jbc T210 Series User manual

Soldering Iron Handles
Ref. T210 / T245 / T470
INSTRUCTION MANUAL
www.jbctools.com

For C245 Cartridge range
The soldering iron handles for general purposes are suitable for both SMD components and jobs
with high power requirements (e.g. ground plane soldering).
Features
Soft foam (Ref. 0016057)
Non-slip soft touch
Blue grip to easily distinguish it from other handles
General Purpose Handle
Ref. T245-A
Note: All models are supplied with a 1.5 m cable.
Blue Handle
Ref. T245-PA
Non-slip Handle
Ref. T245-B
General Purpose Handle with reinforced cable
Ref. T245-GA
Soft foam (Ref. 0016057)
2

Precision Purpose Handle
Ref. T210-A
For C210 Cartridge range
The T210 handles are suitable for precision soldering jobs with medium power requirements.
Due to their size, they work with conventional and small SMDs as well as under a microscope.
Blue Precision Handle
Ref. T210-PA
For C470 & C245 Cartridge ranges
For intensive soldering jobs requiring continued high thermal power. They feature good thermal
insulation with a screw to fasten the cartridge which prevents rotation.
HD Purpose Handle Heavy Duty HD Handle HD Purpose Handle + 3m cable
Ref. T470-A Ref. T470-B Ref. T470-SA
Tri-lobed HD Handle
Ref. T470-ZA
Thermal Insulator HD Handle Soft Thermal Insulator HD Handle + 3m cable
Ref. T470-FA Ref. T470-MC
Note: All models are supplied with a 1.5 m cable except those specified with 3 m.
Tri-lobed for better handling
Soft foam (Ref. 0018658)
Blue grip to easily distinguish it from other handles
Foam
www.jbctools.com
3

For C245 Cartridge range
Nitrogen Handle
Ref. T245-NA
For C470 Cartridge range
Nitrogen HD Handle
Ref. T470-NA
Nitrogen Handles features
Nozzles
Ref. B6193
B6194
B6195
Nozzles
Ref. B7968
B7244
These are for working in an oxygen-free atmosphere providing better quality soldering. They
offer extra heat to the solder joint and help prevent oxidation. The JBC GN-A Nitrogen Generator
Module or an external nitrogen feed is needed at the operator’s bench.
For C210 Cartridge range
Nitrogen Precision Handle
Ref. T210-NA
Nozzles
Ref. B6647
Nitrogen feed
Nitrogen feed
Nitrogen feed
4

Mark
*Important
It is essential to insert the cartridges as far as the mark for a proper connection.
Changing T210 & T245 Cartridges
1. Removing 2. Inserting 3. Fixing
Place the Cartridge in the
extractor and pull the handle
to remove it.
Place the handle on top
of the new Cartridge and
press down.
Use the holes to fix the
Cartridge* as follows:
A. For straight C210.
B. For curved C245.
C. For curved C210.
D. For cold cartridge holder
BC
A
D
Save time and change cartridges safely without switching the station off.
www.jbctools.com
5

Loosen the screw. Place the Soldering Iron in
the extractor and remove the cartridge.
Changing T470 Cartridges
1. Removing 2. Inserting
Loosen
Insert the new cartridge* and press slightly
as far as the mark and tighten the screw.
Nozzle
After changing the cartridgeBefore changing the cartridge
Insert the cartridge, tighten the screw and then
place the nozzle.
Mark
First remove the nozzle. Then loosen the screw
to remove the cartridge (T245-NA / T470-NA).
Use a pliers to change or remove
nozzles when hot.
Mark
*Important
It is essential to insert the cartridges as far as the mark for a proper connection.
Changing Nitrogen Cartridges
6

Insert the slide-on tabs into
the new grip.
Push the grip with the tabs
onto the handle.
Hold the grip and pull them
out. Use a pliers if necessary.
tabs
new grip
Easily replace the Grips (Ref. 0016057 and Ref. 0018658) using the slide-on tabs.
Before replacing the grip, unplug the power supply and make sure the device is not hot.
1. Inserting tabs 2. Inserting handle 3. Removing tabs
Replacing grips
Maintenance
- Before carrying out maintenance, always unplug the stand and the tool.
- Check periodically that the metal parts of the tool and the stand are clean to ensure detection of
the tool when it is in the stand. Use a damp cloth or alcohol.
- Periodically check all cables and tubes connections.
- Replace any defective or damaged pieces. Use original JBC spare parts only. Repairs should only
be performed by a JBC authorized technical service.
www.jbctools.com
7

Fume extractor
Ref. F3435 (for T245 / T470)
Ref. F3450 (for T210)
Cable collector
Ref. CC1001
Keeps the work
area free of cable.
Clips can be easily
removed for quick
maintenance.
Accessories
The Seal is meant to prevent undesirable flux vapors or particles from entering inside the tool. Its
usage is highly recommended for intensive applications when soldering in exposed to FOD environ-
ments or for applications where the soldering iron works close to vertical position.
Replacing Seals
Before replacing the seal, unplug the power supply and make sure the device is not hot.
Note the Seal mounting posi-
tion. The chamfered side has
to be positioned towards the
Handle.
2. Mounting position 3. Inserting the Seal1. Removing the Seal
Seal
Handle
Gently push the Seal inside
the handle until it is complete-
ly into the Handle.
Handle and Seal edges have
to be aligned.
Enter a small shaft or screw-
driver in order to gently lift
and pull the Seal.
Do not insert the tool more
than 8 mm deep.
Never use a cartridge to do
this operation.
8

Handle Cartridge
Range CD Stand DI DDE DME HDE
T210-A C210
AD-SE
T210-PA
T245-A
C245
T245-PA
T245-B
T245-GA
T470-A C245 AD-SE
C470 HD-SE
T470-B C245 AD-SE
C470 HD-SE
T470-SA C245 AD-SE
C470 HD-SE
T470-ZA C245 AD-SE
C470 HD-SE
T470-FA C245 AD-SE
C470 HD-SE
T470-MC C245 AD-SE
C470 HD-SE
T210-NA* C210
DN-SE
T245-NA* C245
T470-NA* C245
C470
* The MNE Nitrogen Flow Regulator is required. Use the proper nozzle according to the cartridge.
Compatibility
www.jbctools.com
9

Notes
- Do not use the units for any purpose other than soldering or rework. Incorrect use may cause fire.
- The power cable must be plugged into approved bases. Make sure that it is properly grounded
before use. When unplugging it, hold the plug, not the wire.
- Do not work on electrically live parts.
- The tool should be placed in the stand when not in use in order to activate the sleep mode.
The soldering tip, the metal part of the tool and the stand may still be hot after the station
is turned off. Handle with care, including when adjusting the stand position.
- Do not leave the appliance unattended when it is on.
- Do not cover the ventilation grills. Heat can cause inflamable products to ignite.
- Avoid flux coming into contact with skin or eyes to prevent irritation
- Be careful with the fumes produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when
working to avoid personal harm.
- Utmost care must be taken with liquid tin waste which can cause burns.
- This appliance can be used by children over the age of eight as well as persons with reduced
physical, sensory or mental capabilities or lacking experience provided that they have been given
adequate supervision or instruction concerning use of the appliance and understand the hazards
involved. Children must not play with the appliance.
- Maintenance must not be carried out by children unless supervised.
Safety
It is imperative to follow safety guidelines to prevent electric
shock, injury, fire or explosion.
10

Notes
www.jbctools.com
11

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
