keilhauer Syz User manual

Syz Table
Assembly Guide
keilhauer.com
1450 Birchmount Road
Toronto, Ontario, Canada
M1P 2E3
T 416 759 5665
F 416 759 5723
1 800 724 5665

Hardware Included
Peel back protective polyfoam on table legs and extrusions.
Screw the table glides into each table leg.
Prepare a well-padded surface to assemble the base upside-down.
Slide the base extrusions over the table leg inserts. Face the channeled side of the
extrusion inwards.
Repeat step 5 for the remaining 3 corners.
x4 x4
(8) 5/16-18 x 1"
Set Screws
Table Top Mount Clips
(8) 60" (12) 72"/84"
(16) 96"/102"/108"/114"/120"
1/4-20 x 3/4"
Hex Socket Screws
(8) 60"(12) 72"/84"
(16) 96"/102"/108"/114"/120"
(5) Dowels
(for 72" round or square;
84" round tables)
(4) Glides
1
3
2
4
6
(2) Zip Bolt Connectors
(for 72” round or square;
84” round tables)
Line up the extrusion and leg insert set screw holes and insert the (x2) 5/16-18 x 1" set
screw, first tightening the screw by hand to ensure the screw is threading correctly, then
using a flat head screwdriver to complete.
5

Tools Required
Flip the base over.
For two-piece table tops: Place the two zip bolt connectors in the corresponding
depressions in the underside of the table top, and use the allen key to tighten.
Assemble the table top mount clips and corresponding 1/4-20 x 3/4" hex socket screws.
Ensure the threaded inserts on the underside of the table are aligned with the base
extrusions and screw in the table top mount clips loosely, rotating them so that they
clip the top to the lip of the extrusions, then once in place tighten all clips with the
driver gun to secure the top to the base.
For two-piece table tops: Place the table top on the base. If the top is in two pieces
(for models that are 72" round or square; 84" round), fit the dowels into the holes on
one half of the top and push the halves together.
Move the table into place and adjust the glides for a level surface.
x2
(1) Hex Allen Key
7
9
11
8
10
12
x2

SyzTable Designed by EOOS
Made by Keilhauer
