iSinwheel I9 User manual
i9
ELECTRIC SCOOTER
USER MANUAL
The manufacturer reserves the right to make changes to the product,
and update this manual at any time.
Contents
1. Package Contents 01
2. Product Overview 02
3. Assembly 04
4. Charging 05
5. First Riding 05
6. Riding Basics 06
7. Safety Instructions 07
8. Dangerous Actions (No Attempting!) 08
9. Riding Notice 09
10. Folding and Carrying 10
11. Disc Brake Adjustment 11
12. Daily Care and Maintenance 12
13. Specifications 13
14. Limited Warranty Statement 14
15. Question & Answer 15
16. Contact Us 15
02
Product Overview
Folding Clip
Handlebar
Display
Brake
Folding Latch
Front Light
Platform
Brake Light
Kickstand
Disc Brake
03
Control Panel
Tips
When the scooter starts to coast, put both feet
on the deck and press the accelerator (the
accelerator initiates once the coasting speed
exceeds 3 mph). Or you can connect the
"MiniRobot" APP, then, turn on the zero start.
Power Button
Click to turn on. Long press to turn off.
Battery Indicator
The power level is indicated by five battery bar on the control panel.
Light
Turn on your scooter, one-click to turn on/off the front light.
S
Mode
Double-click to switch power mode.
Cruise Control
Keep same speed for 3 seconds, and it will beep and active the cruise control.
Lock indicator
The scooter can be locked and unlocked by MiniRobot app.
04
Assembly
1. Unfold the stem and colse the folding latch until
you hear a click. Then unfold the kickstand to
support the scooter.
2. Install the 4PCS screws (two on each side) into
the holes, then tighten the each screws properly
with the included hex wrench.
Attention
Folding latch:
Fold up the latch until you hear a click.You must make sure the folding latch is
locked before riding.
05
First Riding
Charging
Your scooter will be fully charged when the LED light on the charger
changes to green from red.
The scooter has charging protection and charging will cut off
automatically after fully charge.
Even so, we still don't recommend charging your scooter for a long
time more than 24 hours at one time.
Do not connect the charger if the charging port is wet.
Keep the charging port closed when not charging.
Download the "MiniRobot" app from the App Store(iPhone)
or Google Play (Android phone) for more information and
functions.
When the scooter starts to coast, put both feet on the deck and press
the accelerator (the accelerator initiates once the coasting speed
exceeds 3 mph). Or you can connect the "MiniRobot" APP, then, turn on the
zero start.
06
Riding Basics
Wear helmets and knee pads in case of falls
and injuries when you learn to ride the scooter,
as shown in the figure.
1. Turn the power on, and check the electricity
indicator.
2. Stand on the base with one foot and propel
yourself with the other foot.
3. When the scooter starts to coast, put both
feet on the deck and press the accelerator
(the accelerator initiates once the coasting
speed exceeds 3mph)
4. Release the accelerator and the kinetic energy
recovery system (KERS) initiates automatically to
brake slowly; And squeeze the brake lever for a
sudden brake.
5. Tilt your body to the steering direction as you
turn, and slowly turn the handlebar.
07
Safety Instructions
Do not ride in the rain. Please keep a medium or low speed (5mph)
when you ride through speed bumps, elevator
door sills, bumpy roads or other uneven
surfaces Slightly bend your knee to better
adjust mentioned surfaces.
Look out for doors, elevators and other
overhead obstacles.
Do not press the accelerator when you're
walking alongside the scooter.
Do not accelerate when you go downhill.
Always steer clear of obstacles.
08
Do not hang bags or other heavy stuff on the
handlebar.
Keep both feet on the deck all time.
Dangerous Actions (No Attempting!)
Do not ride in traffic lanes or residential areas
where vehicles and pedestrians are both allowed.
Do not turn the handlebar violently
during high-speed riding
Do not ride in a ponding that is higher than 2cm. Do not ride with anyone else, including children.
09
Riding Notice
Keep your feet off the rear mudguard. Always keep your hands on the handlebar.
Do not try riding up or down stairs, and
jumping over obstacles
The iSinwheel I9 electric scooter is a leisure device. But once they're in a public area, they'll be
seen as vehicles, subject ing to any risks faced by vehicles. For your safety, please follow
instructions in the manual and traffic laws and regulations set forth by government and regulatory
agencies.
●
At the same time, you should understand that risks cannot be entirely avoided as others may
violate traffic regulations and drive incautiously, and you're exposed to road accidents just as
when you're walking or biking. The faster the scooter is, the longer it takes to stop. On a smooth
surface, the scooter may slip, lose balance, and even result in a fall. Thus it is crucial that you
use caution, keep proper speed and distance, especially so when you're unfamiliar with the
place.
●
Respect pedestrians' Right of Way. Try not to startle them while driving, especially children.
When you ride from behind pedestrians, ring your bell to give them a heads-up and slow your
scooter to pass from their left (applicable to countries where vehicles drive on the right). When you
ride across pedestrians, keep to the right at a low speed. When you drive across pedestrians,
keep the lowest speed or getting off the vehicle.
