Inepro PayMatic AD 2400 User manual

© 2020 Inepro B.V. All rights reserved
Technical Manual | PayMatic AD 2400 (-B)
PayMatic AD 2400 (-B)

PayMatic AD 2400 (-B)
Congratulations on your selection of the Inepro PayMatic AD 2400 (-B). We are certain
you will be pleased with your purchase of one of the flexibele solutions of the market.
We want to help you get the best result from your PayMatic AD 2400 (-B). This
manual contains information on how to do that; please read it carefully. Due to
continuous product improvements this manual is subject to changes without notice.
We strongly recommend you read the license agreement to fully understand its
coverage and your responsibilities of ownership.
Your Inepro dealer is dedicated to your satisfaction and will be pleased to answer your
questions and your concerns.
Best wishes,
Inepro BV.
The most versatile payment solution

All rights reserved. No parts of this work may be reproduced in any form or by any means -
graphic, electronic, or mechanical, including photocopying, recording, taping, or information
storage and retrieval systems - without the written permission of the publisher.
Products that are referred to in this document may be either trademarks and/or registered
trademarks of the respective owners. The publisher and the author make no claim to these
trademarks.
While every precaution has been taken in the preparation of this document, the publisher and
the author assume no responsibility for errors or omissions, or for damages resulting from the
use of information contained in this document or from the use of programs and source code
that may accompany it. In no event shall the publisher and the author be liable for any loss of
profit or any other commercial damage caused or alleged to have been caused directly or
indirectly by this document.
Revision number R 1. This revision of the manual can be applied to products with version V.23
or higher.
Publisher
Managing Editor
Technical Editors
Cover Design
Inepro B.V.
K. de Graaf
P. Grimmerink
K. de Graaf
Production
Inepro B.V.
Team Coordinator
R. Groen
H. Wagenaar
J. van den Berg
PayMatic AD 2400 (-B)
P. Blom

Table of Contents
Introduction 1
Functionality 3
.................................................................................................... 4Versions
.................................................................................................... 4Standard functioning (without Ecos modules):
.................................................................................................... 5Extra functioning (with all Ecos modules):
Programming Functions 0
Function Overview 6
Specifications 17
Connection 19
.................................................................................................... 20Open / disassemble the PayMatic
.................................................................................................... 23Connection sheet for solenoid valve.
.................................................................................................... 26Connection sheet for a 4 pole 20 A contactor
Appendix 27
.................................................................................................... 28Wiring diagr am
.................................................................................................... 33T roubleshooting
.................................................................................................... 3 4Flowchart
Notes 35

ATTENTION!!
Read this manual carefully before installing the P ay M atic A D 2400 (-B)!
Mains connection
Guar entee
Security
Before connecting the appliance to the mains, check that the mains supply v oltage corresponds
to the v oltage printed on the ty pe plate of the adapter. If the mains v oltage is different, consult
y our supplier.
No guarantee can be giv en if safety regulations are not follow ed.
A lw ay s disconnect the pow er supply before handling any thing inside the dev ice.
This dev ice is in conformity w ith the EM C directiv e and low -v oltage directiv e.
CE Confor mité Eur opeène (C onfor m Eur opean Norm)
WEEE Dir ective (Waste of Electrical and Electr onic Equipment)
Inepro considers it important to properly take the climate into account. We therefore produce as
many climate-friendly products. Your new dev ice contains materials w hich can be recy cled and
then reused. A t the end of life, specialized companies can dismantle the dev ice, to materials w hich
can be reused in order to recy cle and reuse. F or example, the materials that must be discarded w ill
be limited to a minimum. P lease take into account the rules and regulations in y our area regarding
the rules about disposal of packaging materials, exhausted bateries and old equipment.
Thank y ou, Inepro BV
This dev ice may only be used indoors.
Indoor User O nly
Directives
Due to continuous product improv ements this manual is subject to change w ithout notice. This
document describes the technical and functional operation of the Pay M atic A D 2400 (-B). G reatest
care has been taken drafting the information in this manual and it may be said that it is reliable.
How ev er, the producer is not liable for any shortcomings in the text or incompleteness of the
information. Thank y ou for y our decision to use the Pay M atic A D 2400 (-B).
T his document:

