jbc TE User manual

Reference Guide
TE
PRECISION HOT-AIR
STATION
www.jbctools.com

2
TE / PRECISION HOT-AIR
CONTENTS
CONTROL UNIT STAND
JT-SA
HEATING SET
TE-TA (230V/120V/100V)
EXTRACTOR STAND *
0008752
Protector
Extractor
NOZZLE
0009209 ø3
0009208 ø4
0009080 ø5
SUCTION CUPS *
0930110
SUCTION TUBE *
0932330
TRIPOD *
T2250 ø40
CORD MANUAL
* These accessories are not supplied with TE-2QA or TE-1QA stations
Reference Guide
TE
PRECISION HOT-AIR
STATION

3
INSTALLATION
Power Cord
Socket
Equipotencial
connector
Pedal 0964551 (Optional)
DESCRIPTION
Display
Function keys
Connectable tools:
JT-T2A / JT-T1A
TE-TA
Heating element
Suction
Tube
Heater inlet
Main switch
Vacuum inlet for tripods
and extractors
Activation of
suction pump

4
ORIGINAL PIN: 0105
Main menu
Settings
Counters
1 Reset settings
2 Settings
3 Counters
4 Program version
1 Temp unit Celsius
2 Maximum temp 450
0
C
3 Minimum temp T OFF
4 Fix temp 400
0
C
5 Max air 100%
6 Min air 10%
7 Fix air 40%
8 Time to stop 120 sec
9 Beep ON
10 Pop up ON
11 Change PIN
1 Station ON hours 0
2 Works hours 0
3 Works cycles 0
Exit
Back
Back
Temp º CAir %
Time to stop 45 seconds
Power 70%
400 80
WORKING
SETTINGS
Selected temperature
Current temperature
% Instant power supplied to the heater
Remaining time
Selected flow
Decrease & move down Selection Increase & move up
400ºC Select
SELECT Key 2 seconds
to access Menu

5
DESOLDERING PROCEDURE
1. Lock the extractor
2. Hot-air melts the solder
3. IC is removed automatically

6
MAINTENANCE
CHANGING THE HEATING SET
Ensure that the tool is stopped.
Use a wrench to unscrew the cover.
FOLLOW THIS PROCESS INVERTED TO RE-CONNECT THE HEATING ELEMENT
This step has to be performed when the tool is stopped and the heating set is cold.
1. Untighten screw.
2. Separate the heating element from the heating set’s handle.
3. Connect the new heating element, pushing it’s extreme.
4. Insert screw to avoid air-loss which could reduce the heating element’s lifetime.
Move back the cover. Pull the connector from the socket to disconnect the heating set from the station.
Follow this process inverted to re-connect the heating set.
Heating element
0006997 (230V/120V/100V)
Handle
0005896
Heating set
TE-TA (230V/120V/100V)

7

WARRANTY
The JBC 2 years warranty, guarantees this equipment against all
manufacturing defects, covering the replacement of defective parts
and all necessary labour.
Warranty does not cover product wear due to use or mis-use.
In order for the warranty to be valid, equipment must be returned,
postage paid, to the dealer where it was purchased enclosing this,
fully filled in, sheet.
MORE INFORMATION
www.jbctools.com
SERIAL N`
STAMP OF DEALER
DATE OF PURCHASE
0009325/0610
TECHNICAL SPECIFICATIONS
- Temperature selection from150 to 450°C (±5%) and “cool”.
- Power: 300W.
- Air flow regulation: 6-45l/min.
- TE-2A 230V control unit. Input: 230V 50/60Hz.
- TE-1A 120V control unit. Input: 120V 50/60Hz.
- TE-9A 100V control unit. Input: 100V 50/60Hz.
- Total weight of unit: 2.5Kg.
- Complies with CE standards on electrical safety, electromagnetic compatibility and ESD protected housing
“skin effect”.
- RoHS compliant.
- Equipotential connector and the tool tip are connected to station mains ground supply for ESD protection.
This product should not be
thrown in the garbage.
