Iseo STYLOS User manual

Credential reader
User Manual
EN 02
STYLOS

3
About this manual
Dear Customer,
Thanks for choosing this innovative ISEO product, designed and developed following the highest standard of
production, for an effective user-friendly and, at the same time, powerful and flexible access control.
This manual explains the functions, configurations and characteristics of Stylos, the ISEO credential reader.
For commercial documents (catalogues and leaflets), technical documents (installation and maintenance
manuals) and certifications, refers to the ISEO website at the following link:
https://www.iseo.com
Information icons
For an easy reading of the manual, please take note of the following icons:
CAUTION: situations that could cause damage to your Device or other equipment.
NOTE: notes, suggestions and additional information.
WARNING: situations that could cause injury to yourself or others.

4
About this manual
Information on copyright
• No part of this guide may be reproduced, distributed, translated, or transmitted in any form or by any me-
ans, electronic or mechanical, including photocopying, recording, or storing in any information storage and
retrieval system, without the prior written permission of ISEO.
• ISEO reserves the right to change the specifications of the hardware and software described in this manual
at any time and without prior notice.
• ISEO will not be held liable for any damages resulting from the use of this product.
Trademarks
• The Apple logo, Apple™, iPhone™, iPad™ and App Store™ are trademarks of APPLE Inc.
• The Android logo, Google™, YouTube™, Google Play™ Store are trademarks of Google Inc.
• Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
• IOS is a trademark or registered trademark of Ciscoin the U.S. and other countries.
• MIFARE® is a registered Trademark of NXP B. V.
• All other trademarks and copyrights are the property of their respective owners.
Keywords
• Access control device:electronic and/or mechanical device to allow selective access through the users’
door.
• Contactless card: electronic card that can be read by the Access control device, by simply bringing it
closer to the same, without physical contact.
• Credential: device that allows to identify the user and authorize or not authorize access through a door.
For example: smartphone, tablets, Mifare cards or Mifare tags.
• Door: passage which access is electronically controlled by the Access control device.
• Master Card: Contactless card used to program the system.
• Master Card set: set of three Master Cards numbered from 1 to 3, belonging to the same System code.
The Master Card of higher number disable the Master Card of lower number.
• Opening time: time during which a door remains open, following a standard opening through credential.
• Programming mode: software condition, feasible by Master Card, that allows software modification to the
Device.
• Smart series:Access control devices featuring a built-in Bluetooth radio.
• System code:unique number associated to a Master Card set.
• User card:Contactless card used to open one or more doors.
• Users list:list of User cards enabled to open an Access control device.

5
Table of Contents
About this manual
3 Information icons
4 Information on copyright
4 Trademarks
4 Keywords
Safety and Environment
6 Warnings
7 Handling lithium batteries
8 Disposal and recycling
Certifications
9 Certifications and compliance
Overview
10 What is Stylos
11 Technical data
13 Dimensions
14 Options and versions
17 Accessories
Getting started
19 Package contents
20 Installing Stylos
20 Programming and using Stylos
Installation examples
21 Introduction
22 Stylos opening Multiblindo eMotion
23 Stylos opening Serie 5 electric lock
24 Stylos opening Trim Tronic
25 Stylos opening ISEO Automatic Swing Door
Operator IS9100
26 Stylos opening Thesis 2.0
27 Two Stylos opening an electric strike
Cable sizing
28 Lockbus technical data
29 Lockbus and power supply unit sizing
calculation example
Maintenance
31 Battery replacement
34 Cleaning
34 Storage
Troubleshooting
35 Error messages
35 Stylos Troubleshooting
36 Light and acoustic signals
36 Technical assistance

6
Safety and Environment
To prevent damage to your product or injury to yourself or to others, read the following safety precautions in
their entirety before using this equipment.
Keep this manual in a convenient place so that you can refer to it when necessary.
Warnings
• Read this manual prior to use the device in order to ensure a safe and proper use.
• Preserve this manual as future reference.
• The installation of the device requires the intervention of qualified staff, adequately trained by ISEO.
• The instructions should be carefully followed during installation. These instructions and any mainte-
nance instructions should be passed on by the installer to the user.
• No modifications of any kind are permitted, except for those described in these instructions.
• The product must be destined only for the use for which it is expressly designed and therefore
as a credential reader for civil and industrial locations. Any other use is considered improper and
dangerous.
• The electrical connection must be made according to the constructor’s instructions and respecting
the regulations in force.
• In the event of a failure and/or poor operation, remove the power supply using the main switch and
do not tamper with it. For all repairs, exclusively contact a technical assistance center authorized by
the constructor.
• Disconnect the power supply before carrying out any technical ser vice that involves opening or
accessing the internal parts of the product.
• RFID: frequency 13,553 - 13,567 MHz, maximum magnetic field: 0,89 µA/m (measured at 10m at
the maximum power capacity)
• Only for device with on-board radio: frequency 2,40 - 2,4835 GHz, maximum power: 5,25 mW
• Operating temperature: -20°C + 60°C

