Jacto J600 User manual

J-600 ELECTRIC
English version / MI_USA - 0344
JACTO INC.
19217 SW 119th Ave
Tualatin, Oregon 97062
Tel.: (503) 885-8723
Fax.: (800) 511-3671
Toll Free: (800) 522-8610
E-mail: [email protected]
Home page: www.jacto.com
Operatos’s Manual
EDITION Nº 07/2011
Code: 059179
WARNING!
Read Operator’s Manual before setting up, operating, or maintaining sprayer. Failure
to follow safety precautions in this manual an in labels on the product could result in
serious injury or death to the operator or bystanders.
Keep manual nearby for futher reference. If manual is demaged or illegible, contact
your Jacto dealer or Jacto at the address below for a replacement.


3
TABLE OF CONTENTS
Introduction
Precautions.............................................................................Chapter 1
Assembling.............................................................................Chapter 2
Technical specifications..........................................................Chapter 3
Operation and Adjustments....................................................Chapter 4
Maintenance ..........................................................................Chapter 5
Warranty.................................................................................Chapter 6
J-600 ELECTRIC


5
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
INTRODUCTION
The agrochemicals application is necessary to
achieve higher and economical production.
However, since applying agrochemicals can pres-
ent risks to humans, the environment and to crops,
Jacto is concerned about helping users to use these
sprayers in a proper, efficient, and safe way.
Therefore, read carefully and understand thor-
oughly this manual before operating this sprayer
and keep it always at hand when handling this
sprayer for quick consultation in case you are not
quite sure of some operation or adjustment.
If you still have questions, contact your Jacto dealer.
ATTENTION!
The J-600 ELECTRIC was developed exclusively for the chemical spray application.
The J-600 ELECTRIC sprayer manual refers only to instructions of use and maintenance of parts
and components manufactured by Jacto.
Read it carefully and follow strictly the instructions.
Should your doubt persist, please contact your Jacto dealer.
> Identification plate
MACHINE NO.
WEIGHT
MACHINE
MODEL
LOT
Your sprayer has a plate showing its model and se-
rial number.
This information is very important so that Jacto can
keep records of eventual modifications made on
the material used and on its construction charac-
teristics.
In requesting replacement parts or maintenance,
always specify the model and serial number of
your sprayer for prompt and efficient service.
JACTO is trademark registered by MÁQUINAS AGRÍCOLAS JACTO S.A.
JACTO RESERVES THE RIGHT TO CHANGE SPECIFICATIONS AND DESIGN WITHOUT
PRIOR NOTICE.


7
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
CHAPTER 1 Precautions
Safety manual .................................................................................. 9
Safety decals .................................................................................. 10
Safety guidelines ............................................................................ 13
Safety recommendations for transport............................................ 14
Recommendation to unload the equipment................................... 15
Operational safety.......................................................................... 16
Warning to assemble the components ........................................... 17
Warning when using and filling the tank........................................ 18
Safety in agrochemicals application............................................... 19
Maintenance safety........................................................................ 22


9
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
Safety manual
This chapter of the manual guides the operator to
work safely with this equipment.
It is important to remember that this equipment
was carefully developed so as to provide maxi-
mum efficiency with economy, easy operation and
safety.
In order to accomplish this, be always aware to the
information provided on the owner’s manual. If any
question comes up at anytime, please contact us.
The instruccions on this manual are accompany
with symbols which have the following
interpretation:
To ignore the safety procedures, you are risking
your life and all the people around you.
ATTENTION: to inform potential risk’s
situations of accident, which demands
constant attention from the operator.
NOTE: reminds or warnings.
OBSERVATION: warn or clarify cer-
tain instructions/situations.
According to the standard NR31 - Safety and
Healthy Regulation Standard in the Agriculture
Work, the owner and the agriculture equipment’s
operator can cooperate with the chemical
application safety, since they be aware of their
responsabilities.
Operator’s responsabilities
∙To follow the determinations about safety
procedures to accomplish with his activities.
∙To operate the equipment within the limits and
restrictions indicated in this manual.
∙To read this manual and ensure to understand all
the information prior to use the equipment.
Owner’s responsabilities
∙The equipment’s owner must keep the owner’s
manual in a place of easy access to the operator
when needed.
∙It’s the employer duty, always when in use of
chemical, to provide the adequated EPI - Individual
Protection Equipment, to take care of the EPI
hygienization, to trainee the operator to require
and make the EPI use.
∙The employee must to replace or repair the
equipment’s components always when they present
any defect that put in risk the a safety operation.
∙The employee will be responsable for the
operator’s training to ensure a safe application.
> Operator and owner’s responsabilities

