Infinity EVOLUTION MAX 4D User manual

EVOLUTION MAX 4D
User Manual

Welcome to
Thank you and congratulations on purchasing an Infinity Massage Chair - you’ve made a
great choice.
With over a decade of experience designing, building and servicing massage chairs,
Infinity takes pride in every chair sold, including yours. We are here for you. The US-
based Customer Care team can be reached at [phone] or visit us online at www.
infinitymassagechairs.com and find valuable self service resources under the SUPPORT tab,
including electronic copies of all documents and video tutorials.
Inside this manual, you will find everything you need to setup and safely enjoy your chair.
Please review the entire manual, including all safety information, before assembling or
using your chair. If you are assembling the chair yourself, please see the Assembly Guide
next and reference the online assembly video.
For convenience, we’ve also created a Quick Start Guide. We suggest you keep it in the
remote pocket as a tool to get to know all the features of your new chair.
Get ready to sit back, relax and enjoy the Ultimate Massage Experience.
We know you can’t wait to sit in your new Infinity Massage chair! Take a picture of you enjoying the ultimate
massage experience and make sure to tag us on social media with the hashtag #infinitymassagechairs
Register your product at www.infinitymassagechairs.com/warranty
to ensure it is in our system. This will simplify the warranty process
should you ever need it.
Alternatively, scan the QR code to go directly to the URL above.
Before assembling your chair, watch an assembly video at:
www.infinitymassagechairs.com/assembly-tutorials
Alternatively, scan the QR code to go directly to the URL above.
THE ULTIMATE MASSAGE EXPERIENCE
@infinitymassagechairs@infinitymassagechairs @infinity_chairs@infinity_chairs @infinitymassagechairs@infinitymassagechairs
SCAN CODE
SCAN CODE
Warranty Registration
Assembly Video

Table of Contents
Before Getting Started
Your Chair
Chair Setup
Taking Control
Installation Site
Clearance Space for the Chair
Floor Protection
Move Methods
Connect to Power
Chair Features
External Structure
8
8
8
9
9
6
7
Getting Comfortable
Main Power Switch
Adjust Pillow
Adjustable Shoulder Airbags
Reduce the Intensity of Your
Massage - Manually
TruefitTM Body Scanning
Getting Out Of The Chair
USB Charging Station
10
10
10
10
11
11
11
12
Remote Control Layout
Remote Control Operation
Auto Programs
Navigating the Remote
4D Intensity Control
Program Descriptions
Airbag Massage
Airbag Region
Airbag Intensity
Back Heat
Foot Reflexology Rollers & Total
Calf™Kneading and Oscillation
Joystick Control and Wireless
Charging/USB Port
14
15
16
16
16
17
18
18
18
18
19
19
Language
Voice Control
Remote Control Screen Brightness
Button Lights
Remote Control Sound
Bluetooth®Audio
Sleep Mode
Trouble Shooting
Specifications
Frequently Asked Questions
Manual Programs
Back Massage Technique Mode
Massage Part (Back Region)
Back Node Width
Massage Speed
Foot Reflexology Rollers & Total
Calf™Kneading and Oscillation
Weightless Zero Gravity Recline
Remote Control In-Use Screen
26
26
26
27
27
27
27
33
33
34
28
28
28
28
29
29
29
29
Staying Safe
Settings
Set Your Environment
Build Your Own
Fixing Issues
30
5
Warning! Read important safety information found on page 30 before using or operating chair.
WARNING
Air Ionizer
Timer
App Download & Installation
Activating Voice Control
Intelligent Voice
Command+Control
Turn Off Listening
Bluetooth®Audio
Sounds
Volume
Remote Control Beep
Demo Voice
Chromotherapy Programs
Light Themes
Light Colors
Light Brightness
20
20
20
21
21
21
22
22
23
23
23
24
24
24
25
Chair Entry & Exit
Chair Entry and Exit Hazards 13

Truefit
TM
Body
Scanning
Chair Features
6
Your Chair
4D Back Massage
Mechanism
Zero Wall Fit
TM
Space-
Saving Technology
See page 8 See page 16
See page 10
Adjustable
Shoulder Fit
See page 11
Foot Reflexology
Rollers
Bluetooth
R
Speakers
Joystick Control and
Wireless Charging/USB Port
See page 19
See page 19 & 29
See page 22 & 27
Manual Massage
Customization
See page 28
Air Ionizer
Complete Calf™
Kneading + Oscillation
Apple & Android
App Functionality
Intelligent Voice
Command + Control
See page 19 & 29 See page 20
See page 21
See page 20
Back Heat
See page 18
See page 24
Chromotherapy
Programs
See page 22
Nature Sounds
Weightless Zero
Gravity Recline
See page 29

