Impex CB-729 User manual

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
CB-729
Retain This
Manual for
Reference
07-23-09
OWNER'S
MANUAL
COMPETITOR
WEIGHT BENCH
CB-729
IMPEX®INC.
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................…. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
HARDWARE PACK…….....…....................................................................…… 4
ASSEMBLY INSTRUCTIONS........................................................................… 5
EXPLODED DIAGRAM……………………………………………………………… 9
PARTS LIST...............................................................................................…… 10
WARRANTY.................................................................................................…. 11
ORDERING PARTS.......................................................................................… 11
BEFORE YOU BEGIN
Thank you for selecting the COMPETITOR CB-729 Weight Bench by
IMPEX®INC. For your safety and benefit, read this manual carefully
before using the machine. As a manufacturer, we are committed to
provide you complete customer satisfaction. If you have any questions,
or find there are missing or damaged parts, we guarantee you complete
satisfaction through direct assistance from our factory. To avoid
unnecessary delays, please call our TOLL-FREE customer service
number. Our Customer Service Agents will provide immediate
assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]m

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain
precautions apply whenever you operate a piece of exercise equipment. Be
sure to read the entire manual before you assemble or operate your machine.
In particular, note the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other
abnormal symptoms, STOP the workout at once. CONSULT A
PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the
machine near water or outdoors.
5. Keep hands and feet away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. A spotter is recommended during exercise.
CARE AND MAINTENANCE
1. Inspect and tighten all parts before using the machine.
2. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
3. Maximum weight on Crutch 300 lbs.
4. Maximum user weight: 300 lbs.
5. Maximum weight on Leg Developer: 100 lbs.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT
YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH
PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS
EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR
PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2

WARNING LABEL REPLACEMENT
The Warning Label shown here has been placed on the Cross Brace. If the label is missing or
illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in
location shown.
3

HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size.
4

ASSEMBLY INSTRUCTION
Tools Required for Assembling this Machine: Two Adjustable Wrenches and Allen
Wrenches. NOTE: It is strongly recommended that two or more people assemble
this machine to avoid possible injury.
STEP 1 (See Diagram 1)
A.) Do not tighten Nuts and Bolts until instructed to do so.
B.) Connect the two Upright Beams (#1) by a Cross Brace (#3) in the Mid-span. Secure
each end of the Cross Brace with two M10 x 3 1/8” Carriage Bolts (#25), one Bracket
(#10), two ∅¾” Washers (#35), and two M10 Aircraft Nuts (#32).
C.)Insert two Crutches (#2) into the two Upright Beams. Secure each Crutch with a Lock
Knob (#12) at selected height. DIAGRAM 1
5

STEP 2 (See Diagram 2)
A.) Attach the Main Seat Support (#4) to the Front Post (#5). Secure it with three M10 x
5/8” Allen Bolts (#40) and three Ø ¾” Washers (#35).
B.) Attach the Main Seat Support to the Cross Brace (#3). Secure it with two M10 x 2
5/8” Carriage Bolts (#26), one Bracket (#10), two Ø ¾” Washers (#35), and two
M10 Aircraft Nuts (#32).
C.) Attach the Diagonal Support (#6) to the Main Seat Support and Front Post. Secure
each end with one M8 x ¾” Allen Bolt (#28) and one Ø 5/8” Washers (#37).
D.) Securely tighten all Nuts and Bolts installed in Step-1 and Step-2. DIAGRAM 2
6

STEP 3 (See Diagram 3)
A.) Attach the Leg Developer (#7) to the open bracket on the Front Post (#5). Secure it
with one M8 x 3” Allen Bolt (#30), two Ø 5/8” Washers (#37), and one M8 Aircraft
Nut (#33).
B.) Attach the pivot on Backrest Support (#8) to the open bracket on Main Seat
Support (#4). Secure it with one M12 x 3 ½” Allen Bolt (#39), two Ø 1” Washers
(#36), and one M12 Aircraft Nut (#34).
C.) Attach the pivot on Incline Support (#9) to the open bracket on Backrest Support.
Secure it with one M10 x 2 3/8” Allen Bolt (#31), two Ø ¾” Washers (#35), and one
M10 Aircraft Nut (#34). Attach the other end of Incline Support onto the selected
slot on Main Seat Support to obtain the desired Backrest incline.
D.) Note: Do not over tighten the Nut and Bolt to the pivot. The Backrest Support
and Incline Support need to be able to move smoothly. DIAGRAM 3
7

STEP 4 (See Diagram 4)
A.) Attach the Backrest Board (#14) to the Backrest Support (#8). Secure it with two M8
x 1 ¾” Allen Bolts (#29) and two Ø 5/8” Washers (#37).
B.) Attach the Seat Pad (#13) to Main Seat Support (#4). Secure it with four M6 x 1 ¼”
Hex Bolts (#27) and four Ø ½” Washers (#38).
C.) Insert two Foam Tubes (#11) halfway through the holes on the Leg Developer (#7).
Push four Foam Rolls (#17) onto the Tubes from each end. Plug four Foam Roll End
Caps (#19) to each End.
D.) Slide an Olympic Sleeve (#41) onto the weight post on Leg Developer. Attach a
Spring Clip (#24) onto Olympic Sleeve.
DIAGRAM 4
8

9