7
Safety and Environment
Handling lithium batteries
Batteries may leak or explode if improperly handled. Observe the following precautions when handling batteries
for use in this product:
• Do not connect the battery during the shipping and the storage. Connet the battery just during
installation and use.
• Risk of explosion if the battery is replaced by an incorrect type.
• Use only battery of the same type as indicated in the product installation guide.
• Do not open, drill through or squash lithium batteries.
• Do not expose the battery to flame or to excessive heat.
• Do not immerse in or expose to water.
• Do not short circuit lithium batteries.
• Do not recharge lithium batteries.
• Do not connect lithium batteries in parallel.
• Do not transport or store the battery with metal objects such as necklaces or hairpins.

8
Safety and Environment
Disposal and recycling
This product and battery are designated for separate collection at an appropriate collection point. Do not
dispose of as household waste.
For more information, contact the retailer or the local authorities in charge of waste management.
This symbol on the battery indicates that the battery is to be collected separately.
Dispose of batteries according to your local environmental laws and guidelines.
This symbol indicates to not dispose of the packaging with household waste,
but send it for recycling.
Dispose of the product separately from household waste, in accordance with
local laws and regulations.
Remove the batteries before disposing of the product.

9
Certifications
Certifications and compliance
In conformity with the essential requirements and other relevant requirements of the:
Directive 2014/53/EU (RED)
Donwload the conformity certificate at iseo.com website
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to
radio waves (radio frequency electromagnetic fields), recommended by international guidelines.
RFID tag reader
BTLE*
Frequency type Frequency band MAX emission value
13,553 - 13,567 MHz Maximum magnetic field: 0,89 µA/m (at 10m)
2,40 - 2,4835 GHz Maximum power: 5,25 mW
* BTLE only on models with radio communication option.

10
Overview
What is Stylos
Stylos is a multistandard ISO 14443 A/B credential reader that in combination with the Electric Lock Actuator,
is able to control any electrical. Stylos Smart version embeds the Bluetooth Smart Technology, in order to
work with Argo, the ISEO application running on iOS and Android smartphone.
Stylos it is suitable for private houses, apartment blocks, light commercial (offices, single entrance of
commercial, ser ver rooms, etc.).
For the installation of Argo app, device initialization, setup of the opening, and other operations not
described herein, refer to the Argo User Manual, available at iseo.com.
Signallling LED
LCD Display
RFID reading area
RFID reading area
Keypad
Stylos take also advatanges of the next importants and uniques features:
• Real Time Clock/Calendar.
• Optical and acoustic signalling.
• Wall mounting with fixing spacer available.
• Outdoors IP66 version available.
• Lockbus communication interface.
• On-site software upgrading.

11
Overview
Technical data
Multistandard 13,56 Mhz:
Internal cell Lithium Battery CR2032 for date and time
synchronizations when Stylos is not powered.
V364 Software.
RFID Reader
Battery
Feature
Acoustic buzzer.
Acoustic buzzer.
Software
Power supply
Power consumption
12 buttons with backlight controlled from firmware.Keyboard (only Display version)
ISO14443A/B (Mifare Classic, Mifare Plus and Mifare Desfire).
VAR/OEM development platform available.
Argo app available for Android and iOS phones (Stylos Smart).
Software upgrade on site.
10 years of average duration*.
8Vdc to 30Vdc.
3W
LEDs 3 color series: green, red and blue.
Graphic display O-led 128x64 dots
Signallling LED version
Signallling Display version
3 wires multipoint serial bus for power and data.
Connection up to 100 mt.
Self-adjusting power supply from 8Vdc to 30Vdc.
Secure device authentication (among readers and actuators)
and encrypted data transmission for high security against
manipulation.
Lockbus interface
(*) Depending on usage and environment.
Characteristics
Bluetooth Smart (4.0)
Lockbus interface
Bluetooth 4.0 Module
RFID Near Field Magnetic communication.Communication interface
Assembly Wall assembly.
Spacer available