7
External Structure
Speaker
Pillow
Back Cushion
Seat Cushion
Leg Rest
Back Cover
Joystick Control
Arm Rest
Caster
Foot Rest

8
- 4” clearance for the recline of the backrest; 24” clearance for the extension of footrest and
sliding forward of the chair.
- Keep it 3 feet away from the TV, radio or other audio & video appliance to avoid signal
interference.
Clearance Space for the Chair
Installation Site
Before Getting Started
We recommend to place a piece of thin carpet or soft mat underneath it to avoid damaging
the floor.
Floor Protection
- Do not use the massage chair in high moisture environment such as near a swimming pool or bathroom to
prevent electric shock accident.
- Please keep the massage chair away from heated surfaces to prevent fire hazard or damage to the product.
WARNING
Massage chair
Floor
Carpet
4”
- Keep the distance between the power socket and power switch within 60” to avoid damage of power cord
while massage chair sliding forward.
- Straighten the power cord while in use to avoid tangle or damage.
CAUTION
- To avoid serious injury or death, before sliding chair forward or backward check to make sure area is clear
of children, pets, or obstacles.
WARNING
24”

9
Apply pressure to the back of the massage chair from behind to pivot on the Castors.
Have a second person up front to guide the Footrest until in the correct position. Maintain
clearances as mentioned above. Gently lower into place. Do not pull on the side arms.
Move Methods
Connect to Power
CAUTION
- Do not move the chair when there is user inside.
- Chair is heavy. Use caution and get assistance when lifting to avoid injury. Do NOT lift chair by footrest or
armrests to avoid damage to product.
Plug into a 110V grounded outlet.
4”
WARNING – Improper connection of the equipment-
grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or serviceman if you are in doubt as to
whether the product is properly grounded. Do not modify the plug
provided with the product – if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
This product is for use on a nominal 120-V circuit and has a
grounding plug that looks like the plug illustrated. Make sure that
the product is connected to an outlet having the same configuration
as the plug. No adapter should be used with this product.
Earthing
This massage chair is a Class 1 electrical appliance. Make sure to
use a grounded outlet to the grounded power supply circuit and a
properly installed earth grounding rod with ground connection, to
avoid electric shock.
Grounding Instructions
To avoid risk of electrical shock, turn power switch off before plugging unit into electrical outlet. Use only
with properly grounded outlet (3 prong). Do not plug into ungrounded outlet.
Grounded
outlet
Grounding pin
WARNING

10
To power up the chair, flip the main
power switch located on the side of
the base of the chair to ON. Ensure
the electrical cord is connected to a
110V grounded outlet and plugged into
the power cord port located on the
back of the base of the chair.
Main Power Switch
Getting Comfortable
Chair Setup
Take a seat in the chair and take note of where the neck pillow
rests on your neck. Adjust the pillow so that it rests comfortably
in the arch of your neck. Do this by removing it from the velcro,
aligning it, and then reattaching to the velcro once it is in the
desired position.
Adjust Pillow Neck Pillow
Shoulder Airbag
- When not in use for a long period of time, we recommend that the chair be covered, the power cord be coiled
and that the unit be placed in an environment free of dust and moisture.
- To avoid possible damage to product or injury to unsupervised children, always turn off power switch and
unplug massage chair from electrical outlet immediately after use.
CAUTION
The shoulder airbags on your massage chair can be adjusted
to better your shoulder height. Should you need to adjust
the shoulder airbags up or down, simply grab the top of the
airbag and pull down. To bring the airbag back up, reverse this
process by grabbing the bottom edge and pulling up.
Adjustable Shoulder Airbags
Main Power
Switch
Power Cord Port

11
HO
M
E
HOMEHOM
E
To easily exit the chair at any time, press the ON/OFF power button
on the remote control to restore the chair to the upright position.
WARNING! Check to make sure children and pets are clear of chair
before pressing on/off button to return chair to upright position. See
next page for detailed hazard warnings.
Getting out of the Chair
Smart tip: To increase intensity in the neck
and shoulder region, flip the pillow or the
pillow and pillow pad up so you lay directly
on the seat back pad.
Body Scanning Shoulder Adjust Prompt
Truefit
TM
Body Scanning
Select any auto program and press the OK
button. The chair will automatically begin
scanning your body, mapping your back,
shoulders, and neck. During this process it
is important to remain seated back into the
chair without lifting your head. The scan can
be viewed on the remote control screen. If
fine tuning is needed just after your body
scan, wait for the shoulder adjust prompt to
appear and then use the Back Adjustment
buttons to move the massage rollers up or
down for the perfect shoulder kneading
position.
To make the massage less intense, you can add the back pad to the seat back of your chair,
or you can also fold down the neck rest to provide more cushioning between you and the
massage mechanism in the seat back. To make the foot rollers less intense, insert the foot
pads that came with your chair into the foot bed of the footrest.
Reduce the Intensity of your Massage - Manually

