Kaba Ilco 790 Series Assembly instructions

PK3612_07_12
IMPORTANT: Wear Safety glasses before starting the replacement of parts.
790/79 Series Rework Installation Sheet
Current PCB
Switch
Holder
New
Cam
Protective
Bracket
New privacy
Switch
New PCB
1
4 6
A
B
C
D
5
2 3
Remove screw and take out battery pack
Remove foam, cam & screws and discon-
nect cables
Assemble New PCB
Option
Option
Option
Motor (See step 4)
Pass cables in
housing gap push
cables away from
the screw head
Place the plastic clip to hold the cables in place. Make sure
the clip is not on the cables before to hold it with the screw
Before placing PCB connect
standard cables and cables
for door option if applicable
at orientation as shown
Use screws from step 4
Override Switch
(See step 4)
Remove PCB
Remove 5 screws and take off the back
plate Assemble protective bracket and hold with one of the 5 screws from step 2
Screw below center label
Protective Bracket
790/79 Series LOCK PCB + PRIVACY MECH. PARTS
