%+5)
Resistance 4.000k/40.00k/400.0k Ω±(1.0%+2) 600V DC/AC rms
4.000MΩ  ±(1.2%+2)
40.00MΩ  ±(2.0%+5)
40.00nF ±(3.0%+10)
Capacitance* 400.0n/4.000µ/40.00µ F ±(3.0%+5) 600V DC/AC rms
400.0µ/4000µ F ±(20%+5)
Frequency 10.00/100.0/1.000k/10.00k/100.0k/1.000M/10.00M Hz ±(0.1%+3) 600V DC/AC rms
Sensitivity: <1MHz: 0.7Vrms ; >1MHz: 5Vrms
Duty Cycle 0.1 - 99.9% ±(2.5%+5) (<10kHz)
Diode CheckTest current : (1±0.6) mA and then open circuit voltage is 2.5VDC typical. 600V DC/AC rms
Continuity The beeper turns on <25Ωand turns off at >120Ω. 600V DC/AC rms
Temperature** -58~1500°F ±(3.0%+5) —
-50~800°C ±(3.0%+3)
*Accuracy not available for <10nF capacitance. **Accuracy is stated for meter only. Thermocouple accuracy adds another ±2.5% to reading.
Input Impedance : 10MΩfor VAC & VDC. CF > 2, add ±1.0% to accuracy.
Symbols on the Unit

AC Converter: 61-340 model is averaging sensing, rms calibrated; 61-342 model is true rms sensing.
Accuracy: Accuracy is specified as +/-(a percentage of the reading + a fixed amount) at 23°C±5°C (73.4°F ± 9°F), less than 75% relative humidity.
Temperature Coefficient: 0.1 times the applicable accuracy specification from 32°F to 64°F and 82°F to 122°F (0°C to 18°C ; 28°C to 50°C).
Function Range & Resolution Accuracy Overload Protection
DC Voltage 400.0m/4.000/40.00/400.0 V ±(0.5%+5)
600.0V ±(1.0%+3)
AC Voltage 400.0m/4.000/40.00/400.0/600 V ±(1.5%+5)
(40~400Hz)
DC Current 400.0/4000 µA ; 40.00/400.0 mA ±(0.5%+5) 500mA/600V Fast Fuse
4.000/10.00 A ±(1.5%+5) 10A/1000V Fast Fuse
AC Current 400.0/4000 µA ±(1.5%+5) 500mA/600V Fast Fuse
(40~400Hz) 40.00/400.0 mA ±(2.0%+5)
4.000/10.00 A ±(2.5%+5) 10A/1000V Fast Fuse
400.0Ω±(1.2%+5)
Resistance 4.000k/40.00k/400.0k Ω±(1.0%+2) 600V DC/AC rms
4.000MΩ  ±(1.2%+2)
40.00MΩ  ±(2.0%+5)
40.00nF ±(3.0%+10)
Capacitance* 400.0n/4.000µ/40.00µ F ±(3.0%+5) 600V DC/AC rms
400.0µ/4000µ F ±(20%+5)
Frequency 10.00/100.0/1.000k/10.00k/100.0k/1.000M/10.00M Hz ±(0.1%+3) 600V DC/AC rms
Sensitivity: <1MHz: 0.7Vrms ; >1MHz: 5Vrms
Duty Cycle 0.1 - 99.9% ±(2.5%+5) (<10kHz)
Diode CheckTest current : (1±0.6) mA and then open circuit voltage is 2.5VDC typical. 600V DC/AC rms
Continuity The beeper turns on <25Ωand turns off at >120Ω. 600V DC/AC rms
Temperature** -58~1500°F ±(3.0%+5) —
-50~800°C ±(3.0%+3)
*Accuracy not available for <10nF capacitance. **Accuracy is stated for meter only. Thermocouple accuracy adds another ±2.5% to reading.
Input Impedance : 10MΩfor VAC & VDC. CF > 2, add ±1.0% to accuracy.

