Juxta Slab
Assembly Guide

Tools Required Hardware Included
Place the slab top upside down on a well-padded flat surface.
Use eight 1/4-20 x 3/4" machine screws to secure the inserts to the top. Hand
tighten the screws first to allow some play for the screws to properly line up. Secure
the screws with a screwdriver once all the screws are aligned.
Gently lift the leg into place over the metal leg inserts.
Place the metal leg inserts as shown.
Before assembling the first, wider table leg, note the detail, as the channeled end
goes against the underside of the table.
Use two 1/4-20 x 1 1/4" flat socket screws (one on each end) to secure the plate.
keilhauer.com
(1) Pneumatic Driver Gun (1) Hex Bit(1) Robertson Bit (16) 1/4-20 x 3/4"
Machine Screws
(4) 1/4-20 x 11/4"
Flat Socket Screws
(4) Glides
1
3
5
2
4
6

Assemble the leg glide after the flat socket screw and leave enough thread, as
this will assist in protecting the table leg edge when turning the table back on its legs.
Making sure there is sufficient padding in place to avoid damages, turn the
table onto its legs.
Move table into place and adjust glides to provide level surface.
Repeat leg assembly steps for the second table leg.
Warning
Ensure that the channeled end
of the slab table leg goes against
the underside of the table, not the
ground, as shown in step 4.
7
9
8
10