I
Introduction
Part

Introduction
2
Introduction
This document:
This document describes the technical and functional operation of
the 240V mains voltage and 24V low voltage PayMatic® versions.
Greatest care has been taken drafting the information in this manual
and it may be said that it is reliable. However, the producer is not
liable for any shortcomings in the text or incompleteness of the
information.
Thank you for your decision to use the PayMatic®.
Introduction
The PayMatic® standard control board design includes a minimum
of functionality. The functionality of the PayMatic® can be expanded
by means of additional “ECOS”® software modules. Thus, it is
possible to produce perfectly customised PayMatics®. PayMatic®
outputs have two neutral relay points to control a connected device
over a certain programmable length of time. This PayMatic® is
programmed in a user-optimised way by means of two control keys.
With its potted electronics and its extensibility by means of
“ECOS”® software modules the PayMatic® is a very special timer of
its kind.
“ECOS”® : Electronic Customised Option System

II
Functionality
Part

Functionality
4
Versions
There are two types of PayMatic® available as the functioning of the
PayMatic® mainly depends on the additional software modules and
the settings.
The difference between the two types of timer is in the design of the
mechanical coin selector. Both types of coin selector accept 1 type
of coin or token only. The PayMatic can be fixed to a wall using the
4 x M4 x 40mm screws and the M4 40mm plugs.
Standard (without Ecos modules)
In the basic version during stand-by a point () will be shown on the
display.
As soon as the main time is connected the display will change into
two hyphens ( ). The maximum period of time to be programmed
in the PayMatic® is 15 minutes.
The main time starts after inserting a coin or by means of a
continuous external drive. The PayMatic® output is programmable. It
may be chosen between the standard “continue” output, which
means that both relays are activated during main time, and a “pulse”
output, which means that a pulse is generated at the beginning and
the end of the main time.
The operator may choose either to allow the creation of a pause
during the main time or not. If a pause is allowed, it can be created
by pressing the up key. The operator can also choose between
interrupting and continuing the main time during the pause mode.

Extra functioning (with all Ecos modules):
5 - PayMatic AD 2400 (-B)
Extra (with all Ecos modules)
The PayMatic® can be activated with three freely programmable
time-segments. The duration of these time-segments can be set at 0
to 255 minutes.
The PayMatic® starts with a prior time . During the prior time the
length of the main time will be shown intermittently on the
display. During the prior time it is possible to reduce the main time if
necessary. The prior time can also be bypassed so that the main
time will start automatically. During the main time the remaining time
will be shown on the display.
Another possibility consists of the automatic main time
adjustment based on the progression of the service counter.
The main time is automatically followed by the post time . During
the post time (cool) is displayed.
After the post time it is possible to activate a clean function , in
this case is displayed intermittently. This clean function inhibits
the PayMatic®.
Furthermore, there is an “after start” function by means of which
an extra main time of 30 seconds can be given at the end of the
whole session.
Registration facilities, as for example coin, running time and service
counters can also be used. The start and running time counters may
either be activated as counters, which can be reset, or as cumulative
counter, which can not be reset. Automatic representation of the
Running time counter is affected by pressing the Down key during 3
seconds. The service counter generates a (service message) on
the display.
7
7
13
7
10
14