10
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC Safety decals
Safety decals are placed on the equipment to redu-
ce the risk of damages or accidents to the operator
or to the equipment during the use.
Before operating the equipment, identify and
understand the mean of all decals, through this
page.
Keep them in good repair, clean and legible. Re-
plade them immediately in case of damage by or-
dering them through the part numbers specified
below.
P/N: 276220
ATTENTION: Lubrication
point.
ATTENTION: Read the
operator’s manual before
operating the sprayer.
P/N: 379248
P/N: 379230
ATTENTION: Read the
operator’smanualbefore
operating the sprayer.
ATTENTION: Risk of serious
injuries. Keep all protection
devices in its places.
P/N: 379065 P/N: 379040
ATTENTION: Risk of inju-
ries. Keep away from the
sprayer when it is running.
P/N: 379057
ATTENTION: Risk of serious
injuries. Keep away and do
not make any kind of main-
tenance while the fan is in
motion and the PTO is en-
gaged.
P/N: 389387
ATTENTION: Drain point.
P/N: 395061
ATTENTION: Lubrication
point with oil.

11
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
Safety decals
ATTENTION: Risk of serious
injuries. Do not make any
operation on the PTO shaft
if the PTO is engaged.
ATTENTION: Obligatory use
of protective clothing.
P/N: 379131
P/N: 379008
ATTENTION: Maximum
speedallowedforthemachine
is 18.5 mph.
P/N: 379214
ATTENTION: Never op-
erate the valve of the
chemical rinse nozzle
if the container is not
duly positioned over the
rinse nozzle.
P/N: 169128
ATTENTION: This machine
is not allowed in highways.
P/N: 379222
P/N: 379073
ATTENTION: Clean water
tank for washing hands.
Instructions to connect the PTO shaft
P/N: 428631
ATTENTION: Hydraulic oil
level indicator.
P/N: 379107

12
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC Safety decals
Identification plate.
P/N: 047035
Final test of the equipment.
P/N: 013169
ATTENTION:Obligatoryuseof
protective mask.
P/N: 379115
ATTENTION:Obligatoryuseof
hearing protector.
P/N: 379123
Decal “J - 600 EXPORT”.
P/N: 219691
Instructions to unlock the fan.
P/N: 018705
Logotype “Jacto”
P/N: 763672

13
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
Safety guidelines
∙ Onlyqualifiedoperatorsandwithinformation’s
knowledge of the owner’s manual that comes with
the machine must operate the J-600 ELECTRIC;
∙ Priortoinitiateanyoperation,it’sveryimportant
to be aware all the information in this manual. In
case of doubts, please contact Jacto.
∙ Do not drink alcoholic drinks, sedative or
stimulant before or during work.
∙ Duringthechemicalhandling,alwaysuseEPIs
approved, recommended and adequated like: long
sleeve coverall, water resistant, gloves, hat, boots,
special mask with filter for each type of chemical.
In case of doubt, please check the chemical label
or get in contact with the chemical manufacture.
∙ When checking the machine’s components
that are in direct contact with the chemical,
use EPIs approved and in accordance with the
recommendation in the chemical label.
∙ If you’re using cabin tractor and it has air
filter system, clean up the shoes and take off the
contaminated clothes. Keep them out of the cabin
in a sealed place.
∙ Ifthe tractor’s manufacturerecommends, use
ear protector.
∙ Use breath facial protector (mask) approved,
recommended and adequated if the chemical
label requires the individual protection.
∙ Be aware. Keep away from places where
there’re obstacles like trees, rocks, bumps, electric
post, etc.
∙ The use in different conditions and not
recommended can compromise the equipment’s
integraty and components, failuring to warranty
and exonerating the manufactory of any accident
and consequencies.
∙ Avoidtoparkthetractorininclinedplaces.If
necessary, use block behind the tires when parked
in inclined areas.

