Syz Table with Power
Assembly Guide
keilhauer.com
1450 Birchmount Road
Toronto, Ontario, Canada
M1P 2E3
T 416 759 5665
F 416 759 5723
1 800 724 5665

x4 x4
Peel back protective polyfoam on table legs and extrusions.
Screw the table glides into each table leg.
Prepare a well-padded surface to assemble the base upside-down.
Slide the base extrusions over the table leg inserts. Face the channeled side of the
extrusion inwards.
keilhauer.com
1
3
2
4
Line up the extrusion and leg insert set screw holes and insert the 5/16-18 x 1" set
screw, first tightening the screw by hand to ensure the screw is threading correctly,
then use driver gun to complete.
Repeat step 5 for the remaining 3 corners.
5 6
Tools Required
(1) Pneumatic Driver Gun (1) Hex Bit (1) Hex Allen Key
1
2

Flip the base over.
Slide 1 of each of this assembled hardware into the channels of two opposite
extrusions (the depth-side extrusions if assembling a rectangular table).
To assemble the cable management system, feed the mesh tube through the large black
plastic disc, and then secure the mesh tube to the disc by inserting 1 of the collar tube
fasteners inside the bottom of the mesh and screwing the base of the collar to the
underside of the disc with 4 8-15 x 3/8"pan head screws.
Fit the 4 nylon spacers over the 5/16-18 x 11/2"quad pan screws and leave loose.
7
9
8
10
Hardware Included
(8) 5/16-18 x 1"
Set Screws
1/4-20 x 3/4"
Hex Socket Screws
(8) 60” (12) 72”/78x42”/84”/
90x44”/90x50” (16) 96”/102”/
108”/114”/120x44”/120x50”
(4) Slot Nuts
(4) 5/16-18 x 11/2"
Quad Pan Screws
(8) 8-15 x 3/8"
Pan Head Screws
(4) 4-15 x 1/4"
Socket Pan Head Screws
(4) 8-15 x 5/8"
Quad Pan Screws
(4) Glides(2) Bottom Tabs (2) Bottom Weights(4) Nylon Spacers
Table Top Mount Clips
(8) 60" (12) 72"/78x42"/84"/
90x44"/90x50" (16) 96"/102"/
108"/114"/120x44"/120x50"
Power Unit
(1 or 2 depending on model ordered)
(5) Dowels
(for models with two-piece
table tops)
(2) Zip Bolt Connectors
(for models with two-piece
table tops)

Attach the 2 bottom weights to the underside of the black disc with the
4 8-15 x 5/8"quad pan screws.
Feed the other side of the mesh tube through the smaller black plastic disc, and use
the second collar tube fastener to secure the disc and mesh in the same way as in
step 10.
Assemble table top mount clips and corresponding 1/4-20 x 3/4"set screws.
Attach the 2 white bottom tabs with the 4 4-15 x 1/4"socket pan screws.
For two-piece table tops: Place the table top on the base. If the top is in two pieces
(for models that are 72"round or square; 84"round), fit the dowels into the holes on
one half of the top and push the halves together.
keilhauer.com
Syz Table with Power
11
13
15
14
12
x2
16
To affix the cable management system to the table base: loop one of the conduit ends
around the nylon spacer coming out from the extrusions on either side. Next, secure
in place by inserting the remaining 2 nylon spacers and sliding them into place so the
other side of the conduit can be looped around them, then tighten the spacers in place.

1
2
3
For two-piece table tops: Place the two zip bolt connectors in the corresponding
depressions in the underside of the table top, and use the allen key to tighten and
hold the halves together.
Insert the power box(s) into the space(s) on the table top, feeding the cord through
first. Clips are included to secure the power unit and cord into place. Push the clips
into the power unit and use a clip and adhesive to secure the cord. Firmly press the
power unit into place.
Line the cable management system under the top and feed the power cords along the
conduit as you lift the system up to align with the extrusions.
Ensure the threaded inserts on the underside of the table are aligned with the base
extrusions and screw in the table top mount clips loosely, rotating them so that they
clip the top to the lip of the extrusions, then once in place tighten all clips with the
driver gun to secure the top to the base.
Move the table into place and adjust the glides to provide a level surface.
1
2
1
17
19
21
18
20
22
x2
To affix the mesh tubing to the cord management conduit squeeze the sides of
the tube at the small disc end to move the clips forward, and insert through the
appropriate gap in the conduit. Release pressure and the clips will move back,
securing the tube system to the cord management conduit. Feed power cord
through the tubing while affixing to the conduit.
