Innohome Smart Socket SSC100 User manual

SMART SOCKET SSC100 USER MANUAL
1
www.innohome.com smart safety for your kitchen
INNOHOME
Smart Socket SSC100
user manual

SMART SOCKET SSC100 USER MANUAL
2
SMART SOCKET SGS100 USER MANUAL
2
CONTENTS
smart safety for your kitchen
1. Innohome Smart Socket 1
2. A quick guide 2
3. Electric appliance re guard 3
3.1. Setup for alarm signal detection 3
3.2. Setup for timer 3
4. Additional signalling device 4
4.1. Setup for use as a signalling device 4
4.2. Turning an appliance o for alerting purposes (eg. a TV) 4
5. Informing a Telecare service of any alarms 5
6. Water leak guard 5
7. Checking the mode 6
8. Troubleshooting 6
9. Technical Information and EU Declaration of Conformity 6
10. Warranty 6

SMART SOCKET SSC100 USER MANUAL
1
Innohome Smart Socket is an intelligent safety socket with unique technology that
has several areas of use.
- Electric appliance re guard. The Smart Socket helps to prevent res by switching
o an appliance in the event of a gas/carbon monoxide/smoke alarm, and/or using a
timer. (Section 3)
- Additional signalling device. Stove Guard or smoke/carbon monoxide/gas alarm
signal activates the Smart Socket’s signalling light and sound. The Smart Socket can
also be used to transform any light or a signalling light that connects to a normal pow-
er socket to an alternative signalling device for any of the above mentioned alarms. Al-
ternatively the Smart Socket can be used to alert the user during a Stove Guard alarm
by switching an appliance (eg. a TV set) o. (Section 4)
- Informing a Telecare service of any alarms. The Telecare service is notied of any
gas/carbon monoxide/smoke or Stove Guard alarms. (Section 5)
- A water leak Guard. An identied water leak triggers the Smart Socket to turn o
the Aquastop washing machine’s or dishwasher’s power and water supply (additional
leak sensor required). (Section 6)
The Smart Socket is compatible with all gas, carbon monoxide and smoke alarms and
can be used with all electrical appliances that connect via a normal power socket.
1. Innohome Smart Socket

SMART SOCKET SSC100 USER MANUAL
2
2. A quick guide
If the Smart Socket/the device connected to it is signalling it
can be turned o by pressing the Smart Socket push-button
(1) once.
If the Smart Socket has turned the appliance connected to
it o, it can be turned back on by pressing the Smart Sock-
et push-button (1) once.
1

SMART SOCKET SSC100 USER MANUAL
3
The Smart Socket can be used with any household appliance that is powered via a normal
power socket. Potential uses are for instance washing machines and dishwashers, microwaves,
toasters, stereos, TV’s and lighting appliances.
Gas/carbon monoxide/smoke alarm signal will trigger the Smart Socket to turn the appliance
o. The Smart Socket also works as a safety timer for over 500W appliances (eg. washing ma-
chines, irons).
NOTE. Alarms need to be installed in the same room and within 5 metres distance of the Smart
Socket. The Smart Socket is compatible with all gas, carbon monoxide and smoke alarms.
A detected alarm also activates the Smart Socket’s own alarm signal and signalling light.
The alarm is reset (and the appliance connected to the Smart Socket turned back
on) by pressing the Smart Socket push-button (1) once.
The Smart Socket push-button (1) can be used to turn the appliance on/o.
3.1 Setup for alarm signal detection
Gas, carbon monoxide and smoke alarms: Connect the Smart Socket in between the appli-
ance’s plug and the power socket. Gas, carbon monoxide and smoke alarms need to be locat-
ed in the same room and within 5 metres distance of the Smart Socket. Do a test alarm with
alarms and check that the Smart Socket turns o the appliance connected to it.
3.2 Setup for timer
The timer can only be used with over 500W appliances.
3. Electric appliance re guard