14
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC Safety guidelines
∙ Keepastepandhandrailalwaysclean;oiland
grease can cause accidents.
∙ Donot use equipmentif there isrepair need
in some key components. Make the repair
prevously.
∙ This equipment can cause accidents if used
inept or irresponsabily.
∙ Donothoponthemachinewhenit’smoving.
∙Before initiate the tranport, it’s important that the
track where the equipment will be transported be
carefully studied and that the regulator body that
regulates this type of transport be contacted about
the law and legislation current.
∙All freeways, roads and streets that have utilization
caracteristics for utilization that are influenced by
natural’s factors (clime, growing of a tree without
mankind interference, etc.) and construction (used
material, bridges height, electric post, lane width,
etc). These caracteristics must be carefuly valued
before the equipment tranportation.
∙Incasedoubt,do not make the transport. Con-
tract a specific company for this type of job.
∙Be sure that the chemical circuit was rinse and
the tank is totally empty after rinse. The checmical
leaking, as minimum it can be, may risk put in risk
people’s life, animals, envirolment.
∙Wash ouside the equipment after it’s use. Even
it looks clean, tje strps used to hold the equipment
must not be reused to hold food, the straps may be
polluted and pollute it.
∙During the equipment strap process, make use
EPIs. If necessary, make a combination of the re-
quired EPIs during the equipment load (i.e.: safety
boots, gloves, helmets, etc.) with EPIs required for
the chemical application. This combination will
minimize the contamination risk.
∙The equipment hold on the truck or trailer must
be done by the tires and by the specific points (see
illustration below). The hold must be made safety,
since it can cause serious accident’s risk.
> Safety recommendations for transport

15
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
Recommendation to unload the equipment
> Warning To Hook up the Equipment to the Tracto’s Traction Bar
∙Desengage the equioment from the tractor, hook
the jack. Do not forget to install the safety chain in
the traction bar.
∙The unload must be in specific’s places for this
type of job. Do not make improvisation to unload
the equipment.
∙During the strap’s remove that holds the equio-
ment, make sure to use EPI. If the equipment is
used use EPI to unload the equipment (i.e..: safety
boots, gloves, helmet, etc.) with the EPIs used for
spraying (i.e.: mask, gloves, etc.), to minimize the
contamination risk and accident.
∙To unload the equipment, use a tractor with ca-
pacity for this type of job. The tractor to be used
must be according to it pull capacity and sprayer
weight.
∙Do not desassemble removable parts from the
equipment such: PTO shaft, etc; before unloading
the equipment from the truck or trailer and park in
a safety area.
∙After positioning the equipment in a safety area
and far from electric post, hook up the jack and
unhook the equipment from the tractor.
∙Check the owner’s manual prior to do this
operation. The warning realated to follow are re-
commended just for the J-600 ELECTRIC hook
up too the tractors. Warning related to the use
and component’s adjustment of the tractor are it’s
manufacture’s responsabilities.
∙The information related to the correct adjustment
of the trantion bar and the procedures to hook up
the equipment the right way are exposed in chap-
ter “ASSEMBLY” in this manual.
∙The hook up operation of the equipment to the
traction bar can be made for more than one per-
son. In this case, the people involved must be awa-
re of risks, trained, qualified and experiencied this
type of job.
∙Avoid to stand on the tractor’s way. If possible,
hook up the equipment by yourself. Do not forget
the safety chain in the traction bar.
∙Before to get out of the tractor to do the hook uo,
activate the parking brake Turn off the engine and
remove the key from the ignition.
∙After hooking it up, put on the jack on the working
position and move the equipment to the place
where the assembly will be made.

