John Lewis POTTER User manual

John Lewis Partnership
171 Victoria Street
London SW1E 5NN
johnlewis.com
Made in China Please retain these instructions for future reference.
5 year guarantee
If you experience any unresolvable technical issues with the product,
contact your nearest John Lewis & Partners shop or John Lewis & Partner
Technical Support on 03301 230106.
Aftercare and
Troubleshooting
Max. power: 2x 15W
Voltage: 220–240V, 50Hz
IP rating: 44
Weight: 3.960kg
At John Lewis & Partners we test every light to high quality standards so we are
able to offer you a 5 year guarantee.
Specification
Recycling
Caring for
your product
We recommend cleaning with a soft dry cloth. Do not use abrasive materials as
these will damage the nish.
This symbol indicates that this product should not be treated as
normal household waste and it should be recycled. John Lewis & Partners
do not operate instore take back, but as members of the Distributor Take
Back scheme have funded the development and upgrade of recycling
facilities across the UK. Please take it to your nearest collection facility or
for further details contact your local council or visit www.recycle-more.
co.uk.
POTTER OUTDOOR WALL LIGHT
USER GUIDE
24/11/2020

01 02
Light tting 1
Wall plugs 2
Screws 2
Parts list Qty
Introduction Thank you for purchasing this Potter outdoor wall light.
Please read the instructions carefully before
use to ensure safe and satisfactory operation
of this product.
Warnings This is a Class 1 product and must be earthed.
Please read these instructions carefully before commencing any work. It is
recommended that this tting is installed by a qualied electrician.
Install in accordance with the IEE Wiring regulations and the Building Regulations.
To prevent electric shock switch off at mains supply before installing or maintaining
this tting. Ensure other persons cannot restore the electrical supply without your
knowledge.
If you are in any doubt, please consult a qualied electrician.
This light tting should be connected to a 5 amp fused circuit.
If replacing an existing tting, make a note of the connections.
This product is rated IP44 and is suitable for outdoor use.
This product is suitable for installation on surfaces with normal ammability e.g.
wood, plasterboard, masonry. It is not suitable for use on highly ammable surfaces
(e.g. polystyrene, textiles).
For your safety, always switch off the supply before changing lightbulbs, cleaning
or removing shades. Always take care when handling lightbulbs to avoid injury in case
of breakage.
Recommended bulb (not included)
2 x 15W (Max.) E27 GLS
When changing a bulb, always switch off at the mains and allow the bulb to cool
before handling. Dispose of used bulbs carefully. Do not exceed the rated power
stated or use a different shape bulb from that indicated on the tting.
Recommended bulb
Product assembly
1
4
2Remove the shade (A) from the product by undoing
top and bottom screws and washers. Save for retting
later.Remove the back plate (C) from the tting by
removing nials and rubber washers (B).
Using the wall plugs and screws provided in the xing
pack, secure the back plate to the wall. Take care to
avoid damaging any concealed wiring and pipes.
Having identied the household wiring from your
existing light tting, connect to the outdoor rated
connection block (D) inside the product in the
following way.
Check that:
You have correctly identied the house wires.
•The connections are tight.
•No loose strands have been left out of the
connection block.
•Ensure the grommet is in place to maintain IP rating.
Re-attach the light tting to the back plate (C) by
locating the screw holes over the screws and replacing
the rubber washers and the nials (B) and tightening
them securely.
Fit the recommended bulbs.
Ret the shade (A) onto the light tting ensuring drain
hole (E) is at the bottom. Ret top and bottom washers
and screws and tighten to secure.
Carefully unpack the carton, making sure all the parts
are present before assembly.
Before removing the existing tting, carefully note the
position of each set of wires.
NEUTRAL
EARTH
SWITCHED LIVE
BLUE (N)
GREEN/YELLOW or
METALLIC EARTH CONNECTION
BROWN (L)
HOUSEHOLD SUPPLY LIGHT FITTING
3
A
B
C
D
E