SMART SOCKET SSC100 USER MANUAL
4
The Smart Socket can be used as an alternative signalling device for Innohome Stove Guard or
gas/carbon monoxide/smoke alarms (light and audible signal). It can also turn any light or sig-
nalling light to a signalling device, or be used to activate any alternative signalling device that
connects via a normal power socket.
The Smart Socket can also be used to turn an appliance o, for instance a TV, to alert the user
of a Stove Guard alarm.
The Stove Guard can be located in another room and within any distance, the gas/carbon
monoxide/smoke alarms need to be located in the same room and within 5 metres distance.
The Smart Socket is compatible with all gas, carbon monoxide and smoke alarms.
To reset the alarm press the Smart Socket push-button (1, see image on the previ-
ous page) once.
The alarm can also be reset by pushing the Intelligent Heat Sensor push-button/cover once
(when using with the Innohome Stove Guard).
4.1 Setup for use as a signalling device
1. Connect the Smart Socket to a power socket and wait for 5 seconds.
2. Press the Smart Socket push-button (1, see image on the previous page) and hold it down
until rst a red light alights, then a green light. Release the push-button when the green light
is lit.
4.2 Turning an appliance o for alerting purposes (eg. a TV)
Use with the Stove Guard
1. Connect the Smart Socket to a power socket and wait for around 30 seconds, until you hear
a signal.
2. Press the Smart Socket push-button (1, see image on the previous page) until a green light
starts to blink.
3. Make a test alarm with the Stove Guard by pressing the Intelligent Heat Sensor push-but-
ton/cover until you hear a signal.
4. The Smart Socket will emit a signal when the pairing of devices is successful.
5. Connect the desired appliance to the Smart Socket.
4. Additional signalling device

SMART SOCKET SSC100 USER MANUAL
5
The Smart Socket can be used to send information about Innohome Stove Guard or gas, car-
bon monoxide or smoke alarms to a Telecare centre. The Smart Socket also has its own alarm
signal and signalling light.
The alarm signal and light are reset by pressing the Smart Socket push-button (1,
see image on page 2) once.
The alarm can also be reset by pressing the Intelligent Heat Sensor push-button/cover once
(when used with the Stove Guard).
The Smart Socket alarm can be reset from the Telecare centre.
The Stove Guard can be located in another room and within any distance, gas, carbon mon-
oxide and smoke alarms need to be located in the same room and within 5 metres distance of
the Smart Socket. The Smart Socket is compatible with all gas, carbon monoxide and smoke
alarms.
Setup
1. Connect the cable (sold separately) to the Telecare unit.
2. Connect the Smart Socket to the power socket. Wait for ve seconds, after which press the
Smart Socket push-button (1, see image on page 2) and hold it down until first a red light
alights and then a green light. Release the button after the green light has turned o.
Innohome Smart Socket used together with the Innohome Water Leak Sensor provide addi-
tional protection for Aquastop washing machines/dishwashers. A leak detected by the Water
Leak Sensor will trigger the Smart Socket to turn o the washing machine/dishwasher’s pow-
er and water supply. The power and water are also cut-o in the event of a smoke or carbon
monoxide alarm, or using a timer. See the setup instructions from the Water Leak Sensor user
manual.
5. Informing a Telecare service of any alarms
6. Water leak guard

SMART SOCKET SSC100 USER MANUAL
6
If you want check that which mode is the Smart Socket programmed to, disconnect it from the
power socket and then connect back again. The Smart Socket will now emit one, two or three
signals, depending on its mode.
One signal - Electric appliance re guard, turning an appliance o for alerting purposes or
water leak guard (an alarm turns o the appliance connected to the Smart Socket).
Two signals - Additional signalling device (an alarm activates the appliance connected to the
Smart Socket).
Three signals - Informing a Telecare service of any alarms (transfers information of an alarm).
If you want to change the mode carry out the setup from the section of the desired mode
(sections 3 – 6).
The Smart Socket is not working as it should
Check the Smart Socket’s mode (see section 7). If the Smart Socket was set to a wrong mode
carry out the setup from the section of the desired mode (sections 3 – 6).
16A 230VAC, power consumption <1W, RF 433Mhz.
This device fulls EU directives’ requirements.
Technical Director Matti Myllymäki
See more detailed description on www.innohome.com/eudeclaration.
This product has a 2 year warranty that covers defects in material or workmanship, starting
from the date of purchase. The warranty does not cover any indirect damage caused by a mal-
functioning appliance, damage caused by negligence, or damage caused by failure to follow
the instructions properly.
7. Checking the mode
8. Troubleshooting
10. Warranty
9. Technical Information and EU Declaration of Conformity
