IFM Efector 200 OGE08 Series User manual

Operating instructions
Through-beam sensor
OGE08x
OGS08x
704942 / 00 10 / 2010
UK

2
1 Functions and features
The through-beam sensor detects objects and materials without contact and
indicates their presence by a switching signal.
For the range see the type label.
2 Installation
► Install the receiver (OGE08x) and secure it to a bracket.
► Align the transmitter (OGS08x) to the receiver and secure it also to a bracket.
> Maximum range only with accurate alignment.
3 Electrical connection
► Disconnect power.
► Connect the unit as follows.
► The device shall be protected by a Listed fuse rated 2A max
► Recommendation: check the unit for reliable function after a short
circuit
3.1 Transmitter
2
3
L1
N

3
UK
3.2 Receiver
2
3
L1
N
4 Operation
Check whether the sensor operates correctly.
• Receiver (OGE08x): The yellow LED is lit when the switching output is swit-
ched.
• Transmitter (OGS08x): The green LED is lit when the sensor is ready for
operation.
5 Maintenance
► Keep the lens of the sensor free from soiling.
► For cleaning do not use any solvents or cleaning agents which could damage
the plastic material.
