Jbc Jt series User manual

JT High-Power hot-air station

120V - Ref. JT-1A | 230V - Ref. JT-2A

BASIC SPECIFICATIONS:

 Air pump for hot-air with electronic control of temperature and air flow.

 Vacuum pump for holding ICs

 Maximum Power: 1000 W.

 Temperature selection: ºC or ºF, Room - 450° C and cool

 Air flow regulation: 6-45 l/min.

 The system is protected against antistatic discharge.

 Weight of complete system: 8,7 kg.

JT-2A High power hot air station 230V

The JT-2A is a high power hot air station used for desoldering all types of SMDs.

Its powerful heater enables quick and safe desoldering of even the biggest QFPs and PLCCs. In addition, it desolders small and

medium sized BGA’s in a very reduced time span. Digital read-out temperature allows more precision and tool control.

The system, exclusive to JBC, uses extractors/protectors and hot air, to desolder in a quick, safe and clean way while protecting the

surrounding components by concentrating the heat onto the IC. A medium-sized QFP, for example, can be desoldered in 20

seconds.

(*The JT-Q is the same hot-air station but is supplied whithout accessories.)

Connectable tools: JT heater

Includes:

120V - Ref. JT-1A

230V - Ref. JT-2A

 JT control unit

 1000 W heater.

 JT Extractor stand.

 5 extractors, 5 shields and 2 tripods.

 JT-SA stand

 Accessories set

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Reference Guide

English

JT

HIGH-POWER HOT-AIR

STATION

www.jbctools.com

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

2

JT / HIGH-POWER HOT-AIR

CONTAINS

CONTROL UNIT

JTE-2A or JTE-1A

STAND

JT-SA

HEATING SET

0005783 (230V) or

0007293 (120V)

EXTRACTOR STAND *

0008748

Protector

Extractor

NOZZLE

0932015 ø4

0932012 ø6

0932020 ø8

SUCTION CUPS *

0930110

SUCTION TUBE *

0932330

TRIPOD *

T2050 ø20

T2250 ø40

CORD MANUAL

* These accessories are not supplied with JT-2QA or JT-1QA stations

JT

HIGH-POWER HOT-AIR

STATION

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

3

INSTALLATION

Electric inlet

Equipotencial

connector

Pedal 0964551 (Optional)

DESCRIPTION

Display

Function keys

Connectable tools:

JT-A with corresponding heating element only version JT-A

TE-A with corresponding heating element only version TE-A

Heating element

Suction

Tube

Heater inlet

Main switch

Vacuum inlet for tripods

and extractors

Activation of

suction pump

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

4

ORIGINAL PIN: 0105

Press during 2 seconds

to enter SETTINGS

SELECT

Main menu

Settings Counters

1 Reset settings

2

Settings

3

Counters

4

Program version

1

Temp unit Celsius

2

Fix temp 400

0

C

3

Fix air Flow 40%

4

Cycle time 2:00 min

1 StationONhours

0

2

Works hours 0

3Works

cycles 0

5

Change PIN

Exit

Back

Temp Flow

Time to stop 0.45

Power 70%

400oC80%

WORKING

SETTINGS

Selected temperature

Current temperature

% Instant power supplied to the heater

Selected time

Selected ﬂow

Decrease & move down

Selection

Increase & move up

400ºC

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

5

DESOLDERING PROCEDURE

1. Lock the extractor

2. Hot-air melts the solder

3. IC is removed automatically

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

6

MAINTENANCE

CHANGING THE HEATING SET

Turn off the station.

Use a wrench to unscrew the cover.

FOLLOW THIS PROCESS INVERTED TO RE-CONNECT THE HEATING ELEMENT

This step has to be performed when the heating set is cold.

1. Untighten screw.

2. Separate the heating element from the heating set’s handle.

3. Connect the new heating element, pushing it’s extreme.

4. Insert screw to avoid air-loss which could reduce the heating element’s lifetime.

You will ﬁnd all the information about control unit JTE in our web site:

http://www.jbctools.com

Move back the cover. Pull the connector from the socket to disconnect the heating set from the station.

Follow this process inverted to re-connect the heating set.

Heating element

0006993 (230V) or

0007565 (120V)

Handle

0005390

Heating set

0005783 (230V) or

0007293 (120V)

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

ENGLISH / WARRANTY

The JBC 2 years warranty, guarantees this equipment against all

manufacturing defects, covering the replacement of defective parts

and all necessary labour.

Warranty does not cover product wear due to use or mis-use.

In order for the warranty to be valid, equipment must be returned,

postage paid, to the dealer where it was purchased enclosing this,

fully ﬁlled in, sheet.

MORE INFORMATION

www.jbctools.com

SERIAL N`

STAMP OF DEALER

DATE OF PURCHASE

0009044-0709

TECHNICAL SPECIFICATIONS

- Temperature selection from150 to 450°C (±5%) and “cool”.

- Power: 1000W.

- Air ﬂow regulation: 6-45l/min.

- JT-2A 230V control unit. Input: 230V 50Hz.

- JT-1A 120V control unit. Input: 120V 50/60Hz.

- Total weight of unit: 2.5Kg.

- Complies with CE standards on electrical safety, electromagnetic compatibility and ESD protected housing

“skin effect”.

- RoHS compliant.

- Equipotential connector and the tool tip are connected to station mains ground supply for ESD protection.

This product should not be

thrown in the garbage.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

jbc JT Series User manual