AC Converter: 61-340 model is averaging sensing, rms calibrated; 61-342 model is true rms sensing.
Accuracy: Accuracy is specified as +/-(a percentage of the reading + a fixed amount) at 23°C±5°C (73.4°F ± 9°F), less than 75% relative humidity.
Temperature Coefficient: 0.1 times the applicable accuracy specification from 32°F to 64°F and 82°F to 122°F (0°C to 18°C ; 28°C to 50°C).
Function Range & Resolution Accuracy Overload Protection
DC Voltage 400.0m/4.000/40.00/400.0 V ±(0.5%+5)
600.0V ±(1.0%+3)
AC Voltage 400.0m/4.000/40.00/400.0/600 V ±(1.5%+5)
(40~400Hz)
DC Current 400.0/4000 µA ; 40.00/400.0 mA ±(0.5%+5) 500mA/600V Fast Fuse
4.000/10.00 A ±(1.5%+5) 10A/1000V Fast Fuse
AC Current 400.0/4000 µA ±(1.5%+5) 500mA/600V Fast Fuse
(40~400Hz) 40.00/400.0 mA ±(2.0%+5)
4.000/10.00 A ±(2.5%+5) 10A/1000V Fast Fuse
400.0Ω±(1.2%+5)
Resistance 4.000k/40.00k/400.0k Ω±(1.0%+2) 600V DC/AC rms
4.000MΩ  ±(1.2%+2)
40.00MΩ  ±(2.0%+5)
40.00nF ±(3.0%+10)
Capacitance* 400.0n/4.000µ/40.00µ F ±(3.0%+5) 600V DC/AC rms
400.0µ/4000µ F ±(20%+5)
Frequency 10.00/100.0/1.000k/10.00k/100.0k/1.000M/10.00M Hz ±(0.1%+3) 600V DC/AC rms
Sensitivity: <1MHz: 0.7Vrms ; >1MHz: 5Vrms
Duty Cycle 0.1 - 99.9% ±(2.5%+5) (<10kHz)
Diode CheckTest current : (1±0.6) mA and then open circuit voltage is 2.5VDC typical. 600V DC/AC rms
Continuity The beeper turns on <25Ωand turns off at >120Ω. 600V DC/AC rms
Temperature** -58~1500°F ±(3.0%+5) —
-50~800°C ±(3.0%+3)
*Accuracy not available for <10nF capacitance. **Accuracy is stated for meter only. Thermocouple accuracy adds another ±2.5% to reading.
Input Impedance : 10MΩfor VAC & VDC. CF > 2, add ±1.0% to accuracy.
900VDC
750VAC rms

AC Voltage (V~)
DC
DC
DC Voltage (V )
Toggle for
Frequency
(>20% of
range)

Capacitance ( )
nF
nF
WARNING: De-energize circuit before
taking resistance measurement.
WARNING: De-energize circuit and
discharge capacitor before taking capaci-
tance measurement.
Measuring time: < 15sec for <400µF
< 1min for <4000µF
MΩ
MΩ
Resistance (Ω)
Toggle for

AC/DC Current (A )
DC A
Closed
Circuit
Open
Circuit
Ω
WARNING: De-energize circuit first.
~
Toggle for
AC
Toggle for
Hz
Toggle for
•)))
Closed
Circuit
Open
Circuit
Ω
Audible Continuity (•))))
DC A
Turn power off, break circuit, insert meter in
series, then turn power back on.
WARNINGS:
• Check fuse for continuity before testing.
• Use the proper switch position and lead
inputs.
• Never attempt to measure current on
circuits or equipment with more than
600 volts potential.
• Duty cycle: 15sec ON / 15min OFF for
10A MAX

Bad Diode
Good Diode
Ope
nS
horted
Foward Reverse
Diode Test ( )
WARNING: De-energize circuit before
checking diode.
WARNING: To avoid electric shock, do
not place test leads or thermocouple on a
voltage source.
Toggle for
Bad Diode
Good Diode
Open Shorted
Foward Reverse
CAT II
MAX
300V
+
–
Temperature
Toggle for
°C
Bad Diode
Good Diode
Open Shorted
Foward Reverse
CAT II
MAX
300V