Do not touch the disc brake.
10
Folding and Carrying
●
Closely follow the safety instructions in the manual. iSinwheel shall not be liable for any
financial losses, physical injuries, accidents, legal disputes and other interest conflicts resulted
from actions that violate user instructions.
●
Do not lend your scooter to whoever doesn't know the operations. And when you do lend it to
your friends, please take the responsibility to ensure he/she knows the operation and wears the
safety gear.
●
Check the scooter before every use. When you note loosen parts, low battery alerts, excessive
wear, strange sounds, malfunctions and other abnormal conditions, stop riding.
●
WARNING – Risk of Fire – No User Serviceable Parts.
1
Make sure that the scooter's turned off. To fold, unlock the folding mechanism, and bend the handlebar
stem to hook the buckle on the rear fender. To open, press the bell trigger to remove from the buckle,
erect the handlebar and lock the folding structure.
2
11
Disc Brake Adjustment
To adjust the disc brake sensitivity:
You need the Allen wrench to loosen the screw on the rocker.
• When the disc brake is too sensitive, rotate the disc brake rocker down a bit. Then, reinstall
the screw back to the brake cable core to tighten.
• When the disc brake cannot stop, rotate the disc brake rocker up a bit. Then, reinstall the
screw back to the brake cable core to tighten.
Notice: The disc brake may squeak when in use until it is broken in. This is normal and does
not affect the brake's function or performance.
To remove the disc brake noise,
First make sure the scooter is turned off. For easier operating, we suggest
you put the scooter on the desk.
• Loosen two screws on the pump (not the screw on the rocker).
• Adjust the position of the disc brake pump to ensure that the brake disc is in the middle of
the two brake pads.
• Keep the brake disc and brake pad not touching each other.
• Hold the disk brake pump in the desired position, then retighten the screws to the pump.
12
Cleaning and storage
Battery maintenance
Storage and Disposal
Daily Care and Maintenance
If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains won't
scrub off, put on some toothpaste, and brush them with a toothbrush, then wipe them off with a
damp cloth.
Notes:
•
Do not clean the scooter with alcohol, gasoline, kerosene or other corrosive and volatile chemical
solvents to prevent dire damage.
•
Do not wash the board with a high-pressure water spray. During cleaning, make sure that the
scooter's turned off, the charging cable is unplugged, and the rubber flap is closed as water leakage
may result in electric shock or other major problems. When the scooter not in use, keep it indoors
where it is dry and cool.
•
Do not put it outdoors for a long time. Excessive sunlight, overheating and overcooling accelerate
the battery pack's lifespan．
1.
Use original battery packs, use of other models or brands may bring about safety issues;
2.
Do not touch the contacts. Do not dismantle or puncture the casing. Keep the contacts
away from metal objects to prevent short circuit which may result in battery damage or
even injuries and deaths;
3.
Use original power adapter to avoid potential damage or fire;
4.
Mishandling of used batteries may do tremendous harm to the environment. To protect
natural environment, please follow local regulations to properly dispose used batteries.
5.After every use, fully charge the battery to prolong its lifespan.
1.
Please try to store the scooter in a cool and dry place between 14℉and 104℉. In extremely
humid environments the interior of the scooter may suffer condensation or even water
accumulation, which may damage the battery rapidly.Devices are not intended for use at
elevations greater than 2000 m above sea level Prolonged Exposure to UV Rays, Rain and
the Elements May Damage the Enclosure Materials, Store Indoors When Not in Use.
2.
In daily use, try to avoid recharging the scooter after completely exhausting the battery. If
the battery is low, charge it as soon as possible.
3.
Please charge the scooter every other month to preserve the battery.
13
Specifications
i9 ltem
Electric Scooter
Dimensions
weight
User
Unfolded (Length. x Width x Height)
Folded (Length. x Width x Height)
Net Weight
Load
42*17*44 inch/108*43*112 cm
42*17*19 inch/108*43*50 cm
26.4 lbs/12 kg
264 lbs/120 kg
Charger
Output Voltage
Output Current
Charging Time
42 V
2A
4-6 h
(1) The height of the body: Distance from the ground to the highest end of the body.
(2) Description of the battery life: It is measured under the condition of full charge, a load of
150 lb, at 77°F, on a flat road without wind, and at a speed of 9.3mph. The real battery life will
differ with different factors of the load, humidity, wind speed and operation habits.
(3) The maximum allowable weight shall be kept within 264 lb (driver and objects included)
in any case. Consider an extra weight of the clothes or other accessories with us during the trip
and the gravity generated by speed, the scooter will not support it if this load limit is exceeded.