IV
Function Overview
Part

7 - PayMatic AD 2400 (-B)
Function overview
This is an overview of all the functions in the MT 2400. Functions
with the symbol need the relevant ECOS module. These software
modules need to be bought and installed with the unit.
Function F0, Quitting the function menu
Function
Quit Menu
Activ ate this f unction the MT 2400® to program or quit the menu.
Function F1, Main time setting per coin
Function
Main time setting per coin
Value
Description
Default
1-15
Main time duration in minutes, per 1 inserted coin. (1-15 minutes)
12 (Max. 15)
1-255
With ECOS module EM-01 y ou can set the main time f rom 1-
255 minutes.
12 (Max. 255)
Note:
If a v alue of more than 100 minutes is programmed the indication will be display ed
intermittently in two parts; f irst display “1”, second display “00”.
Function F2, Prior time setting
(ECOS module EM-02)
Function
Prior time setting. Before the main time is started, relay 2 will be closed.
Prior Time is the duration in minutes that relay 2 is closed before the main
time begins. The relay will remain closed during the the main time.
Value
Description
Default
1-255
Duration in minutes
3
Function F3, Post time setting
(ECOS module EM-03)
Function
Post time setting. When the main time has ended, relay 2 is still closed. Post
Time is the duration in minutes that relay 2 will stay closed after the main
time has ended. After this relay 2 will open.
Value
Description
Default
1-255
Duration in minutes
2

Function Overview
8
Function F4, Maximum amount of coins
(ECOS module EM-04)
Function
Maximum amount of coins. Maximum amount of coins that can be activated
to increase cumulatively the total main time.
Value
Description
Default
1-255
Max. number of coins
1
Note:
The v alue of this setting has to be at least 1.
Function F5, Minimum amount of coins
(ECOS module EM-05)
Function
Minimum amount of coins which have to accepted in order to activate the MT
2400®. For example, 3 coins for 5 minutes. The value of this setting has to
be at least 1. If the programmed value is higher than 1, the coins will be
shown on the displayed until the necessary amount is reached.
Value
Description
Default
1-255
Max. number of coins
1
Note:
The v alue of this setting has to be at least 1.
Configuration example F4 & F5 , with F1 (time per coin) set at 5
minutes
Example #
Event
1
2
3
4
5
6
1e coin inserted
5 minutes
5 minutes
0 minutes
0 minutes
5 minutes
0 minutes
2e coin inserted
-
5 minutes
5 minutes
10
minutes
5 minutes
10 minutes
3e coin inserted
-
-
-
-
5 minutes
5 minutes
Total time
5 minutes
5 minutes
10
minutes
10
minutes
15
minutes
15 minutes
Value F4 (Max.
Coins)
1
1
2
2
3
3
Value F5 (Min.
Coins)
1
2
1
2
1
2

9 - PayMatic AD 2400 (-B)
Function F6, Service indicator 1
(ECOS module EM-06)
Function
The maximum amount of programmable running hours before a revision
service is required. This register will count down per 1000 minutes of relay
1 activity.
The value of this register represents the number x 1000 minutes, e.g. 5 =
5000 minutes.
When the counter reaches zero, the message will appear on the display.
This is the standard message to indicate that a revision “service” is
required.
Value
Description
Default
1-254
Number of serv ice minutes bef ore serv ice on dev ice is required.
When this counter has counted down to zero (serv ice counter = 0)
the MT 2400® will display . Number of minutes = Setting x 1000
minutes.
0
255
Disabled
Note:
The timer will keep running as usual. To reset, simply set the
v alue to a v alue higher then '0'.
Function F7, Service indicator 2
(ECOS module EM-07)
Function
The maximum amount of programmable running hours before a revision
service is required. This register will count down per 1000 minutes of relay
1 activity.
The value of this register represents the number x 1000 minutes, e.g. 5 =
5000 minutes.
When the counter reaches zero, the message will appear on the display.
This is the standard message to indicate that a revision “service” is
required.
Value
Description
Default
1-254
Number of serv ice minutes bef ore serv ice on dev ice is required.
When this counter has counted down to zero (serv ice counter = 0)
the MT 2400® will display and is inhibited until the counter is
reset. Number of minutes = Setting x 1000 minutes.
0
255
Disabled
Note:
To reset, simply set the v alue to a v alue higher then '0'.

