keilhauer GSD User manual

GSD Table
Assembly Instructions
Bar & Counter Table Only
Tool Required
5/32” Hex Allen Key
Hardware Included
1/4-20 x 1”
Button head cap
screw (x2)
Screw the glide (x4) into each aluminum table leg.
Interlock the aluminum table legs (x2) by positioning
the bosses in line with their corresponding pockets. Pull
and hold the legs towards each other.
3
1
1
Place the aluminum leg sub assemblies at each
end of the channel. Using the 5/32” hex key, install
the 1/4”-20 x 1” button head cap screw (x2).
2
Using the 5/32” hex key, fasten the channel to the
aluminum legs with with 1/4”-20 x 1/2” button head cap
screw (x4).
5
Overlap table brace (x2) and place into aluminum legs. Using
the 5/32” hex key, install the 1/4”-20 x 1/2” button head
cap screw (x4). Attach brace (x2) to the channel with the
1/4”-20 x 3/4” flat head screw (x2) using the 5/32” hex key.
4
Using the 5/32” hex key, fasten the table base to the
table top with 1/4- 20x 3/4” button headcap screw
and washer (x6) or (x8).
6
Washer Glide
(x4)
1/4-20 x 1/2”
Button head cap screw
1/4-20 x 3/4”
Flat head cap screw
(x2) Bar & Counter
1/4-20 x 3/4”
Button head cap screw
(x6) per 71 & 86 inch table
(x8) per 102 inch table (x4) Conference
(x8) Bar & Counter
(x6) per 71 & 86 inch table
(x8) per 102 inch table
keilhauer.com

GSD Table
Assembly Instructions
GSD Power Table Assembly Instructions
Tool Required
3/32” Hex Allen Key
5/32” Hex Allen Key
Hardware Included
Feed the power cord through the cut out and install the
power box (x1).
Press the table end cap (x2) over each end of the channel.
9
7
2
Place the assembled table in it’s final position.
8
Press the table end cap (x2) over each end of the channel.
Attach the power cord to the leg with the cable clamp (x3)
and #8-32 x 3/8” cap screw (x3), using the 3/32” hex key.
Place the assembled table in it’s final position.
11 12
Using the 5/32” hex key, fasten the table base to the table
top with 1/4- 20x 3/4” button headcap screw and
washer (x6) or (x8).
10
#8-32 x 3/8”
Cap screw (x3)
1/4-20 x 3/4”
Button head cap screw
(x6) per 71 & 86 inch table
(x8) per 102 inch table
Cable Clamp
(x3)
keilhauer.com

GSD Table
Ganging Instructions
See GSD Table Assembly Instructions for General Assembly
Bar & Counter Table Only
Tool Required
5/32” Hex Allen Key
1/4” Hex Allen Key
Hardware Included
1/4-20 x 1”
Button head cap screw
(x1)
Using the 5/32” hex key, fasten the ganging channel to
the aluminum legs with 1/4”-20 x 1/2” button head cap
screw (x2).
Place the aluminum leg sub assembly on the ganging
channel. Using the 5/32” hex key, install the 1/4”-20 x 1”
button head cap screw (x1).
3
1
3
Screw the glide (x2) into each aluminum table leg.
2
Overlap table brace (x1) and place into aluminum legs. Using
the 5/32” hex key, install the 1/4”-20 x 1/2” button head
cap screw (x4). Attach brace (x1) to the channel with the
1/4”-20 x 3/4” flat head screw (x1) using the 5/32” hex key.
5
4
Glide
(x4)
1/4-20 x 1/2”
Button head cap screw
1/4-20 x 3/4”
Flat head cap screw
(x1) Bar & Counter
(x2) Conference
(x4) Bar & Counter
Using a #14 wrench and 1/4” hex key, fasten the ganging
channel to the table channels with 3/8 - 16 x 1” socket
head screw (x6) and 3/8” lock nut (x6).
3/8”
Lock Nut
(x6)
3/8-16 x 1”
Socket head screw
(x6)
#14 Wrench
keilhauer.com

GSD Table
Ganging Instructions
U sing the 5/32” hex key, fasten the table base sub
assembly to the table tops with 1/4- 20x 3/4” button
headcap screwand washer (x6) or (x8) per table top.
Place the assembled tables in their final position.
6
8
4
Press the table end cap (x2) over each end of the
channel.
7
Tool Required
5/32” Hex Allen Key
Hardware Included
Washer1/4-20 x 3/4”
Button head cap screw
(x6) per 71 & 86 inch table
(x8) per 102 inch table
(x6) per 71 & 86 inch table
(x8) per 102 inch table
Underside of table
shown.
Underside of table
shown.
keilhauer.com
