jbc TRA245 User manual

Automatic Soldering Irons
for Automation
Ref. TRA245-A / TRA470-A
www.jbctools.com

Packing List
The following items should be included for TRA245:
Insulator Clamp ..............1 unit
Ref. 0021512
Screws
DIN 912 M3X40 .............. 2 units
Ref. 0021514
Soldering Iron
for Automation .............. 1 unit
Ref. TRA245-A
Works with R245 cartridges
Screws
DIN 912 M3X25 .............. 2 units
Ref. 0001392
Manual ......................... 1 unit
Ref. 0021282
Washers
DIN 125 Ø3,2 ............ 2 units
Ref. 0242404
Either TRA245 or TRA470 are included.
2
Ref. TR245-A / TR470-A
Automatic Soldering Irons
for Automation
www.jbctools.com

Screws
DIN 912 M3x12 .......... 2 units
Ref. 0926733
Screws
DIN 912 M3x25 ........... 2 units
R ef. 0 0 21511
Insulator Clamp ..............1 unit
Ref. 0021513
Washers
DIN 125 Ø3,2 ............ 2 units
Ref. 0242404
Soldering Iron
for Automation .............. 1 unit
Ref. TRA470-A
Works with R470 cartridges
The following items should be included for TRA470:
www.jbctools.com
3
Manual ............................ 1 unit
Ref. 0021282
Ref. TR245-A / TR470-A
Automatic Soldering Irons
for Automation
www.jbctools.com

A
B
Assembly
Screws
Ref. 0021514
Washers
Ref. 0242404
Automatic
Soldering Iron
Ref. TRA245-A
Screws
Ref. 0001392
Connection to UCR245
using Tool Cable
Ref. 0021403
Gripper Actuator
Fluid Air
Applicable tubing Ø4mm
Operating pressure 0,15 to 0,7 MPa
A Air tube connection to fix cartridges
B Air tube connection to release cartridges
Soldering Head for Automation*
Ref. RBA-A
*Not included, sold separately
TRA245
Insulator Clamp
Ref. 0021512
It is mandatory to have the electrical
Insulator Clamp assembled for proper
tool working.
Don’t remove the Insulator Clamp.
4

Screws
Ref. 0 0 21511
Washers
Ref. 0242404
Screws
Ref. 0926733
Automatic
Soldering Iron
Ref. TRA470-A
A
B
Connection to UCR470
using Tool Cable
Ref. 0021403
Gripper Actuator
Fluid Air
Applicable tubing Ø4mm
Operating pressure 0,15 to 0,7 MPa
A Air tube connection to fix cartridges
B Air tube connection to release cartridges
Soldering Head for Automation*
Ref. RBA-A
*Not included, sold separately
TRA470
Insulator Clamp
Ref. 0021513
It is mandatory to have the electrical
Insulator Clamp assembled for proper
tool working.
Don’t remove the Insulator Clamp.
www.jbctools.com
5

122,1
4,807
~166
~6,535
68,4
2,693
53,5
2,106
40,6
1,598
28
1,102
8,6
0,339
30
1,181
29,8
1,173
15,8
0,622
2x
3,4
2x0,134
21
0,827
15,8
0,622
Working point
TRA245-A
Dimensions
mm
(in)
6

138,1
5,437
~166
~6,535
68,4
2,693
69,5
2,736
56,6
2,228
12
0,472
8,6
0,339
30
1,181
29,8
1,173
15,8
0,622
21
0,827
15,8
0,622
2x
3,4
2x0,134
Working point
TRA470-A
mm
(in)
www.jbctools.com
7

Inserting Cartridges
The Automatic Soldering Iron for TRA is directed towards the cartridge. Once in position its
valve must be activated.
JBC recommends bi-stable valves to prevent the cartridges from falling out in case of an
emergency stop or power cut.
When using the Automatic Cartridge Stand CS2R, you have to activate its valve to open the
gripper and to release the cartridge before making any movement.
Gripper Actuator
TRA
CS2R*
Soldering
Irons
Cartridge Range Control Unit Cartridge Stand
R245 R470 UCR245 UCR470 CS2R245 CS2R470
TRA245
TRA470
RBA, SFR, GSFR and CLMR are compatible with R245 and R470 ranges.
*Not included, sold separately
Compatibility
8

Accessories
Solder Feeder
for Automation*
Ref. SFR-A
Guide Kit
for Automation*
Ref. GSFR
Soldering Head for Automation*
Ref. RBA-A
Automatic
Soldering Iron
Ref. TRA245-A
TRA470-A
Automatic Cartridge Stand*
Ref. CS2R245-A
CS2R470-A
*Not included, sold separately
www.jbctools.com
9

*Not included, sold separately
Work Place Example
Solder Feeder*
Ref. SFR-A
Automatic Tip
Cleaner*
Ref. CLMR-A
Soldering Head*
Ref. RBA-A
Automatic Soldering Iron
Ref. TRA245-A
TRA470-A
Automatic Cartridge Stand*
Ref. CS2R245-A
CS2R470-A
Control Unit*
Ref. UCR245-5A
UCR470-5A
Guide Kit*
Ref. GSFR
10