16
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC Operational safety
ATTENTION!
Ignoring the safety practices, you’re risking your life and all of those around.
This manual contains important safety advices. Read it carefuly, and be aware to any possibility
of personal accident. Keep all the stickers on the machine and replace it, if necessary.
∙ The incorrect handling by unprepared personal
can cause serious accident or fatal.
∙Do not make adaptations or improvisations; they
can compromise the equipment and risk your
life.
∙Do not allow children, eldery or animals close
to the equipment during it uses, maintenance or
even with the equipment stored.
∙Keep hands, feet, loosen clothes and long hair
far from moving parts.
∙Before executing any type of service, adjustment
or maintenance in your equipment, turn off the
PTO shaft and the tractor’s engine.
∙If the equipment used, even if it was washed and
seems to be clean, use all recommended EPIs for
chemical handling.
∙Do not touch PTO shaft, belts, fan or any other
moving part of the equipment with the PTO shaft
or tractor on.
∙When unhook the machine, keep it in firm ter-
rain, flat, and if the equipment has parking brake,
activate it!
∙Do not run the pump dry.
∙Do not exceed 540 rpm at the PTO.
∙Keep the machine always in perfect care.
∙In all over the equipment were placed safety’s
stickers guiding about the risk of damage or ac-
cident that can happen to the operator or to the
equipment.
∙Request a JACTO representative during the
technical delivery of the equipment for a proper
assembly instructions, maintenance, warranty
instructions to be carefuly explained.
∙It is totally phrohibit the use of PTO shaft
without the shield.

17
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
Warning to assemble the components
> Warning to adjust and hook the PTO shaft into the tractor
∙Check the tractor’s owner’s manual prior to do
this operation.
∙Turn off the tractor’s engine, activate the park-
ing brake and remove the key from the ignition,
before to hook the tractor’s PTO.
∙Try to engage the PTO shaft into the tractor’s
PTO. In case it’s necessary to adjust the PTO shaft’s
lenght, make use of specific EPIs for this operation:
safety glass, gloves, boots, etc.
∙When hooking the PTO shaft in the tractor, make
sure to lock the safety pin.
∙The instructions on how to adjust the PTO shaft’s
lenght correctly are in chapter 2 “ASSEMBLY” in
this manual.
∙After adjusting the lenght, clean and lubricate
the PTO shaft’s components. In this case, use
protective gloves.
∙Never use the PTO shaft with no shield.
∙The PTO shaft will be adjusted for the specific
use of the J400. It’s not recommended to use the
PTO shaft for other equipment.
∙Do not make adaptations and PTO shaft reuse.
∙Fix the safety chain from the PTO shaft shield
in the tractor; this chain will avoid that the shield
spin with it.
∙Before to turn on the tractor’s PTO, fill up the
tank.

18
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
Warning use and tank filling
> Fresh water tank for hand’s wash
∙Fill up the fresh water tank for hand’s wash only
with clean water. The use of soap or solutions are
prohibited.
∙ In any circunstance the water in this tank must
be drank or used for other use.
∙It’s extremely important to keep that this tank
always full.
There’re two ways to fill up the 160 gallon tank.
The instructions for this operation are explained in
chapter 4 “OPERATIONS AND ADJUSTMENTS”
in this manual. The warning in to fill this tank are
the following:
∙For the filling of the 160 gallon tank, it’s impor-
tant that all personal involved use the indicated
EPIs. It’s important to read the chemical’s label
used. On the label you’ll find many information
about the product, warning, etc.
∙Prior to initiate the fillinf, make sure that the
drain cap is tight.
∙Never remove the filling hose from the quick
fitting, with the filling valve open. In case the valve
is open, overflow can happen through the filling
hose.
∙ The residuos exisiting in the hose must be re-
moved with a bucket and returned to the tank. Do
not leave residuos on the floor.
∙Do not pollute water fountain. The sprayer filling
with the filling unit must be used in an appropried
are for this.
∙Avoid to get water from rivers, lakes, etc.
∙Following these recommendations you’ll save
the enviroment.
> 160 Gallon tank

