jbc T210 Series User manual

Soldering Iron Handles
Ref. T210 / T245 / T470
www.jbctools.com

Soft foam
Non-slip soft touch
Blue grip to easily distinguish it from other handles
Blue grip to easily distinguish it from other handles
Foam
2 322 33
Precision Handle
Ref. T210-A
For C210 Cartridge range
The T210 handles are suitable for precision soldering jobs with medium power requirements.
Due to their size, they work with conventional and small SMDs as well as under a microscope.
For C245 Cartridge range
The soldering iron handles for general purposes are suitable for both SMD components and
jobs with high power requirements (e.g. ground plane soldering).
Blue Precision Handle
Ref. T210-PA
General Purpose Handle
Ref. T245-A
Blue Handle
Ref. T245-PA
Non-slip Handle
Ref. T245-B
Features
For C470 & C245 Cartridge ranges
For intensive soldering jobs requiring continued high thermal power. They feature good thermal
insulation with a screw to fasten the cartridge which prevents rotation.
HD Purpose Handle HD Purpose Handle with 3m cable
Ref. T470-A Ref. T470-SA
Tri-lobed HD Handle
Ref. T470-ZA
Thermal Insulator HD Handle Thermal Insulator HD Handle with 3m cable
Ref. T470-FA Ref. T470-MA
Soft Thermal Insulator Handle
Ref. T245-C
Note: All models are supplied with a 1.5m cable except those specified with 3m.
Easily replace the Grips for T245-C using the slip-on tabs (Ref. 0016057 Supplied with 4 grips).
1. Inserting tabs 2. Inserting handle 3. Removing tabs
Tri-lobed for better handling
Put the slip-on tabs into the
new grip.
Slide the grip with the tabs
onto the handle.
To remove the tabs, hold the
grip and pull.
tabs
new grip
www.jbctools.com

Nitrogen feed
Nitrogen feed
4 544 55
Nitrogen Handle
Ref. T245-NA
Nitrogen HD Handle
Ref. T470-NA
Mark
*Important
It is essential to insert the cartridges as far as the mark for a proper connection.
T210 & T245 Changing cartridgesNitrogen Handles features
1. Removing 2. Inserting 3. Adjusting
Place the handle in the
extractor and pull to
remove the cartridge.
Place the handle on top of
the new cartridge and press
down.
Use the holes for fixing the
cartridge* as follows:
A. For straight C210.
B. For curved C210.
C. For curved C245.
D. For straight C245.
B
C
A
D
Save time and change cartridges safely without switching the station off.
Nozzles
Ref. B6193
B6194
B6195
Nozzles
Ref. B7243
B7244
Loosen the screw. Place the Soldering Iron in
the extractor and remove the cartridge.
T470 Changing cartridges
1. Removing 2. Inserting
Loosen
These are for working in an oxygen-free atmosphere providing better quality soldering.
They offer extra heat to the solder joint and help prevent oxidation. The JBC GN-A Nitrogen
Generator Module or an external nitrogen feed is needed at the operator’s bench.
For C245 Cartridge range
For C470 Cartridge range
Nozzle
After changing the cartridge
Insert the cartridge, tighten the screw and
then place the nozzle.
Mark
Changing nozzles
Before changing the cartridge
First remove the nozzle. Then loosen the
screw to remove the cartridge. Use a
pliers to change nozzles when hot.
Insert the new cartridge and press slightly
as far as the mark* and tighten the screw.
www.jbctools.com

Handle Stand Cartridge
Range CD DI DDE DME HDE
T210-A
AD-SD
C210
T210-PA
T245-A
C245
T245-PA
T245-B
T245-C
T245-NA* DN-SD
T470-A
HD-SD
C245
C470
T470-SA C245
C470
T470-ZA C245
C470
T470-FA C245
C470
T470-MA C245
C470
T470-NA* DN-SE C245
C470
6 7
66 77
Safety
It is imperative to follow safety guidelines to protect health and prevent electric
shock, injury, fire or explosions.
- Do not use the tool for any purpose other than soldering or rework. Incorrect use may cause fire.
- The power cord must be plugged into approved bases. Be sure that it is properly grounded
before use. When unplugging it, hold the plug, not the wire.
- Do not work on electrically live parts.
- The tool should be placed in the stand when not in use in order to activate the sleep mode.
The soldering tip, the metal part of the tool and the stand may still be hot even when the station is
turned off. Handle with care, including when adjusting the stand position.
- Do not leave the appliance unattended when it is on.
- Do not cover the ventilation grills. Overheating can cause inflamable products to ignite.
- Use a “non residue” classified flux and avoid contact with skin or eyes to prevent irritation.
- Be careful with the fumes produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protective glasses and gloves when
working to avoid personal harm.
- Utmost care must be taken with liquid tin waste which can cause burns.
- This appliance can be used by children over the age of eight and also persons with reduced
physical, sensory or mental capabilities or lack of experience provided that they have been given
adequate supervision or instruction concerning use of the appliance and understand the hazards
involved. Children must not play with the appliance.
Maintenance
Before carrying out maintenance, always unplug the stand and the tool.
- Check periodically that the metal parts of the tool and the stand are clean to ensure detection of
the tool when it is in the stand. Use a damp cloth or alcohol.
- Periodically check all cables and tubes connections.
- Replace any defective or damaged pieces. Use original JBC spare parts only.
- Repairs should only be performed by a JBC authorized technical service.
Fume extractor
Ref. F3435 (for T245 / T470)
Ref. F3450 (for T210)
Cable collector
Ref. CC3702
Keeps the work
area free of cable.
Clips can be easily
removed for quick
maintenance.
Accessories
* The MNE Nitrogen Flow Regulator is required. Use the proper nozzle according to the cartridge.
Compatibility
www.jbctools.com

0015073-0515
This product should not be thrown in the garbage.
In accordance with the European directive 2002/96/EC, electronic equipment at the end of its life
must be deposited at an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment
against all manufacturing defects, including the
replacement of defective parts and labour.
Warranty does not cover product wear due to use
or mis-use.
In order for the warranty to be valid, equipment
must be returned, postage paid, to the dealer
where it was purchased.