12
USB Charging Station
Your massage chair includes a USB-A port to charge your phone or tablet while using the chair.
This feature is especially helpful when using the app to control the chair.
The port is located on the left arm panel on the Joystick Control.
Chair Setup
Station
USB Charging

13
DANGER
DANGER
DANGER
Chair Entry and Exit Hazards
Chair Entry & Exit
WARNING! The areas under the footrest and behind the back rest are potentially
dangerous for a child or pet. The chair back is heavy and reclines with force. A small child or
pet located behind the chair could be crushed as chair is reclined resulting in serious injury
or death. When chair is reclined, small children or pets who have crawled under the leg rest
may not be visible to the user and could be crushed when leg rest is lowered or when chair is
returned to upright position. To avoid serious injury or death, check these areas carefully
before reclining, lowering leg rest, or returning chair to upright position.
Make sure to check for
children or pets between the
chair back and the base of
the chair before entering zero
gravity recline.
Make sure to check for children
or pets underneath the footwell
before exiting zero gravity
recline and returning to upright
position.
Make sure to check for
children or pets between the
footrest and the chair body
before lowering the legrest.

14
Remote Control Layout
Taking Control
HOME

15
Remote Control Operation
On/Off – Powers up the remote or returns the chair to the exit position and
powers down remote.
Home – Shortcut to the home page of all menu screens.
Pause – Press pause to immediately stop all massage chair activity, press again to
resume.
Feet Adjust – Press and hold up arrow to bring foot rest up, press and hold
down arrow to bring foot rest down.
4D 4D – Press to increase or decrease 4D intensity of back mechanism. In-use
screen displays intensity dial.
Auto – Shortcut to the Auto Programs menu screen.
Back Adjust – Back mechanism position adjustment; press and hold up to raise,
press and hold down to lower. Use during initial body scan fine tuning or in
manual point or Partial zone mode.
Foot Rollers – Press this button to toggle the foot reflexology rollers on or off.
Directional Button – Press up, down, left or right to navigate the display screen.
During the massage, press up or down buttons to adjust massage speed. Press
left or right button to adjust airbag intensity.
OK – After navigating to the command desired on the display, push OK to
select. During the massage, press OK button to switch to zero gravity.
Seat Back Position – Press and hold down arrow to recline the seat back, press
and hold the up arrow to upright the seat back.
Zero Gravity – Press for Zero Gravity 1, press again for Zero Gravity 2, press
again to restore recline to upright position.
Leg Length – Press and hold right arrow to extend the leg length adjustment,
press and hold the left arrow to retract the leg length adjustment.

16
H
OM
E
Auto Programs
Taking Control
When massage chair is operating, press
the AUTO button on the remote control
to enter Auto Program Menu. Choose
from Extension, Release, Full Body, Thai,
Chinese, Post Workout, Vigor, Night, Calm,
Neck & Shoulder, Waist & Glutes, or Back &
Spine. Press OK to enter the program you
desire. Selected program will show on the
home screen.
Navigating the remote
To show the Auto Programs list: Use the directional buttons to
highlight AUTO from Home display, press OK button to select. Press
up or down button to navigate amongst the 12 auto programs.
To select an auto program: Use the up and down directional buttons
to highlight the program you wish to run. Press OK button to select
and begin program.
While the in-use screen is showing, use the 4D button on your
remote control to increase or decrease intensity. Intensity dial
shows on in-use display area.
4D Intensity Control

17
Sports Refresh
Neck & Shoulder
Extension
Waist & Spine
Working Relief
Deep Shiatsu
Relaxation
Healthy Breath
All Air
Massage Extend
ProgramW hat for? Description
W
Demo
Performs a strong massage with deep, penetrating massage
techniques to alleviate your aches and pains, improve circulation,
and recuperate the body after intense physical activity.
Inspired by Thai massage. The strong kneading and
stretching functions effectively decompress the entire
body.
A progression of mild massage techniques and chair
movements brings harmony to your body. This program
helps you unwind from a long day, and prepares you for a
restful night’s sleep.
A powerful combination of kneading, grabbing, and
pressing massage techniques target the neck, shoulder,
and upper back to help ease unwanted pain and stiffness.
Performs a strong massage to ease muscles and
recuperate the body.
Designed to be an incredible injury prevention program,
this massage focuses on the lumbar vertebra with targeted
massage to loosen rigid muscles, relieve tension, improve
circulation, and revitalize your energy levels.
Deep shiatsu on the back for 10 minutes.
Rhythmic five-minute massage to aid with deep breathing.
Designed for morning or midday relaxing, this massage helps
to boost the vitality of muscles.
Reduce built up tension carried
in the body from everyday
stress.
Best for winding down and
re-energizing yourself after a
long day.
Many find this program beneficial
to relax and ease stress when
winding down.
A quick way to feel all the massage
techniques and chair movements in
a brief 8 minute session.
Designed for morning or midday
relaxing.
This program is reccomended to
relieve lower back pain.
Helps to relax, recover, and
revitalize the main back muscles
along your spine.
This is a great program for
people who work at a desk or
travel a lot.
Soothing pain and tension in the
neck and shoulders.
This program is the best choice
to relax tired muscles and
increase physical vigor.
Soothe muscles after sports
activities and exercise.
Try this program as you prepare
your body to rest for the night.
Assists in relieving lower and upper back pain through a
series of massage techniques.
Full-body airbag-only massage without any kneading and
tapping.
A quick show of massage chair’s features and functions. That
can be accompanied by an explanatory voice over. The voice
can be turned off and on in SOUNDS.
Full Body
Rest & Sleep