19
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC
Safety in agrochemicals application
1•READtheoperator’smanualofthesprayer:To
spray efficiently it is necessary to know the sprayer
fully. This way, the chemical waste and the bad
use of the equipment will be avoided, and the de-
sired result will be obtained.
2•CorrectADJUSTMENTofthesprayer:Thead-
justment of the sprayer is a simple operation. Only
with the sprayer adjsuted the best results will be
reached.
3•USEappropriateindividualprotectiveclothing:
When handling chemicals or preparing the chemi-
cal mixture, use the protective individual clothing
recommended by the agrochemical manufactur-
er. After spraying, take a shower and change the
clothes. Wash the working clothes immediately
and separately from other clothes to remove the
chemical residues.
Wash at least 15 minutes with running water any
part of the body that have touched agrochemicals.
Remember that most of poisoning cases occur dur-
ing the preparation of the chemical mixture when
the chemical is still concentrated.
Do not wear or store into the cabin the protec-
tive individual clothing used to hand or prepare
the chemical mixture in order to not contaminate
the local.
Inside the cabin, use only hearing protector when
operating the machine and/or spraying. When
perceiving a contamination (smell of chemical)
caused incautiously by open door or windows or
entry of contaminated materials in the cabin, im-
mediately use a proper and approved protective
mask and contact your dealer.
Special protective masks with filters are only indi-
cated if the chemical in use requires them.
4•USEthesprayerinperfectconditions:Check
if there is no leakage. If any, eliminate it. Leakage
not causes only agrochemical waste but also ir-
regular spraying and environment contamination.
5•USEtheappropriatenozzle:Eachagrochemi-
cal has an appropriate nozzle for its application.
The weather also has influence when choosing
the nozzle. The spraying volume can vary from
one chemical to another. Contact your chemical
manufacturer to choose the ideal nozzle.

20
CHAPTER 1 - PRECAUTIONS
J-600 ELECTRIC Safety in agrochemicals application
6•NEVERblowthroughnozzles,valvesorpipe-
lines by mouth. For this operation use protective
gloves. All spraying equipment has agrochemicals
residues. Never put spraying parts in touch with
mouth. This is the quickest way to be poisoned.
If it is necessary to clean the nozzles, use a nylon
bristle brush (toothbrush).
7•NEVERcontaminatewatersources.Thesprayer
must be filled in proper places or through vehicles
(trucks, etc.) designed for this operation. Avoid
using water from rivers, lakes, dams, streams, etc.
PROTECT THE ENVIRONMENT.
8•NEVEReat,drinkorsmokewhenhandlingthe
chemical or spraying neither keep food next to the
sprayed area.
9•KEEPchildren,animalsandunprotectedpeo-
ple away from the sprayed area. Never allow that
children or other unsolicited people remain in the
areas of chemical handling or application.
10 • APPLY only the recommended rate: The
application rates recommended by the manufac-
turers must be followed. They are result of many
years of research. Any change in the application
rate or error in calculating it can damage the crop
or the environment. Never use chemicals on crops
for which they are not recommended.
11• NEVERspray whenthe windisstrong:The
excessive wind can cause several problems. It pre-
vents the agrochemical from reaching the target,
thus causing bad distribution on the crop, besides
blowing the sprayed chemical against water sour-
ces, animals and environment. Never spray if the
wind speed is over 10 km/h. A good application
can be obtained when the wind speed is between
3 and 7 km/h, the temperature is between 7 and
30°Candtherelativehumidityisover55%.
Other manuals for J600
1
This manual suits for next models
2
Table of contents
Other Jacto Paint Sprayer manuals
Popular Paint Sprayer manuals by other brands

Smithco
Smithco Spray Star 3184 with Raven 203 System Operator's

Sumake
Sumake SS-1180S manual

DeVilbiss
DeVilbiss PLUS SB-2-475-F Service bulletin

Mesto
Mesto 3232 Series Instructions for use

Anest Iwata
Anest Iwata AIRGUNSA AZ1 HTE 2P Use and maintenance instruction manual

Kremlin-Rexson
Kremlin-Rexson M 22 G HTI Adjustment manual