Function Overview
10
Function F8, Buzzer setting
(ECOS module EM-08)
Function
Buzzer Setting
Setting
Description
Default
Note:
This setting is not applicable in this dev ice.
0
Function F9, Clean Function
(ECOS module EM-09)
Function
By means of this function it is possible to force the cleaning of a connected
device. After the posted time the MT 2400® does not accept any further coin
anymore. This blockage can be raised by pressing the internal or external
up key for 3 seconds. To indicate the necessity of cleaning will appear
intermittently on the MT 2400® display.
Setting
Description
Default
00
Clean f unction of f
1
01
Clean f unction on.
Function FA, Standard or external start mode
Function
Start Mode Type
Setting
Description
Default
00
The Pay Matic can be started by pushing the Timer button or by
generating a puls, which is longer as 200 msec, on the external
connection (remote button print).
1
01
The Pay Matic can be started by generating a pulse between the 20
and 200 msec. This setting is dedicated f or mechanical coin
mechanisms.
Note:
In case the coin mechanism input is selected (setting “01”) then
starting the timer with the Timer button is not possible.
When the timer button is selected (setting “00”), then by
generating a signal on the coin mechanism input, the pre-time can
be bridged to start the main-time. (This can be done by short
circuiting the coin mechanism connection pins)
This setting
must be set on
01 f or this
machine.

11 - PayMatic AD 2400 (-B)
Function FB, Running time counter (reset possible)
(ECOS module EM-10)
Function
Running time counter (reset possible)
Setting
Description
Default
0-6
The running time counter is an electronic counter, which registers
cumulativ ely the number of minutes the main channel, relay 1,
has been operativ e. The main channel relay 1 is only activ e during
the main time of the MT 2400®. It is possible to scroll the
counters by pressing the up key . The 6-digit counter is read
back to f ront, as f ollows;
Counter index
Example Value
1
1
2
3
3
7
4
5
5
0
6
0
In this example the total running time amounts to 005731 minutes
#
Value
1
0
2
0
3
0
4
0
5
0
6
0
Note:
Resetting the counters
Af ter reading the counters, these can be reset. The reset-procedure is as f ollows;
1) Af ter hav ing read the count (6X) press the up and the down key s
simultaneously
a) (2 hy phens) will appear on the display
2) To reset the counter press the up key ,
a) will appear on the display
3) Now press the up and the down key s simultaneously
a) The counters are reset and the MT 2400® will automatically resume its
f unction.
Note: if necessary , y ou can also read out the indication on the counter without
resetting it during the stand-by period, to do so, press the down key during 3
seconds. The indication of the counters of Function FB will be represented
automatically , but cannot be reset.
Function FC, Coin counter (reset possible)
(ECOS module EM-10)
Function
Coin counter (reset possible) This counter reproduces the number of coins.
Setting
Description
Default
0-6
Reading procedure as in f unction FB .
0
Note:
Counter can be reset, procedure like in f unction FB .
11
11
11

Function Overview
12
Function FD, Running time counter (reset
impossible)
(ECOS module EM-12)
Function
Running time counter (reset impossible)
Setting
Description
Default
0-6
Reading procedure as in f unction FB .
0
Note:
Counter can't be reset, procedure like in f unction FB .
Function FE, Coin counter (reset impossible)
(ECOS module EM-12)
Function
Coin counter (reset possible) This counter reproduces the number of coins.
Setting
Description
Default
0-6
Reading procedure as in f unction FB .
0
Note:
Counter can't be reset, procedure like in f unction FB .
11
11
11
11