18
Airbag Region
Taking Control
Select AIRBAG from Home display, press up or down button to
navigate among: PART and FORCE. Select by pressing OK.
PART allows you to select which airbags to use. Select Full for all
airbags. Otherwise pick and choose amongst the other Parts to
turn them on or off. You may select more than one Part. To turn
off all Airbags, select any lit parts and hit OK to turn off. When no
Parts are lit, all airbags are off.
Airbag Massage
Navigate to PART, press right button, then use the up or down
button to select your desired airbag region: Full, Arm & Shoulder,
Leg & Foot, Buttock. Press OK button to select the airbag region.
Airbag Intensity
Navigate to FORCE, press right button, then use the up or down
button to select your desired intensity: 1 = light, 5 = firm, or Off.
Press OK button to select the airbag intensity.
While the in-use screen is displayed during a massage program,
press the left or right directional button to adjust the airbag
intensity (this feature works in both Auto and Manual programs).
Select HEAT from Home display, press right
button, then press up or down button to
navigate to desired heat setting: 1 = low, 2,
3 = high or Off. Press OK button to select
the heat setting.
Back Heat

19
Select MANUAL from Home display, then
press up or down button to navigate to
ROLLER. Press right button, then use the
up and down buttons to select your desired
foot roller speed: 1 = slow, 2, 3 = fast, or Off
(deactivate foot rollers). Press OK button to
select the foot roller setting.
Alternatively, press the Foot Roller button
on your remote control. If the foot rollers
are on, pressing this button will turn the
foot rollers off. Press again to turn on. Your
current foot roller speed is displayed in the
in-use screen in the bottom right corner.
Foot Reflexology Rollers &
Total CalfTM Kneading and Oscillation
Smart tip: While the in-use screen is
displayed during a massage program, press
the left or right directional button to adjust
the airbag intensity (this feature works in
both Auto and Manual programs).
As well as having a corded remote control, your chair also comes with a built in joystick
controller which is located on the top of the left arm panel. The joystick controller allows you
to turn the chair on and off, select from six of the auto program’s, adjust the recline angle of
the seat back, and wirelessly charge your mobile device.
Wireless Charging Pad: Place any wireless charging-enabled phone directly on to pad to charge.
Button: Press and hold to turn chair ON. Press again to cycle through six of the auto
program’s. The program name is announced through the speakers and starts immediately.
Press and hold to turn chair OFF.
Dial: Use dial to recline and upright the Evolution Max 4D massage chair by turning left or right.
USB Charging port: Attach a standard USB-A cord to charge devices.
Joystick Control and Wireless Charging/USB Port
Button
Dial
USB Charging Port
Wireless Charging

20
Set your Environment
Android System Software (Android System V2.2 or later)
- Open the Google play store. In the search bar, search for ‘Infinity Massage Chair Evolution
Max’. Click on the Evolution Max app tile.
- Click “Install” to download and install the Evolution Max APK, then press Settings button on
your computer or Android device > press Wireless and Web Setting > Bluetooth®> Scan
Bluetooth®device > Evolution Max, then pair.
- Start the Evolution Max APK, press Settings menu > Bluetooth®> and pair with the Evolution
Max to link the APK
Apple iOS: (iPhone or iPad devices)
- Open the App Store. In the search bar, search for ‘Evolution Max by Infinity’ to find the app.
Click “Get” at the top right corner to download and install the software.
- In your device settings, open Bluetooth®and connect it to the massage chair.
- Please note: Only Apple equipment compatible with Bluetooth®4.0 can connect to the chair’s Bluetooth®.
App Download & Installation
Select TIME from Home display, press right
button, then press up or down button to
select your desired timer: 10 minutes, 20
minutes, or 30 minutes. Press OK to select
your desired massage timer length. 20
minutes is the default setting.
Timer
Select AIR IONIZER from Home display,
press right button, then press up or down
button to select your desired air ionizer
setting: On, or Off. Press OK button to
select the setting.
Air Ionizer