12
Overview
Feature Characteristics
Assembly Wall assembly.
Storage temperature: -25°C ÷ +75°C.
Operating temperature: -20°C ÷ +60°C.Environmental characteristics
Spacer available
Protection system (IP grading): IP54 or IP66 (All-weather
version for outdoors installation).
48 x 18 x 130 mm.Dimensions (D x W x H)
For DIN35 rail.Box
For detailed commercial information, please check related catalogue and leaflet at: iseo.com.
3 Inputs (1 digital, 1 analogic and 1 digital or analogic).Inputs (by electronic actuator)
Outputs (by electronic actuator) 1 relay (24V/1A) + 1 booster (for direct electric lock).
Feature Characteristics
Power supply 8Vdc to 30Vdc.
Storage temperature: -25°C ÷ +75°C.
Operating temperature: 0°C ÷ +60°C.Environmental characteristics
Protection system (IP grading): IP54
Electric Lock Actuator
Power consumption 3W
3 wires multipoint serial bus for power and data.
Connection up to 100 mt.
Self-adjusting power supply from 8Vdc to 30Vdc.
Secure device authentication (among readers and actuators)
and encrypted data transmission for high security against
manipulation.
Lockbus interface
36 x 58 x 90 mm.Dimensions (D x W x H)

13
Overview
Dimensions
A = 47,50
B = 17,50
C = 130
Dimensions (mm)
C
A
B

14
Overview
Options and versions
Stylos can be supplied in different version: Stylos LED, Stylos Display with keyboard and Stylos All Weather
(only LED version). For more detailed information go to the on-line catalogue at iseo.com website.
1) Stylos LED
2) Stylos Display with keyboard
LED
Display
Numeric keypad

15
Overview
3) Stylos All Weather (IP66 Outdoor version - only LED version)
RFID reading area
Bluetooth 4.0 inside.
DIN35 rail housing
Stylos All Weather is composed by 3 units.
1. IP66 Credential reader module (outdoor).
2. Control Unit (indoor).
3. Connection cable (5mt length).
To connect the Credential reader to the Control Unit. 5mt is the maximum allowed distance between the 2
modules.
The module encloses the RFID contactless multi-
standard reader, completeley sealed for outdoors
installation, to resist against rain, snow and humi-
dity exposure (IP66).
This module encloses the Stylos electronic board
with Bluetooth 4.0 and Lockbus communication
interface. It needs to be installed indoors, at a
maximum distance of 5mt from the Credential re-
ader.
•
•

16
Overview
For more information about Stylos and Stylos All Weather installation, refer to the Installation Guides
available at: iseo.com.
Stylos All Weather installation scheme.
Credential reader
Connection cable:
max 5mt lenght
Control unit
OUTDOOR SIDE INDOOR SIDE

17
Overview
Accessories
A) Electric Lock Actuator
The Electric Lock Actuator allows a direct control
of electromechanical locks and electric strikers
or, by using the built-in relay, of any other access
control device: such as car park bars, sliding do-
ors, electric locks and many more.
Controlled by Stylos allows to open any electrical
device.
Lockbus interface
DIN35 rail housing
Electric Lock Actuator dimensions:
For more information about the Electric Lock Actuator installation, read to the Installation Guides or
the catalogue available at: iseo.com.
•
•

18
Overview
B) Power supply
The Stylos Line products are provided with a self-adjusting power supply from 8Vdc to 30 Vdc, ensuring top
flexibility and allowing in most cases the use of an existing supply even when the theoretical parameters are
deteriorated.
ISEO can also provide different power supply units depending on needs. In the following table are shown the
common ones.
For all the power supply codes refer to the catalogues available at: iseo.com.
Graphic Description Features
Power supply unit 24Vdc - 30W
Power supply unit 24Vdc - 70W
• Input 120-230Vac.
• Output 24Vdc 1,2A.
• DIN35 rail mounting.
• Input 120-230Vac.
• Output 24Vdc 3A.
• DIN35 rail mounting.
B) Plastic back housing for wall installation
Specifically designed for mounting with external
electrical conduit or to avoid direct contact of the
Stylos back surface to the wall.
Dimensions D x W x H (mm) = 40 x 10 x 125
•
•
Power supply unit 12Vdc - 50W • Input 120-230Vac.
• Output 12Vdc 3,5A.
• DIN35 rail mounting.

19
Getting Started
Package contents
The product box contains the following items:
• Stylos.
• 2 screws for metal.
• 2 screws for plastic.
• 2 washers.
• 2 fisher adaptors.
• Installation guide.
The items supplied with the Device and any available accessories may vary depending on the region or
service provider. Appearances and specifications are subjected to change without prior notice.

20
Getting Started
Installing Stylos
Programming and using Stylos
Installation must be performed only by skilled technical staff, following the Stylos Installation Guide,
available at: iseo.com.
For a correct procedure see also Warnings at the Safety and Environment chapter.
For these operations, please refer to Argo User Manual for Stylos Smart, or V364 System Administra-
tor Manual for Stylos. Both available at: iseo.com.
