John Lewis Ridley User manual

John Lewis Partnership
171 Victoria Street
London SW1E 5NN
johnlewis.com
Made in China 08/05/2018
We have taken great care to ensure that this product reaches you in perfect condition.
However, should any parts be damaged or missing please contact the Product Helpline on
[phone].
This symbol indicates that this product should not be treated as normal household waste
and it should be recycled. John Lewis do not operate instore take back, but as members of the
Distributor Trade Back scheme have funded the development and upgrade of recycling facilities
across the UK. Please take it to your nearest collection facility or for further details contact your
local council or visit www.recycle-more.co.uk.
User manual
Ridley
Floor lamp
Specifications
Max. power: 30W
Voltage: 240V, 50Hz
IP rating: IP20
Weight: 8.4kg
2400 lumen output
Colour temperature:Warm white (3000K)
Please retain these instructions for future reference.
Recommended bulb (included)
1 x 30 Watt energy efficient LED module
&
1 x 5 Watt energy efficient LED module
This product contains a non-replaceable LED Module. If the LEDs become damaged then the whole
product must be replaced.
When moving or cleaning, always switch off at the mains and allow the module to cool before
handling.

Assembly
Refer to assembly drawings. Carefully unpack the carton, making sure all the parts are present
before assembly.
Step 1
Do not attempt to plug in or use this product until it has been fully assembled. Disconnect from
mains during assembly or maintenance.
Step 2
Remove all packaging from the base, the central tubes and shade. Remove any cable protection
pieces in the ends of the tubes.
Thank you for purchasing this Ridley oor lamp. Please read the instructions carefully before use to
ensure safe and satisfactory operation of this product.
Care instructions
We recommend cleaning with a soft dry cloth. Do not use abrasive materials as these will damage
the nish.
Warnings!
This is a Class 1I product and must NOT be earthed.
Please read these instructions carefully before commencing any work.
Your standard lamp has been packaged as separate parts to prevent damage during transit.
When manoeuvring or assembling this product, it must be lifted from the bottom.
If you are in any doubt, please consult a qualied electrician.
For your safety, always switch off the supply before cleaning or adjusting.
This product is suitable for indoor use only
Parts list Image Qty
Light tting 1
Shade glass 1
Central tube 2
Shade xings 3
Base xings 1
Hex key 1
Spanner 1
Figure 1
Figure 2
Figure 3
Figure 4
Step 3
Fit the glass shade in place by placing the glass over the main light
and xing in place using the screws.
Step 4
Secure the upper tubes to the main light head using the hex key
provided, being aware of cross-threading, and ensuring no cables
are strained or trapped.
Step 5
Screw the two lower tubes into the central control unit, being
aware of cross-threading, and ensuring no cables are strained or
trapped.
Step 6
Fit the lower tubes to the base, by slotting through the plate
and into the base. Gently pull any excess cable through the base.
Secure the tubes in place using the base xings and spanner
provided.
Step 7
Stand the product upright and check the tightness of the joints.
Step 8
Your standard lamp is now ready to use. Plug in to the mains
supply, and switch on using the dimmer switches on the central
panel; the top switch (A) operates the main light, and the bottom
switch (B) operates the reading light.
Figure 5
A
B
Parts list