S
Recommended Age
14+
Max.Speed
15.5 mph/25 km/h
Max.Range
14-17.5 miles/22-28 km
Scooter
Max. Slope
15%
Operating Temperature
32-104°F
lP Rating
IP54
Voltage
36 V
Battery
Max.Charging Voltage
42 V
Capacity
7.5 AH
Motor
Nominal Power
350 W
Input Voltage
100-240 V
14
30 DAY SATISFACTION GUARANTEED RETURN POLICY
TO QUALIFY FOR A REFUND, ALL THE FOLLOWING CONDITIONS MUST BE MET
LIMITED PRODUCT WARRANTY
REMEDIES
HOW TO OBTAIN WARRANTY SERVICE
LIMITATION OF DAMAGES
Limited Warranty Statement
If you are unsatisfied with your purchase, iSinwheel’s return policy allows you to return the product purchased on the
Authorization channel within 30 days counting from the date of receipt of shipment, and request a refund from the
Authorization channel for any reason. Note: Express shipping cost is non-refundable.
For the return request, iSinwheel is not responsible for lost packages due to the carrier, or products received that
cannot be verified. Received products that have damage determined to have been caused by the end-user may
be subject to denial of the return request.
1. A ReturnMerchandise Authorization(RMA) must be requestedfrom iSinwheel within 30 daysfrom the date of receiptof shipment.
2. The cost of return shipping will be borne by the customer.
3. For warranty service, please keep your receipt and/or invoice to validate proof of purchase.
4. Returned product must be in good physical condition (not physically broken or damaged).
5. All accessories originally included with your purchase must be included with your return.
6.If you return a product to iSinwheel, (a) without an RMA from iSinwheel(b) without all parts included in the original package,
iSinwheel retains the right to refuse delivery of such return.
iSinwheel warrants the original purchaser that your iSinwheel product shall be free from defects in materials and workmanship
under normal use for a period aforementioned.
iSinwheel does not warrant the operation of the product will be uninterrupted or error-free.
iSinwheel is not responsible for damage arising from failure to follow instructions relating to the product's usage.
If a hardware defect is found and a valid claim is received by iSinwheel within the Warranty Period, iSinwheel will, at its option and
to the extent permitted by law, either (1) repair the product at no charge, using new or refurbished replacement parts or, (2)
replace the product with a new or refurbished product. In the event of a defect, to the extent permitted by law, these are your sole
and exclusive remedies. Shipping and handling charges may apply except where prohibited by applicable law. This Limited
Warranty is valid only in the jurisdictions where the products are sold by www.iSinwheel.com, and is valid to the extent permitted
by the applicable laws of such jurisdictions.
Any replacement hardware product will be warranted for the remainder of the original warranty period or thirty (30) days,
whichever is longer, or for any additional period of time that may be applicable in your jurisdiction.
A Warranty Service Order mustbe requested from iSinwheel within WarrantyPeriodfrom thedate of receipt of shipment. To request a
To obtain warranty service, you must deliver the product, in either its original packaging or packaging providing an equal degree of
protection, to the address specified by iSinwheel. In accordance with applicable law, iSinwheel may require the customer to furnish
proof of purchase details and/or comply with registration requirements before receiving warranty service.period or thirty (30) days,
whichever is longer, or for any additional period of time that may be applicable in your jurisdiction.
Except to the extent prohibited by applicable law, iSinwheel shall not be liable for any incidental, indirect, special, or consequential
damages, including but not limited to loss of, even when iSinwheel has been advised of the profits, revenue or data, resulting from
any breach of express or implied warranty or condition, or under any other legal theory possibility of such damages.
Some jurisdictions do not allow the exclusion or limitation of special, indirect, incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
15
E04
Short Circuit Failure
E10
Controller/Instrument Communication Failure
E11
Motor Phase A Current Sensor Failure
E12
Motor Phase B Current Sensor Failure
E13
Motor Phase C Current Sensor Failure
E14
Accelerator Failure
E15
Brake Failure
E16
Motor Hall Failure
Question & Answer
1. What if the E-Scooter arrived missing accessory or broken part?
A: Please take a photo and send to iSinwheel Support Team by sending email:
vip.support@iSinwheelglobal.com
.
And iSinwheel Support Team will reply you
soon and send correct accessory or part replacement.
2. Is the tire replaceable and how to replace the tire?
Yes, the tire is replaceable. Please contact iSinwheel support team for more
information or search the video “How to replace the solid tire”
in YouTube instead.
3. What if the rear disc brake of the scooter doesn't work well?
A: You may please contact us for instructions of brake adjusting, or search
"How to adjust rear brake of scooter" in YouTube for tutorial video as well.
4. What should I do when I hear an unusual noise coming from the rear wheel?
A: It usually means your disc brake tilt and cause friction noise. Please see
Disc Brake Adjustment page. If you still have problem, please contact us
for help.
5. Why the screen returns an error code?
A: If you see any error code below, Please contact iSinwheel Support Team
to remove the error code.
Contact Us
Contact us if you experience issues relating to riding, maintenance and safety,
or errors/faults with your iSinwheel I9 electric scooter.
E-mail Service: support@isinwheel.com
Table of contents
Other iSinwheel Scooter manuals