13 - PayMatic AD 2400 (-B)
Function FF, TAT (Automatic main time adjustment)
(ECOS module EM-11)
Function
TAT (Automatic main time adjustment) Activating this function, the main time
is automatically adjusted on the basis of the service counter progression
(F6 & F7). If one of the two service counters is programmed again the TAT
function has to be reset again as well.
Setting
Description
Default
00
TAT f unction disabled
1
01
TAT f unction enabled
note:
Running hours
Prolongation per
minute
Running hours
Prolongation per
minute
0 – 49
+ 0 sec p/m
450 – 499
+ 24 sec p/m
50 – 99
+ 3 sec p/m
500 – 549
+ 27 sec p/m
100 – 149
+ 5 sec p/m
550 – 599
+ 30 sec p/m
150 – 199
+ 8 sec p/m
600 – 649
+ 30 sec p/m
200 – 249
+ 11 sec p/m
650 – 699
+ 30 sec p/m
250 – 299
+ 14 sec p/m
700 – 749
+ 30 sec p/m
300 – 349
+ 16 sec p/m
750 – 799
+ 30 sec p/m
350 – 399
+ 19 sec p/m
800 – 849
+ 30 sec p/m
400 – 449
+ 22 sec p/m
850 - 899
+ 30 sec p/m
The time adjustment is preprogrammed and depend on the maximum number of
running hours set in F6 & F7 . This table shows the prolongation per range
of running hours.
9 9

Function Overview
14
Function P0, Output configuration
Function
Output configuration. Relay output type.
Setting
Description
Default
00
Signal output, which is activ e throughout the whole session.
0
01
Pulse output, which is brief ly activ e/generating a pulse in the
beginning of the main time and in the beginning of the post time.
note:
This diagram
shows the
response of the
relay s at the
signal and pulse
setting.
Function P1, External drive facility
Function
External drive facility
Setting
Description
Default
00
Starting the Pay Matic happens through a short pulse on the timer
button or coin input (Depending on menu FA )
0
01
Starting the Pay Matic happens by an external dev ice. This dev ice
controls the main time. In case the signal is activ e, then also the
timer is activ e, unless the set time has ended. Interrupting the
activ e signal will put the Pay Matic in post-time (when enabled).
The controls is depending on the setting in menu FA (remote
button print input or coin mechanism input).
note:
This setting must be set on 0 f or this dev ice.
Function P2, After start
(ECOS module EM-07)
Function
After start; At the end of a whole session it is possible to allow one extra
time of 30 seconds. To obtain this time the down key has to be pressed. This
setting provides a solution for machines, which have to be connected for a
short period of time after the programmed time has expired, e.g. to open the
electric door of a washing machine.
Setting
Description
Default
00
Af ter start is disabled
1
01
Af ter start is enabled
10
10

15 - PayMatic AD 2400 (-B)
Function P3, Display indication
(ECOS module EM-14)
Function
Display indication, choice between of .
Setting
Description
Default
00
Display during stand by one point ( ), during the prior time, main
time and post time two hy phens will be display ed ( ).
1
01
Display indication in minutes
Function P4, Reduction of the main time
(ECOS module EM-13)
Function
Reduction of the main time
Setting
Description
Default
00
Main Time reduction disabled
1
01
Main Time reduction enabled
Note:
See P7 f or conf iguration.
Function P5, Pause during the main time
Function
Pause during the main time
Setting
Description
Default
00
Pause during the main time disabled
1
01
Pause during the main time enabled
note:
During a pause situation the remaining time will be intermittently indicated (if
display indication is set to 1 (P3 )). Note; this f unction works only with long
distance board!
Function P6, Main time during the pause
Function
Main time during the pause
Setting
Description
Default
00
Main time stops during the pause
1
01
Main time continues during the pause
16
15
Other manuals for PayMatic AD 2400
3
This manual suits for next models
1
Table of contents
Other Inepro Payment Terminal manuals

Inepro
Inepro Card Master CM500 User manual

Inepro
Inepro PayCon Touch - First Time Log On User manual

Inepro
Inepro PM - Copy Coin CM7000 - Xerox Config User manual

Inepro
Inepro PayMatic P2000 User manual

Inepro
Inepro PayCon Touch - Pillar User manual

Inepro
Inepro PayMatic 4B - Xerox MFP Manual

Inepro
Inepro Sales Master User manual

Inepro
Inepro Back Office Suite User manual

Inepro
Inepro PayMatic - D2000 - Internet Timer User manual

Inepro
Inepro PM - Copy 1600T for iR1600 User manual
